SERVICE MANUAL
Ver 1.1 2003. 07
Revision History
Revision History
Z MECHANISM
Link
Link
SPECIFICATIONS
SPECIFICATIONS
SERVICE NOTE
SERVICE NOTE
DISASSEMBLY
DISASSEMBLY
• For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (987622441.pdf).
• For MECHANISM ADJUSTMENTS, refer to the "DV MECHANICAL ADJUSTMENT MANUAL
Z MECHANISM " (9-876-210-11).
On the VC-311 board
This service manual provides the information that is premised the circuit board replacement service and not intended repair
inside the VC-311 board.
Therefore, schematic diagram, printed wiring board, waveforms, mounted parts location and electrical parts list of the VC-311
board are not shown.
The following pages are not shown.
Schematic diagram ............................. Pages 4-37 to 4-52
Printed wiring board ............................ Pages 4-73 to 4-76
Waveforms ........................................... Page 4-79 to 4-80
DCR-TRV12E/TRV14E/
BLOCK DIAGRAMS
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
Mounted parts location ............................. Page 4-83
Electrical parts list ................................... Pages 5-21 to 5-24
DIGITAL VIDEO CAMERA RECORDER
TRV19/TRV19E
RMT-814
LEVEL
US Model
Canadian Model
Korea Model
AEP Model
East European Model
North European Model
DCR-TRV12E/TRV14E/TRV19E
UK Model
DCR-TRV14E/TRV19E
Hong Kong Model
DCR-TRV19/TRV19E
Australian Model
Chinese Model
PRINTED WIRING BOARDS
PRINTED WIRING BOARDS
REPAIR PARTS LIST
REPAIR PARTS LIST
2
DCR-TRV19
E Model
DCR-TRV19E

Advertisement

   Related Manuals for Sony DCR-TRV12E

   Summary of Contents for Sony DCR-TRV12E

  • Page 1

    DCR-TRV12E/TRV14E/ TRV19/TRV19E RMT-814 SERVICE MANUAL LEVEL US Model Ver 1.1 2003. 07 Canadian Model Korea Model Revision History Revision History DCR-TRV19 AEP Model East European Model North European Model DCR-TRV12E/TRV14E/TRV19E UK Model DCR-TRV14E/TRV19E E Model Hong Kong Model DCR-TRV19/TRV19E Australian Model...

  • Page 2: Specifications

    CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU PUBLISHED BY SONY.

  • Page 3

    DCR-TRV12E/TRV14E/TRV19/TRV19E • SUPPLIED ACCESSORIES Make sure that the following accessories are supplied with your camcorder. 1 AC-L15A/L15B AC Adaptor (1), Power 8 Shoe cover (1) cord (1) 9 USB cable (1) 2 NP-FM30 rechargeable battery pack q; CD-ROM (USB Driver)

  • Page 4: Table Of Contents

    DCR-TRV12E/TRV14E/TRV19/TRV19E TABLE OF CONTENTS SERVICE NOTE • PD-188 (2/2)(BACKLIGHT DRIVE) SCHEMATIC DIAGRAM ···························· 4-25 1-1. SERVICE NOTE ····························································· 1-1 • JK-242 (A.V/DV IN/OUT) POWER SUPPLY DURING REPAIRS ·························· 1-1 SCHEMATIC DIAGRAM ···························· 4-27 TO TAKE OUT A CASSETTE WHEN NOT EJECT •...

  • Page 5

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5-2. ELECTRICAL PARTS LIST ········································ 5-14 Parts list of the VC-311 board are not shown. Pages from 5-21 to 5-24 are not shown. — 5 —...

  • Page 6: Service Note

    DCR-TRV12E/TRV14E/TRV19/TRV19E SECTION 1 COVER COVER SERVICE NOTE 1-1. SERVICE NOTE POWER SUPPLY DURING REPAIRS In this unit, about 10 seconds after power is supplied to the battery terminal using the regulated power supply (8.4V), the power is shut off so that the unit cannot operate.

  • Page 7: Self-diagnosis Function

    DCR-TRV12E/TRV14E/TRV19/TRV19E 1-2. SELF-DIAGNOSIS FUNCTION SELF-DIAGNOSIS FUNCTION SELF-DIAGNOSIS DISPLAY When problems occur while the unit is operating, the self-diagnosis When problems occur while the unit is operating, the counter of the function starts working, and displays on the viewfinder, or LCD viewfinder or LCD screen consists of an alphabet and 4-digit number, screen what to do.

  • Page 8: Self-diagnosis Code Table

    DCR-TRV12E/TRV14E/TRV19/TRV19E SELF-DIAGNOSIS CODE TABLE Self-diagnosis Code Block Detailed Symptom/State Correction Function Code Non-standard battery is used. Use the info LITHIUM battery. Condensation. Remove the cassette, and insert it again after one hour. Video head is dirty. Clean with the optional cleaning cassette.

  • Page 9: Disassembly

    DCR-TRV12E/TRV14E/TRV19/TRV19E SECTION 2 COVER COVER HELP HELP DISASSEMBLY The following flow chart shows the disassembly procedure. DISASSEMBLY PD-188 board service position DISASSEMBLY HELP DISASSEMBLY SERVICE POSITION TO CHECK THE VTR SECTION DISASSEMBLY HELP DISASSEMBLY DISASSEMBLY HELP DISASSEMBLY DISASSEMBLY DISASSEMBLY HELP...

  • Page 10

    DCR-TRV12E/TRV14E/TRV19/TRV19E NOTE: Follow the disassembly procedure in the numerical order given. [CONNECTION OF EQUIPMENT] LANC jack AC power Adjustment remote AC IN adaptor commander (RM-95) DC-IN connector CPC lid Screw (M1.7 × 4), CPC-7 jig lock ace, p2 (J-6082-382-A)

  • Page 11: P Cabinet (c) Assembly

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-1. P CABINET (C) ASSEMBLY Turn the Turn the LCD panel LCD panel Caution Rotation of the LCD panel has limitation due to its hinge in this model. Excessive force to rotate the LCD panel damages the hinge. Follow the precaution below.

  • Page 12: Cabinet (r) Cover (39e) Assembly

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-2. CABINET (R) COVER (39E) ASSEMBLY Raise the Finder in the Two screws (M1.7 × 6), direction of the arrow lock ace, p2 Screw (M1.7 × 3), lock ace, p2 Two screws (M1.7 × 3), lock ace, p2 Open the LCD panel...

  • Page 13: F Panel Section

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-3. F PANEL SECTION Screw (M1.7 × 4), lock ace, p2 Open the Cassette lid Screw (M1.7 × 4), lock ace, p2 Screw (M1.7 × 4), lock ace, p2 Remove the claw Remove the F panel section in the direction of the arrow...

  • Page 14

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-4. MA-421 BOARD Remove the MA-421 board in the way of twisting it in the direction of the arrow 9 HP sheet Microphone Microphone retainer Microphone (4P) Tapping screw (M1.7 × 5) MA cover, MA cover cushion MA-421 board Two tapping screws (M1.7 ×...

  • Page 15: Cabinet (r) Section

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-5. CABINET (R) SECTION Screw (M1.7 × 4), lock ace, p2 Screw (M1.7 × 4), lock ace, p2 Two screws (M1.7 × 4), Three screws (M1.7 × 4), lock ace, p2 lock ace, p2 FP-618 flexible board (16P) Remove the Cabinet R section...

  • Page 16: Lcd Section

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-6. LCD SECTION Caution Attach the Tape (A) as shown in the illustration. LCD section Two tapping screws (M1.7 × 5) Cabinet R section Tape (A) Harness (PV-140) (4P) FP-626 flexible board (6P) Tape (A) 2-7. CK-129 BOARD, CONTROL SWITCH BLOCK (CF-CX4000)

  • Page 17: Pd-188 Board, Lcd Unit

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-8. PD-188 BOARD, LCD UNIT Four claws Two screws (M1.7 × 4), lock ace, p2 P cabinet (C) assembly (M) Caution When remove the Harness (PV-140), be careful to damage the Harness (PV-140). Harness (PV-140) (20P, 40P) Tapping screw (M1.7 ×...

  • Page 18: Hinge (40) Assembly

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-9. HINGE (40) ASSEMBLY Caution Rotation of the LCD panel has limitation due to its hinge in this model. Excessive force to rotate the LCD panel damages the hinge. (Refer to "Caution"of 2.1 Pcabinet assembly.) Rotate to the "A" marked portion...

  • Page 19: Bt Panel/evf Section

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-10. BT PANEL/EVF SECTION BT panel/EVF section FP-619 flexible board Screw (20P) (M1.7 × 4), lock ace, p2 Two screws (M1.7 × 4), lock ace, p2 Battery terminal board (3P) 2-11...

  • Page 20: Board (removing Of The Evf)-1

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-11. LB-085 BOARD (REMOVING OF THE EVF)-1 Caution When installing the EVF flexible retainer, please be sure to install it while the viewfinder is kept pushed up to attach. Finder EVF flexible retainer Caution When installing, pass the FP-619 flexible...

  • Page 21: Board (removing Of The Evf)-2

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-12. LB-085 BOARD (REMOVING OF THE EVF)-2 Visiblity knob (40) VF slide cabinet (upper) assembly To raise the VF slide cabinet (upper) Tapping screw assembly, insert a flat head (M1.7 × 3.5) (-) screwdriver into the position shown by the arrow.

  • Page 22: Board (removing Of The Evf)-3

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-13. LB-085 BOARD (REMOVING OF THE EVF)-3 Two screws (M1.7 × 2.5), lock ace, p2 Pull out the VF slide assembly fully in the direction of the arrow. VF slide Cabinet (upper) assembly VF slide assembly, etc. 3 Slide the VF slide cabinet assembly and others once...

  • Page 23: Va-118 Board, Lens Section

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-14. VA-118 BOARD, LENS SECTION Caution Caution Fold the harness of the control switch When attach the Tape (A), fold the FP-620 block (FK-CX4000) toward the board as flexible board as shown in the illustration. shown in the illustration.

  • Page 24: Mechanism Deck, Vc-312 Board (1)

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-15. CD-430 BOARD q; CD-430 board Two tapping screws Lens frame (39) assembly optical filter block (M1.7 × 5) Seal rubber (W) Two tapping screws 8 CCD block (M1.7 × 3.5) assembly 9 Remove soldering FP-623 flexible board (14P) Lens device LSV-650E 2-16.

  • Page 25: Mechanism Deck, Vc-312 Board (2)

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-17. MECHANISM DECK, VC-311 BOARD (2) Flexible board (from the capstan motor) (27P) Flexible board (from the FP-468 flexible board) (27P) Flexible board (from the drum motor) (10P) Flexible board (from the video head) (10P) Claw VC-311board q; Mechanism deck...

  • Page 26: Control Switch Block (fk-cx4000)

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-19. CONTROL SWITCH BLOCK (FK-CX4000) Caution FK flexible retainer When installing, fix the flexible board of the Control switch block (FK-CX4000) with the FK flexible retainer as shown in the illustration. Control switch block (FK-CX4000) FK flexible retainer Screw (M1.7 ×...

  • Page 27

    DCR-TRV12E/TRV14E/TRV19/TRV19E [SERVICE POSITION TO CHECK THE VTR SECTION] Connection to Check the VTR Section To check the VTR section, set the VTR to the “Forced VTR power ON” mode. Operate the VTR functions using the adjustment remote commander (with the HOLD switch set in the OFF position).

  • Page 28: Circuit Boards Location

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-21. CIRCUIT BOARDS LOCATION LB-085 CD-430 JK-242 VC-311 VA-118 MA-421 CK-129 PD-188 NAME FUNCTION CD-430 CCD IMAGER CK-129 FUNCTION SWITCH JK-242 RELAY LB-085 EVF, BACKLIGHT MA-421 MIC AMP, Y/P SENSOR, V/A IN/OUT PD-188 RGB DRIVE, TIMING GENE, BACKLIGHT VA-118 RGB DRIVE, HI CONTROL, Y/P SENSOR AMP, POWER IN, CHARGE, CONNECTOR CAMERA A/D CONV., TIMING GENERATOR, IRIS/FOCUS/ZOOM DRIVE,...

  • Page 29: Flexible Boards Location

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2-22. FLEXIBLE BOARDS LOCATION The flexible boards contained in the mechanism deck and that in the lens device are not shown. CONTROL SWITCH BLOCK (FK-CX4000) FP-620 CONTROL SWITCH BLOCK (CF-CX4000) FP-618 FP-621 FP-623 FP-626 FP-619 FP-625 2-21E...

  • Page 30

    DCR-TRV12E/TRV14E/TRV19/TRV19E 24/Feb/2003 HELP Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown. OVERALL SECTION -1 FK flexible retainer Flexible board FP-618 flexible board FP-620 flexible board Tape (A) VA-118 board VA-118 board VA-118 board Harness of the Control...

  • Page 31

    DCR-TRV12E/TRV14E/TRV19/TRV19E OVERALL SECTION -2 Flexible cover Harness CABINET R SECTION Tape (A) BT PANEL/EVF SECTION Flexible board of the LCX032AN-5 Sheet (VF) VF hinge assembly FP-619 flexible board FP-619 flexible board EVF flexible retainer FP-619 Sheet (VF) flexible board HELP...

  • Page 32

    DCR-TRV12E/TRV14E/TRV19/TRV19E CABINET L SECTION Z sheet HP, sheet Headphone jack MA-421 boarf HELP...

  • Page 33: Block Diagrams

    DCR-TRV12E/TRV14E/TRV19/TRV19E COVER COVER 3. BLOCK DIAGRAMS Link Link OVERALL BLOCK DIAGRAM (1/4) POWER BLOCK DIAGRAM (1/2) OVERALL BLOCK DIAGRAM (1/4) POWER BLOCK DIAGRAM (1/2) OVERALL BLOCK DIAGRAM (2/4) POWER BLOCK DIAGRAM (2/2) OVERALL BLOCK DIAGRAM (2/4) POWER BLOCK DIAGRAM (2/2)

  • Page 34

    DCR-TRV12E/TRV14E/TRV19/TRV19E SECTION 3 3. BLOCK DIAGRAMS 3. BLOCK DIAGRAMS COVER COVER BLOCK DIAGRAMS ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located. 3-1. OVERALL BLOCK DIAGRAM (1/4) CD-430 BOARD...

  • Page 35

    DCR-TRV12E/TRV14E/TRV19/TRV19E 3. BLOCK DIAGRAMS 3. BLOCK DIAGRAMS COVER COVER ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located. 3-2. OVERALL BLOCK DIAGRAM (2/4) VA-118 BOARD(2/4) PD-188 BOARD(1/2) CN1002 CN4004...

  • Page 36

    DCR-TRV12E/TRV14E/TRV19/TRV19E 3. BLOCK DIAGRAMS 3. BLOCK DIAGRAMS COVER COVER 3-3. OVERALL BLOCK DIAGRAM (3/4) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located. CN1004 Z MECHA DECK FOR ADJUSTMENTS...

  • Page 37

    DCR-TRV12E/TRV14E/TRV19/TRV19E 3. BLOCK DIAGRAMS 3. BLOCK DIAGRAMS COVER COVER ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located. 3-4. OVERALL BLOCK DIAGRAM (4/4) VC-311 BOARD(4/4) CK-129 BOARD VA-118 BOARD(4/4)

  • Page 38

    DCR-TRV12E/TRV14E/TRV19/TRV19E 3. BLOCK DIAGRAMS 3. BLOCK DIAGRAMS COVER COVER 3-5. POWER BLOCK DIAGRAM (1/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located. VA-118 BOARD D 2.8V (3/5) R400,4005...

  • Page 39

    DCR-TRV12E/TRV14E/TRV19/TRV19E 3. BLOCK DIAGRAMS 3. BLOCK DIAGRAMS COVER COVER ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located. 3-6. POWER BLOCK DIAGRAM (2/2) MA-421 BOARD PD-188 BOARD LCD901 2.5 INCH CN5402 EP 4.6V...

  • Page 40: Printed Wiring Boards And Schematic Diagrams

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER SECTION 4 PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS 4-1. FRAME SCHEMATIC DIAGRAM (1/3) CN5001 CN1401 MECHANISM DECK(Z100) IMAGER TO CAPSTAN MOTOR TO SENSOR,LOADING MOTOR...

  • Page 41: Frame Schematic Diagram (1/3)

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER FRAME SCHEMATIC DIAGRAM (2/3) VC-311(960H) BOARD 2/2 B TO B VA-118 BOARD 1/2 FP-620 FP-619 FLEXIBLE FLEXIBLE FP-621 FLEXIBLE INTELLIGENT ACCESSORY SHOE BT901...

  • Page 42: Frame Schematic Diagram (3/3)

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER FRAME SCHEMATIC DIAGRAM (3/3) CK-129 BOARD CN5207 REG_GND CONTROL N.C. SWITCH KEY_AD1 BLOCK BATT_INFO_SW (CF-CX4000) EVER_3.0V XCHARGE_LED BT5201 (LITHIUM BATTERY) CN5209 REG_GND REG_GND...

  • Page 43: Schematic Diagrams

    DCR-TRV12E/TRV14E/TRV19/TRV19E COVER COVER 4-2. SCHEMATIC DIAGRAMS Link Link CD-430 BOARD PD-188 BOARD (1/2) CD-430 BOARD PD-188 BOARD (1/2) (CCD IMAGER) (CCD IMAGER) (DRIVER, TG) (DRIVER, TG) LB-085 BOARD PD-188 BOARD (2/2) LB-085 BOARD (EVF, BACK LIGHT) PD-188 BOARD (2/2) (BACKLIGHT DRIVE)

  • Page 44: Schematic Diagram

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS COVER COVER THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS (In addition to this, the necessary note is printed in each block) (For schematic diagrams) 1. Connection • All capacitors are in µF unless otherwise noted. pF : µ...

  • Page 45

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS CD-430 BOARD CD-430 BOARD LB-085 BOARD LB-085 BOARD COVER COVER For Schematic Diagram 4-2. SCHEMATIC DIAGRAMS • Refer to page 4-55 for printed wiring board of CD-430 board. • Refer to page 4-57 for printed wiring board of LB-085 board.

  • Page 46

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS VA-118 BOARD SIDE A VA-118 BOARD SIDE A VA-118 BOARD SIDE B VA-118 BOARD SIDE B COVER COVER For Schematic Diagram • Refer to page 4-61 for printed wiring board. VA-118 BOARD(1/5) RGB DRIVE,TG(EVF BLOCK) EP_4.6V...

  • Page 47

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS VA-118 BOARD SIDE A VA-118 BOARD SIDE A VA-118 BOARD SIDE B VA-118 BOARD SIDE B COVER COVER For Schematic Diagram • Refer to page 4-61 for printed wiring board. VA-118 BOARD(2/5) NO MARK:REC/PB MODE...

  • Page 48

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS VA-118 BOARD SIDE A VA-118 BOARD SIDE A VA-118 BOARD SIDE B VA-118 BOARD SIDE B COVER COVER For Schematic Diagram • Refer to page 4-61 for printed wiring board. CN4004 100P B TO B...

  • Page 49

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS VA-118 BOARD SIDE A VA-118 BOARD SIDE A VA-118 BOARD SIDE B VA-118 BOARD SIDE B COVER COVER For Schematic Diagram • Refer to page 4-61 for printed wiring board. VA-118 BOARD(4/5) BATT_UNREG...

  • Page 50

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS VA-118 BOARD SIDE A VA-118 BOARD SIDE A VA-118 BOARD SIDE B VA-118 BOARD SIDE B COVER COVER For Schematic Diagram • Refer to page 4-61 for printed wiring board. VA-118 BOARD(5/5) POWER IN,CHARGE(FU BLOCK)

  • Page 51

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS CK-129 PRINTED WIRING BOARD CK-129 PRINTED WIRING BOARD COVER COVER For Schematic Diagram • Refer to page 4-65 for printed wiring board. CK-129 BOARD FUNCTION SWITCH XX MARK:NO MOUNT CN5208 CN5210 TP_TOP LI_3V...

  • Page 52

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS PD-188 PRINTED WIRING BOARD PD-188 PRINTED WIRING BOARD COVER COVER For Schematic Diagram • Refer to page 4-67 for printed wiring board. PD-188 BOARD(1/2) DRIVER,TG(RGB/TG BLOCK) XX MARK:NO MOUNT Q6004 NO MARK:REC/PB MODE...

  • Page 53

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS PD-188 PRINTED WIRING BOARD PD-188 PRINTED WIRING BOARD COVER COVER For Schematic Diagram • Refer to page 4-67 for printed wiring board. PD-188 BOARD(2/2) BACKLIGHT DRIVE(BL BLOCK) XX MARK:NO MOUNT NO MARK:REC/PB MODE...

  • Page 54

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS JK-242 PRINTED WIRING BOARD JK-242 PRINTED WIRING BOARD COVER COVER For Schematic Diagram • Refer to page 4-69 for printed wiring board. JK-242 BOARD A.V/DV IN/OUT XX MARK:NO MOUNT FB5301 J5301 AUDIO/VIDEO OUT...

  • Page 55

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER CONTROL SWITCH BLOCK (FK-CX4000) XX MARK:NO MOUNT S071 PHOTO LOCK RV001 (PHOTO FREEZE) (ZOOM) (PHOTO REC) CN1004 LND001 N.C. LND002 XPHOTO_FREEZE LND003 KEY_AD0...

  • Page 56

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS MA-421 PRINTED WIRING BOARD MA-421 PRINTED WIRING BOARD COVER COVER For Schematic Diagram • Refer to page 4-71 for printed wiring board. R5528 MA-421 BOARD(1/2) R5501 R5502 C5535 C5537 2200 2700 0.047u 0.047u...

  • Page 57

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS MA-421 PRINTED WIRING BOARD MA-421 PRINTED WIRING BOARD COVER COVER For Schematic Diagram • Refer to page 4-71 for printed wiring board. MA-421 BOARD(2/2) Y/P SENSOR,V/A IN/OUT CN5402 XX MARK:NO MOUNT XS_JACK_IN XS_JACK_IN...

  • Page 58: Pages From 4-37 To 4-52 Are Not Shown

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS FP-467, FP-468, FP-228 FLEXIBLE BOARD FP-467, FP-468, FP-228 FLEXIBLE BOARD COVER COVER For Schematic Diagram • Refer to page 4-59 for flexible wiring board. (PAGE 4-45 of LEVEL 3) TO VC-311 BOARD(5/8) CN2502...

  • Page 59: Printed Wiring Boards

    DCR-TRV12E/TRV14E/TRV19/TRV19E COVER COVER 4-3. PRINTED WIRING BOARDS Link Link CD-430 BOARD VA-118 BOARD (SIDE B) CD-430 BOARD VA-118 BOARD (SIDE B) LB-085 BOARD CK-129 BOARD LB-085 BOARD CK-129 BOARD FP-626 FLEXIBLE BOARD PD-188 BOARD FP-626 FLEXIBLE BOARD PD-188 BOARD FP-467/468/228 FLEXIBLE BOARD (MD BLOCK)

  • Page 60

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER THIS NOTE IS COMMON FOR WIRING BOARDS (In addition to this, the necessary note is printed in each block) (For printed wiring boards) • Chip parts. • : Uses unleaded solder.

  • Page 61: Printed Wiring Board

    DCR-TRV12E/TRV14E/TRV19/TRV19E MOUNTED PARTS LOCATION 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION COVER COVER 4-3. PRINTED WIRING BOARDS • : Uses unleaded solder. CD-430 (CCD IMAGER) PRINTED WIRING BOARD • Refer to page 4-53 for common note for printed wiring board.

  • Page 62

    DCR-TRV12E/TRV14E/TRV19/TRV19E MOUNTED PARTS LOCATION 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION COVER COVER LB-085 (EVF, BACK LIGHT) PRINTED WIRING BOARD • : Uses unleaded solder. • Refer to page 4-53 for common note for printed wiring board.

  • Page 63

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER FP-467/468/228 FLEXIBLE WIRING BOARD (MD BLOCK) • : Uses unleaded solder. FP-626 FLEXIBLE WIRING BOARD • Refer to page 4-53 for common note for printed wiring board.

  • Page 64

    DCR-TRV12E/TRV14E/TRV19/TRV19E MOUNTED PARTS LOCATION 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION COVER COVER VA-118 (RGB DRIVE, TG, HI CONTROL, Y/P SENSOR AMP, CONNECTOR, DC/DC COVERTER, POWER IN, CHARGE) PRINTED WIRING BOARD •...

  • Page 65

    DCR-TRV12E/TRV14E/TRV19/TRV19E MOUNTED PARTS LOCATION 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION COVER COVER • : Uses unleaded solder. • Refer to page 4-53 for common note for printed wiring board.

  • Page 66

    DCR-TRV12E/TRV14E/TRV19/TRV19E MOUNTED PARTS LOCATION 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION COVER COVER CK-129 (FUNCTION SWITCH) PRINTED WIRING BOARD • : Uses unleaded solder. • Refer to page 4-53 for common note for printed wiring board.

  • Page 67

    DCR-TRV12E/TRV14E/TRV19/TRV19E MOUNTED PARTS LOCATION 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION COVER COVER PD-188 (DRIVER, TG, BACKLIGHT DRIVE) PRINTED WIRING BOARD • : Uses unleaded solder. • Refer to page 4-53 for common note for printed wiring board.

  • Page 68: A.v/dv In/out)

    DCR-TRV12E/TRV14E/TRV19/TRV19E MOUNTED PARTS LOCATION 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION COVER COVER JK-242 (A.V/DV IN/OUT) PRINTED WIRING BOARD • : Uses unleaded solder. • Refer to page 4-53 for common note for printed wiring board.

  • Page 69: Pages From 4-73 To 4-76 Are Not Shown

    DCR-TRV12E/TRV14E/TRV19/TRV19E MOUNTED PARTS LOCATION 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION COVER COVER MA-421 (MIC AMP, Y/P SENSOR, V/A IN/OUT) PRINTED WIRING BOARD • : Uses unleaded solder. • Refer to page 4-53 for common note for printed wiring board.

  • Page 70: Waveforms

    DCR-TRV12E/TRV14E/TRV19/TRV19E CD-430 BOARD CD-430 BOARD VA-118 BOARD SIDE A VA-118 BOARD SIDE A VA-118 BOARD SIDE B VA-118 BOARD SIDE B PD-188 BOARD PD-188 BOARD COVER COVER 4-4. WAVEFORMS CD-430 VA-118 PD-188 BOARD CAMERA REC BOARD BOARD REC/PB IC5001 1,2...

  • Page 71: Mounted Parts Location

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER 4-5. MOUNTED PARTS LOCATION no mark : side A * mark : side B CD-430 BOARD LB-085 BOARD VA-118 BOARD * C5001 * C5601 * C4001 C4538 * L4513...

  • Page 72: Is Not Shown

    DCR-TRV12E/TRV14E/TRV19/TRV19E 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER no mark : side A * mark : side B CK-129 BOARD PD-188 BOARD JK-242 BOARD MA-421 BOARD * BT5201 C-1 C6001 R6020 CN5301 A-3 C5402 J5401 C6002 R6021...

  • Page 73: Repair Parts List

    DCR-TRV12E/TRV14E/TRV19/TRV19E COVER COVER NOTE NOTE 5. REPAIR PARTS LIST NOTE: Characters A to Z of the electrical parts list indicate location of exploded views in which the desired part is shown. EXPLODED VIEWS EXPLODED VIEWS Link Link OVERALL SECTION F PANEL SECTION...

  • Page 74

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER NOTE: • -XX, -X mean standardized parts, so they may have some differences from When indicating parts by reference number, the original one. please include the board name. •...

  • Page 75

    Remarks Ref. No. Part No. Description Remarks X-3953-088-1 CAP ASSY, LENS 4-942-636-01 EMBLEM (NO.3.5), SONY 3-989-735-81 SCREW (M1.7), LOCK ACE, P2 3-989-735-51 SCREW (M1.7), LOCK ACE, P2 3-080-571-01 COVER, SHOE 3-080-421-01 BUTTON, CF (TRV19/TRV19E) 3-056-030-81 SCREW (M1.7), LOCK ACE, P2...

  • Page 76

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-2. F PANEL SECTION ns : not supplied MIC901 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-080-516-01 COVER, S TERMINAL A-7013-812-A MA-421 (MSNASHI) BOARD, COMPLETE...

  • Page 77

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-3. MAIN CHASSIS SECTION ns : not supplied Cabinet (L) section (See page 5-7) Mechanism deck (See page 5-11, 5-13) Lens section (See page 5-6) Ref. No. Part No.

  • Page 78

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-4. LENS SECTION IC5001 Be sure to read “Precautions upon replacing CCD imager” on page 4-9 when changing the CCD imager. Ref. No. Part No. Description Remarks Ref. No.

  • Page 79

    Ver 1.1 2003. 07 DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-5. CABINET L SECTION ns : not supplied Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks X-3953-220-1 CABINET (G) ASSY (39V) (TRV19/TRV19E)

  • Page 80

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-6. BT PANEL/EVF SECTION ns : not supplied LCD902 BT901 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-080-420-01 CABINET, VF TILT 3-080-617-01 CABINET (LOWER), VF SLIDE X-3953-118-1 SLIDE ASSY, VF 3-713-791-11 SCREW (M1.7X5), TAPPING, P2...

  • Page 81

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-7. CABINET R SECTION ns : not supplied LCD section (See page 5-10) SP901 : BT5201 (Lithium battery) CK-129 board on the mount position. (See page 4-65) CAUTION : Danger of explosion if battery is incorrectly replaced.

  • Page 82

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-8. LCD SECTION S101 LCD901 ND901 CAUTION : Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. Ref. No. Part No. Description Remarks Ref.

  • Page 83

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-9. OVERALL (MECHANISM DECK-Z100) M901 LS chassis block assembly (See page 5-12) Mechancal chassis block assembly (See page 5-13) Ref. No. Part No. Description Remarks Ref. No. Part No.

  • Page 84

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-10. LS CHASSIS BLOCK ASSEMBLY ns : not supplied MIC902 Q901 FP-468 D901 (Note) H901 Q902 H902 S903 Note: FP-468 is included in the LS block assy and is attached to chassis by hot-press.

  • Page 85

    DCR-TRV12E/TRV14E/TRV19/TRV19E 5. REPAIR PARTS LIST 5. REPAIR PARTS LIST COVER COVER 5-1-11. MECHANICAL CHASSIS BLOCK ASSEMBLY ns : not supplied M902 S902 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-079-314-01 SPRING (EJ), EXTENSION 3-079-308-01 SHAFT, WORM...

  • Page 86: Electrical Parts List

    DCR-TRV12E/TRV14E/TRV19/TRV19E CD-430 CK-129 FP-626 JK-242 LB-085 5-2. ELECTRICAL PARTS LIST Ref. No. Part No. Description Ref. No. Part No. Description A-7013-526-A CD-430 BOARD, COMPLETE 1-687-550-11 FP-626 FLEXIBLE BOARD, COMPLETE ********************** ****************************** (IC5001 is not included in this complete board.) S101 1-771-039-31 SWITCH, PUSH(PANEL REVERSE) <...

  • Page 87

    DCR-TRV12E/TRV14E/TRV19/TRV19E LB-085 MA-421 Ref. No. Part No. Description Ref. No. Part No. Description < TRANSISTOR > FB5406 1-500-444-11 FERRITE FB5407 1-500-444-11 FERRITE Q5602 8-759-054-48 TRANSISTOR UP04601008S0 FB5408 1-500-444-11 FERRITE FB5409 1-500-444-11 FERRITE < RESISTOR > FB5410 1-500-444-11 FERRITE R5602 1-218-947-11 RES-CHIP...

  • Page 88

    DCR-TRV12E/TRV14E/TRV19/TRV19E MA-421 PD-188 Ref. No. Part No. Description Ref. No. Part No. Description < VARISTOR > < IC > VD5401 1-801-862-11 VARISTOR, CHIP(1608) IC6001 8-752-109-08 IC CXA3289BR-T4 VD5402 1-801-862-11 VARISTOR, CHIP(1608) IC6002 8-752-407-33 IC CXD3512R-T4 VD5403 1-801-923-11 VARISTOR, CHIP(1608) IC6101...

  • Page 89

    DCR-TRV12E/TRV14E/TRV19/TRV19E PD-188 VA-118 Ref. No. Part No. Description Ref. No. Part No. Description < TRANSFORMER > C4509 1-125-777-11 CERAMIC CHIP 0.1uF C4510 1-164-934-11 CERAMIC CHIP 330PF 0 T6101 1-435-786-31 TRANSFORMER, INVERTER C4511 1-125-777-11 CERAMIC CHIP 0.1uF ************************************************************ C4512 1-165-908-91 CERAMIC CHIP...

  • Page 90

    DCR-TRV12E/TRV14E/TRV19/TRV19E VA-118 Ref. No. Part No. Description Ref. No. Part No. Description < CONNECTOR > L4508 1-469-524-91 INDUCTOR 4.7uH L4509 1-469-524-91 INDUCTOR 4.7uH CN4001 1-691-374-11 CONNECTOR, FFC/FPC 10P L4510 1-469-757-21 INDUCTOR 10uH CN4002 1-766-613-21 CONNECTOR, FFC/FPC 36P L4511 1-469-524-91 INDUCTOR 4.7uH...

  • Page 91

    DCR-TRV12E/TRV14E/TRV19/TRV19E VA-118 Ref. No. Part No. Description Ref. No. Part No. Description < RESISTOR > R4512 1-218-965-11 RES-CHIP 1/16W R4513 1-218-971-11 RES-CHIP 1/16W R4002 1-218-953-11 RES-CHIP 1/16W R4514 1-218-972-11 RES-CHIP 1/16W R4004 1-216-009-91 RES-CHIP 1/10W R4515 1-218-953-11 RES-CHIP 1/16W R4005...

  • Page 92

    DCR-TRV12E/TRV14E/TRV19/TRV19E VA-118 VC-311 Ref. No. Part No. Description Ref. No. Part No. Description < VIBRATOR > X4101 1-760-458-21 VIBRATOR, CRYSTAL(32.768KHZ) X4102 1-795-244-11 VIBRATOR, CERAMIC(10MHz) ************************************************************ A-7016-786-A VC-311(DVO)BOARD, COMPLETE (TRV12E/TRV14E) ************************************** A-7016-562-A VC-311(DVIO)BOARD, COMPLETE (TRV19/TRV19E) ************************************** ************************************************************ Electrical parts list of the VC-311 board are not shown.

  • Page 93

    (US, CND model) (not supplied) 0 1-790-107-22 Power cord (Main lead)(1) Wireless Remote Commander (1) (KR model) (RMT-814E) 0 1-776-985-11 1-475-141-61 (EXCEPT DCR-TRV12E) USB cable (1) Shoe cover (1) 1-823-931-11 3-080-571-01 CD-ROM Cleaning cloth (1) 21-pin adaptor (1) 2-pin conversion adaptor (1)

  • Page 94

    DCR-TRV12E/TRV14E/TRV19/TRV19E 2003G1600-1 Sony EMCS Co. 9-876-224-31 ©2003.7 — 130 — Published by DI CS Strategy Div.

  • Page 95: Revision History

    Reverse 987622432.pdf Revision History S.M. Rev. Ver. Date History Contents issued 2003.03 Official Release — — 2003.07 Correction-1 Correction of the Parts No. S.M. correction: Page...

This manual also for:

Dcr-trv14e, Dcr-trv19, Dcr-trv19e
