T T o o e e n n t t e e r r o o r r e e x x i i t t t t i i m m e e r r m m o o d d e e m m a a n n u u a a l l l l y y : :
1. Make sure the remote start system is not operating the engine.
2. Turn the ignition on.
Timer Mode will be exited and the parking lights will flash four times.
t t a a b b l l e e o o f f z z o o n n e e s s
When using the Diagnostic functions, use the Table of Zones to see which input has triggered the system. It is
also helpful in deciding which input to use when connecting optional sensors and switches.
Z Z O O N N E E N N O O . . T T R R I I G G G G E E R R T T Y Y P P E E
1 Multiplexed Input
2 Multiplexed Shock Sensor Input Mux BLUE wire.
3 Door Trigger
4 Multiplexed Shock Sensor
5 Ignition
6 Hood Brake Trigger
N N O O T T E E : The Warn Away® response does not report on the LED.
s s h h u u t t d d o o w w n n d d i i a a g g n n o o s s t t i i c c s s
t t o o p p e e r r f f o o r r m m s s h h u u t t d d o o w w n n d d i i a a g g n n o o s s t t i i c c s s
1. With the ignition OFF, press and H H O O L L D D the Valet/Program button.
2. Turn the ignition ON and then back OFF while H H O O L L D D I I N N G G the Valet/Program button.
3. Release the Valet/Program button.
4. Press and release the Valet/Program button. The LED will report the last shutdown for one minute or until
the ignition is turned on.
© 2005 Directed Electronics, Inc. Vista, CA
I I N N P P U U T T D D E E S S C C R R I I P P T T I I O O N N
BLUE (H1/6)
GREEN (H1/5) and VIOLET (H1/7).
Mux GREEN wire
Yellow ribbon harness wire
GRAY on the 6-pin shutdown harness.
