Getting to know the FD100

Port connections

The pictures show an FD100
the FD100
pads, check readers and contactless readers.
Phone (blue)
➔
For dial-up transactions using a phone line.
USB (gray) and Serial (green)
➔
You may connect additional peripherals to the USB or COM
ports, such as the FD-10 or FD-10C PIN Pads, and/or the
FD-30 PIN Pad or Vivopay
and/or MagTek
Ethernet (yellow)
➔
For Internet transactions using Cable or DSL.
4
ETHERNET
terminal enable you to add peripherals such as PIN
Ti
MiniMICR Check Reader.
®
USB COM1
terminal. The ports on the back of
Ti
4500 Contactless Readers,
®
PHONE
Ti
