Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 5: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 6: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 8: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply. If you are unsure of your local power specifications, consult Warning your service representative or local power company.
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 10: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 11: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 14: Lcd Screen Care
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 15: Table Of Contents
Preface Contents Notice .................I System Map: Right View ..........1-11 FCC Statement .............II System Map: Left View ..........1-12 Instructions for Care and Operation ......IV System Map: Bottom View ..........1-13 Power Safety .............. VI Windows Vista Start Menu & Control Panel ....1-14 Battery Precautions ...........VII Video Features .............1-15 Cleaning ..............
Page 16 Preface Install Instructions: ...........2-11 Drivers & Utilities Parallel Printer ............2-11 What to Install ..............4-1 Module Driver Installation ..........4-1 Power Management Driver Installation ............4-2 Overview ................3-1 Updating/Reinstalling Individual Drivers ....4-4 The Power Sources ............3-2 User Account Control (Win Vista) ......4-4 AC/DC Adapter ............3-2 Windows Security Message .........4-4 Battery .................3-2 Manual Driver Installation .........4-4...
Page 17 Preface BIOS Utilities Fixed disk boot sector: (Security Menu) ......5-11 TPM Support (Security Menu) ........5-11 Overview ................5-1 TPM State ..............5-12 The Power-On Self Test (POST) ........5-2 TPM Function (TPM State) .........5-12 Failing the POST ............5-3 Boot Menu ..............5-14 Fatal Errors ..............5-3 Exit Menu ..............5-15 Non-Fatal Errors ............5-3 The Setup Utility ............5-4...
Page 18 Preface PC Camera Driver Installation .........7-11 Interface (Ports & Jacks) Security Modules (TPM & Fingerprint) ......7-16 Overview ...............A-1 Trusted Platform Module ..........7-17 Ports and Jacks ..............A-2 Initializing TPM ............7-17 Card Reader ..............A-2 TPM Module Driver Installation ......7-19 TV Antenna Jack ............A-2 Initializing TPM ............7-20 Consumer Infrared Transceiver ........A-2 TPM Manager ............7-22...
Page 19 Preface Display Modes .............. B-7 Windows XP Information Enabling TV Display ..........B-10 DVD Regional Codes ...........D-2 Changing the TV Signal Format ....... B-11 Windows XP Start Menu & Control Panel ....D-3 Audio Features ..............D-4 Specifications Function/Hot Key Indicators ........D-5 Processor Types ............
Page 20 Preface Driver Installation ............D-21 MPC788/MPC718 Driver & Cyberlink PowerCinema In- Updating/Reinstalling Individual Drivers ....D-23 stallation ..............D-41 Chipset ................D-24 Video ................D-24 Audio ................D-24 Modem ................D-24 LAN ................D-24 Card Reader/ExpressCard ...........D-25 TouchPad ..............D-25 Hot Key ...............D-25 Module Drivers............D-25 Intel WLAN Module ........... D-26 Intel WLAN Driver Installation ........D-26 Bluetooth Module ............
Page 21: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 22: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 23: Model Differences
Quick Start Guide Model Differences This notebook series includes two different design types, however only one design is pictured in this manual. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.
Page 24: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, TV Tuner Module you will find the following operating systems are supported: Support Note that the TV Tuner module (factory) options...
Page 25: System Startup
Quick Start Guide System Startup 1. Remove all packing materials. Shutdown 2. Place the computer on a stable surface. 3. Securely attach any peripherals you want to use with the notebook (e.g. keyboard Note that you should and mouse) to their ports. always shut your com- 4.
Page 26: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open 1. Optional Built-In PC Wireless Device Camera Operation Aboard 2. LCD Aircraft 3. Hot Key Buttons 4. Power Button The use of any portable elec- tronic transmission devices 5.
Page 27: Led Indicators
Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Green The Computer is On Orange The Battery is Charging Blinking Blinking The Battery has Reached Critically Low The Computer is In Sleep Mode Green Orange...
Page 28: Hot Key Buttons & Keyboard
Quick Start Guide Hot Key Buttons & Keyboard Activate the Number Lock feature by pressing the Num Lk key at the top right of the keyboard. You may These buttons give instant access to the default Inter- check if Number Lock is enabled or not by looking at net browser and e-mail program, and to a user-defined the LED status indicators.
Page 29: Function/Hot Key Indicators
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is in- stalled (see “Hot Key Utility”...
Page 30: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front View 1. LCD Latches 2 3 4 5 2. Line-In Jack 3. Headphone-Out Jack 4. Microphone-In Jack 5. S/PDIF-Out Jack 6. LED Indicators 7. Infrared & Consumer Infrared Transceiver Overheating...
Page 31: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 5 Right View 1. Express Card Slot 2. 7-in-1 Card Reader 3. 2 * USB 2.0 Ports 4. Mini-IEEE 1394 Port 5. RJ-11 Phone Jack 6. RJ-45 LAN Jack 7. CATV Antenna Jack Mini-IEEE 1394 Port (Enabled With TV Tuner Only)
Page 32: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 6 Left View 1. Speaker 2. Security Lock Slot 3. Optional Device Drive Bay (for CD/DVD Device, see page Changing DVD Regional Codes CD/DVD Emergency Eject If you need to manually eject a CD/DVD Go to the Control Panel and double-click (e.g.
Page 33: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 7 Bottom View 1. Vent/Fan Intake/Out- 2. Battery 3. Optical Device Release Latches 4. Component Bay Cover 5. Infrared & Consumer Infrared Transceiver 6. Sub Woofer Battery Information Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial dis- charges.
Page 34: Windows Vista Start Menu & Control Panel
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 35: Video Features
Quick Start Guide Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appro- priate video driver is installed. For more detailed video information see “NVIDIA Video Driver Installation” on page B - To access Display Settings in Windows: 1.
Page 36: Display Devices & Options
Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display (con- nected to the DVI-Out port) or TV (connected to the S-Video-Out jack) as your display device. Figure 1 - 9 - Display Settings &...
Page 37: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 38 Quick Start Guide 1 - 18...
Page 39: Storage Devices, Mouse, Audio & Printer
Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • 7-in-1 Card Reader •...
Page 40: Hard Disk Drive
Storage Devices, Mouse, Audio & Printer Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 41: Optical Device
Storage Devices, Mouse, Audio & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...
Page 42: Handling Cds Or Dvds
Storage Devices, Mouse, Audio & Printer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 43: Dvd Regional Codes
Storage Devices, Mouse, Audio & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 44: 7-In-1 Card Reader
Storage Devices, Mouse, Audio & Printer 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 45: Expresscard Slot
Storage Devices, Mouse, Audio & Printer ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g.
Page 46: Application Hot Key
Storage Devices, Mouse, Audio & Printer Application Hot Key To configure a program to open when the application hot key button is pressed Application.exe (Windows Media Player is the default program), follow the instructions below. You will need to locate the actual application execut- Double-click the hot key driver icon in the taskbar.
Page 47: Touchpad And Buttons/Mouse
Storage Devices, Mouse, Audio & Printer TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 48: Audio Features
Storage Devices, Mouse, Audio & Printer Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
Page 49: Adding A Printer
Storage Devices, Mouse, Audio & Printer Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options.
Page 50 Storage Devices, Mouse, Audio & Printer 2 - 12...
Page 51: Power Management
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 52: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components (see page Attach the AC/DC adapter to the DC-In jack at the rear of the computer.
Page 53: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when it is pressed for less than 4 seconds (pressing and holding the power...
Page 54: Power Plans
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 55 Power Management Each Windows Power Plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.
Page 56: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.
Page 57: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 58: Configuring The Power Buttons
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.
Page 59: Resuming Operation
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color send the computer to...
Page 60: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.
Page 61: Conserving Battery Power
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 62: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
Page 63: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 64: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 65 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 66 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 67: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utili- Table 4 - 1, on page 4 - 3 lists what you need to install ties essential to the operation or improvement of some and it is very important that the drivers are in- of the computer’s subsystems.
Page 68: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the CD-ROM and click Install Drivers (button), or Op- Drivers Installer menu below.
Page 69 Drivers & Utilities Driver Page Driver Location Chipset Page 4 - 5 Vista 64bit: X:\drivers\00Chipset\Setup.exe Video Page 4 - 5 Vista 64bit: X:\drivers\01VGA\64bit\setup.exe Audio Page 4 - 5 Vista 64bit: X:\drivers\02Audio\Setup.exe Modem Page 4 - 5 Vista 64bit: X:\drivers\03Modem\ssetup.exe Card Reader/ExpressCard Page 4 - 5 Vista 64bit: X:\drivers\04CardReader\Setup.exe Page 4 - 6...
Page 70: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue/Al- this go to the Control Panel in the Windows OS and low, and follow the installation procedure as directed.
Page 71: New Hardware Found
Drivers & Utilities New Hardware Found Audio If you see the message “New Hardware Found” 1. Click 3. Install Audio Driver > Yes. (Found New Hardware Wizard) during the installa- 2. Click Next. tion procedure (other than when outlined in the 3.
Page 72: Lan
Drivers & Utilities Optional Drivers 1. Click 6.Install LAN Driver > Yes. See the pages indicated for the driver installation pro- cedures for any modules included in your purchase op- 2. Click Next > Install. tion. 3. Click Finish. TouchPad 1.
Page 73: Wireless Lan
Drivers & Utilities Wireless LAN Fingerprint Reader Module See the appropriate install procedure for your WLAN See the install procedure in “Fingerprint Reader module in “Intel WLAN Driver Installation” on Driver Installation” on page 7 - page 7 - Consumer Infrared & TV Tuner Bluetooth See the install procedure in “Mini-PCI TV Tuner...
Page 74 Drivers & Utilities 4 - 8...
Page 75: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.
Page 76: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 77: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 78: The Setup Utility
BIOS Utilities The Setup Utility The Phoenix Setup utility tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 on page 5 - 2 is usually present for a...
Page 79: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 80: Main Menu
BIOS Utilities Main Menu Phoenix TrustedCore(tm) Setup Utility Main Main Advanced Security TPM State Boot Exit Figure 5 - 2 Main Menu Item Specific Help System Time: [22:12:05] System Date: [05/25/2007] <Tab>, <Shift Tab>, or IDE Primary/Master [FUJITSU MHV2100BH PL-(S1)] <Enter>...
Page 81: Ide Primary/Master (Main Menu)
BIOS Utilities IDE Primary/Master (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a HDD on the com- puter’s IDE Primary/Master Channel. Use the Auto (Type:) setting to have the items configured automatically for you. IDE Secondary/Master (Main Menu) Pressing Enter opens the sub-menu to show the configuration of an optical Device on the computer’s IDE Channel 1.
Page 82: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Phoenix TrustedCore(tm) Setup Utility Advanced Menu Main Advanced Advanced Security TPM State Boot Exit Item Specific Help IO Device Configuration Peripheral Reset Configuration Data: [No] Configuration Legacy USB Support: [Enabled] Boot-time Diagnostic Screen: [Enabled] Power on Boot Beep [Disabled]...
Page 83: Reset Configuration Data: (Advanced Menu)
BIOS Utilities Reset Configuration Data: (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have in- stalled a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.
Page 84: Security Menu
BIOS Utilities Security Menu Phoenix TrustedCore(tm) Setup Utility Security Menu Main Advanced Security S S e e c c u u r r i i t t y y TPM State Boot Exit changes Item Specific Help Supervisor Password Is: Clear make here affect the Set Supervisor Password...
Page 85: Password On Boot: (Security Menu)
BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer (you may only set a password on boot if a supervisor password is enabled). If “Enabled” Password Warning is selected, only users who enter a correct password can boot the system (see the If you set a boot pass- warning in the sidebar).
Page 86: Tpm State
BIOS Utilities TPM State Phoenix TrustedCore(tm) Setup Utility TPM State Menu Main Advanced Security Boot Exit TPM State Item Specific Help To access this menu you must first enable TPM support from the Current TPM State: Enabled and Deactivated Changes TPM State security menu (see...
Page 87 BIOS Utilities If you have made any changes to the TPM State you will be asked to execute or reject the changes made after you have saved and exited the BIOS. Highlight the required option (it will be white), and then press Enter to save it. Phoenix TrustedCore(tm) Setup Utility Figure 5 - 6 Aded...
Page 88: Boot Menu
BIOS Utilities Boot Menu Phoenix TrustedCore(tm) Setup Utility Figure 5 - 7 Main Advanced Security TPM State Boot Exit Boot Menu Item Specific Help Boot priority order: USB KEY: Keys used to view or USB FDC: configure devices: USB CD: Optiarc CD-RW CRX880A-(SM) Up and Down arrows IDE HDD: FUJITSU MHV2100BH PL-(S1) select a device.
Page 89: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 8 Phoenix TrustedCore(tm) Setup Utility Main Advanced Security TPM State Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to Discard Changes CMOS.
Page 90 BIOS Utilities 5 - 16...
Page 91: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 92: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 93: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, turn it over and remove the battery. service representative Slide latch...
Page 94: Upgrading The Hard Disk Drive(S)
Upgrading The Computer Upgrading the Hard Disk Drive(s) The hard disk drive(s) can be taken out to accommodate other 2.5" serial (SATA) HDD System Warning hard disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3).
Page 95 Upgrading The Computer Remove the bay cover Figure 6 - 3 Bay Cover Removal Remove screws from the hard disk cover. Slide the hard disk assembly in the direction of the arrow Figure 6 - 4 Hard Disk Assembly Removal Upgrading the Hard Disk Drive(s) 6 - 5...
Page 96 Upgrading The Computer Carefully remove the hard disk assembly in the direction of the arrow Figure 6 - 5 HDD Removal Remove screws to separate the hard disk from the bracket. Reverse the process to install any new hard disk. Figure 6 - 6 HDD Bracket Screws...
Page 97: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDR II (DDR2) type memory modules (see “Memory” on page C - 2). The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 98 Upgrading The Computer Remove the bay cover Figure 6 - 8 Bay Cover Removal Contact Warning Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest Gently pull the two release latches ( & on the sides of the memory socket in hands have oils which the direction indicated by the arrows in...
Page 99 Upgrading The Computer The RAM module will pop-up, and you can remove it. Figure 6 - 10 RAM Module Removal Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory socket.
Page 100: Upgrading The Optical (Cd/Dvd) Device(S)
Upgrading The Computer Upgrading the Optical (CD/DVD) Device(s) Turn the computer off, turn it over and remove the battery. Slide the latch towards the unlock symbol and hold it in place. Slide latch (while still holding latch in place) in the direction indicated by the arrow in order to push the device out of the computer.
Page 101: Modules
Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 102: Wireless Lan Module
Modules Wireless LAN Module If you have included an Intel PRO/Wireless 4965AGNABG (802.11a/g/n) PCIe Wireless Device WLAN module in your purchase option, make sure that the Wireless LAN module Operation Aboard is on before installing the driver. Use the Fn + F11 key combination (see Table 1 - Aircraft 4, on page 1 -...
Page 103: Connecting To A Wireless Network
Modules Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 1 Taskbar Menus Click icon...
Page 104 Modules Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network). Figure 7 - 3 Connecting Move the cursor over the taskbar icon...
Page 105 Modules To disconnect from the wireless network you can click the taskbar wireless icon , and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make sure that any network you...
Page 106: Windows Mobility Center
Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 107: Bluetooth Module
Modules Bluetooth Module The optional Bluetooth module allows you to connect your computer to Bluetooth Wireless Device enabled devices such as other computers, desktop computers, mobile phones, print- Operation Aboard ers, digital cameras, PDAs, headsets etc. using a short-range radio frequency. Aircraft Make sure that the Bluetooth module is on.
Page 108 Modules User Guides & Help View BlueSoleil User Guides from the Help Menu (or press the F1 key) in the IVT Cor- poration BlueSoleil - Main Window control panel. Click the Help menu select Contents and Index. Look through Getting Started or select the ap- propriate User Guide from...
Page 109: Bluetooth Local Area Connection
Modules Bluetooth Local Area Connection You can check the Bluetooth connection status from the Network and Sharing Center: Disconnecting Use the Fn + F12 key combination to turn on the Bluetooth module. In order to have the Local Area Connection icon dis- Run the IVT Corporation BlueSoleil program from the desktop icon or Start menu.
Page 110 Modules Do not use the close button or Fn + F12 key combination before clicking File > Exit or the correct status will not be displayed. You can then use the Fn + F12 key combination to turn off the Bluetooth module (check the LED icon for the Bluetooth module power status).
Page 111: Pc Camera Module
Modules PC Camera Module Before installing the driver, make sure the PC Camera is on. Use the Fn + F10 key Latest PC Camera combination (see Table 1 - 4, on page 1 - 9) to toggle power to the PC Camera Driver Information module Make sure you install the drivers in the order indicated in Table 4 - 1, on...
Page 112 Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 113 Modules Figure 7 - 10 Audio Setup for PC Camera Right-click PC Camera Module 7 - 13...
Page 114 Modules BisonCap BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate process - see Set Capture File below).
Page 115 Modules Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 116: Security Modules (Tpm & Fingerprint)
Modules Security Modules (TPM & Fingerprint) The encrypted channel between the Trusted Platform Module security chip and Password Warning the optional fingerprint reader Protector Suite Software provides a high level of security for your computer. A further level of security and control is provided in the If you set passwords for BIOS (see “Security Menu”...
Page 117: Trusted Platform Module
Modules Trusted Platform Module Before setting up the TPM functions you must initialize the security platform. Initializing TPM Restart the computer. Enter the PhoenixBIOS Setup Utility by pressing F2 during the POST. Use the arrow keys to select the Security menu. Select TPM Support and set the item to Enabled.
Page 118 Modules Use the arrow keys to select the TPM State menu. Select TPM State, and set the item to Enable & Activate. Phoenix TrustedCore(tm) Setup Utility Figure 7 - 13 Main Advanced Security Boot Exit TPM State TPM State Item Specific Help Current TPM State: Enabled and Deactivated Changes TPM State...
Page 119: Tpm Module Driver Installation
Modules TPM Module Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. 2. Click Optional, and then click 4.Install TPM Utility > Yes. 3.
Page 120: Initializing Tpm
Modules Initializing TPM On the first run of the program you will need to initialize the TPM. Password Warning Run the application from the Security Manager shortcut on the desktop, or from the TPM Secure Tools item in the Start > Programs/All Programs menu. Do not lose the pass- If the Wizard does not appear click Initialize Owner, and then click Next.
Page 121 Modules Click Next. Type a TPM User Password, and then retype to confirm the password. Click Next > Next to begin the user initialization process. Click Finish. 10. Enter the user password and click Logon (click Logon in the top menu to log on at any time).
Page 122: Tpm Manager
Modules TPM Manager The TPM Manager allows you to manage and check the TPM state, manage your password information, and to backup and restore the TPM data. As TPM is usually Logon administered within large enterprises and organizations, your system administrator Make sure you have will need to assist you in managing the information in the TPM Manager.
Page 123 Modules Encrypting/Decrypting a File You can encrypt and decrypt files from the context menu in Windows. Right-click the file icon to bring up the context menu. Select File Encryption Tool. Select Encrypt/Decrypt. The file will then be encrypted/decrypted. Click OK. Figure 7 - 17 Encrypting/Decrypting a File...
Page 124 Modules Creating an Encrypted Virtual Disk You can create an encrypted virtual disk drive (an area of the hard disk you can hide and mount when required) from the Security Manager application. Run the application from the Security Manager shortcut on the desktop, or from the TPM Secure Tools item in the Start >...
Page 125 Modules Type in the Image File name, Volume Label, location (Browse to file location) and capacity in MB (maximum size is 1GB). Click OK. The disk will now be created. Click OK. Image File DO NOT lose the image file or you will be unable to mount Figure 7 - 19 the disk, and this may result...
Page 126 Modules Mounting and Removing an Encrypted Virtual Disk You can mount and remove the disk using the Security Manager application. Run the application from the Security Manager shortcut on the desktop, or from the TPM Secure Tools item in the Start > Programs/All Programs menu. Click Encryption Tools.
Page 127 Modules Mounting the disk will require the encrypted image file. If you click Disconnect you can hide the disk without the need to browse to the encrypted image file (simply click Connect to bring up disk again). Clicking Remove will clear the disk information from the menu (the data is still safe), and you will be required to Mount the disk again to access it (by accessing the encrypted image file).
Page 128 Modules Backing up a TPM Profile It is recommended that you backup your TPM profile and save it to a safe location (DO NOT save the file to a virtual disk). Run the application from the Security Manager shortcut on the desktop, or from the TPM Secure Tools item in the Start >...
Page 129: Fingerprint Reader Module
Modules Fingerprint Reader Module If you have included the fingerprint reader in your purchase option (for Model B computers only) you will need to install the driver as per the instructions below. Help & Manual Right-click the taskbar icon Make sure you have administrator’s rights to your computer, and have a Windows to bring up the menu to password enabled for full security protection.
Page 130: User Enrollment
Modules User Enrollment Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next (“Enrollment to the hard disk”...
Page 131 Modules Click Next for each window of the tutorial (you can click the button to “skip tutorial” at any time). Click the button above any of the fingers to begin the enrollment process for that Fingerprint finger. Enrollment 10. Swipe the finger three times to enroll that finger. 11.
Page 132 Modules 16. If you have not already initialized the TPM the computer will show the message “Invalid TPM status” after the restart . Figure 7 - 25 17. Click the message to start the TPM Initialization Wizard. TPM Invalid 18. Click Next. 19.
Page 133 Modules 20. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, Start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu.
Page 134: Mini-Pci Tv Tuner Module
Modules Mini-PCI TV Tuner Module A CD containing drivers, software and a user guide will be supplied if your purchase TV Antenna configuration includes the optional Mini-PCI TV Tuner module. In addition a driver is provided on the Device Drivers & Utilities + User’s Manual CD-ROM for the The TV antenna sup- plied with any TV Tuner remote control supplied with the TV Tuner.
Page 135: Consumer Infrared Remote Control Unit Driver
Modules Consumer Infrared Remote Control Unit Driver 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. TV Tuner Module 2. Click Optional, and then click 6.Install ITE CIR Driver > Yes. Support 3.
Page 136 Modules MPC718 Module 1. This TV Tuner module is fully supported by Windows Media Center in Windows Vista (Home Premium Edition & Ultimate Edition). Screen Rotation & 2. Run Windows Media Center directly from the Start menu (Start > Pro- TV Tuner Modules grams >...
Page 137: Digital Tv Broadcast Signal
Modules Digital TV Broadcast Signal The antenna is the most crucial factor in receiving a clear digital terrestrial TV broadcast signal. The passive antenna provided should provide a clear signal when CATV Cable Safety placed beside a window. If the signal is not clear then you can purchase an active Make sure that your antenna (it should also be placed beside a window) to improve the signal.
Page 138 Modules 7 - 38...
Page 139: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 140: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 141: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 142: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 143: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 144 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 145: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution The DVD regional codes The code has been changed the maximum 5 times. DVD region detection is device dependent, can no longer be not OS-dependent. You can select your module’s region code 5 times. The fifth selection is changed.
Page 146 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 147 Troubleshooting Problem Possible Cause - Solution Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk. The sound cannot be The volume might be set too low.
Page 148 Troubleshooting Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press a key on the the screen goes dark. keyboard, or press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.
Page 149: Screen Resolution Error
Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Manger) when the notebook lid (S3) is closed. TMM disconnects the LCD display from the OS and then adds the LCD display back when the lid is opened.
Page 150 Troubleshooting Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. Figure 8 - 2 - TMM Disable Close all the control panels. 8 - 12 Screen Resolution Error...
Page 151: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 152: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) RS MMC (requires PC adapter) SD (Secure Digital) Mini SD (requires PC adapter) MS (Memory Stick) MS Duo (requires PC adapter) MS (Memory Stick Pro) TV Antenna Jack...
Page 153: Headphone-Out Jack
Interface (Ports & Jacks) Item Description Headphone-Out Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. Infrared (FIR) The FIR (far infrared) transceiver at the front of the computer allows the computer to Transceiver communicate with similarly equipped devices (see “Adding a Printer”...
Page 154: Rj-11 Phone Jack
Interface (Ports & Jacks) Item Description RJ-11 Phone Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. RJ-45 LAN Jack This port supports LAN (Network) functions.
Page 155: Usb 2.0/1.1 Ports
Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power supply which comes with the device).
Page 156 Interface (Ports & Jacks) A - 6...
Page 157: Nvidia Video Driver Controls
NVIDIA Video Driver Controls Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Resolution Error NVIDIA Video Driver Installation If you are experiencing screen resolution prob- Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - lems/screen flickering after resuming from Sleep in...
Page 158: Nvidia Control Panel
NVIDIA Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Open the Display Settings (see page 16) control panel. To access the Ge- Click Advanced Settings (button). Force..
Page 159 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allows quick access to features such as display configuration, 3D Set- tings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 160 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure B - 3 Help Menus B - 4 NVIDIA Control Panel...
Page 161: Attaching Other Displays
NVIDIA Video Driver Controls Attaching Other Displays Configuring an External Display in Windows Vista Display Devices Attach your external display to the external monitor port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Besides built-in Windows Mobility Center control panel (Mobile PC >...
Page 162 NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel Attach your external display to the external monitor port and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel” on page B - Function Key Click Display, and then click Change Display configuration.
Page 163: Display Modes
NVIDIA Video Driver Controls Display Modes Single Display Mode Resolution Error Only one of your displays is used. If you are experiencing screen resolution prob- Clone Mode lems/screen flickering after Clone Mode simply shows an exact copy of the Primary display desktop on the other resuming from Sleep in Windows Vista see page display(s).
Page 164 NVIDIA Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the external monitor port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 165 NVIDIA Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the external monitor port and turn it on. Click Start, and click Control Panel (or point to Settings and click Control Display Settings Panel). Extended Desktop Click Adjust screen resolution under the Appearance and Personalization menu (or double-click Personalization >...
Page 166: Enabling Tv Display
NVIDIA Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an Detect Displays S-Video cable from the TV to the 7-pin S-Video-Out jack at the rear of the computer. To get a full range of dis- You will need to enable the TV display from the NVIDIA Control Panel as per the play options click...
Page 167: Changing The Tv Signal Format
NVIDIA Video Driver Controls Changing the TV Signal Format When the TV is selected as a display device, click the home icon to return to the category menu. Click Video and Television, and then click “Change the signal or HD format” Select the TV signal format (the menu allows you to select TV format by country if you are unsure of your TV format).
Page 168 NVIDIA Video Driver Controls B - 12...
Page 169: Specifications
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 170: Processor Types
Specifications Feature Specification Processor Types Intel® Core™2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package, Socket P 2MB On-die L2 Cache & 800MHz FSB T7100 1.80 GHz Intel® Core™2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package, Socket P 4MB On-die L2 Cache &...
Page 171: Video Adapter Options
Specifications Feature Specification Video Adapter NVIDIA GeForceGo 7950 Options G71GM-UU Modular 512MB DDR3 Video Ram On Board PCI-Express * 16 MS DirectX® 9.0 compatible Video Card Options MXM-IV Note that card types, specifications and drivers are subject to continual updates and changes. NVIDIA GeForce 8700M GT Check with your service center for the latest de- NB8E-SE Modular...
Page 172: Audio
Specifications Feature Specification Audio Intel® High Definition Audio Interface (HDA) S/PDIF Digital Output 7.1CH 3D Stereo Enhanced Sound System Built-In Microphone SRS WOW Surround Sound Technology 3 * Built-In Speakers Ω Ω Inside (Two 1.5W, 8 , One Sub Woofer 1.5W 8 Sound-Blaster PRO™...
Page 173: Communication
Specifications Feature Specification Communication Built-In 56K MDC Modem with V.90 & V.92 TV Tuner Module (Hybrid OR Windows MCE Compliant options) with Mini-PCI Interface (Factory Option) Built-In Gigabit Ethernet LAN Bluetooth 2.0 + EDR (Enhanced Data Rate) Module (Factory Option) Wireless LAN Module: Intel®...
Page 174: Optional
Specifications Feature Specification Optional Optical Drive Module Options: TV Tuner Module Options: DVD/CD-RW Combo Drive Module (All Factory Options): DVD-Super Multi Drive Module Hybrid (Digital & Analog) TV Tuner Module with Mini-PCI Interface Intel® Wireless LAN WiFi Link 4965AGN with MiniCard, PCIe Interface MCE TV Tuner Module with Mini-PCI Interface for Windows Vista/XP Media Center Edition...
Page 175: Windows Xp Information
Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. • DVD Regional Codes • Windows XP Start Menu & Control Panel • Audio Features •...
Page 176 Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Page 177: Windows Xp Start Menu & Control Panel
Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 178: Audio Features
Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel. For advanced options double-click the Realtek Adjustment HD Audio Manager icon in the taskbar (or click the control panel) to bring up How high the sound vol- the Realtek Audio Configuration menus.
Page 179: Function/Hot Key Indicators
Windows XP Information Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is in- stalled (see “Hot Key”...
Page 180: Application Hot Key
Windows XP Information Application Hot Key To configure a program to open when the application hot key button is pressed (Windows Media Player is the default program), follow the instructions below. Application.exe You will need to locate the 1. Double-click the Hot Key driver icon in the taskbar.
Page 181: Video Features
Windows XP Information Video Features You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is installed. To access Display Properties in Windows: 1. Click Start, point to Settings and click Control Panel (or just click Control Panel). 2.
Page 182: Display Properties
Windows XP Information Display Properties Figure D - 5 - Display & Additional Properties Video Card Options Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest details on video cards supported. The items listed in the Additional Properties window allow you to configure your display(s).
Page 183: Display Devices & Options
Windows XP Information Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as your display device. A VGA monitor/Flat Panel Display connects to the DVI-Out port or external monitor port;...
Page 184: Attaching Other Displays
Windows XP Information Attaching Other Displays 1. Attach your external display to the external monitor port/DVI-Out Port (or TV to the S- Video-Out jack), and turn it on. Device Settings 2. Go to the Additional Properties in the GeForce..Properties control panel tab. Click the display icon to 3.
Page 185 Windows XP Information 6. Select the display option from the Primary Display/ Secondary Display dropbox. If you have a TV and external monitor/flat panel display attached you will have a number of available options. Select and Apply the appropriate option. nView Display Mode Options The display options list-...
Page 186: To Enable Extended Desktop
Windows XP Information To Enable Extended Desktop Attach your external monitor to the external monitor port and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes). Double-click Display (icon).
Page 187: Power Management Features
Windows XP Information Power Management Features The Power Options control panel icon in Windows (see page 3) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk, or you may use either Stand by or Hibernate mode to conserve power throughout the system.
Page 188: System Power Options
Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.
Page 189: Stand By
Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memory.
Page 190: Configuring The Power Button
Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hibernate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery). If you are in a power saving mode set to save power through individual components (e.g.
Page 191: Battery Information
Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page D - 20). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and pe- ripheral devices attached.
Page 192: Recharging The Battery With The Ac/Dc Adapter
Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason “Removing the Battery”...
Page 193: Proper Handling Of The Battery Pack
Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.
Page 194: Battery Faq
Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 195: Driver Installation
Windows XP Information Driver Installation Check the driver installation order from Table D - 4, on page D - 22 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the Drivers Installer menu below.
Page 196 Windows XP Information WinXP SP2 Driver Page # Manual Driver Path Notes Manual Driver D - 24 X:\Drivers\00Chipset\Setup.exe Chipset Installation D - 24 X:\Drivers\01VGA\setup.exe Video If you wish to install the drivers D - 24 X:\Drivers\02Audio\Setup.exe Audio manually, click the Exit button to quit the Drivers Installer D - 24 X:\Drivers\03Modem\ssetup.exe...
Page 197: Updating/Reinstalling Individual Drivers
Windows XP Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do Windows XP Service Pack 2 this go to the Control Panel in the Windows OS and Make sure you install Windows XP Service Pack 2 (or a double-click the Add/Remove Programs item.
Page 198: Stallation
Windows XP Information Chipset Modem 1. Click 1.Install Chipset Driver > Yes. 1. Click 4.Install Modem Driver > Yes. 2. Click Next > Yes > Next > Next. 2. Click OK. 3. Click Finish to restart the computer. 3. The modem is now ready for configuration. Video 1.
Page 199: Card Reader/Expresscard
Windows XP Information Card Reader/ExpressCard Module Drivers 1. Click 6.Install CardReader Driver > Yes. See the following pages for the driver installation pro- cedures for any of the optional modules included in 2. Click Next > Next. your purchase configuration. 3.
Page 200: Intel Wlan Module
Windows XP Information Intel WLAN Module Before installing the Wireless LAN driver use the Fn + F11 key combination to toggle power to the module . Intel WLAN Driver Installation 1. Make sure the module is powered on (use the Fn + F11 key combination to toggle power to the mod- ule), and then insert the Device Drivers &...
Page 201 Windows XP Information User Guide You can view the User Guides from the Device Drivers & Utilities + Us- er’s Manual CD-ROM (WinXP). Click Optional > Yes and then click the Unlock but- ton. Click 1.Wireless Lan > Yes. Click View User Guide (button).
Page 202: Bluetooth Module
Windows XP Information Bluetooth Module Before installing the Bluetooth driver use the Fn + F12 key combination to toggle power to the module . Bluetooth Driver Installation 1. Make sure the module is powered on and then insert the Device Drivers & Utilities + User’s Manual CD-ROM (WinXP) into the CD/DVD drive.
Page 203 Windows XP Information User Guide View the BlueSoleil User Guides (Contents and In- dex) from the Help menu (or press the F1 key) in Corporation BlueSoleil - Main Win- dow control panel. Click BlueSoleil User Guides in the Contents tab, and click to select the appro- priate User Guide from the panel on the right.
Page 204 Windows XP Information Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: Disconnecting 1.Access the Network Connections control panel in Windows (Start > Settings > Net- In order to have the taskbar work Connections OR Start >...
Page 205 Windows XP Information Use the Fn + F12 key combination to turn on the Bluetooth module. Run the IVT Corporation BlueSoleil program from the desktop icon or Start menu. The connection status will then be displayed. Figure D - 18 - Bluetooth Connected To disconnect click File from the IVT Corporation BlueSoleil - Main Window, and select Exit (the Local Area Connection will then display “A network cable is unplugged”).
Page 206: D - 32 Pc Camera Module
Windows XP Information PC Camera Module Before installing the optional PC Camera module driver use the Fn + F10 key com- Taking Still Pictures bination to toggle power to the module. Double-click PC Camera Driver Installation Computer icon on the 1.
Page 207 Windows XP Information PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double- click the Sounds &...
Page 208 Windows XP Information BisonCap BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space 1. Run the BisonCap application from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate the process - see Set Capture File below).
Page 209 Windows XP Information Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap application. Go to Options and scroll down to select “Video Capture Filter...”. Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 210: Tpm Security Chip
Windows XP Information TPM Security Chip If you have included the Trusted Platform Module security chip module in your purchase option, you will have the appropriate software provided on the Device Drivers & Utilities + User’s Manual CD-ROM (WinXP). After installing the driver as per the instructions below, see “Trusted Platform Module”...
Page 211: Initializing Tpm
Windows XP Information Initializing TPM On the first run of the program you will need to initialize the TPM. Password Warning Run the application from the Security Manager shortcut on the desktop, or from the TPM Secure Tools item in the Start > Programs/All Programs menu. Do not lose the pass- Click Next.
Page 212: Fingerprint Reader
Windows XP Information Fingerprint Reader If you have included the fingerprint reader in your purchase option you will need to Help & Manual install the driver as per the instructions below. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security pro- Right-click the taskbar icon tection.
Page 213: User Enrollment
Windows XP Information User Enrollment Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next (“Enrollment to the biometric device”...
Page 214 Windows XP Information 10. Click Finish. 11. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu.
Page 215: Mini-Pci Tv Tuner Module
Windows XP Information Mini-PCI TV Tuner Module The Mini-PCI TV Tuner Module driver and Cyberlink PowerCinema application are provided on a separate CD- ROM for Windows XP (see “Mini-PCI TV Tuner Module” on page 7 - 34 for further information). In addition a driver is provided on the Device Drivers &...
Page 216 Windows XP Information 7. Click Next > Yes. 8. Type in the Cyberlink PowerCinema CD Key provided (make sure you also input a User and Com- pany Name), and then click Next. 9. Click Next > Next > Next > Finish. 10.

Clevo M570RU User Manual

Quick Start Guide

Storage Devices, Mouse, Audio & Printer

Power Management

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules

Troubleshooting

Interface (Ports & Jacks)

NVIDIA Video Driver Controls

Specifications

Windows XP Information

Quick Links

Related Manuals for Clevo M570RU

Summary of Contents for Clevo M570RU
