Operator's Manual
Read these instructions carefully and make sure
you understand them before using the 150D.
Manual del operador
Lea cuidadosamente estas instrucciones y asegúrese
de que las comprende bien antes de usar el 150D.
Manuel d'utilisation
Veuillez lire attentivement ces instructions et assurez-vous de
bien les comprendre avant d'utiliser la machine modèle 150D
150D

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna 150D

Summary of Contents for Husqvarna 150D

  • Page 1 150D. Manual del operador Lea cuidadosamente estas instrucciones y asegúrese de que las comprende bien antes de usar el 150D. Manuel d’utilisation Veuillez lire attentivement ces instructions et assurez-vous de bien les comprendre avant d’utiliser la machine modèle 150D...

  • Page 2: Table Of Contents

    Unpacking ..........techniques. Discard or recycle the packing material per your Transporting ..........regional laws. In your container will be the 150D saw, a blade Sound Data ..........shaft cover, two (2) blade shaft wrenches, spark plug wrench, an owner’s manual, an engine owner’s manual, a part list, a ntroduction, personal safety ......

  • Page 3: I Ntroduction, Personal Safety

    It was also designed to be economical and durable. The 150D has a low noise, low vibration Robin engine and is ideal for large and small jobs alike. This saw is set up to handle the full line of Husqvarna ProEdge beveled blades, which create a “Tooled Joint”...

  • Page 4: Registration Of The Product

    SERIAL No: __________________ ENGINE MODEL: _____________ ENGINE TYPE: ______________ ENGINE CODE: ________________ The 150D model and serial number as well as the engine model number, engine type and code are critical in order to obtain the correct service parts. SAFETY DEFINITIONS...

  • Page 5: Safety Warnings

    Always move away from the fueling area before starting the engine. Do not smoke while refueling. • Use only Husqvarna ProEdge Series blades or blades marked with a maximum operating speed greater than 4450 • Do not operate the saw while smoking or near an open flame.

  • Page 6: Proedge Series Blades

    PROEDGE SERIES BLADES The ProEdge Line of beveled diamond blades is especially designed for architectural scoring to replace labor-intensive hand tooling. These specialty blades are ideal for residential and commercial applications to chase standard joints for a beveled look. Chasing cuts using the ProEdge blades would begin the next day or later after the concrete is placed and control joints have been made.

  • Page 7: Proedge Blade Installation

    PROEDGE BLADE INSTALLATION NOTE: Step 4 The 150D is shipped from the factory with the blade pre- Match the blade tri-arbor to the blade shaft arbor and install set to the proper cutting depth. Little or no adjustment is the blade firmly against the rear flange (E). Insure the blade is necessary.

  • Page 8: What Is What

    WHAT IS WHAT Model number and serial number What is what? Oil dipstick or fill Oil drain C. Fuel shut off lever D. Choke lever Throttle lever Starter rope G. Air cleaner H. Fuel tank Engine on/off switch...

  • Page 9: Operating Instructions

    NOTE: Do not completely lower the saw and the blade into the concrete until the front and rear guide wheels are The 150D saw is not designed for Ultra Early Entry positively aligned in the saw cut. concrete sawing. The ProEdge line of blades is not...

  • Page 10: Blade Depth Adjustment

    BLADE DEPTH ADJUSTMENT NOTE: The radius and V-blade depth of cut for the 150 saw is preset at maximum depth at the factory for optimum WARNING performance. Do not attempt the following adjustment un- less necessary. Do not adjust for more depth--doing so will produce an undesirable “house effect”...

  • Page 11: Fuel And Fuel Safety Warnings

    Please read the enclosed Robin Operator’s Manual for com- when filling. plete oil information. - Remove the 150D from the truck or trailer and refuel it on the ground. If this is not possible, then refuel the equipment with a portable container, rather than from a gasoline dispenser nozzle.

  • Page 12: Maintenance

    Refer to the supplied engine manual and the “Cyclone Dual- Filter-Element Type” for additional information. Do not modify the saw! Use only Husqvarna Construc- tion Products replacement parts. Use of unauthorized parts may create a danger or damage the engine.

  • Page 13: Sawing Contraction Joints

    Husqvarna sawed contraction joints should be a minimum of 1/8th the concrete depth and a minimum of 1”...

  • Page 14: Maximizing The Soff-Cut System

    Cut is being specified more today than ever, sometimes the ultra early-entry spec is not always followed on the job site. In order for the Soff-Cut system and an experienced Husqvarna contractor to do a satisfactory job, four components must exist to meet the “specification”:...

  • Page 15: Troubleshooting

    TROUBLESHOOTING ENGINE WILL NOT START BEVEL OR RADIUS CUT INCONSISTENT - Check if there is fuel in the tank and it is the correct fuel. - Check to see if the diamond blade is worn out, glazed, Make sure there is no water in the fuel. warped or damaged.

  • Page 16: Technical Specifications

    TECHNICAL SPECIFICATIONS Weight and Dimensions 150D Weight – dry 96 lbs 43.5 kg Weight with gasoline and oil full 100 lbs 45.4 kg Length (handle folded in) 34 inch 864 mm Width 19 inch 483 mm Height 21 inch 533 mm...

  • Page 17: Warranty

    HUSQVARNA EQUIPMENT WARRANTY New 150D sold by Husqvarna Construction Products are warranted to be free from manufacturing defects in nor- mal service for a period of six (6) months for labor and up to one (1) year on parts from date of purchase by the original consumer purchaser or date of introduction into rental company fleet.
  • Page 18 505 41 78-10 Printed In U.S.A. 2009-03...
