- Page 1 Installation Guide AXIS 2191 Audio Module Sight, Speech and Sound — over IP!
-
Page 2: The Axis 2191 Audio Module
The module connects quickly and easily to the serial port of the camera and is configured and controlled via the camera’s user interface. An Axis network camera ( ) with an AXIS 2191 Audio Module connected provides live audio and video to browser clients ( ) on the network. Features and Functions •... -
Page 3: The Front Panel
AXIS 2191 Installation Guide Page 2 of 7 The Front Panel Serial Port Connector - Connect Power Connector the serial cable from here to the serial port on the camera. Power Indicator - Normally lit. Activity Indicator - Lights up when the camera has configured the audio module. -
Page 4: Installing The Audio Module
Page 3 of 7 Installing the Audio Module Follow the guide below to quickly get your AXIS 2191 up and running. Refer to the illustrations on the previous page for connector details. Before you start the installation of the AXIS 2191 Audio Module, you must first install your network camera. -
Page 5: Configuring The Audio Module
The network camera’s administration pages provide all the tools required for successfully configuring the AXIS 2191. From the camera’s home page, click on the link to Administration Tools. A new page containing the tools will open. To complete the configuration of your audio module, follow these instructions: From the Admin tools, click External Devices. - Page 6 Simplex - Talk mode means that only the web-client end of the connection can transmit audio (that is, to the AXIS 2191). This could be used, for example, to provide spoken instructions to a person seen in the network camera. This mode also requires you to use the Push-to-Talk button.
-
Page 7: Troubleshooting
Check the setting in the camera’s administration tools. See also page 4. Sound card does not support For information on how to check if your sound card supports full- full-duplex. duplex, please visit www.axis.com and see the support section for Axis camera products. Poor performance. Too many users/clients Try limiting the number of clients allowed to connect. -
Page 8: Technical Specifications
• Microphone Input: 1-50mVpp. PC type. Connection Diagram The Audio Module to Camera Serial Cable The serial cable supplied with your AXIS 2191 is wired as shown in the table below: Pinouts for the RS-232 Port Audio Camera...
