OPERATING INSTRUCTIONS
1. IMPORTANT: Always operate the compressor at or below the MAXIMUM PRESSURE RATING of
the compressor. Please refer to Application & Specifications Sections of this manual for details.
2. Always observe the MAXIMUM DUTY CYCLE of the air compressor. Refer to Compressor
Applications and Specifications Sections of this manual for details. Operation exceeding
maximum pressure ratings and/or duty cycle will result in damage to the air compressor.
3. Your air compressor is equipped with an AUTOMATIC THERMAL OVERLOAD PROTECTOR.
This feature is designed to protect the air compressor from overheating and causing permanent
damage to your air compressor. The thermal overload protector will automatically cut power to
your air compressor should the internal operating temperature of the air compressor rise above
safe levels during excessive use.
4. Should at any time during use, your air compressor automatically shuts off; do not attempt to
restart the air compressor. Turn off power and allow unit to cool for about 30 minutes. This will
allow the Thermal Overload Protector to reset so you can safely resume use of the air compressor.
5. To prevent discharge of battery (power source), always supply charging voltage to enhance
performance. (12-volt charging voltage up to 14.4 volts & 24-volt charging voltage up to 28 volts).
6. Only operate compressor in well ventilated areas.
7. The use of a relay is strongly recommended for installation of this compressor.
(60-amp relay value or higher).
MAINTENANCE & REPAIRS
1. Periodically check all electrical and fittings connections. Clean and tighten as needed.
2. Periodically check all mounting screws. Tighten as needed.
3. Replace air filter element periodically. Replacement frequency depends on operating frequency and
operating environment. For frequent use in dusty environment, we recommend that you replace air
filter element at least once a month.
4. Regularly clean dust and dirt from compressor cooling fins and motor housing.
5. Your air compressor is equipped with a permanently lubricated, maintenance free motor.
Never try to lubricate the compressor.
6. All repairs should be performed by Manufacturer or Manufacturer's Authorized Service Agent only.
CAUTION:
Never touch the air compressor or fittings connected to the air compressor with bare hands during
or immediately after use. The leader hose and fittings connected to leader hose will become very
HOT during and after use. If necessary, wear heat resistant gloves to handle fittings, air line, and
leader hose.
SPECIFICATIONS
• Part No. 33050 / 330C-IG-12V Compressor Kit
Motor Voltage:
Max. Current Consumption:
Motor Type:
Horsepower:
Max. Working Pressure:
Max. Duty Cycle (@ 72°F & 100 PSI):
Minutes On/Off (@ 72°F & 100 PSI):
Max. Restart Pressure:
Max. Ambient Temperature:
Min. Ambient Temperature:
Auto. Reset Thermal Protection:
Dimensions:
Net Weight:
330C-IG - 450C-IG COMPRESSOR KIT
12 Volts
12 Amps
Permanent Magnetic
1/4
150 PSI
100%
Continuous
200 PSI
158°F
-40°F
Yes
8.86"L x 4"W x 6.75H"
8.25 Lbs.
USER MANUAL
(CE Spec.)
