Clevo M540J Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for Clevo M540J

Summary of Contents for Clevo M540J

  • Page 3 Preface Notebook Computer M540J/M545J/M550J/M555J Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.

  • Page 5: About This Manual

    This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M540J/ M545J/M550J/M555J series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: Related Documents

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 11: Table Of Contents

    External Locator - Left Side & Rear View ........1-7 LCD (M550J) ................. A-6 External Locator - Bottom View .............1-8 LCD (M555J) ................. A-7 M540J Mainboard Overview - Top (Key Parts) ......1-9 DVD-RW Drive (M550J) .............. A-8 M540J Mainboard Overview - Bottom (Key Parts) ......1-10 Top (M540J) .................. A-9 M540J Mainboard Overview - Top (Connectors) ......1-11...
  • Page 12 Preface MCP51 PCI .................. B-16 MCP51 SATA / IDE ..............B-17 MCP51 AUDIO / USB / MISC ............ B-18 MCP51 RGMII ................B-19 MCP51 PWR / GND ..............B-20 MINI PCI, USB2.0*2 ..............B-21 SIO, SATA HDD, CD-ROM ............B-22 LAN RTL8201CL ................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M540J/M545J/M550J/M555J series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 14: System Specifications

    Introduction System Specifications Feature Specification µ Processor Mobile AMD Turion™ 64 Processor (35W), 0.09) 0.09 Micron Silicon-On-Insulator (SOI) Process 754-pin Micro-PGA Package, 64bit Technology, 1MB L2 Cache Models ML-30/ ML-34/ ML-37/ ML-40/ ML-44 1.6GHz/ 1.8GHz/ 2.0GHz/ 2.2GHz/ 2.4GHz µ Mobile AMD Turion™ 64 Processor (35W), 0.09) 0.09 Micron Silicon-On-Insulator (SOI) Process 754-pin Micro-PGA Package, 64bit Technology, 512KB L2 Cache...
  • Page 15 Introduction Feature Specification M550J: M540J: 15.0" XGA (1024*768) Flat Panel TFT 14.0" WXGA (1280*768) Flat Panel TFT 15.0" SXGA+ (1400*1050) Flat Panel TFT Video Adapter nVIDIA C51MV Integrated Graphics Adapter Shared Memory Architecture of up to 128MB of Video Memory...
  • Page 16 C ~ 35 Operating: 20% ~ 80% Non-Operating: -20°C ~ 60°C Non-Operating: 10% ~ 90% Physical M550J: M540J: Dimensions & 333mm (w) * 276mm (d) * 24-33mm (h) 333mm (w) * 243mm (d) * 24-33mm (h) Weight 2.4 kg Without Battery 2.2 kg Without Battery...

  • Page 17: External Locator - Top View With Lcd Panel Open

    3. LED Status Indicators 4. Speakers 5. LED Power & Communication Indicators 6. Power Button 7. Keyboard 8. Built-In Microphone 9. TouchPad and Buttons 10. AP-Key Buttons M550J M540J External Locator - Top View with LCD Panel Open 1 - 5...

  • Page 18: External Locator - Front & Right Side Views

    External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power & Communication Indicators 2. LCD Latch (M550J Only) M550J 3. 4-in-1 Card Reader (M540J Only) M540J Figure 3 Right Side Views 1. Headphone-Out Jack 2. Microphone-In Jack 3. USB 2.0 Port 4.

  • Page 19: External Locator - Left Side & Rear View

    3. 2 * USB 2.0 Ports 4. S/PDIF-Out Jack 5. Line-In Jack 6. PC Card Slot 7. 4-in-1 Card Reader (M550J Only) M540J Figure 5 Rear View 1. External Monitor Port 2. Serial Port 3. Security Lock Slot 4. Battery...

  • Page 20: External Locator - Bottom View

    1. Vent/Fan Intake 2. Battery 3. Memory (RAM)/ WLAN Module/ CPU Cover 4. Hard Disk Cover 5. Speakers (M550J Only) M540J Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use.

  • Page 21: M540J Mainboard Overview - Top (Key Parts)

    Introduction M540J Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. PC Card Assembly 2. H8/2111 3. RS-232 Transceivers 4. PC87381 Super I/O M540J Mainboard Overview - Top (Key Parts) 1 - 9...

  • Page 22: M540J Mainboard Overview - Bottom (Key Parts)

    Module) Connector 5. Memory Slots DDR2 So-DIMM 6. Southbridge- MCP51M 7. ENE PCMCIA & Card Card Control 8. RTL820KL 10/100M Fast Ethernet Phyceiver 9. ALC880 Audio Codec 10. Audio Amp. 1 - 10 M540J Mainboard Overview - Bottom (Key Parts)

  • Page 23: M540J Mainboard Overview - Top (Connectors)

    Introduction M540J Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. PCMCIA Socket 2. Keyboard 3. Hot-key board Connector 4. USB Port 5. S/PDIF-Out Jack 6. Line-In Jack M540J Mainboard Overview - Top (Connectors) 1 - 11...

  • Page 24: M540J Mainboard Overview - Bottom (Connectors)

    6. Modem Module Connector 7. TouchPad Connector 8. CMOS Bat. Connector 9. Microphone Cable Connector 10. LED Board Connector 11. Card Reader Socket 12. LAN Board Connector 13. Fan CPU Cable Connector 1 - 12 M540J Mainboard Overview - Bottom (Connectors)

  • Page 25: M550J Mainboard Overview - Top (Key Parts)

    Introduction M550J Mainboard Overview - Top (Key Parts) Figure 11 Mainboard Top Key Parts 1. PC Card Assembly 2. H8/2111 3. RS-232 Transceivers 4. PC87381 Super I/O M550J Mainboard Overview - Top (Key Parts) 1 - 13...

  • Page 26: M550J Mainboard Overview - Bottom (Key Parts)

    Introduction M550J Mainboard Overview - Bottom (Key Parts) Figure 12 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Northbridge- C51MV 3. Mini-PCI (Wireless Lan Module) Connector 4. Flash BIOS ROM 5. Memory Slots DDR2 So-DIMM 6. Southbridge- MCP51M 7.

  • Page 27: M550J Mainboard Overview - Top (Connectors)

    Introduction M550J Mainboard Overview - Top (Connectors) Figure 13 Mainboard Top Connectors 1. PCMCIA Socket 2. Keyboard 3. Hot-key board Connector 4. USB Port 5. S/PDIF-Out Jack 6. Line-In Jack 7. TouchPad Connector 8. Card Reader Socket M550J Mainboard Overview - Top (Connectors) 1 - 15...

  • Page 28: M550J Mainboard Overview - Bottom (Connectors)

    Introduction M550J Mainboard Overview - Bottom (Connectors) Figure 14 Mainboard Bottom Connectors 1. D/D Board Connector 2. LCD Connector 3. Speaker Cable Connector 4. Audio Board Connector 5. BT Connector 6. Modem Module Connector 7. Microphone Cable Connector 8. CMOS Bat. Connector 9.

  • Page 29: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M540J/M545J/M550J/M555J series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 30: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 31: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 32: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Wireless LAN Module: 1. Remove the battery page 2 - 5 1.

  • Page 33: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Locate the battery bay at point (Figure 1a). Battery Removal 3. Slide the latch in the direction of the arrow, and hold it in place. 4.

  • Page 34: Removing The Hard Disk Drive

    You have all the CD-ROMs and FDDs required to install your operating system and programs. • 1 Screw (M550J) • 2 Screws (M540J) If you have access to the internet, download the latest application and hardware driver updates for the operating system you plan to install.
  • Page 35 ,and reverse the process to install any new hard disk. 7. HDD Case (M550J) 16. HDD Case (M540J) 17. HDD • 4 Screws (M550J) • 2 Screws (M540J) Removing the Hard Disk Drive 2 - 7...

  • Page 36: Removing The System Memory (Ram)

    Even the clean- est hands have oils which can attract parti- cles, and degrade the module’s perfor- M540J mance. M550J 1. Bay Cover • 7 Screws (M550J) • 5 Screws (M540J) 2 - 8 Removing the System Memory (RAM)
  • Page 37 Disassembly 4. Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the Figure 5 arrows (Figure 5a). Memory Removal Sequence a. Pull release latch(es). b. Remove the module(s). 5. The RAM module(s) will pop-up Figure 5b , and you can then remove it...

  • Page 38: Removing The Optical (Cd/Dvd) Device

    9. 6. Restart the computer to allow it to automatically detect the new device. M540J M550J 1. Bay Cover 10. Optical Device • 7 Screws (M550J) • 5 Screws (M540J) 2 - 10 Removing the Optical (CD/DVD) Device...

  • Page 39: Removing The Processor

    7c) off the computer. the computer. c. Remove the screws in the order indicated. d. Remove the heat sink. M550J 1. Bay Cover M540J 14. Heat Sink • 12 Screws (M550J) • 10 Screws (M540J) Removing the Processor 2 - 11...
  • Page 40 Disassembly 6. Turn the release latch towards the unlock symbol , to release the CPU (Figure 8a). 7. Carefully (it may be hot) lift the CPU up out of the socket (Figure 8b). 8. Reverse the process to install a new CPU. 9.

  • Page 41: Removing The Keyboard

    Remove the keyboard. Re-Inserting the Key- board When re-inserting the keyboard firstly align the five keyboard tabs at the bottom of the keyboard with the slots in the case. 4. Keyboard M540J M550J Removing the Keyboard 2 - 13...

  • Page 42: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the bay cover Module Removal 2. Carefully disconnect cable , then gently pull the two release latches ( ) on the sides of the module socket.

  • Page 43: Removing The Modem And Bluetooth Modules

    Disassembly Removing the Modem and Bluetooth Modules Figure 11 For M550J computers: Modem and 1. Turn off the computer, remove the battery (page 2 - 5), the optical device (page 2 - 10), the hard disk drive (page Bluetooth Removal 6), bay cover (page 2 - 8) the CPU heat sink...
  • Page 44 Remove the screw and disconnect the cable. d. Disconnect the antenna cable from the Bluetooth module. e. Lift the Bluetooth module out. 4. Modem Module 8. Bluetooth Module • 3 Screws (M540J) 2 - 16 Removing the Modem and Bluetooth Modules...

  • Page 45: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the M540J/M545J/M550J/M555J series notebook’s construction into a series of illustra- tions. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 46: Part List Illustration Location

    A - 10 Top - (M545J) page A - 11 Bottom - (M540J/M545J) page A - 12 LCD - (M540J) page A - 13 LCD - (M545J) page A - 14 Combo Drive - (M540J) A - 2 Part List Illustration Location...

  • Page 47: Top (M550J

    Part Lists Top (M550J) 鐵弗龍 無鉛 無鉛 無鉛 鐵弗龍 鋁合金 M550J 無鉛 無鉛 無鉛 Figure A - 1 無鉛 Top (M550J) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Top (M550J) A - 3...

  • Page 48: Top (M555J

    Part Lists Top (M555J) 無鉛 鐵弗龍 無鉛 無鉛 無鉛 鐵弗龍 無鉛 無鉛 Figure A - 1 無鉛 Top (M555J) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 A - 4 Top (M555J)

  • Page 49: Bottom (M550J/M555J

    Part Lists Bottom (M550J/M555J) Figure A - 2 Bottom (M550J/M555J) 外 外 鋁合金 M550J 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁合金 M550J 無鉛 無鉛 無鉛 無鉛 元力 M550J 無鉛 無鉛 無鉛 無鉛 昆山 無鉛 昆山 無鉛 無鉛 Bottom (M550J/M555J) A - 5...

  • Page 50: Lcd (M550J

    Part Lists LCD (M550J) Figure A - 3 LCD (M550J) 直徑6.3X3.6H 無鉛 無鉛 (凱明） 中性 無鉛 無鉛 無鉛 惠貿 無鉛 無鉛 (凱明） 鐵弗龍 無鉛 無鉛 無鉛 無鉛 A - 6 LCD (M550J)

  • Page 51: Lcd (M555J

    Part Lists LCD (M555J) Figure A - 4 LCD (M555J) 直徑6.3X3.6H 無鉛 無鉛 無鉛 中性 無鉛 無鉛 無鉛 惠貿 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鐵弗龍 無鉛 無鉛 LCD (M555J) A - 7...

  • Page 52: Dvd-Rw Drive (M550J

    Part Lists DVD-RW Drive (M550J) Figure A - 5 DVD-RW Drive (M550J) A - 8 DVD-RW Drive (M550J)

  • Page 53: Top (M540J

    無鉛 Top (M540J) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 石墨 無鉛 無鉛 無鉛 無鉛 銅片 無鉛 MYLAR 銅箔 FOR TOP CASE M540G 無鉛（尺寸變更） 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 銅片 無鉛 Top (M540J) A - 9...

  • Page 54: Top (M545J

    Part Lists Top (M545J) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Figure A - 7 無鉛 Top (M545J) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 銅片 無鉛 MYLAR 銅箔 FOR TOP CASE M540G 無鉛（尺寸變更） 無鉛 無鉛 無鉛 無鉛...

  • Page 55: Bottom (M540J/M545J

    Part Lists Bottom (M540J/M545J) Figure A - 8 Bottom (M540J) 外 外 昆山無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 元力 無鉛 無鉛 無鉛 無鉛 無鉛 Bottom (M540J/M545J) A - 11...

  • Page 56: Lcd (M540J

    Part Lists LCD (M540J) Figure A - 9 LCD (M540J) 平頭 圓頭 無鉛 無鉛 無鉛 無鉛 無鉛 頭徑3.5MM 頭厚0.3MM 無鉛 無鉛 無鉛 中性 無鉛 無鉛 無鉛 無鉛 鐵弗龍 無鉛 A - 12...

  • Page 57: Lcd (M545J

    Part Lists LCD (M545J) Figure A - 10 LCD (M545J) 平頭 圓頭 無鉛 無鉛 無鉛 無鉛 頭徑3.5MM 頭厚0.3MM 無鉛 無鉛 無鉛 中性 無鉛 無鉛 鐵弗龍 無鉛 無鉛 LCD BACK COVER COSMETIC BAR(銀色) M545G 無鉛 無鉛 LCD (M545J) A - 13...

  • Page 58: Combo Drive (M540J

    Part Lists Combo Drive (M540J) Figure A - 11 Combo Drive (M540J) 無鉛 無鉛 無鉛 A - 14 Combo Drive (M540J)
  • Page 59 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the M540J/M545J/M550J/M555J notebook’s PCB’s. The following table indi- cates where to find the appropriate schematic diagram. Table B - 1 Diagram - Page Diagram - Page Diagram - Page...

  • Page 60: Schematic Diagrams

    Schematic Diagrams System Block Diagram System Block Diagram D/D BOARD 1.+1.2V_HT,+1.5V,+1.5VS 2.+3V,+5V,+12V,+3VS,+5VS,+12VS 1.CHARGER,DC JACK MEMORY TERMINATIONS 3.+2.6VS,+3VS,+5VS,+12VS_ADJ 2.CRT,COM1,RI-11 4.+3VH8,+5VH8 5.+VDD3,+VDD5,+VDD12 PROCESSOR 400 MHz AUDIO BOARD DDR VR 1.+2.6V,+1.3V,+1.2V SOCKET 1.AUDIO PHONE JACK 754 uFCPGA 2.USB CONNECTOR 3.RJ11 CONNECTOR 1.+VCORE SO-DIMM2 SO-DIMM1 HOT KEY BOARD D/D BOARD...
  • Page 61 Schematic Diagrams ATHLON 64 1/4 +1.2V_HT [4,9,13] +3VS [6,8,11,12,13,14,15,16,17,19,20,21,23,24,26,27,29,30,31] VLDT +VDD5 [8,26,31,32,33,34,35] 850mA VLDT +1.2V(1.14~1.26) 500mA +2.6V [3,4,5,6,7,14,31,32] +1.2V_HT C506 C526 C503 C497 0.22u_04 0.22u_04 0.22u_04 0.1u_X7R_04 0.1u_X7R_04 1000p_04 4.7u_08 *22u_12 4.7u_08 0.1u_X7R_04 C508 Sheet 2 of 44 *47u/6.3V_B 4.7u_08 4.7u_08 U25A ATHLON 64 1/4...
  • Page 62 Schematic Diagrams ATHLON 64 2/4 +2.6V [2,4,5,6,7,14,31,32] MEMDATA61 8P4RX10_0402 MMDATA61 +1.3V [4,7,32] DQM7 MEMDQS16 MEMDATA62 MMDATA62 MEMDATA63 MMDATA63 PLACE WITHIN 0.25 - 1.00 INCH FROM CPU MAA[0..13] [6,7] MEMDATA59 RN40 8P4RX10_0402 MMDATA59 MEMDATA58 MMDATA58 MAB[0..13] [6,7] MEMDQS7 MMDQS7 MEMDATA57 MMDATA57 MEMCLK_L4 R351 120_1%...
  • Page 63 Schematic Diagrams ATHLON 64 3/4 +3VH8 +3V [15,17,18,19,20,21,22,26,28,31,32,33] VCORE 10K_04 +3VH8 [25,26,31] +3VS [2,6,8,11,12,13,14,15,16,17,19,20,21,23,24,26,27,29,30,31] 1N4148 +2.6V [2,3,5,6,7,14,31,32] +1.3V +2.6VS [9,12,13,14,31] H8_THRMTRIP# [25] 35mA R347 R346 Z0412 +1.3V [3,7,32] +1.2V_HT [2,9,13] VCORE [5,33] +2.5V 2.4~2.6 35mA 300nH/350mA +VDD3 [8,17,18,31,35] TRMTRIP# [35] 1005 FCI2012F-R33K Z0402...
  • Page 64 Schematic Diagrams ATHLON 64 4/4 VCORE +2.6V 1.5V@ 46A VCORE +2.6V [2,3,4,6,7,14,31,32] VCORE [33] C884 0.1u_X7R_04 VCORE +2.6V Place on Back side of CPU U25E C134 C169 C120 C162 C128 C144 U25D 0.22u_04 0.22u_04 0.22u_04 0.22u_04 0.22u_04 0.22u_04 VDD1 AC15 VSS222 VSS33 VDD2...

  • Page 65: Ddr So-Dimm

    Schematic Diagrams DDR SO-DIMM +3VS [2,8,11,12,13,14,15,16,17,19,20,21,23,24,26,27,29,30,31] +2.6V [2,3,4,5,7,14,31,32] MEMDATA[0..63] +2.6V +2.6V MEMDATA[0..63] [3,7] DDR_SO-DIMM1_R DDR_SO-DIMM2_S MAB[0..13] [3,7] SODIMM-DDR_200P_R CA0144-200N01_R [3,7] MAA[0..13] MAA0 MEMDATA0 MAB0 MAA1 MEMDATA1 MAB1 MAA2 MEMDATA2 MAB2 MAA3 MEMDATA3 MAB3 MAA4 MEMDATA4 MAB4 MAA5 MEMDATA5 MAB5 MAA6 MEMDATA6 MAB6 MAA7...

  • Page 66: Ddr Termination

    Schematic Diagrams DDR TERMINATION +2.6V [2,3,4,5,6,14,31,32] +1.3V [3,4,32] +1.3V 2.4A DQM[0..7] +1.3V [3,6] DQM[0..7] +1.3V RN62 8P4RX68_04 C616 0.1u_X7R_04 C258 0.1u_X7R_04 MEMDATA5 MEMDATA10 MEMDATA4 MEMDATA11 RN58 MEMDATA1 C354 0.1u_X7R_04 MEMDATA15 8P4RX68_04 C286 0.1u_X7R_04 MEMDATA0 MEMDATA21 MEMDATA14 MEMDATA2 MEMDATA20 MEMDQS0 C615 0.1u_X7R_04 MEMDATA18 MEMWEB_L...

  • Page 67: Panel, Inverter, Fan

    Schematic Diagrams PANEL, INVERTER, FAN PANEL PANLE ID SELECTOR LVDS-L0N LVDS-L0N [12] LVDS-L0P LVDS-L0P [12] LVDS-L1N LVDS-L1N [12] PLVDD LVDS-L1P LVDS-L1P [12] LVDS-L2N 1.5A LVDS-L2N [12] LVDS-L2P LVDS-L2P [12] +3VS LVDS-LCLKN LVDS-LCLKN [12] C102 C544 LVDS-LCLKP LVDS-LCLKP [12] LVDS-U0N LVDS-U0N [12] JLCD1 0.1u_04 *10u_08...

  • Page 68: C15 Ht Cpu

    Schematic Diagrams C15 HT CPU +1.2V_HT [2,4,13] +3VS [2,6,8,11,12,13,14,15,16,17,19,20,21,23,24,26,27,29,30,31] +2.6VS [4,12,13,14,31] +1.2VPLL_PWR [11,12,13] U24F L0_CADOUT_H[15..0] L0_CADIN_H[15..0] L0_CADOUT_H[15..0] L0_CADIN_H[15..0] SEC 1 OF 6 L0_CADOUT_H0 L0_CADIN_H0 HT_CPU_RXD0_P HT_CPU_TXD0_P L0_CADOUT_H1 L0_CADIN_H1 HT_CPU_RXD1_P HT_CPU_TXD1_P L0_CADOUT_H2 L0_CADIN_H2 HT_CPU_RXD2_P HT_CPU_TXD2_P L0_CADOUT_H3 L0_CADIN_H3 HT_CPU_RXD3_P HT_CPU_TXD3_P L0_CADOUT_H4 L0_CADIN_H4 HT_CPU_RXD4_P HT_CPU_TXD4_P L0_CADOUT_H5...

  • Page 69: C51 Ht Mcp

    Schematic Diagrams C51 HT MCP +1.2VS [13,14,19,32] U24A HTMCP_DWN[7..0] HTMCP_DWN[7..0] [14] HTMCP_UP[7..0] SEC 2 OF 6 [14] HTMCP_UP[7..0] HTMCP_UP0 AC24 HTMCP_DWN0 HT_MCP_RXD0_P HT_MCP_TXD0_P HTMCP_UP1 AD23 HTMCP_DWN1 HT_MCP_RXD1_P HT_MCP_TXD1_P HTMCP_UP2 AC22 HTMCP_DWN2 HT_MCP_RXD2_P HT_MCP_TXD2_P HTMCP_UP3 AC20 HTMCP_DWN3 Sheet 10 of 44 HT_MCP_RXD3_P HT_MCP_TXD3_P HTMCP_UP4...

  • Page 70: C51 Pci Express

    Schematic Diagrams C51 PCI EXPRESS +3VS [2,6,8,12,13,14,15,16,17,19,20,21,23,24,26,27,29,30,31] +1.2VPLL_PWR [9,12,13] U24B SEC 3 OF 6 PE0_RX0_P PE0_TX0_P PE0_RX1_P PE0_TX1_P PE0_RX2_P PE0_TX2_P PE0_RX3_P PE0_TX3_P PE0_RX4_P PE0_TX4_P PE0_RX5_P PE0_TX5_P PE0_RX6_P PE0_TX6_P PE0_RX7_P PE0_TX7_P PE0_RX8_P PE0_TX8_P PE0_RX9_P PE0_TX9_P PE0_RX10_P PE0_TX10_P PE0_RX11_P PE0_TX11_P PE0_RX12_P PE0_TX12_P PE0_RX13_P PE0_TX13_P PE0_RX14_P...

  • Page 71: C51 Dac / Ifp

    Schematic Diagrams C51 DAC / IFP +3VS [2,6,8,11,13,14,15,16,17,19,20,21,23,24,26,27,29,30,31] +2.6VS [4,9,13,14,31] +1.2VPLL_PWR [9,11,13] U24C Change from D03A to D04 for EMI SEC 4 OF 6 C51M_RED-C_MUX LVDS-LCLKP HCB1608K-121T25 [26] C51_RED-C_MUX DAC_RED IFPA_TXC_P LVDS-LCLKP [8] C51M_GREEN-Y_MUX LVDS-LCLKN HCB1608K-121T25 [26] C51_GREEN-Y_MUX DAC_GREEN IFPA_TXC_N LVDS-LCLKN [8] HCB1608K-121T25 C51M_RLUE-PB_MUX...

  • Page 72: C51 Pwr / Gnd - Decoupling

    Schematic Diagrams C51 PWR / GND - DECOUPLING +2.6VS [4,9,12,14,31] +1.2VS [10,14,19,32] +1.2V_HT [2,4,9] +1.0VS_ADJ [34] +3VS [2,6,8,11,12,14,15,16,17,19,20,21,23,24,26,27,29,30,31] +1.2VS +1.2VPLL_PWR [9,11,12] *HCB2012K-121T30 +1.0VS_ADJ U24E Sheet 13 of 44 1P2VPEA_PWR SEC 5 OF 6 *HCB2012K-121T30 C528 +1.2V_CORE +1.2V_PEA C531 C532 +1.2V_CORE +1.2V_PEA C51 PWR / GND - 22u_12...

  • Page 73: Mcp51 Ht

    Schematic Diagrams MCP51 HT +1.5VS [16,17,19,31] +3VS [2,6,8,11,12,13,15,16,17,19,20,21,23,24,26,27,29,30,31] +1.2VS [10,13,19,32] +2.6VS [4,9,12,13,31] +2.6V [2,3,4,5,6,7,31,32] U32G BGA-508 Sheet 14 of 44 MCP51 HTMCP_DWN[7..0] SEC 1 OF 7 HTMCP_UP[7..0] [10] HTMCP_DWN[7..0] HTMCP_UP[7..0] [10] HTMCP_DWN0 HTMCP_UP0 HT_MCP_RXD0_P HT_MCP_TXD0_P HTMCP_DWN1 HTMCP_UP1 HT_MCP_RXD1_P HT_MCP_TXD1_P MCP51 HT HTMCP_DWN2 HTMCP_UP2 RESISTOR FOR 4X4 LINK...

  • Page 74: Mcp51 Pci

    Schematic Diagrams MCP51 PCI +3VS [2,6,8,11,12,13,14,16,17,19,20,21,23,24,26,27,29,30,31] +5VS [8,19,20,21,23,25,26,27,28,30,31] +3V [4,17,18,19,20,21,22,26,28,31,32,33] U32A BGA-508 PCI_AD[31..0] MCP51 [20,24,29] PCI_AD[31..0] SEC 2 OF 7 PCI_AD0 AF19 AA22 PCI_REQ0# PCI_AD0 PCI_REQ0* PCI_REQ0# [24] PCI_AD1 AB21 AE22 PCI_REQ1# PCI_AD1 PCI_REQ1* PCI_REQ1# [29] PCI_AD2 AC19 AF21 PCI_REQ2# PCI_AD2 PCI_REQ2* PCI_REQ2# [20]...

  • Page 75: Mcp51 Sata / Ide

    Schematic Diagrams MCP51 SATA / IDE +3VS [2,6,8,11,12,13,14,15,17,19,20,21,23,24,26,27,29,30,31] +1.5VS [14,17,19,31] +3.3V_PLL_SP_SS [17] U32B BGA-508 MCP51 SEC 3 OF 7 SATATXP0 Z1602 [21] SATATXP0 SATA_A0_TX_P IDE_DATA_P0 SATATXN0 Z1603 [21] SATATXN0 SATA_A0_TX_N IDE_DATA_P1 Z1604 IDE_DATA_P2 SATARXN0 Z1605 [21] SATARXN0 SATA_A0_RX_N IDE_DATA_P3 SATARXP0 Z1606 [21] SATARXP0...

  • Page 76: Mcp51 Audio / Usb / Misc

    Schematic Diagrams MCP51 AUDIO / USB / MISC RECOVERY HEADER +VDD5 [2,8,26,31,32,33,34,35] +3VS [2,6,8,11,12,13,14,15,16,19,20,21,23,24,26,27,29,30,31] +3V [4,15,18,19,20,21,22,26,28,31,32,33] R248 *10K_04 +VDD3 [8,18,31,35] R6G1 = 1K OHM NORMAL R555 *10K_04 +1.5VS [14,16,19,31] Z1712 R556 *10K_04 +5V [20,21,23,26,31] U32C AC_RST* BGA-508 R6G1 OPEN RECOVERY 1 = *RGMII AC_RST* SPDIF0...

  • Page 77: Mcp51 Rgmii

    C795 0.1u_04 10u_08 0.1u_X7R_04 0.1u_X7R_04 10u_08 0.1u_X7R_04 0.01u_04 C361 32.768KHz C377 Change from D03A to D04 for M540J +1.5V for M550J: +VDD3 +1.5V for M540J: OPEN U43,R603,R604,R605,C908,C909,C910,D52,D53 EMPTY U16,R194,R199,R200,C333,C331,C880 EMPTY *SCD34 *SCD34 +1.5V VREG @ 1.0 AMP MAX +1.5V *SC1565 1.5V_SP_A...

  • Page 78: Mcp51 Pwr / Gnd

    Schematic Diagrams MCP51 PWR / GND +1.2VS [10,13,14,32] +3V [4,15,17,18,20,21,22,26,28,31,32,33] +5VS [8,15,20,21,23,25,26,27,28,30,31] +3VS [2,6,8,11,12,13,14,15,16,17,20,21,23,24,26,27,29,30,31] +1.5V [18,31] +1.5VS [14,16,17,31] MCP51 BACKSIDE DECOUPLING +1.2VS BACKSIDE CAVITY +1.2VS +5VS +3VS C420 C407 C429 C416 C426 C425 C424 C430 C404 U32E +5VS BGA-508 22u_12 4.7u_08 1u_04 1u_04...

  • Page 79: Mini Pci, Usb2.0*2

    Schematic Diagrams MINI PCI, USB2.0*2 MINI PCI USB 2.0 +5VS +3VS +5VS +3VS JMPCI1 PCI_AD[31:0] [15,24,29] PCI_AD[31:0] +VCCUSB0 +VCCUSB0 VOUT VOUT C253 C136 C147 RT9701CBL C146 C157 0.1u_04 0.1u_04 10u_08 10u_08 0.1u_04 [23,25] WLAN_EN R154 0_04 PCI_INTA# [15,29] [15,29] PCI_INTB# Z2129 R155 *0_04...

  • Page 80: Sio, Sata Hdd, Cd-Rom

    Schematic Diagrams SIO, SATA HDD, CD-ROM CD-ROM MASTER +3VS R140 4.7K_04 +3VS SATA HDD IDE_SDD[15..0] [16] IDE_SDD[15..0] Place 0.01U caps at connector. JHDD1 JCD1 [27] CD_L CD_R [27] Z2204 C748 0.01u_04 SATATXP0 [16] [27] CD_G Z2205 C743 0.01u_04 CD_RESET# IDE_SDD8 SATATXN0 [16] R158 10K_04...

  • Page 81: Lan Rtl8201Cl

    Schematic Diagrams LAN RTL8201CL OUT 1.8V HCB2012K-121T30_0805 PWFBOUT PWFBIN C768 C791 C802 +A3V_LAN please close LF-H80P R513 1.5K_04 22u_12 0.1u_04 0.1u_04 Z2309 +A3V_LAN RGMII_MDC [18] RGMII_MDC PWFBOUT RGMII_MDIO [18] RGMII_MDIO MDIO AVDD33 RGMII_TXD0 HCB2012K-121T30_0805 [18] RGMII_TXD0 TXD0 RGMII_TXD1 [18] RGMII_TXD1 TXD1 RGMII_TXD2 0.1u_04...

  • Page 82: Fwh, Touchpad, Led

    Z2413 85201-0405 0.1u_04 [15,21,25] LPC_AD2 FWH2 22p_04 22p_04 FWH3 LPC_AD3 [15,21,25] 85201-1205 609-3211 SOCKET PLCC32 Sheet 23 of 44 FWH, TOUCHPAD, TOUCH PAD FOR M540J +5VH8 +5VH8 R309 R308 JTP_1 Z2415 +5VS *470 *470 TPBUTTON_R TPBUTTON_L Z2420 Z2421 Z2416 *TC031-AA1G-A160T...

  • Page 83: Ieee 1394 Vt6307S

    Schematic Diagrams IEEE 1394 VT6307S IEEE1394 +PVA_1394 +3VS PCI_AD[31:0] [15,20,29] PCI_AD[31:0] C738 C740 C754 C739 *10u_08 *0.1u_04 *0.1u_04 *0.1u_04 R512 PCI_AD31 PCI_AD31 PCI_AD30 *HCB1608K-121T25 *0_08 PCI_AD30 PCI_AD29 PCI_AD29 PCI_AD28 VT6307S PCI_AD28 +VCC_1394 PCI_AD27 PCI_AD27 PCI_AD26 PCI_AD26 PCI_AD25 PCI_AD25 PCI_AD24 PCI_AD24 PCI_AD23 C816 C749...

  • Page 84: H8/2111

    Schematic Diagrams H8/2111 VER. VOLTAGE H8_BAT0_TEMP C192 1u_04 +3VH8 +5VH8 +3VH8 +3VH8 +3VH8 V1.0 1.06V M540J +3VH8 H8_BAT0_V C195 1u_04 H8_MD1 V2.0 100K_1% 1.65V M550J H8_CURSEN C205 1u_04 C240 C201 C241 C242 C243 C580 C579 C578 V3.0 200K 2.20V R130...

  • Page 85: Mdc, Usb Bt, Pwrgd, Ddb Con

    Schematic Diagrams MDC, USB BT, PWRGD, DDB CON ALAZIA MDC JMDC PWRGD R540 R541 C366 C360 10K_04 10K_04 JMDC1 0.1u_04 1u_04 Z2706 RESERVED C851 Z2707 [17,27] AZ_SDOUT Azalia_SDO RESERVED [17,27] AZ_SYNC 3.3V Main/aux +VDD5 0.1u_04 R201 22_04 Azalia_SYNC Z2705 [17] AZ_SDIN1 Azalia_SDI [17,27]...

  • Page 86: Azalia Codec Alc880

    Schematic Diagrams AZALIA CODEC ALC880 +3VS AUD5V HCB1608K-121T25 C216 Z2801 680p C477 C475 C830 C808 C478 C469 C845 C484 C847 SURRB-R Z2831 JSPDIF1 FCM1608K-121T06 0.1u_04 10u_08 0.1u_04 0.1u_04 0.1u_04 0.1u_04 *10u_08 10u_08 0.1u_04 SPDIF/SURRB-L FCM1608K-121T06 Z2832 V_REFOUT AUDG C208 2SJ-S8701N13 SPDIF OUT R290 680p...

  • Page 87: Audio Amp, Usb2.0* 2

    H EAD PH ONE -L CP 5 R406 1 2K_0 4_1 % 8P4CX1 80p FOR M550J C 719 R4 20 M540J R406 = 10K_1% 6 80p 1K _04_ 1% JI NTM IC_1 5 AMPG AMP G PC BEEP JI NTMIC_1...

  • Page 88: Pcmcia Ene Cb714B

    Schematic Diagrams PCMCIA ENE CB714B CLOSE TO CARD SOCKET +VCC_CARD RN64 8P4RX47K SD_CMD R450 *0_04 MS_CLK [15,20] PCI_INTC# R451 0_04 Z3001 SD_CLKIN SD_D3 [15,20] PCI_INTA# PCM_MF1 SD_D2 VCCD1# [30] [15,20] PCI_INTB# VCCD0# [30] RN67 8P4RX47K [15,21,25] INT_SERIRQ VPPD1 [30] PCM_MF4 SD_D1 VPPD0 [30] PCM_MF5...

  • Page 89: Pcm Socket, 3-In-1 Socket

    3-IN-1 SOCKET [29] A_CD14 RFU/D14 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 [29] A_A18 RFU/A18 20216-0021 20216-0021A 3 IN 1 SOCKET SD/MMC/MS(Pro) Card Reader Power FOR M540J FOR M550J +3VS RN30 +5VS +3VS *8P4RX47K A_CCBE0# +AVCC A_CAD10 A_CAD11 JCARD-NOR1 JCARD-REV1 A_CRST# R294 SD_CD#...

  • Page 90: Sysyem Power, Bridge Batt

    Schematic Diagrams SYSYEM POWER, BRIDGE BATT +3VH8 AO3409 150mA Layout Note: +VIN +VINA If U21 is adjustable(G916T1UF). +3VS R116 So 165K_1% will be installed. R353 330K 10K_04 And C496 will be changed to 100K_1%. AM9433P INSTANT_SW [25] [25] PWR_SW# C889 R289 DDON L TO H +VDD5...

  • Page 91: V, +1.3V, +1.2V

    Schematic Diagrams +2.6V, +1.3V, +1.2V +2.6V,+1.3V 1118 +VDD5 R172 10K_04 +VDD5 C631 0.1u_X7R [31] SUSC 2N7002 R584 1SS355 C274 0_04 *0.1u_04 Z3301 Z3310 +VIN VDDQEN OCDDQ R166 C254 C255 C256 7.15K_1% +VDD5 R180 *100K_04 Z3303 Z3311 C266 10u/25V_12 10u/25V_12 0.1u VTTEN BOOST 0.1u...

  • Page 92: Vcore

    Schematic Diagrams +VCORE +2.6VS R581 R582 R583 R579 R580 Reserve For K8-M 1129 *10K_04 *10K_04 *10K_04 *10K_04 *10K_04 *SCS751V CPU_VID4 CPU_VID3 CPU_VID2 *SCS751V CPU_VID1 CPU_VID0 10K_04 10K_04 *SCS751V Z3437 Z3438 R590 R589 R592 R591 R588 *SCS751V 10K_04 10K_04 10K_04 10K_04 10K_04 2N3906 2N3906...

  • Page 93: Vs_Adj, +1.0V_Adj

    Schematic Diagrams +1.2VS_ADJ, +1.0V_ADJ +VIN 0.1u_04 +1.0VS_ADJ C486 0.1u_04 +VDD5 C509 C487 0.1u_04 R318 10u/25V_12 10u/25V_12 0.1u 0.01u_04 10K_04 GND_FIELD4 +VDD5 SCS551V 1.5M C492 +1.0VS_ADJ 10K_04 Z3514 Z3519 Z3505 [31,32] SUSB 2N7002 EN/PSV 0.1u RQA130N03 Z3501 Z3506 Z3507 JOPEN2 [31,32,33] TEST 2N7002 Z3502...

  • Page 94: Vdd3, +Vdd5, +Vdd12

    Schematic Diagrams +VDD3, +VDD5, +VDD12 +VDD3,+VDD5,+VDD12 +VIN1 +VIN +VIN R392 C695 10u_08 C699 C700 C696 C697 C648 C649 10u/25V_12 10u/25V_12 0.1u 0.01u_04 C694 C688 10u/25V_12 10u/25V_12 0.1u SCS551V 0.1u +VDD3 C698 LTC3728LX +VDD5 0.1u Z3601 C693 BOOST1 INTVCC Q83A 0.1u SP8K10 Z3602 Z3613...

  • Page 95: D/D Bd (Rgb & Tv Out Muxes

    Schematic Diagrams D/D BD (RGB & TV OUT MUXES) Change from D03A to D04 MBLU ML10 M_BLUE M_BLUE [37] MCRT1 ML11 M_VSYNC M_VSYNC [37] DS01A91-WL3-TR MID3 ML12 M_DDCACLK M_DDCACLK [37] MR23 M_RED MRED MD13 SCS355V M_GREEN Z4502 Z4503 M+3VS M_BLUE MGRN 1K_04_1% ML13...
  • Page 96 Schematic Diagrams D/D BD (CRT, S-VIDEO, RJ-11) M+3VS MGND M_VSYNC MDAC_VSYNC [36] M_VSYNC MDAC_VSYNC 74AHC1G125 MGND M+3VS MGND M_HSYNC MDAC_HSYNC [36] M_HSYNC MDAC_HSYNC 74AHC1G125 MGND M+3VH8 M+VCC_CCD MJCCD1 JCCD Sheet 37 of 44 MR58 MUSB_PN7 MUSB_PP7 10K_04 D/D BD (CRT, S- MAC_IN# MR63 MR64...

  • Page 97: D/D Bd (Charger, Dc In

    Schematic Diagrams D/D BD (CHARGER, DC IN) CHARGER M+VA M+VB AO4407 47uH_BCRH124 2.5A 2.5A MC79 MC82 MR44 100m_25 MD15 SM340A 15u/25V_D Z3809 15u/25V_D Z3810 Z3811 Z3812 MC73 MD21 MC72 MC48 MC44 MC43 DTA114EUA MD18 MR53 MJOPEN1 0.1u SM340A 0.1u 0.1u 0.1u 0.1u *OPEN...

  • Page 98: Audio Bd (Phone Jack, Usb

    PJR3 0_04 PJHEADPHONE-L Z3908 Z3910 PJMIC1 PJL6 FCM1608K-121T06 Z3913 PJL8 PJR5 FCM1608K-121T06 2SJ-S8701N13 PJC6 2SJ-S8701N13 HEADPHONE MIC IN PJC8 PJR2 680p FOR M540J=330 ohm (FRONT_OUT) (CENTER/SUB_W) 680p 1K_04 PJAUDG PJAUDG PJAUDG PJAUDG B - 40 AUDIO BD (PHONE JACK, USB)

  • Page 99: Hot Key Bd (Hot Key, Led

    Schematic Diagrams HOT KEY BD (HOT KEY, LED) FOR M540G PS+5VS PS+5VS PS+5VS PS+5VS POWER NUM LOCK CAPS LOCK SCROLL SWITCH LOCK PSR4 PSR1 PSR3 PSR2 LED8 LED4 LED5 LED6 PSD8 *KPC-3216QBC-C PSD4 *17-21VGC-TR8 PSD5 *17-21VGC-TR8 PSD6 *17-21VGC-TR8 Z4001 Z4002 PSNUM_LED Z4003 PSCAP_LED...

  • Page 100: Led Board

    Schematic Diagrams LED BOARD FOR M550J L+5VS L+5VS L+5VH8 L+5VH8 L+5VH8 Z4102 Z4103 Z4104 Z4101 WLAN/BT LPOWER_ON LACIN_SUSLED LBATT_FULL KPB-3025YSGC KPB-3025YSGC LBATT_CHARGE L+5VS LEMAIL_LED LWLAN_EN LBT_EN LHD_LED# LACIN_SUSLED LBT_EN LWLAN_EN Sheet 41 of 44 LPOWER_ON 85201-1205 LED BOARD LGND LD1,LD4,LD5 L+5VS L+5VS L+5VH8...

  • Page 101: Click Board

    Schematic Diagrams CLICK BOARD FOR M550J VENDOR PART NUMBER Synaptics E-LAN 800409-5102 CJTP Sheet 42 of 44 Z4201 CTPBUTTON_R CLICK BOARD CTPBUTTON_L CJTP Z4202 Z4203 Z4204 CTP_DATA C+5VS CGND CTP_CLK CGND 0.1u_04 CTP_CLK CTP_DATA 85201-0405 C+5VS 87151-1207 0.1u_04 CGND CSW1~2 CSW2 TC031-AA1G-A160T CSW1...

  • Page 102: Rj-45 Board

    Schematic Diagrams RJ-45 BOARD RJRJ-45 GND1 RMLMX4- shield GND2 RMLMX4+ shield RMLMX3- RMLMX3+ RJLAN RGND RMLMX2- RMLMX2+ RMLMX1- Sheet 43 of 44 RMLMX1+ RJ-45 BOARD C10091-108A4 SPUAZ-10S2-VB-040-1-R RGND RGND RJLAN C237D91 C237D107 RGND RGND B - 44 RJ-45 BOARD...

  • Page 103: Usb Dongle Board

    Schematic Diagrams USB DONGLE BOARD U+5VS Sheet 44 of 44 Z4401 Z4403 USB DONGLE *2N3906 *2N3906 BOARD UJUSB1 Z4402 *0.047u *0.047u Z4404 *1.5K Z4405 5075ARP-04-SM2-WH PIN GND1~2=UGND *2.2K *33K *33K *2.2K UGND UGND UGND UGND UGND USB DONGLE BOARD B - 45...
  • Page 104 Schematic Diagrams B - 46...
