Mechanical vibration specifications
Continuous vibration can cause a slow degradation of mechanical parts and, when
severe, can cause data errors in disk drives. Mechanical connections such as printed
circuit assembly (PCA) conductors, cable connectors, and processor backplane wiring
can also be affected by vibrations. Vibration specifications apply to all three axes. For
vibration testing methods, see ASTM D999-91 Standard Methods for Vibration Testing
of Shipping Containers.
Condition
Operating
Nonoperating
Shipping and storage (product packed in
factory packing)
Shock specifications
The following tables lists shock specifications. For horizontal shock testing methods,
see ASTM D5277-92 Standard Test Methods for Performing Programmed Horizontal
Impacts Using an Inclined Impact Tester. For vertical shock testing methods, see ASTM
D6055-96 Standard Test Methods for Mechanical Handling of Unitized Loads and
Large Shipping Cases and Crates.
Condition
Operating
Nonoperating
Shipping and storage (product packed in
factory packing)
Specification
0.25 mm, 5–10 Hz
0.05 G, 10–300 Hz
2.5 mm, 5–10 Hz
0.5 G, 10–70 Hz
0.05 mm, 70–99 Hz
1.0 G, 99–300 Hz
0.5 G, 15 minutes (at four most severe
resonances between 5–200 Hz)
Specification
None
8 G, 15 ms
Horizontal: Incline impact: 1.22 m/s
Vertical: Rotational edge: 0.1 m
