Docomo SH-07A User Manual page 24

Camera
Hide thumbs Also See for SH-07A:

Advertisement

2
Display a business card in the center of the
t.
: The shutter sounds.
: Hold the FOMA terminal securely to fit the entire business card with
the frame shown on the display. Make sure that no other objects,
especially text-written objects, are displayed on the screen.
: For scanning, the direction of the business card can be either vertical
or horizontal on the screen. Keep it vertical or horizontal when
scanning.
: The larger the displayed image of the business card is, the clearer
the scan result is. However, bringing the camera too close to the
business card makes it difficult to adjust the focus. Keep the camera
approximately 10 cm away from the business card.
3
Press t/add to the phonebook.
: The shot card images are automatically saved and the phonebook
entry screen appears. Scanned items are entered in the phonebook
entry screen.
: When the total number of saved phone numbers, mobile phone
number and fax numbers is four or more or there are four or more
saved mail addresses, the three numbers or addresses from the top
are saved. [T]/[u]/[Z] are the icons for phone number type and [B]
is for mail address type.
: The shot card images are set to Picture call. However, the images do
not appear when making/receiving a call or in the Redial/Received
calls details screen.
Some business cards cannot be scanned or be recognized properly.
The following business cards cannot be scanned.
Business cards with letters written in a language other than
Japanese and English
Business cards with background images
Handwritten business cards and business cards with
handwritten-style fonts
Business cards with letters written in both vertical and horizontal
directions
Business cards shown on a display, etc.
222
screen/
The following business cards cannot be scanned fine.
Business cards with light colored text and low contrast
Business cards with extremely small characters
Business cards with italic fonts
Shiny, coated business cards
Business cards with a logo or logo-style characters
Business cards in which there is no space between characters since
they are placed too close to each other
The reading (pronunciation in kana) may not be saved correctly or
added automatically.
Category of item may not be recognized properly.
The shot card images are saved to the [Camera] folder in My picture of
Data box.
Submenu operations for card reader screen
[Switch camera-mode]/select the camera mode/t
[AF mode]
Information reader
Using Information reader
Information reader allows to scan information such as store
name, phone number, etc. from a magazine, etc. by using the
camera, and newly save it to the FOMA terminal handset
phonebook.
The following items can be saved.
Store name
Mail address (up to three)
Memo (store hours, closed, URL, directions, and other items)
Picture call setting
nP. 213
Phone number (up to three)
Address
