- Page 3 Preface Notebook Computer M550G/M540G Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
-
Page 5: About This Manual
This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M550G/ M540G series notebook PC. -
Page 6: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. -
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 8: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. -
Page 10: Related Documents
Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII... -
Page 11: Table Of Contents
DVD-ROM Drive (M550G/M540G) ..........A-6 External Locator - Bottom View .............1-8 Combo Drive (M550G/M540G) ........... A-7 M550G Mainboard Overview - Top (Key Parts) ......1-9 DVD-RW Drive (M550G/M540G) ..........A-8 M550G Mainboard Overview - Bottom (Key Parts) ....1-10 HDD (M550G) ................A-9 M550G Mainboard Overview - Top (Connectors) .......1-11... - Page 12 Preface MINI PCI, USB2.0* 2 ..............B-17 HDD, CD-ROM, SATA COM ............. B-18 LAN RTL8110SBL/RTL8100CL ..........B-19 FWH, TOUCH PAD, LED ............B-20 IEEE 1394 VT6307S ..............B-21 H8/2111 ..................B-22 MDC, USB BT, PWRGD, DDB CON ......... B-23 AZALIA CODEC ALC880 ............B-24 AUDIO AMP, USB2.0* 2 ............
-
Page 13: Introduction
Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M550G/M540G series notebook computer. In- formation about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer. -
Page 14: System Specifications
Security Security (Kensington® Type) Lock Slot BIOS Password BIOS One 4MB Flash ROM Phoenix™ BIOS, Plug and Play M550G: M540G: 15.0" XGA (1024*768) Flat Panel TFT 14.0" WXGA (1280*768) Flat Panel TFT Video Memory 15.0" SXGA+ (1400*1050) Flat Panel TFT... - Page 15 Introduction Feature Specification Audio Integrated AZALIA Compliant Interface (HDA) 3D Stereo Enhanced Sound System Sound-Blaster PRO™ Compatible 2 * Built-In Speakers Built-In Microphone Keyboard & Winkey Keyboard Built-In TouchPad with Scrolling Function Pointing Device PCMCIA One Type-II PCMCIA CardBus PC Card Slot Interface Four USB 2.0 Ports One RJ-11 Jack for Plug &...
- Page 16 Port Replicator (10/100 Base-T Ethernet Port, 4 * USB 2.0 Ports, Serial Port, Parallel Port, External Monitor Port, (Factory Option) Swap Battery - 2 ~ 3 Minutes Swap DC-In Jack) Time (M550G only) (Note: Port Replicator requires the supplied 90W power adapter) 1 - 4 System Specifications...
-
Page 17: External Locator - Top View With Lcd Panel Open
3. LED Power & Communication Indicators 4. Speakers 5. LED Status Indicators 6. Power Button 7. Keyboard 8. Built-In Microphone 9. TouchPad and Buttons 10. AP-Key Buttons M550G M540G External Locator - Top View with LCD Panel Open 1 - 5... -
Page 18: External Locator - Front & Right Side Views
Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power & Communication Indicators 2. LCD Latch (M550G Only) M550G 3. 4-in-1 Card Reader (M540G Only) M540G Figure 3 Right Side Views Headphone-Out Jack Microphone-In Jack 2 * USB 2.0 Ports... -
Page 19: External Locator - Left Side & Rear View
2. Vent/Fan Intake 3. 2 * USB 2.0 Ports 4. S/PDIF-Out Jack 5. Line-In Jack 6. Mini-IEEE 1394 Port 7. PC Card Slot 8. 4-in-1 Card Reader (M550G M540G Only) Figure 5 Rear View 1. External Monitor Port S-Video-Out Port... -
Page 20: External Locator - Bottom View
External Locator - Bottom View Figure 6 Bottom View M550G Vent/Fan Intake Battery Memory (RAM)/ WLAN Module/ CPU Cover Hard Disk Cover Speakers (M550G Only) M540G Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use. -
Page 21: M550G Mainboard Overview - Top (Key Parts)
Introduction M550G Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. PC Card Assembly 2. H8/211 3. Clock Generator 4. Audio Amp. 5. ALC880 Audio Codec M550G Mainboard Overview - Top (Key Parts) 1 - 9... -
Page 22: M550G Mainboard Overview - Bottom (Key Parts)
4. Memory Slots DDR2 So-DIMM 5. Southbridge-Intel ICH6-M 6. ENE PCMCIA & Card Card Control 7. VIA 1394 8. RTL811 OSBL 10/100/1000 LAN 9. Card Reader Socket 10. Northbridge-Intel 915GM 1 - 10 M550G Mainboard Overview - Bottom (Key Parts) -
Page 23: M550G Mainboard Overview - Top (Connectors)
M550G Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. PCMCIA Socket 2. Keyboard 3. Hot key board Connector 4. USB Port 5. S/PDIF-Out Jack 6. Line-In Jack 7. Mini-IEEE 1394 M550G Mainboard Overview - Top (Connectors) 1 - 11... -
Page 24: M550G Mainboard Overview - Bottom (Connectors)
7. Touch Pad Connector 8. CMOS Bat. Connector 9. Microphone Cable Connector 10. LCD Connector 11. LED Board Connector 12. Bridge Bat. Connector 13. LAN Board Connector 14. Fan CPU Cable Connector 1 - 12 M550G Mainboard Overview - Bottom (Connectors) -
Page 25: M540G Mainboard Overview - Top (Key Parts)
Introduction M540G Mainboard Overview - Top (Key Parts) Figure 11 Mainboard Top Key Parts 1. PC Card Assembly 2. H8/211 3. Clock Generator 4. Audio Amp. 5. ALC880 Audio Codec M540G Mainboard Overview - Top (Key Parts) 1 - 13... -
Page 26: M540G Mainboard Overview - Bottom (Key Parts)
Introduction M540G Mainboard Overview - Bottom (Key Parts) Figure 12 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Flash BIOS ROM 3. Mini-PCI (Wireless Lan Module) Connector 4. Memory Slots DDR2 So-DIMM 5. Southbridge-Intel ICH6-M 6. ENE PCMCIA & Card Card Control 7. -
Page 27: M540G Mainboard Overview - Top (Connectors)
Introduction M540G Mainboard Overview - Top (Connectors) Figure 13 Mainboard Top Connectors 1. PCMCIA Socket 2. Card Reader Socket 3. Keyboard 4. Hot key board Connector 5. Touch Pad Connector 6. USB Port 7. S/PDIF-Out Jack 8. Line-In Jack 9. Mini-IEEE 1394 M540G Mainboard Overview - Top (Connectors) 1 - 15... -
Page 28: M540G Mainboard Overview - Bottom (Connectors)
Introduction M540G Mainboard Overview - Bottom (Connectors) Figure 14 Mainboard Bottom Connectors 1. Inventer Board Connector 2. Speaker Connector 3. CCD Cable Connector 4. Audio Board Connector 5. BT Connector 6. Modem Module Connector 7. CMOS Bat. Connector 8. Microphone Cable Connector 9. -
Page 29: Disassembly
Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M550G/M540G series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. -
Page 30: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 31: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 32: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Keyboard: 1. Remove the battery page 2 - 5 1. -
Page 33: Removing The Battery
Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Locate the battery bay at point (Figure 1a). Battery Removal 3. Slide the latch in the direction of the arrow, and hold it in place. 4. -
Page 34: Removing The Hard Disk Drive
You have backed up any data you want to keep from your old HDD. You have all the CD-ROMs and FDDs required to install your operating system and programs. • 1 Screw (M550G) • 2 Screws If you have access to the internet, download the latest application and hardware driver updates for the operating system you plan (M540G) to install. - Page 35 ,and reverse the process to install any new hard disk. M540G M540G 6. HDD Aseembly 15. HDD 16. HDD Case • 4 Screws (M550G) • 2 Screws (M540G) Removing the Hard Disk Drive 2 - 7...
-
Page 36: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 4 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the HDD bay cover (page 2 - Module Removal 2. Carefully disconnect cable , then gently pull the two release latches ( ) on the sides of the module socket. -
Page 37: Removing The System Memory (Ram)
Memory Upgrade Process 1. Turn off the computer, remove the battery (page 2 - 2. Locate the RAM bay cover , and remove screws (for M550G) OR screws (for M540G). 3. Remove the bay cover Contact Warning Be careful not to touch the metal pins on the module’s... - Page 38 Disassembly 4. Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the Figure 6 arrows (Figure 7a). Memory Removal 5. The RAM module(s) will pop-up Figure 7b , and you can then remove it Sequence a.
-
Page 39: Removing The Optical (Cd/Dvd) Device
(page 2 - Removal 2. Locate the RAM bay cover , and remove screws (for M550G) OR screws (for M540G). 3. Remove the bay cover a. Remove the screws. 4. Use a screwdriver to carefully push out the optical device at point b. -
Page 40: Removing The Processor
1. Turn off the computer, and remove the battery (page 2 - Processor Removal 2. Locate the CPU bay cover , and remove screws (for M550G) OR screws (for M540G). 3. Carefully lift up the CPU cover off the computer. a. Remove the screws. - Page 41 Disassembly 6. Turn the release latch towards the unlock symbol , to release the CPU (Figure 9a). 7. Carefully (it may be hot) lift the CPU up out of the socket (Figure 9b). 8. Reverse the process to install a new CPU. 9.
-
Page 42: Removing The Keyboard
Re-Inserting the Key- board When re-inserting the keyboard firstly align the five keyboard tabs at the bottom of the keyboard with the slots in the case. 4. Keyboard M540G M550G 2 - 14 Removing the Keyboard... -
Page 43: Removing The Modem And Bluetooth Module
Disassembly Removing the Modem and Bluetooth Module For M540G computers: Figure 11 1. Turn off the computer, remove the battery (page 2 - 5), the optical device (page 2 - 11), the hard disk drive (page Modem and 6) and the RAM bay cover(page 2 - Bluetooth Removal 2. - Page 44 Remove the screw and disconnect the cables from the Bluetooth mod- ule. g. Lift the Bluetooth module out. 22. Bottom case 26. Modem module 30. Bluetooth module • 23 Screws (M550G) 2 - 16 Removing the Modem and Bluetooth Module...
-
Page 45: Part Lists
Part Lists Appendix A:Part Lists This appendix breaks down the M550G/M540G series notebook’s construction into a series of illustrations. The compo- nent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 46: Part List Illustration Location
A - 4 Bottom - (M550G) page A - 5 LCD - (M550G) page A - 6 DVD-ROM Drive - (M550G/M540G) page A - 7 Combo Drive - (M550G/M540G) page A - 8 DVD-RW Drive - (M550G/M540G) page A - 9... -
Page 47: Top (M550G
Part Lists Top (M550G) 鐵弗龍 無鉛 無鉛 鐵弗龍 無鉛 無鉛 Figure A - 1 Top (M550G) 無鉛 背膠 無鉛 鋁箔 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 無鉛 無鉛 無鉛 無鉛 Top (M550G) A - 3... -
Page 48: Bottom (M550G
Part Lists Bottom (M550G) Figure A - 2 Bottom (M550G) 加百裕 外 外 外 鎂鋁 M550G 無鉛 無鉛 鎂鋁 M550G 無鉛 無鉛 無鉛 無鉛 元力 M550G 無鉛 無鉛 無鉛 無鉛 無鉛 A - 4 Bottom (M550G) -
Page 49: Lcd (M550G
Part Lists LCD (M550G) Figure A - 3 LCD (M550G) 直徑6.3X3.6H 無鉛 無鉛 無鉛 磁鐵 無鉛 惠貿 無鉛 無鉛 無鉛 無鉛 鐵弗龍 無鉛 無鉛 中性 無鉛 LCD (M550G) A - 5... -
Page 50: Dvd-Rom Drive (M550G/M540G
Part Lists DVD-ROM Drive (M550G/M540G) Figure A - 4 DVD-ROM Drive (M550G/M540G) A - 6 DVD-ROM Drive (M550G/M540G) -
Page 51: Combo Drive (M550G/M540G
Part Lists Combo Drive (M550G/M540G) Figure A - 5 Combo Drive (M550G/M540G) Combo Drive (M550G/M540G) A - 7... -
Page 52: Dvd-Rw Drive (M550G/M540G
Part Lists DVD-RW Drive (M550G/M540G) Figure A - 6 DVD-RW Drive (M550G/M540G) A - 8 DVD-RW Drive (M550G/M540G) -
Page 53: Hdd (M550G
Part Lists HDD (M550G) Figure A - 7 HDD (M550G) HDD (M550G) A - 9... -
Page 54: Top (M540G
Part Lists Top (M540G) 無鉛 無鉛 無鉛 Figure A - 8 Top (M540G) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 無鉛 無鉛 無鉛 石墨 無鉛 邁智 無鉛 無鉛 A - 10 Top (M540G) -
Page 55: Bottom (M540G
Part Lists Bottom (M540G) Figure A - 9 Bottom (M540G) 外 加百裕 外 外 昆山 無鉛 無鉛 無鉛 無鉛 元力 無鉛 Bottom (M540G) A - 11... -
Page 56: Lcd (M540G
Part Lists LCD (M540G) Figure A - 10 LCD (M540G) 平頭 圓頭 無鉛 無鉛 無鉛 無鉛 頭徑3.5MM 頭厚0.3MM 無鉛 無鉛 無鉛 中性 無鉛 無鉛 MAGNET(磁鐵)16*5*3(秀越 )表面 處理 ;NI-PLATED 磁力等 LCD FRONT COVER MAGNET MYLAR ,MYALR M550G A - 12... -
Page 57: Hdd (M540G
Part Lists HDD (M540G) Figure A - 11 HDD(M540G) HDD (M540G) A - 13... - Page 58 Part Lists A - 14 HDD (M540G)
- Page 59 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the M550G/M540G notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table B - 1 Diagram - Page Diagram - Page Diagram - Page Schematic...
-
Page 60: Schematic Diagrams
Schematic Diagrams System Block Diagram CLEVO M540G/M550G System Block Diagram D/D BOARD 1.+3V,+5V,+12V 1.CHARGER,DC JACK 2.+1.5VS,+3VS,+5VS,+12VS CLOCK GEN. 2.CRT,S-VIDEO,RI-11 MEMORY TERMINATIONS 3.+3VH8,+5VH8 3.+VDD3,+VDD5,+VDD12 ICS954226 PROCESSOR DDR VR 1.+1.8V,+1.5V,+0.9V AUDIO BOARD DDR2 SDRAM SOCKET SOCKET 1.AUDIO PHONE JACK 479 uFCPGA 2.USB CONNECTOR 1.+VCORE... -
Page 61: Dothan 1/2
Schematic Diagrams DOTHAN 1/2 JSKT1B H_D#[63:0] H_D#[63:0] [4] H_D#0 H_D#32 D32# H_D#1 AA24 H_D#33 D33# JSKT1A H_D#2 H_D#34 H_A#[31:3] D34# H_A#3 H_D#3 H_D#35 ADS# H_ADS# [4] D35# H_A#4 H_D#4 H_D#36 BNR# H_BNR# [4] D36# H_A#5 H_D#5 H_D#37 BPRI# H_BPRI# [4] D37# H_A#6 H_D#6... -
Page 62: Dothan 2/2
Schematic Diagrams DOTHAN 2/2 JSKT1D VSS0 VSS97 VSS1 VSS98 +VCORE +VCORE VSS2 VSS99 JSKT1C +VCCA_CPU VSS3 VSS100 AA11 200mA VCC0 VCC59 VSS4 VSS101 AA13 VCC1 VCC60 VOUT VSS5 VSS102 AA15 VCC2 VCC61 VSS6 VSS103 AA17 Z0304 VCC3 VCC62 VSS7 VSS104 AA19 C466 VCC4... -
Page 63: Gm 1/5
Schematic Diagrams 915GM 1/5 +VCCP U22A R260 H_D#[63:0] H_A#[31:3] [2] H_D#0 H_A#3 HD0# HA3# H_D#1 H_A#4 1K_04 5/30 HD1# HA4# H_D#2 H_A#5 HD2# HA5# H_D#3 H_A#6 R263 *0_04 [2,3] CPU_BSEL0 CLK_BSEL0 [3,11] HD3# HA6# H_D#4 H_A#7 HD4# HA7# H_D#5 H_A#8 HD5# HA8# H_D#6... -
Page 64: Gm 2/5
Schematic Diagrams 915GM 2/5 R310 24.9_1% +1.5VS U22G U22B Z0503 PEG_COMP [14] DMI_TXN[3:0] SDVOCTRL_DATA EXP_COMPI DMI_TXN0 AA31 CFG0 R439 10K_04 Z0504 +VCCP DMIRXN0 CFG0 SDVOCTRL_CLK EXP_ICOMPO DMI_TXN1 AB35 AB29 MCH_BSEL1 [4] [11] CLK_MCH_3GPLL# DMIRXN1 CFG1 GCLKN DMI_TXN2 AC31 AC29 Z0517 DMIRXN2 CFG2 MCH_BSEL0 [4]... -
Page 65: Gm 3/5
Schematic Diagrams 915GM 3/5 U22C U22D [10] M_A_DQ[63:0] M_B_DQ[63:0] M_A_DQ0 M_B_DQ0 AG35 AK15 AE31 AJ15 SADQ0 SA_BS0# M_A_BS0# [10] SBDQ0 SB_BS0# M_B_BS0# [9] M_A_DQ1 AH35 AK16 M_B_DQ1 AE32 AG17 SADQ1 SA_BS1# M_A_BS1# [10] SBDQ1 SB_BS1# M_B_BS1# [9] M_A_DQ2 AL35 AL21 M_B_DQ2 AG32 AG21... -
Page 66: Gm 4/5
Schematic Diagrams 915GM 4/5 U22E +3VS_TVDACA +VCORE_GMCH VCC0 VCCA_TVDACA0 +3VS VCC1 VCCA_TVDACA1 +1.5VS C579 C578 C570 C147 C174 C572 C136 C137 VCC2 VCCA_TVDACB0 HCB1608K-121T25 VCC3 VCCA_TVDACB1 10u_08 10u_08 10u_08 10u_08 10u_08 10u_08 1u_X7R 0.1u_X7R_04 VCC4 VCCA_TVDACC0 VCC5 VCCA_TVDACC1 HCB1608K-121T25 VCC6 +3VS_TVDACB VCC7 VCCA_TVBG... -
Page 67: 915Gm 5/5
Schematic Diagrams 915GM 5/5 U22F 915GM Sheet 8 of 40 915GM 5/5 +1.8V +VCORE_GMCH U22H 915GM NCTF +VCCP +1.8V [5,7,9,10,28] +VCCP [2,3,4,5,6,7,13,15,29,30] +VCORE_GMCH [7,30] 915GM 5/5 B - 9... -
Page 68: Drii So-Dimm 2
Schematic Diagrams DRII SO-DIMM 2 SO-DIMM 2 +VTT_MEM RESISTORS +VTT_MEM 16-56034-45A M_B_A0 RN11 C139 0.1u_X7R_04 JDIMM-2A M_B_BS1# 4P2RX56_04 M_B_A[13:0] M_B_DQ[63:0] [6] M_B_A0 M_B_DQ0 M_B_A1 M_B_DQ1 M_B_A4 RN18 C128 0.1u_X7R_04 M_B_A2 M_B_DQ2 M_B_A2 4P2RX56_04 M_B_A3 M_B_DQ3 M_B_A4 M_B_DQ4 M_CKE2 RN29 C194 0.1u_X7R_04 M_B_A5 M_B_DQ5... -
Page 69: Ddrii So-Dimm 1
Schematic Diagrams DDRII SO-DIMM 1 SO-DIMM 1 +VTT_MEM RESISTORS +VTT_MEM 16-56034-45A M_A_RAS# C145 0.1u_X7R_04 M_CS0# 4P2RX56_04 JDIMM-1A M_A_A[13:0] M_A_DQ[63:0] [6] M_A_A0 M_A_DQ0 M_CS1# C152 0.1u_X7R_04 M_A_A1 M_A_DQ1 M_ODT1 4P2RX56_04 M_A_A2 M_A_DQ2 M_A_A3 M_A_DQ3 M_A_A13 C135 0.1u_X7R_04 M_A_A4 M_A_DQ4 M_ODT0 4P2RX56_04 M_A_A5 M_A_DQ5 M_A_A6... -
Page 70: Clock Generator, Ccd
Schematic Diagrams CLOCK GENERATOR, CCD CLOCK GENERATOR CLK_MCH_FSB 49.9_1% C559 *10p CLK_MCH_FSB# 49.9_1% C556 *10p +3VS HCB1608K-121T25 Z1109 CLK_CPU_FSB R102 49.9_1% PLACE CRYSTAL +3VS C564 *10p WITHIN 500 MILS C569 C566 C546 C541 C565 C561 C547 OF CK410M CLK_CPU_FSB# R100 49.9_1% 10u_08 0.1u_04... -
Page 71: Panel, Inverter, Fan
Schematic Diagrams PANEL, INVERTER, FAN PANEL PANEL ID SELECTOR LVDS-L0N LVDS-L0N [5] LVDS-L0P LVDS-L0P [5] LVDS-L1N 5/24 LVDS-L1N [5] PLVDD LVDS-L1P LVDS-L1P [5] LVDS-L2N 1.5A LVDS-L2N [5] LVDS-L2P LVDS-L2P [5] +3VS LVDS-LCLKN LVDS-LCLKN [5] C545 C555 LVDS-LCLKP LVDS-LCLKP [5] LVDS-U0N LVDS-U0N [5] JLCD 0.1u_04... -
Page 72: Ich6
Schematic Diagrams ICH6-M 1/3 C721 +VCCRTC R409 5/24 SCS751V C646 32.768KHz +VDD3 U29A LPC_AD[3:0] [19,21] RTC_X1 LPC_AD0 RTCX1 LAD_0 C718 RTC_X2 LPC_AD1 RTCX2 LAD_1/FB1 SCS751V LPC_AD2 LAD_2/FB2 Z1302 R373 180K_1%_04 RTCRST# LPC_AD3 RTCRST LAD_3/FB3 INTRUDER# Z1325 INTRUDER LDRQ_0 R348 Z1326 INTVRMEN (+3VS)LDRQ_1/GPI41 R366... -
Page 73: Ich6-M 2/3
Schematic Diagrams ICH6-M 2/3 U29B [16,18,20,25] PCI_AD[31:0] PCI_AD0 PCI_REQ0# U29C AD_0 REQ_0 PCI_REQ0# [20] PCI_AD1 PCI_GNT0# PM_RI# Z1426 AD_1 GNT_0 PCI_GNT0# [20] HSIN_0 Z1427 PCI_AD2 PCI_REQ1# RN49 AD_2 REQ_1 PCI_REQ1# [18] HSIP_0 Z1412 Z1428 PCI_AD3 PCI_GNT1# 8P4RX100_04 AF17 AD16: LAN AD_3 GNT_1 PCI_GNT1# [18]... -
Page 74: Ich6-M 3/3
Schematic Diagrams ICH6-M 3/3 U29E HCB2012K-500T40 +5VS Z1505 +1.5VS C325 C653 C349 C660 0.1u_04 10u_08 10u_08 100u/6.3V_B +3VS SCS551V U29D V5REF Z1501 VCC5REF AA18 Layout note: V5REF VCC1_5 VCC1_5 V5REF_SUS R382 R154 Place near V5REF_SUS VCC1_5 C314 C354 C326 C353 pin AA19 VCC1_5 100_04... -
Page 75: Mini Pci, Usb2.0* 2
Schematic Diagrams MINI PCI, USB2.0* 2 MINI PCI USB 2.0 +5VS +3VS +5VS +3VS JMPCI PCI_AD[31:0] [14,18,20,25] PCI_AD[31:0] +VCCUSB0 +VCCUSB1 VOUT VOUT RT9701CBL 0.1u_04 0.1u_04 10u_08 10u_08 0.1u_04 [19,21] WLAN_EN [14,18,25] PCI_INTB# PCI_INTC# [14,25] Z1601 Z1612 *4.7K_04 Z1613 [11] PCLK_MPCI PCIRST# [14,18,20,25] [14] PCI_REQ3#... -
Page 76: Hdd, Cd-Rom, Sata Com
Schematic Diagrams HDD, CD-ROM, SATA COM CD-ROM IDE_PDD[15:0] [13] IDE_PDD[15:0] JHDD HD_RESET# [23] CD_L CD_R [23] IDE_PDD7 IDE_PDD8 [23] CD_G IDE_PDD6 IDE_PDD9 CD_RESET# IDE_PDD8 IDE_PDD5 IDE_PDD10 IDE_PDD7 IDE_PDD9 IDE_PDD4 IDE_PDD11 IDE_PDD6 IDE_PDD10 IDE_PDD3 IDE_PDD12 IDE_PDD5 IDE_PDD11 IDE_PDD2 IDE_PDD13 IDE_PDD4 IDE_PDD12 IDE_PDD1 IDE_PDD14 IDE_PDD3... -
Page 77: Lan Rtl8110Sbl/Rtl8100Cl
Schematic Diagrams LAN RTL8110SBL/RTL8100CL LAN_VDD33 LAN_AVDDH LAN_V_12P LAN_AVDDL LAN_V_DAC LAN_DVDD POWER HCB3216K-800T30 RTL8100CL SEE NOTE 1 SEE NOTE 1 RTL8100CL --- X NOTE 1: RTL8110SBL -- V C681 C695 C707 RTL8110SBL SEE NOTE 1 SEE NOTE 1 10u_08 10u_08 0.1u_04 LAN_V_DAC LAN_VDD25 LAN_VDD25... -
Page 78: Fwh, Touch Pad, Led
Schematic Diagrams FWH, TOUCH PAD, LED +3VS TOUCH PAD LED BOARD FOR M550G C741 0.1u_04 +3VS [14] FLASH# FWH-WP# C491 C492 C505 C501 [14] FWH_WP# 0.1u_04 0.1u_04 0.1u_04 0.1u_04 +3VS 74AHC1G08 5/25 C787 JBIOS +5VH8 0.1u_04 PCLK_FWH [11] Z1901 R272... -
Page 79: Ieee 1394 Vt6307S
Schematic Diagrams IEEE 1394 VT6307S IEEE1394 IEEE1394 +PVA_1394 +3VS PCI_AD[31:0] [14,16,18,25] PCI_AD[31:0] +PVA_1394 +3VS PCI_AD[31:0] [14,16,18,25] PCI_AD[31:0] C633 C637 C644 C636 10u_08 C633 0.1u_04 C637 0.1u_04 C644 0.1u_04 C636 10u_08 0.1u_04 0.1u_04 0.1u_04 R361 PCI_AD31 PCI_AD31 PCI_AD30 HCB1608K-121T25 0_08 R361 PCI_AD30 PCI_AD31 PCI_AD29... -
Page 80: H8/2111
Schematic Diagrams H8/2111 VER. VOLTAGE +3VH8 +5VH8 +3VH8 +3VH8 +3VH8 V1.0 1.06V +3VH8 H8_MD1 V2.0 100K_1% 1.65V H8_BAT0_TEMP C106 C493 C167 C171 C520 C521 C528 V3.0 200K 2.20V R287 H8_BAT0_V C105 R289 10u_08 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 10u_08 100K_1% 10K_04 150K... -
Page 81: Mdc, Usb Bt, Pwrgd, Ddb Con
Schematic Diagrams MDC, USB BT, PWRGD, DDB CON POWER OK ALAZIA MDC JMDC C288 C281 JMDC 0.1u_04 +3VS Z2205 RESERVED Z2206 PM_PWROK [12,14,29] [13,23] AZ_SDOUT RST# Azalia_SDO RESERVED [13,23] AZ_SYNC 3.3V Main/aux R151 22 Azalia_SYNC C713 R419 Z2204 [13] AZ_SDIN1 Azalia_SDI IMP809 [13,23]... -
Page 82: Azalia Codec Alc880
Schematic Diagrams AZALIA CODEC ALC880 +3VS +5VS_AUD +5VS HCB1608K-121T25 HCB2012K-500T40 C138 Z2333 680p SURRB-R Z2334 C779 C336 C350 C348 C380 C696 C679 C384 C780 JSPDIF FCM1608K-121T06 0.1u_04 10u_08 0.1u_04 0.1u_04 0.1u_04 0.1u_04 10u_08 10u_08 0.1u_04 SPDIF/SURRB-L FCM1608K-121T06 Z2335 V_REFOUT 5/13 5/13 AUDG C114... -
Page 83: Audio Amp, Usb2.0* 2
THREM/GND SHUTDOWN Sheet 24 of 40 AMPG JSPK_15 C280 Z2505 JSPK_15 LHPIN Z2507 Z2506 R143 10K_04 AUDIO AMP, USB* [23] FRONT-L LLINEIN FOR M550G APA2020A 5/17 C277 85205-0400 C268 47u/6.3V_B HEADPHONE-L R135 10K_04 8P4CX180p C263 R491 5/17 680p 1K_04 AMPG... -
Page 84: Pcmcia Ene Cb714B
Schematic Diagrams PCMCIA ENE CB714B CLOSE TO CARD SOCKET +VCC_CARD RN40 8P4RX47K SD_CMD R406 *0_04 MS_CLK [14,16] PCI_INTC# Z2604 R405 0_04 SD_CLKIN SD_D3 [14] PCI_INTA# PCM_MF1 SD_D2 VCCD1# [26] [14,16,18] PCI_INTB# VCCD0# [26] RN42 8P4RX47K [14,21] INT_SERIRQ VPPD1 [26] PCM_MF4 SD_D1 VPPD0 [26] PCM_MF5... -
Page 85: Pcm Socket, 3 In 1 Socket
A_CD14 RFU/D14 0.1u 0.1u 0.1u_04 0.1u_04 0.1u_04 [25] A_A18 RFU/A18 20216-0021 PCB Footprint = 20216-0021 3 IN 1 SOCKET SD/MMC/MS(Pro) FOR M540G FOR M550G RN39 *8P4RX47K A_CCBE0# +AVCC A_CAD10 Card Reader Power A_CRST# JCARD-NOR JCARD-REV A_CAD11 SD_CD# SD_CD# [25] SD_CD#... -
Page 86: Sysyem Power, Bridge Batt
10u_08 0.1u_04 DD_ON# DD_ON# 0.1u 0.1u 10u_08 0.1u_04 0.1u_04 0.1u_04 0.1u_04 100K_04 SUSB 2N7002 2N7002 0.1u 2N7002 BRIDGE BATTERY FOR M550G +3VS Bridge Battery Connector VSUB C795 C796 C797 C798 C799 C800 C801 C802 C803 C804 5/18 SCS355V Z2810 R454 10K_1% 0.1u_04... -
Page 87: V,+1.5,+Vtt Mem
Schematic Diagrams +1.8V,+1.5,+VTT MEM +1.8V,+0.9V +VDD5 R468 R469 +VIN +VDD5 10K_04 100K_04 R470 R471 VTTEN 1.5M SCS551V R472 2N7002 Z2928 R474 *100K_04 R473 Z2901 Z2921 *0_04 +VDDQ VDDQS JOPEN10 P29_VRON 2N7002 5/25 C750 R475 C751 C752 SUSB# [3,14,18,21,22,27,29] Z2902 *OPEN_10mil 100p_04 2.2K_1% Z2925... -
Page 88: Vcore
Schematic Diagrams +VCORE +VCORE +VCCP +VDD5 8P4RX10K_04 H_VID0 JOPEN1 H_VID1 *OPEN_10mil H_VID2 H_VID4 10K_04 H_VID3 10u_08 10K_04 H_VID5 SCS551V Z3001 +VIN C446 BST1_VCORE +3VS C414 C401 C406 C488 C407 C408 GND_FIELD3 R228 1_1% 0.1u 0.01u 0.1u 0.1u 0.1u 0.1u 0.1u 10u_12 10u_12 10u_12... -
Page 89: Vs, +2.5Vs
Schematic Diagrams +1.05VS, +2.5VS +1.05VS +VIN 0.1u_04 C459 0.1u_04 C463 C464 C462 C460 Z3101 R254 0.1u_04 10u_12 10u_12 0.1u 0.01u GND_FIELD4 R252 SCS551V R244 1.5M 10K_04 JOPEN4 C461 +VCORE_GMCH EN_1.05VS Z3104 R501 EN/PSV 0.1u AO4408 OPEN_3A Z3102 Z3111 +1.05VS C481 Z3105 1.5uH JOPEN3... -
Page 90: D/D Bd (Crt, S-Video
Schematic Diagrams D/D BD (CRT, S-VIDEO, RJ-11) MLP1 FCA3216K4-121T03 MBLU M_BLUE MCRT M_VSYNC DS01A91-WL3-TR M_HSYNC MID3 M_DDCACLK MR503 M_RED MRED MD26 SCD34 Z3201 Z3202 M_GREEN MLP2 M+3VS M_BLUE MGRN FCA3216K4-121T03 1K_0402 MRED M_RED MD14 MD10 MBLU MUSB_CRTPP2 MID1 M_DDCADATA BAV99 BAV99 BAV99 MUSB_CRTPN2... -
Page 91: D/D Bd (+Vdd3, +Vdd5, +Vdd12
Schematic Diagrams D/D BD (+VDD3, +VDD5, +VDD12) +VDD3,+VDD5,+VDD12 M+VIN M+VL M+VIN MR65 M+VIN1 MC41 MC40 MC42 MC39 MC97 MC38 MC99 10u_12 10u_12 0.1u 0.01u 0.1u MC100 MC36 10u_12 10u_12 MC124 MC125 MC126 M+VDD3 SCS551V SCS551V 10u_08 0.1u_04 0.1u_04 0.1u_04 0.1u_04 MGND M+VDD5 MGND... -
Page 92: D/D Bd (Charger, Dc In
Schematic Diagrams D/D BD (CHARGER, DC IN) CHARGER 5/27 M+VA M+VB AO4407 47uH_BCRH124 2.5A 2.5A MC52 MC74 MR18 100m_25 MD17 SM340A 15u/25V_D Z3419 15u/25V_D Z3420 Z3425 Z3426 MQ10 MC58 MD13 MC25 MC28 MC108 MC107 DTA114EUA MD11 MJOPEN1 0.1u SM340A 0.1u 0.1u 0.1u 0.1u... -
Page 93: Audio Bd (Phone Jack, Usb
Schematic Diagrams AUDIO BD (PHONE JACK, USB) DIGITAL PLANE PJL2 PJL3 HCB3216K-800T30 PJU1 HCB3216K-800T30 PJU2 PJ+VCCUSB2 PJ+VCCUSB3 PJGND PJGND *CM1213-02ST *CM1213-02ST PJUSB1 PJUSB2 Z3509 Z3510 PJL1 GND1 PJL4 GND1 GND1 GND1 PJUSB_PN2 Z3501 GND2 PJUSB_PN3 Z3503 GND2 DATA- GND2 DATA- GND2 GND3 GND3... -
Page 94: Hot Key Bd (Hot Key, Led
Z3604 Z3606 LED7 LED1 LED2 LED3 PSD7 KPC-3216QBC-C PSD1 17-21VGC-TR8 PSD2 17-21VGC-TR8 PSD3 17-21VGC-TR8 PSGND FOR M550G Sheet 35 of 40 FOR M540G HOT KEY BD (HOT KEY, LED) PSSW2 PSSW4 PSSW6 PSSW8 5/20 *TC017-BB1J-X160T *TC017-BB1J-X160T *TC017-BB1J-X160T *TC017-BB1J-X160T PSWEB0 PSWEB1#... -
Page 95: Led Board
Schematic Diagrams LED BOARD FOR M550G L+5VS L+5VS L+5VH8 L+5VH8 5/10 Z3702 Z3703 L+5VH8 Z3704 Z3701 WLAN/BT LPOWER_ON LACIN_SUSLED LBATT_FULL KPB-3025YSGC KPB-3025YSGC LBATT_CHARGE L+5VS LEMAIL_LED LWLAN_EN LBT_EN LHD_LED# LACIN_SUSLED LBT_EN LWLAN_EN Sheet 36 of 40 LPOWER_ON 85201-1205 LED BOARD LGND... -
Page 96: Click Board
Schematic Diagrams CLICK BOARD FOR M550G VENDOR PART NUMBER Synaptics E-LAN 800409-5102 CJTP Z3801 CTPBUTTON_R Sheet 37 of 40 CTPBUTTON_L CJTP Z3802 CLICK BOARD Z3803 Z3804 CTP_DATA C+5VS CTP_CLK CGND CGND 0.1u_04 CTP_CLK CTP_DATA 85201-0405 C+5VS 87151-1207 5/25 0.1u_04 CGND... -
Page 97: Rj-45 Board
Schematic Diagrams RJ-45 BOARD RJRJ-45 RMLMX4- GND1 shield RMLMX4+ GND2 shield RMLMX3- RMLMX3+ RJLAN RMLMX2- RGND RMLMX2+ RMLMX1- RMLMX1+ C10091-108A4 Sheet 38 of 40 SPUAZ-10S2-VB-040-1-R RJ-45 BOARD RGND RGND RJLAN C237D91 C237D107 RGND RGND RJ-45 BOARD B - 39... -
Page 98: Usb Dongle Board
Schematic Diagrams USB DONGLE BOARD USB DONGLE BOARD U+5VS Sheet 39 of 40 Z3901 Z3902 USB DONGLE BOARD *2N3906 *2N3906 Z3904 Z3903 UJUSB1 Z3905 *0.047u *0.047u *1.5K 5/30 5075ARP-04-SM2-WH PIN GND1~2=UGND *2.2K *33K *33K *2.2K UGND UGND UGND UGND UGND B - 40 USB DONGLE BOARD...
