INSTALLATION & USER INSTRUCTIONS
FULL DEPTH INSET DECORATIVE GAS FIRE
Superior Fires
Christchurch, Dorset BH23 2BT
Tel: 01202 588 632
Fax: 01202 499326
www.superiorfires.co.uk
e : info@superiorfires.co.uk
SONORA GROVE CHROME
SONORA GROVE BLACK
IN THE UK ALWAYS USE A GAS SAFE REGISTERED ENGINEER TO INSTALL, REPAIR OR SERVICE THIS APPLIANCE
Please note : Except where otherwise stated, all rights, including
copyright in the text, images and layout of this booklet is owned by
Focal Point Fires plc. You are not permitted to copy or adapt any of
the content without the prior written permission of Focal Point Fires
plc.
MODELS COVERED BY THESE INSTRUCTIONS
SONORA GROVE BRASS MANUAL CONTROL NG
SONORA GROVE CHROME MANUAL CONTROL NG
SONORA GROVE BLACK MANUAL CONTROL NG
SONORA GROVE BRASS REMOTE CONTROL NG
SONORA GROVE CHROME REMOTE CONTROL NG
SONORA GROVE BLACK REMOTE CONTROL NG
SONARA BLENHEIM MANUAL NG
SONARA ELEGANCE MANUAL NG
SONARA ELYSEE MANUAL NG
SONARA BLENHEIM REMOTE CONTROL NG
SONARA ELEGANCE REMOTE CONTROL NG
SONARA ELYSEE REMOTE CONTROL NG
1
Please note : All colour/finish variants are not shown.
All instructions must be handed to the user for
safekeeping.
Revision A - 12/11
GB IE
F500452
F500453
F500454
F500455
F500456
F500457
F500458
F500459
F500460
F500461
BS EN 509 : 2000
F500462
KM579168
F500463
SONORA GROVE BRASS
© 2011 Focal Point Fires plc.
Advertisement
Chapters
Table of Contents
Related Manuals for superior fires F500452
Summary of Contents for superior fires F500452
- Page 1 INSTALLATION & USER INSTRUCTIONS FULL DEPTH INSET DECORATIVE GAS FIRE MODELS COVERED BY THESE INSTRUCTIONS GB IE SONORA GROVE BRASS MANUAL CONTROL NG F500452 SONORA GROVE CHROME MANUAL CONTROL NG F500453 SONORA GROVE BLACK MANUAL CONTROL NG F500454 SONORA GROVE BRASS REMOTE CONTROL NG...
-
Page 2: Table Of Contents
GB IE I N S T A L L A T I O N I N S T R U C T I O N S Section Contents Page No. Section Contents Page No. Important Notes 12.0 Spark Gap Appliance Data 12.1 Operating Pressure Installation Requirements... -
Page 3: Appliance Data
GB IE 2.0 APPLIANCE DATA Destination Operating Pressure Model Max Energy Input (kW) Min Energy Input (kW) Country (±2.0 mbar) Natural gas Gross Gross I 2H Sonora 3.15 GB - IE Specifications Manual control models Manual control models Main burner injector Stereo size 76 Stereo size 76 Oxypilot... -
Page 4: Ventilation
GB IE 4.0 SITE REQUIREMENTS - CONTINUED Any type of fire surround used with this appliance must be adequately sealed to the wall and floor. A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below. Maximum depth of shelf Minimum distance from finished hearth surface to underside of shelf 100mm... -
Page 5: Fuel Bed Layout
GB IE 8.0 FUEL BED LAYOUT Please refer to the relevant section of the user manual. 9.0 FITTING THE FIREFRONT Unwrap the firefront and ashpan door. Place the firefront directly in front of the fire and slide the ashpan door into place. Do not use any firefront other than the one supplied with the appliance. -
Page 6: Spark Gap
12.0 SPARK GAP Figure 5 The spark gap (shown in figure 5) between the spark electrode and the thermocouple Spark gap should be 3.5 - 4.5mm to produce a good spark. There should be no need to adjust this. If under any circumstances the electric spark fails, the pilot may be lit manually by proceed- ing with the ignition sequence as previously described, and after turning the control knob through the spark position, the knob should be held in and the pilot lit with a taper. -
Page 7: Briefing The Customer
GB IE 12.4 BRIEFING THE CUSTOMER All instructions must be handed to the user for safekeeping. Show the customer how to light and control the fire. After commissioning the appliance, the customer should be instructed on the safe use of the appliance and the need for regular servicing. Frequency of serv- ice depends on usage, but MUST be carried out at least once annually. -
Page 8: Replacing The Batteries (Remote Control Versions)
GB IE 13.5 REPLACING THE BATTERIES (REMOTE CONTROL VERSIONS) Handset - Remove cover from rear of handset and insert 1 x ‘PP3’ (9 volt) battery - Replace cover Appliance - Ensure appliance is off and cool. Remove cover from top of receiver box. The cover is protected by reflective foil, and located towards the right hand side, underneath the burner unit. - Page 9 GB IE U S E R I N S T R U C T I O N S Section Contents Page No. Section Contents Page No. Important Notes Fuel Bed Layout - Pebble effect Clearances to Combustibles Fuel Bed Layout - Log effect Ventilation Servicing Operating Instructions - Manual control...
-
Page 10: Flue Spillage Monitoring System
GB IE 4.0 OPERATING THE FIRE (MANUAL CONTROL MODELS) The pilot is visible through the left hand side of ceramic fuel matrix. When cold, the coals or pebbles may be rotated for good viewing. The fire features a ‘twin spark’ ignition system to aid lighting, Push the control knob in fully and turn anti-clockwise through both of the SPARK positions, keeping fully depressed, hold there for a few seconds. -
Page 11: Fuel Bed Layout - Coal Effect
6.0 FUEL BED LAYOUT (COAL EFFECT) Figure 5 1. Position the combustion matrix onto the burner tray as shown in figure 5. The front edge of the matrix should sit snugly behind the back edge of the burner rails as shown in figure 6. Do not fit the matrix on top of the burner rails. -
Page 12: Fuel Bed Layout - Pebble Effect
GB IE 6.0 FUEL BED LAYOUT (COAL EFFECT) - CONTINUED Figure 12 6. Finally, take the two remaining coals and place at the back of the fuel matrix, in the centre as shown in figure 12. Adding these coals should complete the appearance of the fuel bed giving an even dis- tribution of equally spaced coals. -
Page 13: Fuel Bed Layout - Log Effect
GB IE 6.1 FUEL BED LAYOUT (PEBBLE EFFECT) - CONTINUED 5. Finally, take the four remaining pebbles and place at the back of the fuel Figure 17 matrix as shown in figure 17. Once again, the pebbles may be orientated as desired in order to give a realistic effect. -
Page 14: Servicing
GB IE 6.2 FUEL BED LAYOUT (LOG EFFECT) - CONTINUED 5. Finally, take the remaining two medium sized logs (numbered 5 and 7) and place in a horizontal position shown, 5 first, resting on the front log Figure 22 strip. 7 next resting on 5. Now take the smallest log (numbered 12) and position in the orientation shown ensuring the log does not fall into the matrix but rests securely on the allocated supports. -
Page 15: Installation Details
GB IE 11.0 INSTALLATION DETAILS Name & contact details of installer : Supplied by : Installer GAS SAFE registration No : Model : Fire serial No. : Date installed : 12.0 SERVICE HISTORY Date of service Serviced by (name): GAS SAFE No. : Contact details of Engineer As our policy is one of continuous improvement and development , we hope therefore you will understand we must retain the right to amend details and/or specifications without prior notice.
