I Power steering fluid reservoir. See Power Steering Fluid Check (page 245).
J Engine coolant reservoir. See Engine Coolant Check (page 244).
1
The filler caps and the engine oil dipstick are coloured for easy identification.

UNDER BONNET OVERVIEW - 2.0L DURATEC-HE (MI4)

E73231
A Brake and clutch fluid reservoir (right-hand drive). See Brake and Clutch Fluid
Check (page 245).
B Engine oil filler cap
C Brake and clutch fluid reservoir (left-hand drive). See Brake and Clutch Fluid
Check (page 245).
D Battery. See Jump-Starting the Vehicle (page 251).
E Engine compartment fuse box. See Fuse Specification Chart (page 222).
F Air cleaner. No maintenance necessary.
G Screen washer fluid reservoir. See Washer Fluid Check (page 245).
H Engine oil dipstick
Maintenance
A
J I
1
. See Engine Oil Check (page 244).
1
. See Engine Oil Check (page 244).
B
C
H
236
D E
G F
