SERVICE MANUAL
Theory of Operation
DF-606
2005.06
Ver. 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DF-606 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Konica Minolta DF-606

Summary of Contents for Konica Minolta DF-606

  • Page 1 SERVICE MANUAL Theory of Operation DF-606 2005.06 Ver. 1.0...

  • Page 2: Revision History

    Revision history After publication of this service manual, the parts and mechanism may be subject to change for improve- ment of their performance. Therefore, the descriptions given in this service manual may not coincide with the actual machine. When any change has been made to the descriptions in the service manual, a revised version will be issued with a revision mark added as required.

  • Page 3: Table Of Contents

    CONTENTS CONTENTS DF-606 OUTLINE 1. PRODUCT SPECIFICATIONS............1 2.
  • Page 4 CONTENTS Theory of Operation Ver1.0 Jun.2005 7. PAPER EXIT SECTION ............. . . 21 Drive .

  • Page 5: Outline

    Theory of Operation Ver1.0 Jun.2005 1. PRODUCT SPECIFICATIONS OUTLINE 1. PRODUCT SPECIFICATIONS A. Type Name Double sided original auto feeder Type Sheet-through type original auto feeder B. Functions Original size Metric: A3, B4, A4, A4R, B5, B5R, A5, A5R, B6R, 11 x 17, 8.5 x 11, 8.5 x 13 Inch: 11 x 17, 8.5 x 14, 8.5 x 11, 8.5 x 11R, 5.5 x 8.5, 5.5 x 8.5R, A3,...
  • Page 6 1. PRODUCT SPECIFICATIONS Theory of Operation Ver1.0 Jun.2005 Originals not allowed to be The following originals are not allowed to be used: OHP film, blueprint master, label paper, offset master, bonded original, high-quality paper of less than 35 g/m or more than 201 g/m Combination of mixed origi- Combinations of the same and different size originals is available.

  • Page 7: Paper Path

    Theory of Operation Ver1.0 Jun.2005 2. PAPER PATH 2. PAPER PATH Single sided original mode 2.1.1 Small size 15sat1c002na Original feed tray Exit gate Original exit tray (for small size) Image read position (slit glass section) 2.1.2 Large size 15sat1c003na Original feed tray Exit roller Original exit tray (for large size)

  • Page 8: Double Sided Original Mode

    2. PAPER PATH Theory of Operation Ver1.0 Jun.2005 Double sided original mode 2.2.1 Small size A. Front scan 15sat1c004na Original feed tray Exit gate Original exit tray (for small size) Image read position (slit glass section) B. Rear scan 1 15sat1c005na Original feed tray Exit gate...
  • Page 9 Theory of Operation Ver1.0 Jun.2005 2. PAPER PATH C. Rear scan 2 15sat1c006na Original feed tray Exit gate Original exit tray (for small size) Image read position (slit glass section) D. Paper exit 15sat1c007na Original feed tray Exit gate Original exit tray (for small size)

  • Page 10: Large Size

    2. PAPER PATH Theory of Operation Ver1.0 Jun.2005 2.2.2 Large size A. Front scan 15sat1c008na Original feed tray Exit gate Original exit tray (for large size) Image read position (slit glass section) B. Rear scan 1 Original feed tray Exit gate Original exit tray (for large size) Image read position (slit glass section)
  • Page 11 Theory of Operation Ver1.0 Jun.2005 2. PAPER PATH C. Rear scan 2 15sat1c010na Original feed tray Exit gate Original exit tray (for large size) Image read position (slit glass section) D. Paper exit 15sat1c011na Original feed tray Exit gate Original exit tray (for large size) Exit roller...

  • Page 12: Mixed Original Mode

    2. PAPER PATH Theory of Operation Ver1.0 Jun.2005 Mixed original mode 2.3.1 AMS not used Single sided original mode: same as the normal single sided original mode Double sided original mode: same as the normal double sided original mode 2.3.2 AMS used (single sided/double sided) In the mixed original copy mode, the size detection of originals in the sub scan direction is made according to the ON time period of the original registration sensor (PS306).

  • Page 13: Composition/Operation

    Theory of Operation Ver1.0 Jun.2005 3. COMPOSITION COMPOSITION/OPERATION 3. COMPOSITION Conveyance section Paper feed section Original feed tray Original exit tray (for large size) Paper exit section (for small size) Original exit tray (for small size) Paper exit section (for large size) Reverse section 15sat2c001na...

  • Page 14: Paper Feed Section

    4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION Drive 4.1.1 Paper feed drive 15sat2c002na Registration roller Pick-up roller Original feed motor (M302) Paper feed roller SDF switching solenoid (SD304) 4.1.2 Tray up/down drive 15sat2c003na Up/down plate Tray up/down motor (M303)

  • Page 15: Operation

    Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION Operation 4.2.1 Size detection control A. Plain original mode (1) Size detection in the main scan direction The size detection of originals in the main scan direction is made according to the position of the guide plate connected to the original size VR (VR301) on the original feed tray.

  • Page 16: Pick-Up Mechanism

    4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 A specified period of time after the PS306 [1] turns OFF, the conveyance roller [3] rotates in the reverse direction to get the leading edge of the original conveyed to the paper exit section back to the scan standby position [5]. The trailing edge of the original returned is conveyed to the paper exit tray (for large size) [2] according to the form of the conveyance guide plate.

  • Page 17: Separation Mechanism

    Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION 4.2.3 Separation mechanism Of the originals that have been fed by the pick-up roller, only one sheet of original is conveyed to the registration roller side by the original feed roller and the separation roller. Even when plural sheets of originals are fed, the separation roller makes a reverse rotation to convey a single sheet of original.

  • Page 18: Conveyance Section

    5. CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 5. CONVEYANCE SECTION Drive 5.1.1 Conveyance drive 15sat2c008na Conveyance roller Original conveyance motor (M301) 5.1.2 Flapper up/down drive 15sat2c009na Flapper Gate solenoid (SD303)

  • Page 19: Operation

    Theory of Operation Ver1.0 Jun.2005 5. CONVEYANCE SECTION Operation 5.2.1 Conveyance control The originals that have been fed up to the registration roller [1] by the separation mechanism are pre-fed by the registration roller to be conveyed to the conveyance roller [2] at a high speed. A specified period of time after the original conveyance sensor (PS308) [4] turns ON, the conveyance roller is switched into the scan speed to con- vey the original onto the slit glass (original scan position) [3].

  • Page 20: Reversal Section

    6. REVERSAL SECTION Theory of Operation Ver1.0 Jun.2005 6. REVERSAL SECTION Drive 6.1.1 Reverse drive 15sat2c011na Reverse roller Reverse conveyance roller Original paper exit motor /1 (M304) 6.1.2 Pressure roller release drive 15sat2c012na Pressure roller release solenoid (SD302)

  • Page 21: Operation

    Theory of Operation Ver1.0 Jun.2005 6. REVERSAL SECTION Operation 6.2.1 Reverse mechanism A. Small size original When the gate solenoid (SD303) starts up, the flapper [3] closes and originals the front face of which has been scanned are conveyed [2] to the reverse section by the reverse roller [1]. A specified period of time after the orig- inal reverse sensor (PS309) [7] turns OFF by detecting the trailing edge of the original, SD303 opens the paper exit gate [6] and the reverse paper feed [5] is made while rotating in the reverse direction at a low speed and then at a high speed to guide the original to the conveyance roller [4].
  • Page 22 6. REVERSAL SECTION Theory of Operation Ver1.0 Jun.2005 B. Large size original When the gate solenoid (SD303) energizes, the flapper [5] is closed and the original the front face of which has been scanned is conveyed [4] to the reversal section by the reverse roller [8]. The original conveyed to the rever- sal section, because it cannot be contained in the reversal section, is conveyed to the paper exit reversal section [2] by the reverse conveyance roller [9] and the paper exit reverse roller [1].

  • Page 23: Registration Control

    Theory of Operation Ver1.0 Jun.2005 6. REVERSAL SECTION 6.2.2 Registration control A. Small size original A specified period of time after the start of the conveyance [1] of the 1st original, the front of the 1st original is read [2]. The 1st original conveyed to the reverse section stops temporarily after being accelerated by the origi- nal paper exit motor /2 (M305) and the original paper exit motor /1 (M304).
  • Page 24 6. REVERSAL SECTION Theory of Operation Ver1.0 Jun.2005 B. Large size original A specified period of time after the start of the conveyance [1] of the 1st original, the front of the 1st original is read [2]. The 1st original conveyed to the reverse section stops temporarily after being accelerated by the origi- nal paper exit motor /2 (M305) and the original paper exit motor /1 (M304).

  • Page 25: Paper Exit Section

    Theory of Operation Ver1.0 Jun.2005 7. PAPER EXIT SECTION 7. PAPER EXIT SECTION Drive 7.1.1 Paper exit drive (for large size) 15sat2c017na Paper exit roller /1 Original paper exit motor /1 (M304) 7.1.2 Paper exit drive (for small size) 15sat2c018na Original paper exit motor /2 (M305) Paper exit roller /2 Paper exit reverse roller...

  • Page 26: Exit Gate Drive

    7. PAPER EXIT SECTION Theory of Operation Ver1.0 Jun.2005 7.1.3 Exit gate drive 15sat2c019na Paper exit gate Exit gate solenoid (SD301)

  • Page 27: Operation

    Theory of Operation Ver1.0 Jun.2005 7. PAPER EXIT SECTION Operation 7.2.1 Paper exit operation of small size original A. Single sided original The originals that have been scanned are conveyed to the reversal section [3] because of the flapper [4] being closed by the gate solenoid (SD303).
  • Page 28 7. PAPER EXIT SECTION Theory of Operation Ver1.0 Jun.2005 B. Double sided original The originals the back face of which has been scanned are conveyed to the exit gate [5] in the same manner as with the single sided originals. At this time, the gate is closed by the exit gate solenoid (SD301), and the originals are conveyed to the paper exit reversal section [2] through the paper exit reverse roller [3].

  • Page 29: Paper Exit Operation Of Large Size Original

    Theory of Operation Ver1.0 Jun.2005 7. PAPER EXIT SECTION 7.2.2 Paper exit operation of large size original A. Single sided original The originals that have been scanned are conveyed to the paper exit roller /1 [2] by the conveyance roller [4] because of the flapper [3] and the paper exit gate [5] being opened by the gate solenoid (SD303).
  • Page 30 7. PAPER EXIT SECTION Theory of Operation Ver1.0 Jun.2005 Blank page...
  • Page 31 SERVICE MANUAL Theory of Operation FS-509/604 2005.08 Ver. 2.0...
  • Page 32 Revision history After publication of this service manual, the parts and mechanism may be subject to change for improvement of their performance. Therefore, the descriptions given in this service manual may not coincide with the actual machine. When any change has been made to the descriptions in the service manual, a revised version will be issued with a revision mark added as required.
  • Page 33 Theory of Operation Ver2.0 Aug.2005 CONTENTS CONTENTS FS-509/604 OUTLINE 1. PRODUCT SPECIFICATIONS............1 2.
  • Page 34 CONTENTS Theory of Operation Ver2.0 Aug.2005 7.2.4 Stacker entrance transfer control ..........44 7.2.5 Stacker paper exit control.

  • Page 35: Outline

    Theory of Operation Ver2.0 Aug.2005 1. PRODUCT SPECIFICATIONS OUTLINE 1. PRODUCT SPECIFICATIONS A. Type Name Flat-stapling finisher (FS-509) Multi folding multi stapling finisher (FS-604) Type Stapling device (FS-509) Multi folding multi stapling device (FS-604) Stapling method Inline clinch method Shifting method Exit paper shifting method B.
  • Page 36 1. PRODUCT SPECIFICATIONS Theory of Operation Ver2.0 Aug.2005 (3) Folding (FS-604) Saddle stitching + folding 20 sheets of 80 g/m paper 19 sheets of 80g/m paper + 1 sheet of 200 g/m paper Less of 16 sheets of 81 to 105 g/m (However, guarantee is not given to some paper according to the paper type) Folding...
  • Page 37 Theory of Operation Ver2.0 Aug.2005 1. PRODUCT SPECIFICATIONS C. Type of paper Paper size A3 wide size paper, A3, B4, A4, A4R*, B5, B5R, A5, A5R, B6, A6, 11 x 17, 8.5 x 14, F4, 8.5 x 11, 8.5 x 11R*, 5.5 x 8.5, 5.5 x 8.5R Applicable paper Plain paper, recycle paper, high-quality paper, coated paper, special paper (same as the main body)

  • Page 38: Paper Path

    2. PAPER PATH Theory of Operation Ver2.0 Aug.2005 2. PAPER PATH Sort/group mode 15sft1c001na Paper path from PI (PI-501 installed) Main tray Paper path from the main body Paper exit unit Gate Shift unit (sort/group mode only) Sorting mode 15sft1c002na Paper path from PI (PI-501 installed) Gate Paper path from the main body...

  • Page 39: Stapling Mode

    Theory of Operation Ver2.0 Aug.2005 2. PAPER PATH Stapling mode 2.3.1 FS-509 15sft1c003na Paper path from PI (PI-501 installed) Stapler Paper path from the main body Main tray Gate Paper exit unit Flat-stapling stopper...
  • Page 40 2. PAPER PATH Theory of Operation Ver2.0 Aug.2005 2.3.2 FS-604 15sjt1c003na Paper path from PI (PI-501 installed) Flat-stapling stopper Paper path from the main body Stapler Gate Main tray Clincher Paper exit unit...

  • Page 41: Folding/Saddle Stitching Mode (Fs-604)

    Theory of Operation Ver2.0 Aug.2005 2. PAPER PATH Folding/saddle stitching mode (FS-604) 15sjt1c004na Paper path from PI (PI-501 installed) Folding blade Paper path from the main body Saddle stitching stopper Gate Booklet tray Clincher Stapler...

  • Page 42: Tri-Folding Mode (Fs-604)

    2. PAPER PATH Theory of Operation Ver2.0 Aug.2005 Tri-folding mode (FS-604) 15sjt1c005na Paper path from PI (PI-501 installed) Saddle stitching stopper Paper path from the main body Booklet tray Gate Tri-folding stopper Folding blade...

  • Page 43: Composition/Operation

    Theory of Operation Ver2.0 Aug.2005 3. COMPOSITION COMPOSITION/OPERATION 3. COMPOSITION FS-509 Conveyance section Main tray section Stapler Stacker section 15sft2c001na...
  • Page 44 3. COMPOSITION Theory of Operation Ver2.0 Aug.2005 FS-604 Conveyance section Main tray section Stapler Stacker section Folding/saddle stitching/tri-folding 15sjt2c001na...

  • Page 45: Conveyance Section

    Theory of Operation Ver2.0 Aug.2005 4. CONVEYANCE SECTION 4. CONVEYANCE SECTION Drive [15] [16] [17] [18] [19] [20] [21] [14] [13] [12] [11] [10] 15sjt2c002na FS conveyance motor (M1) [12] Shift roller PI transfer roller [13] Main tray exit roller Entrance roller [14] Paper exit opening solenoid (SD4)

  • Page 46: Operation

    4. CONVEYANCE SECTION Theory of Operation Ver2.0 Aug.2005 Operation 4.2.1 FS transfer control The FS transfer is conducted by the 24V DC motor controlled by the FS control board (FSCB). A. Interlock control The FS transfer drive control is started when transmitting the start signal from the main body. However, an error message is transmitted to the main body PRCB and the control is not started if the front door interlock switch (MS1) turns OFF.

  • Page 47: Gate Drive Control

    Theory of Operation Ver2.0 Aug.2005 4. CONVEYANCE SECTION 4.2.2 Gate drive control A. Gate drive mechanism The gate switches among the paper transfer path to the main tray, the one to the sub tray, and the one to the stacker. The gate motor (M12) [1] drives the gate cam [2], and then 2 cams /UP [3] and /Lw [4] of the gate cum drive the 2 gates /UP [5] and /Lw [6] respectively.

  • Page 48: Bypass Gate Control

    4. CONVEYANCE SECTION Theory of Operation Ver2.0 Aug.2005 4.2.3 Bypass gate control A. Bypass gate drive mechanism The bypass gate is provided on the paper path to the stacker section, and conveys the next paper even while in the stapling operation. This is a gate to keep productivity at a high level with no loss time. The bypass gate solenoid (SD5) [2] drives the bypass gate [1].
  • Page 49 Theory of Operation Ver2.0 Aug.2005 4. CONVEYANCE SECTION B. Bypass gate control The bypass gate only operates for the small size paper (A4, B5, and 8.5 x 11) in the stapling mode. The FS con- trol board (FSCB) controls the bypass gate solenoid (SD5). When stapling 2 sheets of paper for 3 copies, SD5 operates as follows.

  • Page 50: Shift Control

    4. CONVEYANCE SECTION Theory of Operation Ver2.0 Aug.2005 4.2.4 Shift control A. Shift mechanism The FS conveyance motor (M1) drives the shift roller [4]. The shift roller moves itself backward to shift the paper while transferring the paper to the main tray. During conveying the paper to the main tray [1], the crank mechanism [3] shifts the shift movable section [5] including the shift roller approximately 30 mm backward [6] to shift and exit the paper when shift roller motor (M2) [2] rotates.
  • Page 51 Theory of Operation Ver2.0 Aug.2005 4. CONVEYANCE SECTION B. Shift control In the sort/group mode, the shift roller motor (M2) turns ON [2] and shifts the shift movable section a specified period of time after the FS entrance sensor (PS4) detects the trailing edge of the paper [1]. The FS conveyance motor (M1) drives the shift roller.

  • Page 52: Paper Exit Roller Control

    4. CONVEYANCE SECTION Theory of Operation Ver2.0 Aug.2005 4.2.5 Paper exit roller control The paper exit roller motor (M7) controlled by the FS control board (FSCB) drives the main tray paper exit roller and the paper exit belt of the stacker. A.

  • Page 53: Paper Exit Opening Solenoid Control

    Theory of Operation Ver2.0 Aug.2005 4. CONVEYANCE SECTION 4.2.6 Paper exit opening solenoid control A. Paper exit opening solenoid drive mechanism Since the paper exit roller rotates slower than the conveyance roller, the nip is released except when paper is being exited.

  • Page 54: Paper Exit Opening Control (Fs-509)

    4. CONVEYANCE SECTION Theory of Operation Ver2.0 Aug.2005 4.2.7 Paper exit opening control (FS-509) A. Paper exit opening/closing mechanism The paper exit unit [3] is opened and closed by the crank mechanism [2] which is driven by paper exit motor (M3) [1].
  • Page 55 Theory of Operation Ver2.0 Aug.2005 4. CONVEYANCE SECTION B. Paper exit opening/closing control (1) Stapling mode (when 51 or more sheets of paper are stapled with the size in the sub scan direc- tion shorter than B5R) When the stacker entrance sensor (PS5) detects [1] the leading edge of the 51st sheet of paper while in the paper stack, the paper exit motor (M8) turns ON to open the paper exit opening.
  • Page 56 4. CONVEYANCE SECTION Theory of Operation Ver2.0 Aug.2005 (2) Stapling mode (when the size in the sub scan direction is B5R or longer) The FS operation signal [1] from the main body allows the paper exit motor (M8) to rotate [2] to open the paper exit opening.

  • Page 57: Paper Exit Opening Control (Fs-604)

    Theory of Operation Ver2.0 Aug.2005 4. CONVEYANCE SECTION 4.2.8 Paper exit opening control (FS-604) A. Paper exit opening/closing mechanism In the stapling mode (when the size in the sub scan direction is B5R or longer), and in the folding/saddle stitch- ing/tri-folding mode, paper protrudes from the paper exit opening.
  • Page 58 4. CONVEYANCE SECTION Theory of Operation Ver2.0 Aug.2005 B. Paper exit opening/closing control (1) Stapling mode (when the size in the sub scan direction is B5R or longer) Transmitting the FS operation signal [1] from the main body, the paper exit motor (M8) rotates [2] to open the paper exit opening.

  • Page 59: Sub Tray Paper Exit Control

    Theory of Operation Ver2.0 Aug.2005 4. CONVEYANCE SECTION 4.2.9 Sub tray paper exit control The sub tray paper exit motor (M21) controlled by the FS control board (FSCB) drives the sub tray paper exit roller. A. Sub tray paper exit motor (M21) control The sub tray paper exit motor (M21) rotates in high speed when the sub tray paper exit sensor (PS1) detects the leading edge of the paper.

  • Page 60: Main Tray Section

    5. MAIN TRAY SECTION Theory of Operation Ver2.0 Aug.2005 5. MAIN TRAY SECTION Drive 15sjt2c015na Lift pulley /Up Lift pulley /Lw Lift wire Main tray Main tray lift motor (M3)

  • Page 61: Operation

    Theory of Operation Ver2.0 Aug.2005 5. MAIN TRAY SECTION Operation 5.2.1 Tray lift control A. Tray lift mechanism When the up/down pulley /Lw [7] is rotated by the driving force of the worm gear provided on the shaft of the main tray lift motor (M3) [6] to take up the up/down wire, the main tray [9] goes up and/or down.
  • Page 62 5. MAIN TRAY SECTION Theory of Operation Ver2.0 Aug.2005 B. Tray lift control The main tray lift motor (M3) lifts up and down the main tray by rotating in the forward and reverse direction respectively. The FS control board (FSCB) controls M3. (1) Non-sort/sort/group mode The FS operation signal [1] from the main body allows M3 to raise the main tray.
  • Page 63 Theory of Operation Ver2.0 Aug.2005 5. MAIN TRAY SECTION (2) Stapling mode The FS operation signal [1] from the main body allows the main tray lift motor (M3) to bring up the main tray. When the stapler paper exit upper limit sensor (PS7) turns ON, the up operation of the tray stops. When PS7 turns OFF [2] a specified period of time after the FS operation signal turns ON, M3 brings down the tray.

  • Page 64: Stacker Section (Fs-509)

    6. STACKER SECTION (FS-509) Theory of Operation Ver2.0 Aug.2005 6. STACKER SECTION (FS-509) Drive [12] [11] [10] 15sft2c004na Coupling (from M7) Paper assist roller Alignment motor /Up (M5) Paper exit belt Paper assist motor (M51) Swing belt /Lw Stacker entrance motor (M13) [10] Swing belt /Up Paper assist solenoid (SD51)

  • Page 65: Operation

    Theory of Operation Ver2.0 Aug.2005 6. STACKER SECTION (FS-509) Operation 6.2.1 Alignment control A. Alignment mechanism The alignment in the main scan direction of paper conveyed to the stacker is made by the alignment plate /Up [4] which is opened and closed through the rotation of the alignment motor /Up (M5) [1]. When M5 rotates (in normal/reverse rotation), the alignment plate /Up is opened and closed through the align- ment belt [2].

  • Page 66: Stopper Control

    6. STACKER SECTION (FS-509) Theory of Operation Ver2.0 Aug.2005 6.2.2 Stopper control The secured 5 stoppers determine the position where the paper transferred to the stacker stops. When stapling at the corner, the 3 stoppers excluding the 2 outside stoppers secured to the stapler unit determine the position because the stapler moves to the front and rear sides.

  • Page 67: Stacker Entrance Transfer Control

    Theory of Operation Ver2.0 Aug.2005 6. STACKER SECTION (FS-509) 6.2.3 Stacker entrance transfer control A. Stacker entrance transfer mechanism In the stacker section, to make the device compact, the stack method of approx. 70 degrees tilt angle is employed. And for the stacker entrance roller [5], a corrugation roller is employed to assist the paper convey- ance to the stacker.
  • Page 68 6. STACKER SECTION (FS-509) Theory of Operation Ver2.0 Aug.2005 B. Stacker entrance transfer control (1) Stapling mode (the paper size is not A4, B5, or 8.5 x 11, without the bypassing operation) Transmitting the FS operation signal from the main body [1], the stacker entrance motor (M13) turns ON and rotates in high speed.
  • Page 69 Theory of Operation Ver2.0 Aug.2005 6. STACKER SECTION (FS-509) (2) Stapling mode (the paper size is A4, B5, or 8.5 x 11, with the bypassing operation) The 1st copy is transferred by the same operation for the paper whose size is other than A4, B5, or 8.5 x 11. When transferring the 1st and 2nd paper of the 2nd and following copies, the stacker entrance motor (M13) stops a specified period of time after the stacker entrance sensor (PS5) detects the trailing edge of the last paper of the 1st copy [3].

  • Page 70: Stacker Paper Exit Control

    6. STACKER SECTION (FS-509) Theory of Operation Ver2.0 Aug.2005 6.2.4 Stacker paper exit control A. Stacker paper exit mechanism The paper exit to the main tray in the stapling mode is made by the paper exit arm [2] provided on the paper exit belt [1] of the stacker.

  • Page 71: Stacker Section (Fs-604)

    Theory of Operation Ver2.0 Aug.2005 7. STACKER SECTION (FS-604) 7. STACKER SECTION (FS-604) Drive [12] [13] [14] [15] [16] [11] [10] 15sjt2c019na Coupling (from M7) [10] Flat-stapling stopper release solenoid /Fr (SD8), Flat-stapling stopper release solenoid /Rr (SD7) Alignment motor /Up (M5) Stacker entrance motor (M13) [11] Paper assist roller...

  • Page 72: Operation

    7. STACKER SECTION (FS-604) Theory of Operation Ver2.0 Aug.2005 Operation 7.2.1 Alignment /Up control A. Alignment /Up mechanism While in the stapling, folding, saddle stitching, and the tri-folding modes, the alignment in the main scan direction of paper that has been conveyed to the stacker is made by the rotation of the alignment motor /Up (M5) [1] to open and close the alignment plate /Up [4].

  • Page 73: Alignment /Lw Control

    Theory of Operation Ver2.0 Aug.2005 7. STACKER SECTION (FS-604) 7.2.2 Alignment /Lw control A. Alignment /Lw mechanism While in the saddle stitching mode, the folding mode and the tri-folding mode, the alignment in the main scan direction of paper is made by the oscillation of the alignment plate /Up and the alignment plate /Lw. The oscillation of the alignment plate /Lw is made by the rotation of the alignment motor /Lw (M16) [2].
  • Page 74 7. STACKER SECTION (FS-604) Theory of Operation Ver2.0 Aug.2005 7.2.3 Stopper control A. Stopper mechanism The control of the stop position of the paper that has been conveyed to the stacker is made by 2 stoppers (sad- dle stitching stopper and flat-stapling stopper). The stop position of paper in the vertical direction is not the same for the stapling mode and for the folding, sad- dle stitching and tri-folding modes.

  • Page 75: Stopper Control

    Theory of Operation Ver2.0 Aug.2005 7. STACKER SECTION (FS-604) B. Stopper control (1) Folding mode Transmitting the FS operation signal from the main body [1], the saddle stitching stopper motor (M18) rotates [2] to move down the saddle stitching stopper to the stopping position in accordance with the paper size. After completing the alignment operation of the last paper [3], M18 rotates [4] to move down the saddle stitching stopper to the folding position.
  • Page 76 7. STACKER SECTION (FS-604) Theory of Operation Ver2.0 Aug.2005 (2) Saddle stitching mode Transmitting the FS operation signal from the main body [1], the M18 rotates [2] to move down the saddle stitch- ing stopper to the stopping position in accordance with the paper size. After completing the stapling operation [3], the alignment motors /Up (M5) and /Lw (M16) open the alignment plate and M18 rotates [4] to move down the saddle stitching stopper to the folding position.
  • Page 77 Theory of Operation Ver2.0 Aug.2005 7. STACKER SECTION (FS-604) (3) Tri-folding mode Transmitting the FS operation signal from the main body [1], the M18 rotates [2] to move down the saddle stitch- ing stopper to the stopping position in accordance with the paper size. After completing the alignment operation of the last paper [3], M18 rotates [4] to move down the saddle stitching stopper to the 1st folding position in the tri-folding.

  • Page 78: Stacker Entrance Transfer Control

    7. STACKER SECTION (FS-604) Theory of Operation Ver2.0 Aug.2005 7.2.4 Stacker entrance transfer control A. Stacker entrance transfer mechanism In the stacker section, to make the device compact, the stack method of approx. 70 degrees tilt angle is employed. And for the stacker entrance roller [5], a corrugation roller is employed to assist the paper convey- ance to the stacker.
  • Page 79 Theory of Operation Ver2.0 Aug.2005 7. STACKER SECTION (FS-604) B. Stacker entrance transfer control (1) Stapling mode (the paper size is not A4, B5, or 8.5 x 11, without the bypassing operation) Transmitting the FS operation signal from the main body [1], the stacker entrance motor (M13) turns ON and rotates in high speed.
  • Page 80 7. STACKER SECTION (FS-604) Theory of Operation Ver2.0 Aug.2005 (2) Stapling mode (the paper size is A4, B5, or 8.5 x 11, with the bypassing operation) The 1st copy is transferred by the same operation for the paper whose size is other than A4, B5, or 8.5 x 11. When transferring the 1st and 2nd paper of the 2nd and following copies, the M13 stops a specified period of time after the PS5 detects the trailing edge of the last paper of the 1st copy [3].
  • Page 81 Theory of Operation Ver2.0 Aug.2005 7. STACKER SECTION (FS-604) (3) Folding/saddle stitching mode Transmitting the FS operation signal from the main body [1], the M13 turns ON and rotates in high speed. M13 rotates in low speed [2] to transfer the paper in low speed when the PS5 detects the trailing edge of the paper.
  • Page 82 7. STACKER SECTION (FS-604) Theory of Operation Ver2.0 Aug.2005 (4) Tri-folding mode Transmitting the FS operation signal from the main body [1], the M13 turns ON and rotates in high speed. M13 rotates in low speed [2] to transfer the paper in low speed when the PS5 detects the trailing edge of the paper.

  • Page 83: Stacker Paper Exit Control

    Theory of Operation Ver2.0 Aug.2005 7. STACKER SECTION (FS-604) 7.2.5 Stacker paper exit control A. Stacker paper exit mechanism The paper exit to the main tray in the stapling mode is made by the paper exit arm [2] provided on the paper exit belt [1] of the stacker.
  • Page 84 7. STACKER SECTION (FS-604) Theory of Operation Ver2.0 Aug.2005 B. Stacker paper exit control (1) Stapling mode (in the case where the size in the sub scan direction is shorter than B5R) Completing the stapling operation, the paper exit roller motor (M7) rotates to drive the paper exit belt in the stacker section.

  • Page 85: Stapler (Fs-509)

    Theory of Operation Ver2.0 Aug.2005 8. STAPLER (FS-509) 8. STAPLER (FS-509) Drive [11] [12] [13] [14] [10] 15sft2c012na Stapler /Rr Stapler movement motor (M11) Stapler rotation shaft /Rr Stapler movement home sensor (PS11) Rack mounting platform [10] Stapler drive rack /Fr Spring /Rr [11] Spring /Fr...

  • Page 86: Operation

    8. STAPLER (FS-509) Theory of Operation Ver2.0 Aug.2005 Operation 8.2.1 Stapler movement control A. Stapler movement operation The relationship between the stapler /Fr [11] and the stapler /Rr [1] is symmetrical in operation. So, the explana- tion given here is made of the stapler /Rr. The stapler movement motor (M11) [9] moves the stapler.
  • Page 87 Theory of Operation Ver2.0 Aug.2005 8. STAPLER (FS-509) 8.2.2 Stapler control A. Stapler mechanism In the stapling operation, the stapler motors /Rr (M9) and /Fr (M14) [3] in the staplers /Rr and /Fr drive the clincher side [2] to press the paper [1]. Then, the staple is pushed out from the stapler side [4] and bent at the clincher side.

  • Page 88: Stapler Control

    8. STAPLER (FS-509) Theory of Operation Ver2.0 Aug.2005 B. Staple control (1) Stapling After completing the alignment operation of the alignment plate, the stapler motors /Rr (M9) and /Fr (M14) per- form the stapling operation. The stapling operation is completed when the stapler home sensors /Rr (PS30) and /Fr (PS31) in the staplers /Rr and /Fr detect the home position and turn ON.

  • Page 89: Stapler (Fs-604)

    Theory of Operation Ver2.0 Aug.2005 9. STAPLER (FS-604) 9. STAPLER (FS-604) Drive [10] [10] [11] 15sjt2c034na Stapler movement motor (M11) Stapler /Fr Upper side of the timing belt Stapler movement home sensor (PS11) Clincher rotation motor (M4) Stapler /Rr Clincher /Rr [10] Stapler rotation motor (M6) Clincher /Fr...

  • Page 90: Operation

    9. STAPLER (FS-604) Theory of Operation Ver2.0 Aug.2005 Operation 9.2.1 Stapler movement control The staplers move in the horizontal direction for adjusting their distance. The stapler at the rear also rotates. The movement is made according to the stapling mode. A.
  • Page 91 Theory of Operation Ver2.0 Aug.2005 9. STAPLER (FS-604) (2) Rotational movement While in the one-corner stapling at rear, the stapler /Rr and the clincher /Rr rotate 45°. The rotational movement of the stapler /Rr [9] is made by the stapler rotation motor (M6) [10] and the rotational movement of the clincher /Rr [7] made by the clincher rotation motor (M4) [5].

  • Page 92: Stapler Movement Control

    9. STAPLER (FS-604) Theory of Operation Ver2.0 Aug.2005 B. Stapler movement control (1) 1 staple/front and 2 staples Transmitting the FS operation signal from the main body, the stapler movement motor (M11) turns ON to widen the distance between stapler and clincher. It stops when they are positioned at the specified positions. M11 turns ON a specified period of time after the main tray paper exit sensor (PS6) detects the last paper.
  • Page 93 Theory of Operation Ver2.0 Aug.2005 9. STAPLER (FS-604) 9.2.2 Stapler control A. Stapler mechanism In the staple operation, the stapler motors /Rr and /Fr (M9, M14) contained in the staplers /Rr and /Fr [6] press the paper pressure unit [4] toward the clincher [2] side through the cam mechanism [5] to hold down the paper [1], and then push out the staple [3].

  • Page 94: Stapler Control

    9. STAPLER (FS-604) Theory of Operation Ver2.0 Aug.2005 B. Staple control (1) Stapling After completing the alignment operation of the alignment plate, the stapler motors /Rr (M9) and /Fr (M14) per- form the stapling operation. After a specified period of time, the clincher motors /Rr (M10) and /Fr (M15) bend the staples.

  • Page 95: Folding/Saddle Stitching, Tri-Folding

    Theory of Operation Ver2.0 Aug.2005 10. FOLDING/SADDLE STITCHING, TRI-FOLDING 10. FOLDING/SADDLE STITCHING, TRI-FOLDING 10.1 Drive 15sjt2c039na Folding blade Tri-folding gate solenoid (SD6) Folding blade motor (M19) Tri-folding gate Folding transfer motor (M20) Folding roller Tri-folding roller...

  • Page 96: Operation

    10. FOLDING/SADDLE STITCHING, TRI-FOLDING Theory of Operation Ver2.0 Aug.2005 10.2 Operation 10.2.1 Folding/saddle stitching, tri-folding (first folding) control A. Folding/saddle stitching, tri-folding (first folding) mechanism The folding in the folding/saddle stitching mode and while in the first folding in the tri-folding mode is made by the folding blade [2] that is driven by the folding blade motor (M19) through the gear.
  • Page 97 Theory of Operation Ver2.0 Aug.2005 10. FOLDING/SADDLE STITCHING, TRI-FOLDING [10] [7] [2] [11] 15sjt2c040na Folding blade home sensor (PS22) Folding paper exit sensor (PS25) Paper Tri-folding gate Folding passage sensor (PS26) Booklet tray Folding roller [10] Folding Folding blade [11] Conveyance →...
  • Page 98 10. FOLDING/SADDLE STITCHING, TRI-FOLDING Theory of Operation Ver2.0 Aug.2005 B. Folding/saddle stitching and tri-folding (first folding) control A specified period of time after the folding passage sensor (PS26) detects the paper conveyed and the saddle stitching stopper stops at the folding position, the folding blade motor (M19) turns ON [2] to stick out the folding blade in the direction of the paper.

  • Page 99: Tri-Folding (Second Folding) Control

    Theory of Operation Ver2.0 Aug.2005 10. FOLDING/SADDLE STITCHING, TRI-FOLDING 10.2.2 Tri-folding (second folding) control A. Tri-folding (second folding) mechanism After the saddle stitching stopper stops at the tri-folding position, the tri-folding gate solenoid (SD6) [5] drives the tri-folding gate [6] to switch the paper path from the folding/saddle stitching/ tri-folding (first folding) path to the tri-folding (second folding) path.
  • Page 100 10. FOLDING/SADDLE STITCHING, TRI-FOLDING Theory of Operation Ver2.0 Aug.2005 Blank page...
  • Page 101 SERVICE MANUAL Theory of Operation IC-203 2005.08 Ver. 2.0...
  • Page 102 Revision history After publication of this service manual, the parts and mechanism may be subject to change for improve- ment of their performance. Therefore, the descriptions given in this service manual may not coincide with the actual machine. When any change has been made to the descriptions in the service manual, a revised version will be issued with a revision mark added as required.
  • Page 103 Theory of Operation Ver2.0 August.2005 CONTENTS CONTENTS IC-203 OUTLINE 1. PRODUCT SPECIFICATIONS............1 COMPOSITION/OPERATION 2.
  • Page 104 CONTENTS Theory of Operation Ver2.0 August.2005 Blank Page...

  • Page 105: Product Specifications

    Theory of Operation Ver2.0 August.2005 1. PRODUCT SPECIFICATIONS OUTLINE 1. PRODUCT SPECIFICATIONS A. Type Type: Built-in box type for the KONICA MINOLTA Printer/Copier B. Functions Resolution Printing System: 600 x 600 dpi Scanning Resolution: 200 dpi / 300 dpi/ 400 dpi / 600 dpi...
  • Page 106 1. PRODUCT SPECIFICATIONS Theory of Operation Ver2.0 August.2005 C. Paper Paper Size Same as copier Paper Type Same as copier Paper Weight Same as copier D. Maintenance and Life Maintenance Same as copier Machine Service Life Same as copier E. Machine Data Low Voltage Pentium III Tualatin 800 MHz System Memory 256 MB (Standard), Expandable up to 512 MB (Option: EM-701)

  • Page 107: Composition/Operation

    Theory of Operation Ver2.0 August.2005 2. COMPOSITION COMPOSITION/OPERATION 2. COMPOSITION Print Controller’s Capabilities This product is a print controller to serve as a printer or as a network scanner when used in combination with the copier that may be connected to computers or to networks. This print controller gets files from computers or over networks and converts their contents into image data for the copier to be able to print out.
  • Page 108 2. COMPOSITION Theory of Operation Ver2.0 August.2005 When used as a scanner Receiving as an E-Mail attached file: E-Mail software Import Storing in the internal HDD: Downloading from FTP: TWAIN-compliant applications FTP client Network Scanner Driver File sharing using SMB protocol Original SCAN Copier...

  • Page 109: Print Controller's Options

    Theory of Operation Ver2.0 August.2005 2. COMPOSITION Print Controller’s Options The Print Controller has the following options. Memory (EM-701), PostScript Protection Kit (PS-503) 2.2.1 Memory The IC unit is equipped with 256 MB memory by default. Memory expansion is available by adding DIMM in the memory slot of the system board.

  • Page 110: Operation

    3. OPERATION Theory of Operation Ver2.0 August.2005 3. OPERATION Operating Environment The print controller includes a 800-MHz Intel Low Voltage Pentium III CPU to perform high-speed image pro- cessing (rasterization). While rasterized image data are sent to the engine, data in the following pages are simul- taneously rasterized.

  • Page 111: Each Function On The System Board

    Theory of Operation Ver2.0 August.2005 3. OPERATION Each Function on the System Board Clock Generator BIOS Chip Slot for Memory2 Slot for Memory1 GMCH Serial Port (for servicing) Parallel I/F Super I/O Connector ICH2 Slot for Compact Flash Parallel Chip PostScript Protection Kit RJ-45 Ethernet...

  • Page 112: Data Flow

    3. OPERATION Theory of Operation Ver2.0 August.2005 Data flow Computer Application Web Browser Print Commands Printer Driver Spooler Parallel I/F Ethernet Network I/F ( IEEE 1284 ) ( TCP/IP, IPX/SPX, AppleTalk ) Interface Parallel I/F ( IEEE 1284 ) RJ-45 Network I/F I / F Print Controller PCI bus...
  • Page 113 SERVICE MANUAL Theory of Operation LU-403/404 2005.06 Ver. 1.0...
  • Page 114 Revision history After publication of this service manual, the parts and mechanism may be subject to change for improve- ment of their performance. Therefore, the descriptions given in this service manual may not coincide with the actual machine. When any change has been made to the descriptions in the service manual, a revised version will be issued with a revision mark added as required.
  • Page 115 Theory of Operation Ver1.0 Jun.2005 CONTENTS CONTENTS LU-403/404 OUTLINE 1. PRODUCT SPECIFICATIONS............1 2.
  • Page 116 CONTENTS Theory of Operation Ver1.0 Jun.2005 Blank page...

  • Page 117: Product Specifications

    Theory of Operation Ver1.0 Jun.2005 1. PRODUCT SPECIFICATIONS OUTLINE 1. PRODUCT SPECIFICATIONS A. Type Type Side mount type large volume paper feed tray B. Functions Maximum tray capacity LU-403 4,000 sheets (for paper of 80 g/m or 20 lbs) LU-404 4,000 sheets (for paper of 80 g/m or 20 lbs) C.

  • Page 118: Paper Path

    2. PAPER PATH Theory of Operation Ver1.0 Jun.2005 2. PAPER PATH 15sst1c001na...

  • Page 119: Composition/Operation

    Theory of Operation Ver1.0 Jun.2005 3. COMPOSITION COMPOSITION/OPERATION 3. COMPOSITION Paper feed section Up/down section 15sst2c001na...

  • Page 120: Paper Feed Section

    4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION Drive A. Paper feed drive [10] 15sst2c002na Paper feed motor (M101) Separation roller Feed clutch (CL101) To the front side Pick-up roller Torque limiter Paper feed roller Pre-registration roller One-way mechanism [10]...
  • Page 121 Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION B. Pick-up drive 15sst2c003na Pick-up roller Pick-up solenoid (SD100) To the front side Paper feed roller...

  • Page 122: Operation

    4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 Operation 4.2.1 Paper feed control A. Pick-up control Paper is picked up when the pick-up solenoid (SD100) is turned OFF. When SD100 is turned OFF [2], the pick- up roller goes down to press the paper by its own weight. The pick-up roller pressing the paper is rotated through the transmission of the rotational driving force of the paper feed motor (M101) when the feed clutch (CL101) turns ON [3], and then picks up the paper to convey it to the paper feed roller.
  • Page 123 Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION B. Separation mechanism The separation of paper is made by the separation roller [5]. The separation roller [5] is driven in the opposite direction [10] of the paper conveyance direction [9] through the torque limiter [8] to be pressed against the feed roller [1] by means of the pressure [6] of the spring [7] as well as the operating pressure generated by the torque of the torque limiter.
  • Page 124 4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 C. Pre-registration control The pre-registration roller is driven by the paper feed motor (M101) through the pre-registration clutch (CL102). The turning ON or OFF of CL102 turns on or off the transmission of the driving force to start or stop the rotation. The paper conveyed by the feed roller is pressed against the pre-registration roller, that has been stopped since CL102 turned OFF, and forms a loop [2] to correct a paper skew.

  • Page 125: Paper Empty Detection Control

    Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION 4.2.2 Paper empty detection control The paper empty detection is made in the combination of the upper limit sensor (PS109) [6] and the paper empty sensor (PS108) [1] that turn ON and OFF. When there remains paper in the tray, the paper lift plate [4] goes up and the paper pushes up the actuator [2] to turn ON PS108 [1].

  • Page 126: Remaining Paper Detection Control

    4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 4.2.3 Remaining paper detection control The remaining paper detection is made by the rotating position of the remaining paper detection gear [6] inter- locked with the shaft [5] of paper lift motor (M100) that drives the paper lift plate. The remaining paper detection gear is integrated with the actuator [7].
  • Page 127 Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION • LU-404 15swt2c001na PS102 Shaft of M100 PS103 Remaining paper detection gear PS104 Actuator PS105 It is possible to know the remaining paper in 8 steps by the four sensors that turn ON and OFF. However, the remaining paper is displayed in 5 steps on the main body operation panel.

  • Page 128: Up/Down Section

    5. UP/DOWN SECTION Theory of Operation Ver1.0 Jun.2005 5. UP/DOWN SECTION Drive A. LU-403 [12] [11] [10] 15sst2c009na Remaining paper detection gear Lift wire /Fr4 Paper lift motor (M100) Lift wire /Fr3 Lift wire /Rr1 Lift wire /Fr2 Lift wire /Rr2 [10] Lift wire /Fr1 Lift wire /Rr3...
  • Page 129 Theory of Operation Ver1.0 Jun.2005 5. UP/DOWN SECTION B. LU-404 [12] [11] [10] 15swt2c002na Paper lift motor (M100) Lift wire /Fr4 Remaining paper detection gear Lift wire /Fr3 Lift wire /Rr1 Lift wire /Fr2 Lift wire /Rr2 [10] Lift wire /Fr1 Lift wire /Rr3 [11] To the front side...

  • Page 130: Operation

    5. UP/DOWN SECTION Theory of Operation Ver1.0 Jun.2005 Operation 5.2.1 Up/down control The paper lift plate is brought up or down by driving the paper lift motor (M100) to wind up the lift wire around the pulley or wind it off from the pulley. The paper lift plate is tied up with four lift wires each at front and rear.

  • Page 131: Dehumidification Heater Control

    Theory of Operation Ver1.0 Jun.2005 5. UP/DOWN SECTION B. Down operation When the upper door open/close sensor (PS100) turns OFF [1] with the upper door open, the paper lift motor (M100) turns ON (in reverse rotation) and then turns OFF a specified period of time after the paper lift plate starts to go down to stop [2] the paper lift plate at the position where it goes about 120 mm down.
  • Page 132 5. UP/DOWN SECTION Theory of Operation Ver1.0 Jun.2005 Blank page...
  • Page 133 SERVICE MANUAL Theory of Operation PI-501 2005.06 Ver. 1.0...
  • Page 134 Revision history After publication of this service manual, the parts and mechanism may be subject to change for improve- ment of their performance. Therefore, the descriptions given in this service manual may not coincide with the actual machine. When any change has been made to the descriptions in the service manual, a revised version will be issued with a revision mark added as required.
  • Page 135 Theory of Operation Ver1.0 Jun.2005 CONTENTS CONTENTS PI-501 OUTLINE 1. PRODUCT SPECIFICATIONS............1 2.
  • Page 136 CONTENTS Theory of Operation Ver1.0 Jun.2005 Blank page...

  • Page 137: Product Specifications

    Theory of Operation Ver1.0 Jun.2005 1. PRODUCT SPECIFICATIONS OUTLINE 1. PRODUCT SPECIFICATIONS A. Type Name Post inserter unit Type Torque limiter separation type seat feeding device B. Functions Auto sheet feeding (online Feeds the sheet to FS automatically under the instruction from the main body. operation) Manual sheet feeding Feeds the sheet to FS under the instruction from the operation panel of PI.
  • Page 138 1. PRODUCT SPECIFICATIONS Theory of Operation Ver1.0 Jun.2005 C. Type of paper Paper size Tray /Up Metric: A4, A4R, B5, B5R, A5, 16K, 16KR Inch: 8.5 x 11, 8.5 x 11R, 5.5 x 8.5 Tray /Lw Metric: Wide paper (up to 314 x 459 mm), A3, B4, A4, A4R, B5, B5R, A5, F4, 8K, 16K, 16KR Inch: Wide paper (up to 314 x 459 mm), 11 x 17, 8.5 x 14, 8.5 x...

  • Page 139: Paper Path

    Theory of Operation Ver1.0 Jun.2005 2. PAPER PATH 2. PAPER PATH Auto sheet feeding (online operation) 15jft1c002na Paper path from the tray /Up Paper path from the tray /Lw...

  • Page 140: Manual Sheet Feeding (Offline Operation)

    2. PAPER PATH Theory of Operation Ver1.0 Jun.2005 Manual sheet feeding (offline operation) 15jft1c003na Paper path from the tray /Lw...

  • Page 141: Composition/Operation

    Theory of Operation Ver1.0 Jun.2005 3. COMPOSITION COMPOSITION/OPERATION 3. COMPOSITION Tray /Up section Pick-up /Up section Separation /Up section Conveyance section Tray /Lw section Pick-up /Lw section Separation /Lw section 15jft2c001na...

  • Page 142: Paper Feed Section

    4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION Drive 4.1.1 Paper feed drive [10] [14] [13] [11] [12] [18] [15] [17] [16] 15jft2c002na Pick-up roller /Lw [10] Paper feed roller /Lw Pick-up roller /Up [11] Conveyance roller /Lw Pick-up solenoid /Up (SD201) [12]...

  • Page 143: Tray Lift Drive

    Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION 4.1.2 Tray lift drive 15jft2c003na Front Tray lift motor /Up (M201) Tray lift motor /Lw (M202)

  • Page 144: Operation

    4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 Operation 4.2.1 Tray lift mechanism The tray lift motors /Up (M201) [2] and /Lw (M202) [7] move up and down the trays /Up and /Lw by rotating in the forward and reverse direction to drive the lift arms /Up [10] and /Lw [4] and move up and down the lift plates /Up [8] and /Lw [6], respectively.

  • Page 145: Pick-Up Mechanism

    Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION 4.2.2 Pick-up mechanism The pick-up solenoids /Up (SD201) [2] and /Lw (SD202) turn ON to pick up the paper. The release arm [5] held upward by the spring [1] lifts up the pick-up roller mounting plate [4] to release the pick-up roller [3]. When SD201 and SD202 turn ON, the release arm moves backward, and then the pick-up roller mounting plate and the pick-up roller fall down by their own weight.

  • Page 146: Separation Mechanism

    4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 4.2.3 Separation mechanism The separation roller [4] is driven to rotate in the opposite direction from the paper transfer direction [2]. When transferring no or 1 sheet of paper, the separation roller rotates in the paper transfer direction to transfer the paper to the paper transfer section because the frictional force between the paper feed roller [1] or the paper and the separation roller [4] is stronger than the frictional force of the torque limiter [3].

  • Page 147: Registration Control

    Theory of Operation Ver1.0 Jun.2005 4. PAPER FEED SECTION 4.2.4 Registration control Transmitting the FS start signal [1], the transfer motor (M203) rotates in low speed and the pick-up solenoids / UP (SD201) and /Lw (SD202) turn ON. At the time, the tray lift motors /Up (M201) and /Lw (M202) rotate in the forward direction to lift up the trays /Up and /Lw.

  • Page 148: Paper Size Detection Control

    4. PAPER FEED SECTION Theory of Operation Ver1.0 Jun.2005 4.2.5 Paper size detection control The paper size VRs /Up (VR201) [1] and /Lw (VR202) [3] coupled with the side guide [2] detects the paper size in the main scan direction. The paper set sensors /Up (PS203) [5] and /Lw (PS208) [4] and the L size sensor /Lw (PS212) [6] detects the paper size in the sub scan direction.
  • Page 149 SERVICE MANUAL Theory of Operation PK-503/504/505 2005.06 Ver. 1.0...
  • Page 150 Revision history After publication of this service manual, the parts and mechanism may be subject to change for improve- ment of their performance. Therefore, the descriptions given in this service manual may not coincide with the actual machine. When any change has been made to the descriptions in the service manual, a revised version will be issued with a revision mark added as required.
  • Page 151 Theory of Operation Ver1.0 Jun.2005 CONTENTS CONTENTS PK-503/504/505 OUTLINE 1. PRODUCT SPECIFICATIONS............1 2.
  • Page 152 CONTENTS Theory of Operation Ver1.0 Jun.2005 Blank page...

  • Page 153: Product Specifications

    Theory of Operation Ver1.0 Jun.2005 1. PRODUCT SPECIFICATIONS OUTLINE 1. PRODUCT SPECIFICATIONS A. Type Name Punch unit Type FS-integrated type punching operation device B. Functions Punching method Stops and punches every paper No. of holes PK-503: 2 holes PK-504: 4 holes PK-505: 2 holes/3 holes (inch) or 2 holes/4 holes (metric) φ...
  • Page 154 1. PRODUCT SPECIFICATIONS Theory of Operation Ver1.0 Jun.2005 Paper curling 15knt1c001na a Curling (10 mm or less) [1] 5 sheets of paper D. Maintenance Maintenance Same as the main body. Machine service life Same as the main body. E. Machine data Power source 24V/5VDC (supply from FS) Maximum power...

  • Page 155: Paper Path

    Theory of Operation Ver1.0 Jun.2005 2. PAPER PATH 2. PAPER PATH 15kjt1c002na Paper path from PI Paper path from the main body Punch unit Punch scraps box...
  • Page 156 2. PAPER PATH Theory of Operation Ver1.0 Jun.2005 Blank page...

  • Page 157: Composition/Operation

    Theory of Operation Ver1.0 Jun.2005 3. COMPOSITION COMPOSITION/OPERATION 3. COMPOSITION Punch section Punch scraps box section 15kjt2e001na...

  • Page 158: Punch Section

    4. PUNCH SECTION Theory of Operation Ver1.0 Jun.2005 4. PUNCH SECTION Drive 4.1.1 Punch shift drive 15kjt2c002na Punch unit Punch shift motor (M802 for PK-503/504, Guide shaft and M302 for PK-505) Belt Rack Front Punch shift home sensor (PS803 for PK- 503/504, and PS303 for PK-505)

  • Page 159: Punch Drive

    Theory of Operation Ver1.0 Jun.2005 4. PUNCH SECTION 4.1.2 Punch drive A. PK-503/PK-504 15kjt2c003na Eccentric cam Registration shutter Drive arm Punch blade Registration shutter motor (M803) Punch motor (M801)
  • Page 160 4. PUNCH SECTION Theory of Operation Ver1.0 Jun.2005 B. PK-505 [12] [13] [10] [11] 15kjt2e007na Punch motor (M301) Groove of the switching cam Eccentric cam Projection of the punch blade Slide link [10] Projection of the switching cam Switching cam [11] Punch blade When the punch blade is driven...

  • Page 161: Operation

    Theory of Operation Ver1.0 Jun.2005 4. PUNCH SECTION Operation 4.2.1 Punched hole No. switching operation (PK-505 only) Number of punched holes of PK-505 is switched between 2 to 4 and 2 to 3 holes depending on the country. Number of punched holes is switched by the rotating direction of the punch motor (M301) [3]. The motor M301 drives the slide link in the main scanning direction through the eccentric cam.
  • Page 162 4. PUNCH SECTION Theory of Operation Ver1.0 Jun.2005 The punch unit returns to the home position at the end of the job. 15kjt2c004na Paper size sensor (PS305) Paper Moving distance from the paper edge Punch blade Paper transfer direction Punch unit Note •...

  • Page 163: Punch Position Correction Control (For Explanation, The Part Number For Pk-505 Is Used.)

    Theory of Operation Ver1.0 Jun.2005 4. PUNCH SECTION 4.2.3 Punch position correction control (For explanation, the part number for PK-505 is used.) For the punch unit positioned from the side edge of the paper to the inside (see "4.2.2 Punch standby position movement control (For explanation, the part number for PK-505 is used.)"), the punch position is adjusted in the following procedure so that punching is made symmetrically to the center of paper at all times.
  • Page 164 4. PUNCH SECTION Theory of Operation Ver1.0 Jun.2005 4.2.4 Punch control A. Registration loop control (For explanation, the part number for PK-505 is used.) The registration shutter motor (M303) [6] rotates to rotate the registration shutter drive assembly [5] a specified period of time after the paper exit sensor (PS37) on the main body detects the leading edge of the paper.

  • Page 165: Punch Control

    Theory of Operation Ver1.0 Jun.2005 4. PUNCH SECTION B. Punch control (PK-503/PK-504) Transmitting the start signal from the main body, the FNS conveyance motor (M1) rotates. In the punch mode, M1 stops temporarily a specified period of time after the FNS entrance sensor (PS4) detects the trailing edge of the paper.
  • Page 166 4. PUNCH SECTION Theory of Operation Ver1.0 Jun.2005 C. Punch control (PK-505) The FNS transfer motor (M1) is driven by the main body start signal. In the punching mode, the motor M1 stops temporarily after the FNS entrance sensor (PS4) detects the rear edge of paper. At the same time, the punch motor (M301) [3] rotates in the direction according to the number of punched holes and the slide link [5] moves.

  • Page 167: Punch Scraps Box Section

    Theory of Operation Ver1.0 Jun.2005 5. PUNCH SCRAPS BOX SECTION 5. PUNCH SCRAPS BOX SECTION Drive The punch scraps box section comprises no moving parts.

  • Page 168: Operation

    5. PUNCH SCRAPS BOX SECTION Theory of Operation Ver1.0 Jun.2005 Operation 5.2.1 Punch scraps box control (For explanation, the part number for PK-505 is used.) A. Punch scraps box full detection The punch scraps generated by the punch operation falls in the punch scraps box [3]. The punch scraps box full sensor (PS302) [1] turns ON and transmits the "no punch scraps box"...
  • Page 169 SERVICE MANUAL Theory of Operation RC-501 920) 2005.06 Ver. 1.0...
  • Page 170 Revision history After publication of this service manual, the parts and mechanism may be subject to change for improve- ment of their performance. Therefore, the descriptions given in this service manual may not coincide with the actual machine. When any change has been made to the descriptions in the service manual, a revised version will be issued with a revision mark added as required.
  • Page 171 Theory of Operation Ver1.0 Jun.2005 CONTENTS CONTENTS RC-501 OUTLINE 1. PRODUCT SPECIFICATIONS............1 COMPOSITION/OPERATION 2.
  • Page 172 CONTENTS Theory of Operation Ver1.0 Jun.2005 Blank page...

  • Page 173: Product Specifications

    Theory of Operation Ver1.0 Jun.2005 1. PRODUCT SPECIFICATIONS OUTLINE 1. PRODUCT SPECIFICATIONS A. Type Name Toner recycle cut unit Type Air conveyance waste toner collecting unit B. Functions Toner ejection Air conveyance by the diaphragm pump Waste toner container Waste toner collecting box C.
  • Page 174 1. PRODUCT SPECIFICATIONS Theory of Operation Ver1.0 Jun.2005 Blank page...

  • Page 175: Composition/Operation

    Theory of Operation Ver1.0 Jun.2005 2. COMPOSITION COMPOSITION/OPERATION 2. COMPOSITION Waste toner conveyance section Accumulator Recycle pump control Recycle pump board (RCDB) Waste toner collecting box Waste toner recycle section 14rtt2c050na...

  • Page 176: Waste Toner Conveyance Section

    3. WASTE TONER CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 3. WASTE TONER CONVEYANCE SECTION Operation A. Purpose The surplus of the toner used at the printing is recycled to the developing section by the recycling mechanism. The toner circulating in the devise may slightly deteriorate the print quality because the paper dust adhering to the drum at the transfer/separation is mixed in the cleaning section.
  • Page 177 Theory of Operation Ver1.0 Jun.2005 3. WASTE TONER CONVEYANCE SECTION C. Waste toner conveyance path The waste toner sucked from the toner recycle intake [2] of the toner recycle pipe [1] is conveyed to the accu- mulator [4] via the accumulator hose [3]. The one-way valves are provided at the outlet and inlet of the accumu- lator to prevent the backflow of the waste toner.
  • Page 178 3. WASTE TONER CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 The hose joint [1] conveys the waste toner to the outside. The toner conveyed to the outside is conveyed and recycled to the waste toner collecting box [3] via the hose / 3 [2].

  • Page 179: Waste Toner Recycle Section

    Theory of Operation Ver1.0 Jun.2005 4. WASTE TONER RECYCLE SECTION 4. WASTE TONER RECYCLE SECTION Operation A. Purpose The large amount of air is contained in the recycled waste toner. In the waste toner box, the waste toner and the air is separated to recycle the waste toner only.
  • Page 180 4. WASTE TONER RECYCLE SECTION Theory of Operation Ver1.0 Jun.2005 Blank page...
  • Page 181 SERVICE MANUAL Theory of Operation TU-501 2005.06 Ver. 1.0...
  • Page 182 Revision history After publication of this service manual, the parts and mechanism may be subject to change for improve- ment of their performance. Therefore, the descriptions given in this service manual may not coincide with the actual machine. When any change has been made to the descriptions in the service manual, a revised version will be issued with a revision mark added as required.
  • Page 183 Theory of Operation Ver1.0 Jun.2005 CONTENTS CONTENTS TU-501 OUTLINE 1. PRODUCT SPECIFICATIONS............1 2.
  • Page 184 CONTENTS Theory of Operation Ver1.0 Jun.2005 Blank page...

  • Page 185: Product Specifications

    Theory of Operation Ver1.0 Jun.2005 1. PRODUCT SPECIFICATIONS OUTLINE 1. PRODUCT SPECIFICATIONS A. Type Type Upper blade reciprocating type fore-edge trimming device with large capacity stacker Applicable type of machine FS-604 (When equipped, optional MK-707 is required.) B. Functions Number of sheets trimmed 40 sheets, maxi- •...
  • Page 186 1. PRODUCT SPECIFICATIONS Theory of Operation Ver1.0 Jun.2005 Stacking capacity The stacking capacities shown below are applicable only for the same size. Number of sheets folded *2 Number of stackable booklets 2 to 5 100 or more 6 to 10 50 or more 11 to 16 32 or more...
  • Page 187 Theory of Operation Ver1.0 Jun.2005 1. PRODUCT SPECIFICATIONS C. Type of paper Paper size Fixed size Equivalent to the paper sizes corresponding to the saddle stitching/ folding mode of the FS (A3, B4, A4R, 11 x 17, 8.5 x 14, 8.5 x 11R) Wide paper Equivalent to the paper sizes corresponding to the FS Amount of curling...

  • Page 188: Paper Path

    2. PAPER PATH Theory of Operation Ver1.0 Jun.2005 2. PAPER PATH [10] 15smt1c005na While in use of MK-707 Press conveyance roller /1 Introduction roller Press conveyance roller /2 Entrance conveyance roller /1 Booklets exited Entrance conveyance roller /2 Vertical conveyance roller Blade entrance roller [10] Blade exit roller...

  • Page 189: Composition/Operation

    Theory of Operation Ver1.0 Jun.2005 3. COMPOSITION COMPOSITION/OPERATION 3. COMPOSITION Stacker section Conveyance section Press section Blade section 15smt2c001na...

  • Page 190: Conveyance Section

    4. CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 4. CONVEYANCE SECTION Drive [10] [11] [12] [13] [14] 15smt2c002na Introduction roller Press conveyance roller /2 Belt Vertical conveyance driven roller Entrance conveyance roller /1 [10] Vertical conveyance roller Entrance conveyance roller /2 [11] Blade exit roller Conveyance motor (M101)

  • Page 191: Operation

    Theory of Operation Ver1.0 Jun.2005 4. CONVEYANCE SECTION Operation 4.2.1 Conveyance control A. Trimming mode The conveyance motor (M101) turns on the moment the folding transfer motor (M20) of the FS turns ON [1], and conveys booklets exited from the FS to the entrance conveyance section at the speed of 580 mm/s. A specified period of time after the conveyance sensor (PS102) provided at the press section detects [2] the leading edge (folding side) of the booklet that has been conveyed, M101 turns OFF [3] to stop the conveyance.
  • Page 192 4. CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 B. Through mode The ON/OFF timing of the conveyance motor (M101) is the same up to the registration operation as A. Trimming mode. After the rotational slippage of the booklets is adjusted by the registration operation, the moment the stopper release motor (M104) completes [4] the stopper release operation a specified period of time after M101 turns OFF [3], M101 turns ON again to convey [5] the booklet to the stacker and to hold it upright.

  • Page 193: Press Section

    Theory of Operation Ver1.0 Jun.2005 5. Press section 5. Press section Drive 5.1.1 Press drive 15smt2c005na Press plate Press motor (M105)

  • Page 194: Stopper Drive/Stopper Release Drive

    5. Press section Theory of Operation Ver1.0 Jun.2005 5.1.2 Stopper drive/Stopper release drive 15smt2c006na Belt Stopper Top view Stopper release motor (M104) Front view Stopper motor (M103)

  • Page 195: Operation

    Theory of Operation Ver1.0 Jun.2005 5. Press section Operation 5.2.1 Stopper mechanism The stopper [5] is fixed to the belt [1] and driven left and right by the stopper motor (M103) [8] to decide the posi- tion of the booklet [4]. And the stopper release while in the booklet being exited is made by the stopper release motor (M104) [7] with the stopper brought down through the cam [6].

  • Page 196: Stopper Movement Control

    5. Press section Theory of Operation Ver1.0 Jun.2005 5.2.2 Stopper movement control A. Paper size movement When the stopper conducts the initial operations in the saddle stitching/folding mode of the FS, the stopper motor (M103) turns ON to move up to the specified position for each paper size for standby. B.

  • Page 197: Stopper Release Control

    Theory of Operation Ver1.0 Jun.2005 5. Press section 5.2.3 Stopper release control A. Stopper release while in the trimming mode After completion of the stopper evacuation movement [2] described in the previous section, the stopper release motor (M104) turns ON to start the stopper release [3] operation. When M104 turns OFF with the stopper release home sensor (PS104) OFF, the stopper is brought down.
  • Page 198 5. Press section Theory of Operation Ver1.0 Jun.2005 B. Stopper release while in the through mode After completion of the stopper evacuation movement [2] described in the previous section, the stopper release motor (M104) turns ON a specified period of time after the conveyance motor (M101) turns OFF to start the stopper release [3].

  • Page 199: Press Control

    Theory of Operation Ver1.0 Jun.2005 5. Press section 5.2.4 Press control A. Press mechanism The press operation of the booklet [2] is made by transmitting the driving force of the press motor (M105) [5] to the pressing plate [1] through the gear and the link [3] to press the booklet. And also, the home position is detected by the press home sensor (PS105) [4].

  • Page 200: Blade Section

    6. Blade section Theory of Operation Ver1.0 Jun.2005 6. Blade section Operation 6.1.1 Blade control A. Blade mechanism The blade /Up [1] is driven by the blade motor (M102) [4] to conduct one vertical reciprocating operation to trim the booklet [5] together with the blade /Lw [2]. The blade /Up normally stands by at the upper section where no trimming is made, and it is monitored at all times by the blade home switch (MS101) [3].

  • Page 201: Scraps Removal Control

    Theory of Operation Ver1.0 Jun.2005 6. Blade section 6.1.2 Scraps removal control A. Scraps removal mechanism Trimming scraps are discharged by the scraps removal motor (M108) [1] to be dropped into the scraps box [3]. The scraps box is monitored by the scraps box full LED (LED101) [5] and the scraps box full sensor (PS109) [2]. When LED101 and PS109 detect the scraps box full condition, a message informing the full condition is dis- played on the main body operation panel.

  • Page 202: Stacker Section

    7. Stacker section Theory of Operation Ver1.0 Jun.2005 7. Stacker section Drive 7.1.1 Pusher plate drive 15smt2c014na Pusher plate Pusher motor (M107)

  • Page 203: Holder Plate Drive

    Theory of Operation Ver1.0 Jun.2005 7. Stacker section 7.1.2 Holder plate drive 15smt2c015na Belt Holder plate Holder motor (M106)

  • Page 204: Operation

    7. Stacker section Theory of Operation Ver1.0 Jun.2005 Operation 7.2.1 Paper exit mechanism Normally, the pusher plate [5] is positioned nearer to the paper exit tray [3] side than the holder plate [1]. The paper exit tray is pulled by the fix load spring [2] toward the pusher plate to hold the booklets [4] between the paper exit tray and the pusher plates and stand them on end for stacking.

  • Page 205: Paper Exit Control

    Theory of Operation Ver1.0 Jun.2005 7. Stacker section 7.2.2 Paper exit control A. Trimming mode After completion of the trimming operation, the pusher motor (M107) turns ON a specified period of time after the blade motor (M102) stops to evacuate the pusher plate [1] and open the paper exit path to the stacker. A specified period of time after the exit sensor (PS108) detects the trailing edge (trimming side) of the booklet, the holder motor (M106) is rotated in the reverse direction to bring down [2] the holder plate.
  • Page 206 7. Stacker section Theory of Operation Ver1.0 Jun.2005 C. Stacker full detection control The booklets pushed out from the paper exit path are held between the pusher plate and the paper exit tray to be stacked in an upright posture. When the booklets that have been stacked get to the specified thickness, the stacker full sensor (PS113) [1] turns ON with a message informing the stacker full condition displayed on the main body operation panel.
  • Page 207 SERVICE MANUAL Theory of Operation ZU-601/602 2005.06 Ver. 1.0...
  • Page 208 Revision history After publication of this service manual, the parts and mechanism may be subject to change for improve- ment of their performance. Therefore, the descriptions given in this service manual may not coincide with the actual machine. When any change has been made to the descriptions in the service manual, a revised version will be issued with a revision mark added as required.
  • Page 209 Theory of Operation Ver1.0 Jun.2005 CONTENTS CONTENTS ZU-601/602 OUTLINE 1. PRODUCT SPECIFICATIONS............1 2.
  • Page 210 CONTENTS Theory of Operation Ver1.0 Jun.2005 Blank page...

  • Page 211: Product Specifications

    Theory of Operation Ver1.0 Jun.2005 1. PRODUCT SPECIFICATIONS OUTLINE 1. PRODUCT SPECIFICATIONS A. Type Type Z-folding multi punching device B. Functions Punch Punching method Reciprocal punching method (punching each paper) No. of holes ZU-601: Swedish 4 holes ZU-602: Metric area 2 holes/4 holes (switched automatically) Inch area 2 holes/3 holes (switched automatically) φ6.5 mm Hole diameter...
  • Page 212 1. PRODUCT SPECIFICATIONS Theory of Operation Ver1.0 Jun.2005 Z-folding Z-folding method Buckle folding method with the roller pair Folding length 15ktt1e002na Paper L (mm) a (mm) size Z-folding 209 or less 3.5 ± 1.5 181 or less 11 x 17 215 or less 194 or less Folding...
  • Page 213 Theory of Operation Ver1.0 Jun.2005 1. PRODUCT SPECIFICATIONS Maximum tray capacity The maximum number of sheets for the FS main tray at the (80g/m Z-folding operation • Z folding continuous: Max. 30 sheets • Z-folding/stapling: See the table below No. of sheets per staple No.
  • Page 214 1. PRODUCT SPECIFICATIONS Theory of Operation Ver1.0 Jun.2005 D. Maintenance Maintenance Same as the main body. Machine service life Same as the main body. E. Machine data Power source 100 to 240 VAC (automatic switching) DC5V (supplied from the main body) Maximum power consump- 120 W or less tion...

  • Page 215: Paper Path

    Theory of Operation Ver1.0 Jun.2005 2. PAPER PATH 2. PAPER PATH A. Straight mode/punch mode (for the small size paper) 15kvt1c002na B. Punch mode (for the large size paper) 15kvt1c003na...
  • Page 216 2. PAPER PATH Theory of Operation Ver1.0 Jun.2005 C. Z-folding mode/punch + Z-folding mode 15kvt1c004na From the main body to the 1st folding From the 2nd folding to the paper exit From the 1st folding to the 2nd folding...

  • Page 217: Composition/Operation

    Theory of Operation Ver1.0 Jun.2005 3. COMPOSITION COMPOSITION/OPERATION 3. COMPOSITION Z-folding section Conveyance section Punch section Punch scraps con- veyance section 15kvt2c001na...

  • Page 218: Conveyance Section

    4. CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 4. CONVEYANCE SECTION Drive A. Conveyance drive 15kvt2c002na Gate /Up Registration motor (M1) 1st folding roller Exit roller Conveyance roller 2nd folding roller Registration roller Conveyance motor (M6) Gate /Lw...
  • Page 219 Theory of Operation Ver1.0 Jun.2005 4. CONVEYANCE SECTION B. Gate drive 15kvt2c003na Gate /Up Gate solenoid /Lw (SD1) Gate /Lw Gate solenoid /Up (SD2)

  • Page 220: Operation

    4. CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 Operation 4.2.1 Conveyance path switching The gates /Lw and /Up switch the conveyance path. The gate solenoids /Lw (SD1) and /Up (SD2) drive the gates /Lw and /Up respectively. A. Gate /Lw The gate /Lw [4] switches the paper path between the straight conveyance path [2] and the upper conveyance path [1].
  • Page 221 Theory of Operation Ver1.0 Jun.2005 4. CONVEYANCE SECTION B. Gate /Up The gate /Up [5] switches the paper path of the paper that was conveyed to the upper conveyance path by the gate /Lw. The gate /Up is set to the paper path to the exit side [3] when the gate solenoid /Up (SD2) [4] turns OFF [6].

  • Page 222: Conveyance Line Speed Switching

    4. CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 (2) Punch mode for the small size paper (A4, B5, A5, A5R, 16K, 8.5 x 11, 5.5 x 8.5, 5.5 x 8.5R) Gate solenoids /Lw (SD1) and /Up (SD2) always remain OFF, and never turn ON. (3) Punch mode for the large size paper (other than the small size paper) The gate solenoid /Lw (SD1) turns ON when the paper edge sensor board (PESB) detects the leading edge of the paper, and then the gate /Lw is set to the upper conveyance path.
  • Page 223 Theory of Operation Ver1.0 Jun.2005 4. CONVEYANCE SECTION A. Operation timing (1) Z-folding Transmitting the start signal from the main body, the conveyance motor (M6) turns ON [1] and rotates in high speed. M6 rotates in low speed [2] and perform the 1st and 2nd folding operations [3] a specified period of time after the paper edge sensor board (PESB) detects the leading edge of the paper.
  • Page 224 4. CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 (2) Punch + Z-folding Transmitting the start signal from the main body, the conveyance motor (M6) turns ON [1] and rotates in high speed. M6 rotates in low speed [2] and perform the 1st folding operation a specified period of time after the paper edge sensor board (PESB) detects the leading edge of the paper.

  • Page 225: Registration Control

    Theory of Operation Ver1.0 Jun.2005 4. CONVEYANCE SECTION 4.2.3 Registration control The registration control corrects paper skew in the Z-folding mode and the punch mode. The paper exited from the main body is pressed against the stopped registration roller [3] and forms a loop [2] to correct skew of the paper [1], and then the paper is conveyed with its leading edge nipped.

  • Page 226: Punch Section

    5. PUNCH SECTION Theory of Operation Ver1.0 Jun.2005 5. PUNCH SECTION Drive A. ZU-601 [10] 15ktt2e001na Punch clutch (CL1) Punch edges Punch motor (M4) Front direction Punch shift motor (M5) Eccentric cam Belt Right side view Rack [10] Rear side view...
  • Page 227 Theory of Operation Ver1.0 Jun.2005 5. PUNCH SECTION B. ZU-602 [10] [14] [11] [13] [15] [12] [11] [10] 15kvt2e001na Punch clutch (CL1) Front direction Punch motor (M4) [10] Cam cover Punch shift motor (M5) [11] Eccentric cam (Metric Type: 4/Inch Type: 5) Belt [12] Punch switchover cam...

  • Page 228: Operation

    5. PUNCH SECTION Theory of Operation Ver1.0 Jun.2005 Operation The punch operation is conducted for every paper. The controls related to the punch operation is the punch unit position movement control, the punch operation control, and the punch hole switching control (only for ZU-602). 5.2.1 Punch control The punch operation is conducted by transmitting the rotation of the punch motor (M4) [4] to the eccentric cam...
  • Page 229 Theory of Operation Ver1.0 Jun.2005 5. PUNCH SECTION A. Operation timing The registration motor (M1) and the conveyance motor (M6) turn OFF to stop the conveyance during the punch operation. The punch motor (M4) turns ON [1] when the paper edge sensor board (PESB) detects the leading edge of the paper.

  • Page 230: Punch Position Movement Control

    5. PUNCH SECTION Theory of Operation Ver1.0 Jun.2005 5.2.2 Punch position movement control The punch shift motor (M5) [1] moves the punch unit [3] to move the punch hole position in the main scan direc- tion. 5 sensors of the paper edge sensor board (PESB) [8] detects the punch hole position. The front side sensor [7] among 5 sensors detects the leading/trailing/side edge of the paper and the other 4 sensors [6] detect the side edge of the paper.
  • Page 231 Theory of Operation Ver1.0 Jun.2005 5. PUNCH SECTION A. Standby position movement of the punch unit In the punch mode, the punch unit [5] is set to the standby position in accordance with the paper size before the paper [3] is conveyed. The punch shift motor (M5) [1] moves the punch unit so that the sensor corresponding to the paper size among 5 sensors of the paper edge sensor board (PESB) [6] (in case of A4 paper, the sensor [7] is used) is positioned 5 mm [9] inward from the side edge of the paper [8].
  • Page 232 5. PUNCH SECTION Theory of Operation Ver1.0 Jun.2005 B. Punch position correction The punch unit [13] positioned 5 mm [1] inward from the side edge of the paper [3] conducts the punch position correction operation by moving the punch unit back and forth while conveying the paper to correct the misalign- ment between the conveyed paper [7] and the punch position.

  • Page 233: Punch Hole Switching Control (Zu-602)

    Theory of Operation Ver1.0 Jun.2005 5. PUNCH SECTION 5.2.3 Punch hole switching control (ZU-602) Transmitting the start signal from the main body, the punch switchover motor (M8) [3] switches the number of holes in the punch mode. M8 rotates the punch switchover cam [5] clockwise and moves the eccentric cams [8] and [9] back and forth via the cam cover [6].

  • Page 234: Punch Scraps Conveyance Section

    6. PUNCH SCRAPS CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 6. PUNCH SCRAPS CONVEYANCE SECTION Drive 15kvt2c018na Punch scraps conveyance motor (M7) Punch scraps conveyance screw gear...

  • Page 235: Operation

    Theory of Operation Ver1.0 Jun.2005 6. PUNCH SCRAPS CONVEYANCE SECTION Operation 6.2.1 Punch scraps conveyance control The punch scraps are conveyed by the punch scraps conveyance screw [2] driven by the punch scraps convey- ance motor (M7) [1]. They are conveyed to the punch scraps box [3] via the punch scraps collective duct [4]. M7 turns ON to rotate the punch scraps conveyance screw a specified period of time after the paper edge sen- sor detects the trailing edge of the paper in the punch mode.

  • Page 236: Punch Scraps Control

    6. PUNCH SCRAPS CONVEYANCE SECTION Theory of Operation Ver1.0 Jun.2005 6.2.2 Punch scraps control The punch scraps box set sensor (PS7) [1] and the punch scraps full sensor (PS8) [3] monitor the punch scraps box [2]. 15kvt2c020na Punch scraps box set sensor (PS7) Punch scraps full sensor (PS8) Punch scraps box A.

  • Page 237: Z-Folding Section

    Theory of Operation Ver1.0 Jun.2005 7. Z-FOLDING SECTION 7. Z-FOLDING SECTION Drive A. 1st stopper drive 15kvt2c021na Front side direction 1st stopper home sensor (PS3) 1st stopper motor (M2) 1st stopper B. 2nd stopper drive 15kvt2c022na Front side direction 2nd stopper home sensor (PS4) 2nd stopper motor (M3) 2nd stopper...

  • Page 238: Operation

    7. Z-FOLDING SECTION Theory of Operation Ver1.0 Jun.2005 Operation 7.2.1 1st folding control The registration roller [5], the conveyance roller [4], and the 1st folding roller [3] convey the paper to the 1st fold- ing stopper section via the gate /Up [2]. A loop [6] is formed between the 1st folding roller [3] and the convey- ance drive roller [7] when the leading edge of the paper is pressed against the 1st folding stopper [8].

  • Page 239: 2Nd Folding Control

    Theory of Operation Ver1.0 Jun.2005 7. Z-FOLDING SECTION 7.2.2 2nd folding control The paper conveyed from the 1st folding section to the 2nd folding section is stopped by the 2nd folding stop- per [4] and forms a loop [8] between conveyance drive roller [10] and the 2nd folding roller [9]. The loop grows, and then it is caught by these rollers and the 2nd folding is conducted.
  • Page 240 7. Z-FOLDING SECTION Theory of Operation Ver1.0 Jun.2005 Blank page...

Table of Contents
