INSTALLATION & USER INSTRUCTIONS
Superior Fires
Christchurch, Dorset BH23 2BT
Tel: 01202 588 632
Fax: 01202 499326
www.superiorfires.co.uk
Email : sales@superiorfires.co.uk
This product is only suitable for well insulated spaces or occasional use.
Please note : Except where otherwise stated, all
rights, including copyright in the text, images
and layout of this booklet is owned by Focal
Point Fires plc. You are not permitted to copy
or adapt any of the content without the prior
written permission of Focal Point Fires plc.
LED ELECTRIC FIRE
MODELS COVERED BY THESE INSTRUCTIONS
NDY-19
CLARA LED INSET ELECTRIC FIRE
LONDRA LED REFLECTIONS INSET ELECTRIC FIRE
FRET AND FRAME OPTIONS AVAILABLE
MODEL SHOWN: CLARA LED INSET ELECTRIC FIRE
Image used for illustration puposes only
1
All instructions must be handed to the user
for safekeeping.
Revision D - 12/17
GB IE
