Summary of Contents for Clevo M590K
- Page 3 Preface Notebook Computer M590K Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
-
Page 5: About This Manual
This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M590K series notebook PC. -
Page 6: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. -
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 8: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. -
Page 10: Related Documents
Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII... -
Page 11: Table Of Contents
External Locator - Left & Right Side View ........1-7 DVD DUAL (M590K) ..............A-6 External Locator - Bottom View .............1-8 Combo Drive (M590K) ..............A-7 M590K Mainboard Overview - Top (Key Parts) ......1-9 HDD (M590K) ................A-8 Schematic Diagrams......... B-1 M590K Mainboard Overview - Bottom (Key Parts) ....1-10 M590K Mainboard Overview - Top (Connectors) .......1-11... - Page 12 Preface PCMCIA SOCKET ..............B-22 HITACHI H8S/2111 ..............B-23 BIOS, CCD CON & FAN CON ........... B-24 PCI-E/USB NEW CARD ............. B-25 SUPER I/O & FIR ................ B-26 AUDIO (ALC655) & MDC ............B-27 SRS AP8202Q ................B-28 SUB-WOOFER & DVI CON ............B-29 +5VS, +3VS, +5V, +3V ...............
-
Page 13: Introduction
1: Introduction Overview This manual covers the information you need to service or upgrade the M590K series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about driv- ers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer. -
Page 14: System Specifications
Introduction System Specifications Feature Specification µ Processor Types Mobile AMD Turion™ 64 Processor (35W), 0.09) 0.09 Micron Silicon-On-Insulator (SOI) Process 754-pin Micro-PGA Package Technology, 512KB L2 Cache Models ML-28/ ML-32 1.6GHz/ 1.8GHz/ 2.4GHz µ Mobile AMD Turion™ 64 Processor (35W), 0.09) 0.09 Micron Silicon-On-Insulator (SOI) Process 754-pin Micro-PGA Package Technology, 1MB L2 Cache... - Page 15 Introduction Feature Specification Storage Options One Changeable 2.5" 9.5mm (h) Serial-ATA II (SATA II) Hard Disk Drive One Changeable Optical Device Bay - 12.7 mm (h) for Optical CD/DVD Device Drive Options (see“Optional” on page 1 - Card Reader Built-In 4-in-1 Card Reader (SD/ MMC/ MS/ MS Pro) Audio SRS WOW Surround Sound Technology Inside Virtual 4-Channel Sound System...
- Page 16 Introduction Feature Specification Communication Infrared Transceiver 802.11 a/b/g Mini-PCI Wireless LAN Module Infrared Transfer 1cm ~ 1M Operating Distance Bluetooth™ Class II V1.2 USB 2.0 Module 115.2K bps SIR 4M bps FIR 1.3M Pixel USB 2.0 Video Camera Module (Factory IrDA 1.1 Compliant Option) 10/100/1000 BASE-TX Fast Ethernet LAN on board...
-
Page 17: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Optional Built-In PC Camera 2. LCD 3. LED Power & Communication Indicators 4. Speakers 5. AP-Key Buttons & Power Button 6. Built-In Microphone 7. LED Status Indicators 8. -
Page 18: External Locator - Front & Rear Views
Introduction External Locator - Front & Rear Views Figure 2 Front Views 1. LCD Latches Consumer Infrared Transceiver Enabled with Optional Mini- PCI TV Tuner Only Figure 3 Rear Views 1. 7-Pin S-Video-Out Jack 2. DVI-Out Port 3. DC-In Jack 4. -
Page 19: External Locator - Left & Right Side View
Introduction External Locator - Left & Right Side View Figure 4 Left Side View 1. S/PDIF-Out Jack 2. Line-In Jack 3. Microphone-In Jack 4. Headphone-Out Jack 5. Optical Device Drive Bay (for CD/DVD Device) Figure 5 Right Side View 1. PC Card Slot 2. -
Page 20: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Battery Release Latch 3. CD/DVD Device Release Latch 4. Hard Disk Bay Cover 5. Vent/Fan Intake 6. Sub Woofer 7. Component Bay Cover 8. Speakers Overheating To prevent your com- puter from overheating make sure... -
Page 21: M590K Mainboard Overview - Top (Key Parts)
M590K Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. H8S/2111 2. Audio ALC655 3. SRS WOW Surround 4. Ultra Media 5. PC Card Assembl 6. Super I/O PC87383 7. Infrared Transceiver M590K Mainboard Overview - Top (Key Parts) 1 - 9... -
Page 22: M590K Mainboard Overview - Bottom (Key Parts)
7. Mini-PCI Socket (Wireless Lan Module) 8. ENE Card Control 9. Mini-PCI Socket (TV Tuner Card) 10. Flash BIOS ROM 11. 160-Pin VGA Socket 12. 30-Pin VGA Socket 13. 40-Pin VGA Socket 1 - 10 M590K Mainboard Overview - Bottom (Key Parts) -
Page 23: M590K Mainboard Overview - Top (Connectors)
9. Debug Connector 10. Keyboard Cable Connector 11. Touch Pad Cable Connector 12. Audio Cable Connector 13. AP-Key Buttons & Power Button Cable Connector 14. Modem Module Connector 15. LED Cable Connector M590K Mainboard Overview - Top (Connectors) 1 - 11... -
Page 24: M590K Mainboard Overview - Bottom (Connectors)
9. Chipset Fan Cable Connector 10. VGA Fan Cable Connector 11. VGA Fan Cable Connector 12. Bluetooth Cable Connector 13. Battery Connector 14. CD Connector 15. HDD Connector 16. HDD Fan Cable Connector 1 - 12 M590K Mainboard Overview - Bottom (Connectors) -
Page 25: Disassembly
2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M590K series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. -
Page 26: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 27: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 28: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Wireless LAN Module: 1. Remove the battery page 2 - 5 1. -
Page 29: Removing The Battery
Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide latch towards the unlock symbol and hold it in place, and slide latch in the direction of the arrow. a. Slide latch at point 1 to- 3. -
Page 30: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" serial (SATA II) Removal hard disk drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all nec- essary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk. -
Page 31: Removing The Optical (Cd/Dvd) Device
Disassembly Removing the Optical (CD/DVD) Device Figure 3 Optical Device 1. Turn off the computer, and turn it over and remove the battery (page 2 - Removal 2. Slide latch towards the unlock symbol and hold it in place. Slide the optical device out of the computer at point a. -
Page 32: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 4 RAM Module The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR 400/333 MHz. The main memory can be expanded up to 2GB. The SO-DIMM modules supported are 256MB, 512MB and 1024MB DDR 400/333 MHz Modules. -
Page 33: Removing The Processor
Disassembly Removing the Processor Figure 5 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5) and remove the component bay cover Processor Removal (page 2 - 2. The heat sink will be visible at point on the mainboard a. - Page 34 Disassembly 5. Press down and hold the latch (with the latch held down you will be able to release it). 6. Move the latch fully in the direction indicated to unlock the CPU. Figure 6 7. Carefully (it may be hot) lift the CPU up out of the socket (Figure Processor Removal...
-
Page 35: Removing The Vga Card(S)
Disassembly Removing the VGA Card(s) Figure 7 VGA Card(s) 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5) and remove the component bay cover Removal (page 2 - 2. The VGA Card(s) will be visible at point on the mainboard. -
Page 36: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 8 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5) and remove the component bay cover Wireless LAN (page 2 - Module Removal 2. The wireless LAN module will be visible at point on the mainboard. -
Page 37: Removing The Tv Tuner Card
Disassembly Removing the TV Tuner Card Figure 9 TV Tuner Card 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5) and remove the component bay cover Removal (page 2 - 2. The TV Tuner card will be visible at point on the mainboard. -
Page 38: Removing The Bluetooth Module
Disassembly Removing the Bluetooth Module Figure 10 Bluetooth Module 1. Turn off the computer, and turn it over, remove the battery (page 2 - Removal 1. The Bluetooth module bay cover is located under the battery. 2. Remove screws from the bay cover. a. -
Page 39: Removing The Keyboard
Disassembly Removing the Keyboard Figure 11 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 2. Press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you a. - Page 40 Disassembly 2 - 16...
-
Page 41: Part Lists
Part Lists Appendix A:. Appendix A:Part Lists This appendix breaks down the M590Kseries notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 42: Part List Illustration Location
A - 4 Bottom - (M590K) page A - 5 LCD - (M590K) page A - 6 DVD DUAL - (M590K) page A - 7 Combo Drive - (M590K) page A - 8 HDD - (M590K) A - 2 Part List Illustration Location... -
Page 43: Top (M590K
Part Lists Top (M590K) Figure A - 1 Top (M590K) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Top (M590K) A - 3... -
Page 44: Bottom (M590K
無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 (黑色 )硬度:30度 無鉛 無鉛 無鉛 昆山 M590K 無鉛 無鉛 無鉛 無鉛 系 列 M590K 無 鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛... -
Page 45: Lcd (M590K
Part Lists LCD (M590K) Figure A - 3 LCD (M590K) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 MYLAR LCD MAGNET (24X30) M590K 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 FOR M550G 中性LOGO(STYLE-NOTE) 無鉛... -
Page 46: Dvd Dual (M590K
Part Lists DVD DUAL (M590K) Figure A - 4 DVD DUAL (M590K) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 A - 6 DVD DUAL (M590K) -
Page 47: Combo Drive (M590K
Part Lists Combo Drive (M590K) Figure A - 5 Combo Drive (M590K) 無鉛 無鉛 無鉛 無鉛 無鉛 Combo Drive (M590K) A - 7... -
Page 48: Hdd (M590K
Part Lists HDD (M590K) Figure A - 6 HDD (M590K) A - 8 HDD (M590K) - Page 49 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the M590K notebook’s PCB’s. The following table indicates where to find the ap- propriate schematic diagram. Table B - 1 Diagram - Page Diagram - Page Diagram - Page...
-
Page 50: Schematic Diagrams
Schematic Diagrams SYSYTEM BLOCK DIAGRAM AMD K8 SO-DIMM Athlon64 M590K Socket BLOCK Dual channel TV OUT DIAGRAM Hyper Transport Link0 800Hz Min trace w idth=5 mils DAUGHTER BOARD NFORCE CRUSH Multiplexer K804 PCI-Express 740BGA DAUGHTER Sheet 1 of 45 MINI PCI... -
Page 51: Athlon 64 1/4 Hypertransport
Schematic Diagrams ATHLON 64 1/4 HyperTransport +3VS 4,8,9,10,11,12,13,14,16,18,19,22,23,24,25,28,29,32,33,35,36 850mA VLDT +1.2V(1.14~1.26) 500mA +1.2V_HT 9,14 +1.2VLDTB 4 +1.2V_HT +1.2VLDTB C141 C138 C133 C134 CA13 0.22U 4.7U_0805 0.22U 0.22U 0.22U 0.22U 0.22U 0.22U 0.22U 4.7U_0805 U36A Sheet 2 of 45 L0_CADIN_L[15..0] L0_CADOUT_L[15..0] 9 ATHLON 64 1/4 TX/DW N/OUT/L/#N 94/11/11 Kevin... -
Page 52: Athlon 64 2/2 Ddr
Schematic Diagrams ATHLON 64 2/2 DDR +2.5V 4,5,6,7, 16,30,33 MEMDATA61 RN20 8P4RX10_0402 MMDATA61 +1.25V 4,7, 30 DQM7 MEMD QS16 MEMDATA62 MMDATA62 MEMDATA63 MMDATA63 MAA[0. .13] 6,7 MEMDATA59 RN40 8P4RX10_0402 MMDATA59 MEMDATA58 MMDATA58 MAB[0. .13] 6,7 MEMDQS7 MMDQS7 120_1% MEMDATA57 MMDATA57 MEMC LK_L4 R231 MEMCLK_H4... -
Page 53: Athlon 64 3/4 Misc
Schematic Diagrams ATHLON 64 3/4 Misc Q 3 9 , Q 4 0 ( 3 9 0 4 ) C h a n g e 2 N 7 0 0 2 . +VDD3 Low active to short R197 5 / 2 0 C h a n g e down system. -
Page 54: Athlon 64 4/4 Power
Schematic Diagrams ATHLON 64 4/4 Power 1.5V@ 46A VCORE +2.5V 3,4,6,7,16,30,33 VCORE 32 +2.5V U36E U36D VDD1 AC15 VSS222 VSS33 VDD2 VDDIO1 VSS221 VSS34 VDD3 VDDIO2 VSS220 VSS35 VDD4 VDDIO3 AF19 VSS219 VSS36 VDD5 VDDIO4 AD19 VSS218 VSS37 VDD6 VDDIO5 AB19 VSS217 VSS38... -
Page 55: Ddr Sodimm
Schematic Diagrams DDR SODIMM MEMDATA[0..63] +2.5V +2.5V MEMDATA[0..63] 3,7 +2.5V 3,4,5,7,16,30,33 DDR_SO-DIMM1_R DDR_SO-DIMM2_S MAB[0..13] 3,7 SODIMM-DDR_200P_R CA0144-200N01_R MAA[0..13] MAA0 MEMDATA0 MAB0 94/10/31 Kevin MAA1 MEMDATA1 MAB1 MAA2 MEMDATA2 MAB2 94/10/31 Kevin MAA3 MEMDATA3 MAB3 MAA4 MEMDATA4 MAB4 MAA5 MEMDATA5 MAB5 MAA6 MEMDATA6 MAB6... -
Page 56: Ddr Termination
Schematic Diagrams DDR TERMINATION +2.5V 3,4,5,6,16,30,33 +1.25V 3,4,30 +1.25V 2.4A DQM[0..7] +1.25V DQM[0..7] +1.25V RN21 8P4RX68 C717 0 .1 U_ X7R C720 0.1U_X7R MEMDATA0 Z0701 MEMDATA1 T641 Z0702 RN63 MEMDQS0 C710 0.1U_X7R T642 MEMDATA22 MEMDATA15 8P4RX 68 C484 0.1U_X7R MEMDATA2 DQM2 MEMDATA14 MEMDATA4... -
Page 57: Lcd Con & Lcd Vcc
Schematic Diagrams LCD CON & LCD VCC +VDD3 4,13,16,19,23,29,30,31 +3VS 2,4,9,10,11,12,13,14,16,18,19,22,23,24,25,28,29,32,33,35,36 +5VS 11,14,16,19,22,23,26,28,29,30,33,34,35,36 +12V 20,21,23,26,28,29,30,32 8P4RX0 LVDSUCLKN LVDS_UCLKN 36 JLCD1 3.3V@1130mA LVDSUCLKP LVDS_UCLKP 36 LVDSUN3 LVDS_UN3 36 Del L12(L_0805). LVDSUP3 LVDS_UP 3 36 PLVDD Z0808 8P4RX0 LVDSUN1 LVDS_UN1 36 Z0809 C866 LVDSUP1 5 / 2 0 C h a n g e... -
Page 58: Ck804 Ht Part A
Schematic Diagrams CK804 HT Part A +1.2V_HT 2,14 +3V 4,10,11,13,14,17,18,19,20,21,22,23,24,26,29,32,33 +2.5V 3,4,5,6,7,16,30,33 +3VS 2,4,8,10,11,12,13,14,16,18,19,22,23,24,25,28,29,32,33,35,36 +VDD5 13,16,19,23,26,29,30,32,34,36 U4H1A MBGA740 CK804 L0_CADOUT_H[15..0] L0_CADIN_H[15..0] 2 L0_CADOUT_H0 AG30 SEC 1 OF 7 L0_CADIN_H0 HT_RXD0 HT_TXD0 L0_CADOUT_H1 AF30 L0_CADIN_H1 HT_RXD1 HT_TXD1 L0_CADOUT_H2 AE29 L0_CADIN_H2 HT Bus route 5/5 CK804 Max Power HT_RXD2 HT_TXD2... -
Page 59: Ck804 Pci-E Part B
Schematic Diagrams CK804 PCI-E Part B +1.5VS 14,24,33,34 +3V 4,9,11,13,14,17,18,19,20,21,22,23, 24,26,29,32,33 +3VS 2,4,8,9,11,12,13,14,16,18,19,22,23,24, 25,28,29,32,33,35,36 MBGA740 U 4H1B PEG_RXP[ 0.. 15] PEG_TXP[0..15] PEG_RXP[0..15] 36 SEC 2 OF 7 PEG_TXP0 PEG_R XP0 PE0_RX0 PE0_TX0 CK804 PEG_TXP1 PEG_R XP1 PCIE route 5/5/20. PE0_RX1 PE0_TX1 PEG_TXP2 PEG_R XP2... -
Page 60: Ck804 Pci Part C
Schematic Diagrams CK804 PCI Part C +3VS 2,4,8,9,10,12,13,14,16,18,19,22,23,24,25,28,29,32,33,35,36 +3V 4,9,10,13,14,17,18,19,20,21,22,23,24,26,29,32,33 +5VS 8,14,16,19,22,23,26,28,29,30,33,34,35,36 Shared bus to a ll PCI De vice U4H1C +3VS MBGA740 Route 5/5. PCI_AD[0..31] 18,19,20 PCI_AD[0..31] SEC 3 OF 7 PCI_AD0 R292 PCI_AD0 PCI_REQ0/GPIO* PCI_REQ0# 20 CK804 PCI_AD1 PCI_AD1 PCI_REQ1/GPIO* PCI_REQ1# 18... -
Page 61: Ck804 Sata & Pata Part D
Schematic Diagrams CK804 SATA & PATA Part D +3VS 2,4,8,9,10,11,13,14,16,18,19, 22,23,24,25, 28,29,32,33,35,36 U4H1D MBGA740 I DE_PD D[0.. 15] ID E_PD D[0..15] 35 route 7/12/30 max length 3000mils SEC 4 OF 7 AE20 IDE_PDD 0 SATATXP0 SP_TXP0 CK804 IDE_D ATA_P0 AJ 9 AA17 IDE_PDD 1 SATATXN0... -
Page 62: Ck804 Codec, Usb, Io Part E
Schematic Diagrams CK804 CODEC, USB, IO Part E +VDD5 9,16,19,23,26,29,30,32,34,36 Match RXD[0..3] & Match TXD[0..3] & +VDD3 4,8,16,19,23,29,30,31 +3V 4,9,10,11,14,17,18,19,20,21,22,23,24,26,29,32,33 RXCTL signal to this TXCTL signal to this RGMII(Reduced Gigabit media indepentent I/F) +3VS 2,4,8,9,10,11,12,14,16,18,19,22,23,24,25,28,29,32,33,35,36 signal within 100mil. signal w ithin +5V 15,16,19,21,22,23,29 MII( Gigabit media indepentent I/F) +2.5V 3,4,5,6,7,16,30,33... -
Page 63: Ck804 Power & Gnd F
Schematic Diagrams CK804 POWER & GND F +5VS +5VS +1.5VS 10,24,33,34 9/29 +5VS 8,11,16,19,22,23,26,28,29,30,33,34,35,36 +3V 4,9,10,11,13,17,18,19,20,21,22,23,24,26,29,32,33 Change +1.2V_HT 2,9 RB751V RB751V +3VS 2,4,8,9,10,11,12,13,16,18,19,22,23,24,25,28,29,32,33,35,36 CK804 DECOUPLING Z1407 Z1408 MBGA740 U4H1G +1.5VS +1.5VS SEC 7 OF 7 CK804 AH30 Z1401 94/11/14 Kevin +1.5V1 +5V1 Z1402... -
Page 64: Usb Con X3, Tv-Out
Schematic Diagrams USB CON X3, TV-OUT +5V 13,16,19,21,22,23,29 21-B4900-104 Vcc Power trace >= 60mil JUSB1 Z1501 L_0805(159) Z1504 GN D1 1.1A Z1505 GN D2 USB_PN1 DATA- R265 C236 C224 GN D3 Z1506 GN D4 USB_PP1 DATA+ 5.1K 4P2LX120(097) 0.1U 100U_10V_7343 C235 USB_OC1# 0.1U... -
Page 65: Inv, Web, Click, S/W Con
Schematic Diagrams INV, WEB, CLICK, S/W CON LID SWITCH +5V 13,15,19,21,22,23,29 +3VS +3VS +5VS 8,11,14,19,22,23,26,28,29,30,33,34,35,36 5 / 2 0 C h a n g e 5 / 2 0 C h a n g e +3VS 2,4,8,9,10,11,12,13,14,18,19,22,23,24,25,28,29,32,33,35,36 R 28 2.7K C136 C140 VIN 29,30,31,32,34,36... -
Page 66: Pci-E Lan (Marvell
Schematic Diagrams PCI-E LAN (MARVELL) +3V 4,9,10,11,13,14,18,19,20,21,22,23,24,26,29,32,33 LAN_VDD33 0.01U 0 .01U JMLAN1 Z1704 MDI0+ LANVCC2.5 MX4- TD4- Z1705 MDI0- MX4+ TD4+ Z1706 Z1714 V_DAC L_1 59(0 805 ) MCT4 TCT4 Z1707 MDI1+ C823 C824 C825 C541 C542 C553 C554 C539 MX3- TD3- Z1708... -
Page 67: Ti-1394A (43Ab22A
Schematic Diagrams TI-1394A (43AB22A) +3VS +3V 4,9,10,11,13,14,17,19,20,21,22,23,24,26,29,32,33 +3VS +3VS 2,4,8,9,10,11,12,13,14,16,19,22,23,24,25,28,29,32,33,35,36 +3V1394 L_0805(159) +3V1394 R687 4.7K Z1801 *L_159 8P4RX4.7K C756 C760 C779 C754 Z1802 0.1U 0.1U 0.1U 0.1U +3V1394 Z1804 Z1805 C750 C766 0.1U Z1803 10U_10V_1206 +3V1394 C761 C777 C747 C776 C764 C706 C774... -
Page 68: Minipci (Tuner, Wlan, Bt
Schematic Diagrams MINIPCI (TUNER, WLAN, BT) J ANT3 I-pad +VD D5 JANT2 +VDD3 94/7/25 +VDD 3 4,8,13,16,23,29,30,31 R802 I-pad JANT1 Rubband +3V 4,9,10,11,13,14,17,18,20, 21,22,23,24,26,29,32,33 Z1977 +3VS +3VS 2,4,8,9,10,11,12,13,14, 16,18,22,23,24, 25,28,29,32,33,35,36 J CIR1 Z1978 +5V 13,15, 16,21,22,23,29 Z1905 Z1979 +5VS +5VS 8,11,14,16, 22,23,26,28,29,30,33,34, 35,36 CIR_ RX Z1980 +VDD5... -
Page 69: Pci6411, Mcard Con
Schematic Diagrams PCI6411, MCARD CON PC UVC C 5 / 2 0 C h a n g e U30-1 PCI6411GHK VC CP +3V 4,9, 10, 11,13,14,17,18, 19,21,22,23,24,26,29, 32, 33 R743 5 / 2 0 C h a n g e 11,18,19 PCI_AD[0..31] VC CP... -
Page 70: Pcmcia Socket
Schematic Diagrams PCMCIA SOCKET VC C CA VCC CA NEW PART VR _1.5V 20 +3V 4,9,10,11,13,14,17,18, 19,20,22,23, 24,26,29,32,33 +5V 13,15,16,19,22,23, 29 U 30-3 U30-2 VPPC A +12V 8,20,23,26,28,29, 30,32 Z2111 GN D1 T505 VCCB VCCA GN D GN D Z2112 CAD0 GN D2 T506... -
Page 71: Hitachi H8S/2111
A D D R ? ( 1 0 K ) & R ? ( 1 0 K ) & R ? ( 1 0 K ) . P74/AN4 2N70 02 C345 C354 CIR_EN M590K R383 2 2P C277 C276 C275... -
Page 72: Bios, Ccd Con & Fan Con
Schematic Diagrams BIOS, CCD CON & FAN CON +3VS +12V 8,20,21,26,28,29,30,32 +5VS 8,11,14,16,19,22,26,28,29,30,33,34,35,36 94/11/14 PCIRST7# R683 +5V 13,15,16,19,21,22,29 PCIRST7# +3VS 2,4,8,9,10,11,12,13,14,16,18,19,22,24,25,28,29,32,33,35,36 +3VS +3V 4,9,10,11,13,14,17,18,19,20,21,22,24,26,29,32,33 R732 +VDD3 4,8,13,16,19,29,30,31 SOCKET PLCC32 4.7K 5 / 2 0 C h a n g e C752 C744 C701... -
Page 73: Pci-E/Usb New Card
Schematic Diagrams PCI-E/USB NEW CARD +VDD3 4,8,13,16,19,23,29,30,31 +1.5VS 10,14,33,34 +3VS 2,4,8,9,10,11,12,13,14,16,18,19,22,23,25,28,29,32,33,35,36 +3V 4,9,10,11,13,14,17,18,19,20,21,22,23,26,29,32,33 PCIE_WAKE# PCIE_WAKE# 10,17 10,36 PE_RST# NEWCARD_DET# PE2_PRSNT# 10 R854 R695 *TC7SZ08 +1.5VS +3VS 94/7/25 *10K *10K NEW PART Rubband JNEWCARD1 Z2402 AUXIN AUXOUT +3.3VAUX Z2421 Z2403 3.3VIN 3.3VOUT +3.3V Sheet 25 of 45... -
Page 74: Super I/O & Fir
Schematic Diagrams SUPER I/O & FIR +3VS +3VS 2,4,8,9,10,11,12,13,14,16,18,19,22,23,24,28,29,32,33,35,36 F IRVC C 4.7U_0805 +3VS F IR GND L_0805(159) RN 2 RN 1 8P4RX18 8P4RX18 R 58 *4.7K Z 2504 F IR GND 1000P HSDL-360 I RRX I RM O D E Z 2505 2.2K F IR_SEL... -
Page 75: Audio (Alc655) & Mdc
Schematic Diagrams AUDIO (ALC655) & MDC 5 / 2 0 C h a n g e +5VS AUD_5VS Bry an t +5VS 8,11,14,16,19,22,23,28,29,30, 33,34,35,36 +VDD5 D e l C 6 1 8 +3V 4,9,10,11,13,14,17,18,19,20,21,22,23,24,29,32,33 Change Net Name +3VS 2,4,8,9,10,11,12,13,14,16,18,19,22,23,24,25,28,29,32,33,35,36 C619 C618 AUD_VDD 16,27 R327... -
Page 76: Srs Ap8202Q
Schematic Diagrams SRS AP8202Q PIN32 Focus BYPB Low --->ByPas s . AUDIO PROCESSOR PRE-AMP +12V 8,20,21,23,26,28,29,30,32 AUD_VDD 16,26 R318 R297 Sheet 28 of 45 C296 Z2701 Z2729 R562 16,26 FRONT-L LOUT PRE_LOUT 26 C284 Z2702 Z2730 R563 SRS AP8202Q 16,26 FRONT-R PRE_ROUT 26 ROUT... -
Page 77: Sub-Woofer & Dvi Con
Schematic Diagrams SUB-WOOFER & DVI CON +5VS +5VS 8,11,14,16,19,22,23,26,29,30,33,34,35,36 +12V +12V 8,20,21,23,26,29,30,32 +5VH8 +5VH8 22,29,30 +3VS +3VS 2,4,8,9,10,11,12,13,14,16,18,19,22,23,24,25,29,32,33,35,36 Truth table Mute HP Sense Mo de AUD_VDDA1 C657 270P Z2813 R339 10 K Z2814 R590 13K_1% AUD_AGND C651 C263 C628 C658 C633 0.1U 0.1U... -
Page 78: 5Vs, +3Vs, +5V, +3V
Schematic Diagrams +5VS, +3VS, +5V, +3V +VDD3 VA 22,31 +VDD3 4,8,13,16,19,23,30,31 VIN 16,30,31,32,34,36 +3VH8 22 VIN1 30,36 +3V 4,9,10,11,13,14,17,18,19,20,21,22,23,24,26,32,33 +12V 8,20,21,23,26,28,30,32 +3VS 2,4,8,9,10,11,12,13,14,16,18,19,22,23,24,25,28,32,33,35,36 PR29 +5VH8 22,28,30 +1.5VS 10,14,24,33,34 +5V 13,15,16,19,21,22,23 PQ23 +VDD5 9,13,16,19,23,26,30,32,34,36 +3VS +5VS 8,11,14,16,19,22,23,26,28,30,33,34,35,36 AO4422 PQ11 TEST DD_ON# 2N70 02 DD_ON# PQ22... -
Page 79: Vdd5, +Vdd3, +3V, +5V, +1.25V
Schematic Diagrams +VDD5, +VDD3, +3V, +5V, +1.25V PQ39 0.7A +12V+ +12V VIN 16,29,31,32,34,36 6.8uH AO3 409 VIN1 29,36 Z3016 +12V 8,20,21,23,26,28,29,32 SM140A +5VS 8,11,14,16,19,22,23,26,28,29,33,34,35,36 PR110 100K +5VH8 22,28,29 +VDD5 9,13,16,19,23,26, 29,32,34, 36 +VDD5A PR66 PC101 PC52 PC102 Z3062 +VDD3 4,8,13,16,19,23,29,31 GND2 VIN1 174K_1%... -
Page 80: Charger, Bat Con, Pwr Con
Schematic Diagrams CHARGER, BAT CON, PWR CON VA 22,29 VIN 16,29,30,32,34,36 +VDD3 +VDD3 4,8,13,16,19,23,29,30 C897 C898 C899 *15U_25 V_73 43 *1 5U_ 25V_ 734 3 *15 U_25 V_7 343 Cancel PD10 PQ36 2.5A AO4 433 2.5A PD27 PR89 Z3101 Z3123 Z3108 Z3109 PD26... -
Page 81: Vcore
Schematic Diagrams VCORE +3VS 2,4,8,9,10,11, 12, 13,14,16,18,19, 22, 23,24,25,28,29, 33, 35,36 +VDD5 9,13,16, 19,23,26,29,30,34, 36 Reserve For K8-M +3V 4,9,10,11,13,14,17, 18,19,20,21,22,23, 24,26,29,33 VI N 16,29,30,31, 34,36 +12V 8,20,21,23, 26, 28,29,30 1-----LOW POWER TYPE 0-----STANDARD TPYE VCORE 5 35W CPU R156 R155 CPU_VID0 4 CPU_VID1 4... -
Page 82: Power
Schematic Diagrams POWER +5VS 8, 11,14,16,19,22,23,26,28,29,30,34, 35,36 +3V 4,9,10, 11,13,14,17,18,19,20,21,22,23,24,26,29,32 +3VS +3VS 2, 4,8,9,10,11,12,13,14,16,18,19,22,23,24,25,28,29,32,35,36 +12V 8,20,21,23,26,28,29,30, 32 Change By vin 7/28 +VDD5 9,13,16,19,23,26,29,30,32,34,36 +1.5VS 10,14,24,34 C900 0.1U C904 C905 C906 C907 H 8 BE E P +2.5V 3,4,5,6,7,16,30 H 8 BE E P H 8 _ BE E P +3VS H8_BEEP 26... -
Page 83: Vs, +1.8Vs
Schematic Diagrams +1.5VS, +1.8VS C422 C407 C425 PC89 C424 C426 VIN 16,29,30,31,32,36 +VDD5 +VDD5 9,13,16,19,23,26,29,30,32,36 2.2 U_120 6 *10_ 1206 2.2U_1206 10U_25V_DIP 0.1U 0 .01 U +5VS 8,11,14,16,19,22,23,26,28,29,30,33,35,36 R433 +1.5VS 10,14,24,33 +5VS 94/9/26 5 / 2 0 C h a n g e Rubband R633 08-10692-2D0... - Page 84 Schematic Diagrams SATA HDD & CDROM +5VS 8,11,14,16,19,22,23,26,28,29,30,33,34,36 +3VS 2,4,8,9,10,11,12,13,14,16,18,19,22,23,24,25,28,29,32,33,36 94/11/14 Kevin MASTER +3VS 5 / 2 0 C h a n g e A D D J H D D 2 JHDD1 Place 0.01U caps at connector. Z3501 C516 0.01U SLAVE SATATXP0 12...
-
Page 85: Vga Board Connector
Schematic Diagrams VGA Board Connector Master Slaver Z36142 PEG_TXN[ 0.. 15] T346 PEG_TXN[0.. 15] 10 Master Z36143 VIN1 29,30 T347 21-C2Q10-280 PEG_TXP[ 0. .15] VIN 16,29,30,31,32,34 PEG_TXP[ 0. .15] 10 20-C2D20-220 +VDD5 9, 13,16,19, 23,26,29,30,32,34 21-C2Q10-280 +5VS 8,11,14,16, 19,22,23, 26, 28,29,30, 33, 34,35 CON6 PEG_RXN[ 0..15] +3VS 2,4, 8, 9, 10,11,12,13,14,16,18,19, 22,23,24, 25, 28,29,32, 33,35... -
Page 86: Click Board
CTP_RS_L T714 CTP_RS_DWN T715 TPBUTTON_L CON12_85201-1205 CGND ELAN TECH Touchpad 12 pin connector VENDOR PART NUMBER : 800504-2602 CLEVO PART NUMBER : Not apply C+5V 20-94A10-104 CTP_DATA R-A/F 1.0mm UP CTP_CLK 7/28 CJ1 reverse Gary CON1 CGND Click Board Connect TO MB. -
Page 87: Hot Key Board
Schematic Diagrams HOT KEY BOARD HOT KEY BOARD BT SWITCH EMAIL SWITCH WWW SWITCH WLAN SWITCH CCD SWITCH PWR SWITCH HSW3 HSW4 HSW2 HSW1 HSW5 HCCD_SW# HWEB1# HWEB0# HWLAN_SW# HM_BTN# HCH_STS-02 HCH_STS-02 HCH_STS-02 *HCH_STS-02 HCH_STS-02 VGA SPEED SWITCH PIN 5,6=HG ND PIN 5,6 =HGND PIN 5,6 =HGND PIN 5,6 =HG ND... -
Page 88: Phone Jack Board
Schematic Diagrams PHONE JACK BOARD 20-B4040-006 UJSPDIF1 Z3901 AUDIO_J ACK Z3902 PHONE JACK BOARD Z3903 L_0603(129) Z3904 USPDIF1 Z3905 SPDIF OUT 680P 1/20 VIN UGND UGND UGND 20-B4040-006 UJLINEIN1 Z3906 AUDIO_J ACK Z3907 ULINE_R UL10 L_0603(147) Z3908 Z3909 ULINE_L Z3910 UL11 L_0603(147) (B) LINE IN... -
Page 89: Rj11 Board
Schematic Diagrams RJ11 BOARD RJ11 BOARD MH 3 MH 1 MH 5 C55D55 C55D55 M+3VS M+3VS MTH315D107 MTH315D107 BAV9 9 MD 1 MD 2 MGN D MGND MGND MGN D BAV99 BAV99 MH 6 94/9/14 M S_ IO C M S_ IO Y Rubband SO T -2 3 MMDC C 1... -
Page 90: Cd-Rom Board
Schematic Diagrams CD-ROM BOARD +5VCDROM_DD DVD DRV REAR VIEW MASTER TO CDROM DDJCD2 INT_CD_R_1 INT_CD_L_1 Z4108 CD_GND_1 CDD[8]_1 CRESETN_1 CDD[9]_1 CDD[7]_1 CDD[10]_1 CDD[6]_1 CDD[11]_1 CDD[5]_1 CDD[12]_1 CDD[4]_1 CDD[13]_1 CDD[3]_1 CDD[14]_1 CDD[2]_1 CDD[15]_1 CDD[1]_1 CDMARQ_1 CDD[0]_1 CDIORN_1 CDIOWN_1 CDMACKN_1 CIORDY _1 T261 Z4103 CINTRQ_1... -
Page 91: Cir Board
Schematic Diagrams CIR BOARD CIR+VDD5 C.IR GND2 GND2 C858 C859 GND1 GND1 0.1U 10U_0805 CIR_GND Sheet 43 of 45 CIR_GND CIR_GND CIR_GND CIR BOARD 5 / 2 0 C h a n g e CIR+VDD5 JCIR2 CCIR_ RX ACES_85204-0300 CIR_GND C2 7 6 D1 0 7 CIR_GND CIR BOARD B - 43... -
Page 92: Flash Board
Schematic Diagrams FLASH BOARD 20-51100-110 F+3V JDDEBUG1 F+3V FLASH_MD FUD1 TXDD11 FCD1 0.1U Z4201 RXDD11 DTR#D11 4.7K 4.7K 4.7K Z4202 80CLOCK-D Z4205 FCD3 0.47U FCD13 FCD14 80DATA-D FCD2 0.47U Z4203 0.1U 0.1U 1000P DETECT Z4204 Z4206 FCD4 0.47U TXDD11 FR11 TXDD1 TXDD T1IN... -
Page 93: Debug Board
Schematic Diagrams DEBUG BOARD D +5VS D+5VS D +5 VS D C4 D C8 D C3 DC 5 DJ80DEBUG1 0.1U 0.1U 0.1U 0.1U 10U_10V_1206 10U_10V_1206 10U_10V_1206 10U_10V_1206 80DATA-FH 80CLK-FH LPCDETECT 85205-5 D +5VS D +5VS D +5 VS D+5 VS D +5VS D +5 VS D +5 VS D +5 VS... - Page 94 Schematic Diagrams B - 46...
