  • Page 1 All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Copyright 1998 Ford Motor Company Contents...

  • Page 2: Introduction

    Introduction ICONS Indicates a safety alert. Read the following section on Warnings. Indicates vehicle information related to recycling and other environmental concerns will follow. Correct vehicle usage and the authorized disposal of waste cleaning and lubrication materials are significant steps towards protecting the environment.
  • Page 3 Introduction INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation. SPECIAL NOTICES Notice to owners of Cobra vehicles Before you drive your vehicle, be sure to read the “SVT Cobra Owner’s Guide Supplement.”...

  • Page 4: Instrumentation

    Instrumentation Headlamp control (pg. 16) Turn signal and wiper/washer control (pg. 43) Instrument cluster (pg. 6) Driver side air (pg. 71)
  • Page 5 Instrumentation Electronic sound system (pg. 21) Climate control systems (pg. 18)

  • Page 6: Warning Lights And Chimes

    Instrumentation WARNING LIGHTS AND CHIMES Base instrument cluster FUEL DOOR THEFT Optional instrument cluster Turn signal Illuminates when the left or right turn signal or the hazard lights are turned on. If one or both of the indicators stay on continuously or flash faster, check for a burned-out turn signal bulb.
  • Page 7 Instrumentation High beams Illuminates when the high beam headlamps are turned on. Safety belt Momentarily illuminates when the ignition is turned to the ON position to remind you to fasten your safety belts. For more information, refer to the Seating and safety restraints chapter. Charging system Illuminates when the ignition is turned to...
  • Page 8 Instrumentation Service engine soon Your vehicle is SERVICE ENGINE equipped with a SOON computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD II). The OBD II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
  • Page 9 consists of a cold engine startup followed by mixed city/highway driving.) No additional vehicle service is required. If the Service Engine Soon light remains on, have your vehicle serviced at the first available opportunity. Light is blinking: Engine misfire is occurring which could damage your catalytic converter.
  • Page 10 Instrumentation control switch is depressed or if the light flashes when you are driving, have your vehicle serviced. Traction Control active This light momentarily illuminates when the ignition is turned to ON. It also illuminates when the Traction Control system begins applying and releasing the brakes and adjusting the engine characteristics to limit a wheelspin condition.
  • Page 11 Instrumentation Check coolant Illuminates when the coolant level in the coolant reservoir is low and more needs to be added. This lamp will also illuminate when the ignition is turned to ON and the engine is off. For more information on adding engine coolant, refer to Engine coolant in the Maintenance and care chapter.

  • Page 12: Fuel Gauge

    Instrumentation GAUGES Base instrument cluster gauges FUEL DOOR THEFT Optional instrument cluster gauges FUEL DOOR THEFT Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion.

  • Page 13: Engine Coolant Temperature Gauge

    Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine immediately and let the engine cool.
  • Page 14 Instrumentation Odometer Registers the total kilometers (miles) of the vehicle. Tachometer Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer at the top of the scale or in the red zone may damage the engine. Base instrument cluster Standard instrument cluster...
  • Page 15 Trip odometer Registers the kilometers (miles) of individual journeys. Press the reset button until a “T” appears in the display (this represents the trip mode). Press and hold the button for 2.5 seconds to reset. Battery voltage gauge This gauge shows the battery voltage when the ignition is in the ON position.

  • Page 16: Controls And Features

    Controls and features HEADLAMP CONTROL Pull the headlamp control toward you to the first position to turn on the parking lamps, tail lamps, license plate lamps and marker lamps. Pull the headlamp control toward you to the outer position to turn on the headlamps (in addition to the previous lamps).
  • Page 17 PANEL DIMMER CONTROL To adjust the brightness of the instrument panel: Rotate clockwise/ counterclockwise when the headlamp control is in the parking lamp or low-beam position. To turn on the courtesy lamps: Rotate fully counterclockwise. REAR WINDOW DEFROSTER (IF EQUIPPED) The rear defroster control is located on the instrument panel.
  • Page 18 Controls and features CLIMATE CONTROL SYSTEM Manual heating and air conditioning system Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode selector control Controls the direction of the airflow to the inside of the vehicle.
  • Page 19 Under normal conditions, your vehicle’s climate control system should be left in any position other than MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” through the outside air inlet duct. MAX A/C-Uses recirculated air to cool the vehicle. MAX A/C is noisier than NORM A/C but more economical and will cool the inside of the vehicle faster.
  • Page 20 Controls and features is about 10°C (50°F) or higher, the air conditioner will automatically dehumidify the air to reduce fogging. - Distributes outside air through the windshield defroster ducts. It can be used to clear ice or fog from the windshield. If the temperature is about 10°C (50°F) or higher, the air conditioner will automatically dehumidify the air to reduce fogging.

  • Page 21: Volume Control

    USING YOUR AUDIO SYSTEM AM/FM Stereo/Cassette/Premium Sound FM 1 POWER AUDIO AM/FM – VOLUME Power control Press the control to turn the audio system on or off. Volume control Press the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
  • Page 22 Controls and features station by using the Automatic Music Search (AMS) button. Press the AMS control until the display shows TUNE. Press and release either the SEEK control to change to the next frequency up or down. Press and hold down through the frequencies.
  • Page 23 In order to ensure proper operation of the AMS feature, the tape MUST have a blank section of at least 4 seconds duration between programs. Scan function The scan function works in radio mode. Press the SCAN button to activate the scan mode. The radio scans up the frequency band, stopping on each listenable station for approximately a five-second sampling.
  • Page 24 Controls and features Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Push the AUDIO control repeatedly until the display reads BASS. Press (+) or (−) on the volume control to increase or decrease bass output.
  • Page 25 Speaker fade adjust Speaker sound distribution can be adjusted between the front and rear speakers. Push the AUDIO control repeatedly until the display reads FADE. Press the (+) side of the volume control to shift sound to the front speakers. Press the (−) side of the volume control to shift sound to the rear speakers.
  • Page 26 Controls and features Tape eject Press the control to stop and eject a tape. Dolby noise reduction Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation operates only in tape mode. Dolby reduces the amount of hiss and static during tape playback.
  • Page 27 AM/FM Stereo/Cassette/MACH 460 Sound System with Premium AM/FM Stereo Cassette POWER AUDIO AM/FM VOLUME Power control Press the control to turn the audio system on or off. Volume control Press the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
  • Page 28 Controls and features Tune adjust Tune adjust works in radio mode and allows you to manually tune in a particular radio station. Press the SCAN/TUNE button twice. The display reads TUNE. Press the SEEK control to move up or down through the frequencies.
  • Page 29 Press to listen to the next selection on the tape. Scan function The scan function works in radio, tape and CD mode (if equipped). Scan function in radio mode This feature allows you to scan the frequency band, stopping on each listenable station for approximately a five-second sampling.
  • Page 30 Controls and features Press to scan forward selections. Press the SCAN/TUNE button again to stop the scan mode on the current selection. Radio station memory preset The radio is equipped with five station memory preset controls. These controls can be used to select up to five preset AM stations and ten FM stations (five in FM1 and five in FM2).
  • Page 31 Push the AUDIO control repeatedly until the display reads TREB. Press (+) or (−) on the volume control to increase or decrease treble output. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Push the AUDIO control repeatedly until the display reads BAL.
  • Page 32 Controls and features Push only slightly when inserting a cassette tape (with the open edge to the right). A cassette deck loading mechanism pulls the tape in the rest of the way. Press PLAY to begin PLAY cassette tape play. PROG Rewind/fast forward function in tape mode Press the control to...

  • Page 33: Setting The Clock

    Setting the clock Press the CLOCK control while simultaneously depressing the SEEK control. Press to set the hours. Press to set the minutes. Premium AM/FM Stereo Single CD Radio/Premium Sound or MACH 460 Sound System with Single CD Radio POWER EJECT COMP AM/FM...
  • Page 34 Controls and features AM/FM select The AM/FM select control works in radio mode and allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. Tune adjust The tune control works in radio mode. Tune adjust in radio mode Press the SCAN/ TUNE control twice.
  • Page 35 Scan function The scan function works in radio mode. Scan function with compact disc radio Press the SCAN/ TUNE control once. Push on the SEEK control to hear a brief sampling of listenable stations up the frequency band. Push to hear a brief sampling of listenable stations down the frequency band.
  • Page 36 Controls and features set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Starting automatic memory store 1. Select a frequency using the AM/FM select control. 2. Press the AUTO PRESET control. 3.
  • Page 37 Speaker fade adjust Speaker sound distribution can be adjusted between the front and rear speakers. Push the AUDIO control repeatedly until the display reads FADE. Press the (+) side of the volume control to shift sound to the front speakers. Press the (−) side of the volume control to shift sound to the rear speakers.
  • Page 38 Controls and features Compression feature Compression adjust brings soft and loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. The effect of the feature varies with the music content. Setting the clock Press the CLOCK control while...
  • Page 39 Play function The system enters the PLAY mode when a CD is loaded, label side up, into the disc opening. The PLAY indicator will illuminate. The CD automatically loads into the unit and begins play at the beginning of the first track. When the CD reaches the end, the disc player automatically returns to the beginning of the CD and resumes play.
  • Page 40 Controls and features If you hold down the fast forward control until the end of the CD is reached, the display will show the end time of the last track and the sound will be muted. When the fast forward control is released, the player will resume play at the beginning of the first track.
  • Page 41 Troubleshooting the CD player (if equipped) The laser beam used in the compact disc player is harmful to the eyes. Do not attempt to disassemble the case. If sound skips: You may be traveling on a rough road, playing badly scratched discs or the disc may be dirty. Skipping will not scratch the discs or damage the player.
  • Page 42 Controls and features Cleaning cassette player (if equipped) Clean the tape player head with a cassette cleaning cartridge after ten to twelve hours of play in order to maintain the best sound and operation. Cassette and cassette player care Use only cassettes that are 90 minutes long or less.
  • Page 43 Terrain. Hills, mountains and tall buildings between your vehicle’s antenna and the radio station signal can cause FM reception problems. Static can be caused on AM stations by power lines, electric fences, traffic lights and thunderstorms. Moving away from an interfering structure (out of its “shadow”) returns your reception to normal.
  • Page 44 Controls and features The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals. Push the control on the end of the stalk to activate washer. Push and hold for a longer wash cycle.
  • Page 45 POSITIONS OF THE IGNITION 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
  • Page 46 Controls and features SPEED CONTROL To turn speed control on Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
  • Page 47 If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed. This is normal. Speed control cannot reduce the vehicle speed if it increases above the set speed on a downhill. If your vehicle speed is faster than the set speed while driving on a downhill, you may want to shift to the next lower gear or apply the brakes to reduce your...
  • Page 48 Controls and features To set a lower set speed Press and hold CST/ COAST. Release the control when the desired speed is reached or Press and release CST/COAST. Each press will decrease the set speed by 1.6 km/h (1 mph) or Depress the brake pedal.
  • Page 49 Pressing OFF will erase the previously programmed set speed. To return to a previously set speed Press RES/RSM/ RESUME. For RES/ RSM/RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph). INTERIOR LAMPS Map lamps (if equipped) If equipped with a convertible top the map lamps and...
  • Page 50 Controls and features POWER WINDOWS (IF EQUIPPED) Press and hold the rocker switches to open and close windows. Press the top portion of the rocker switch to close. Press the bottom portion of the rocker switch to open. Express down To make the driver window open fully without holding the...
  • Page 51 Controls and features POWER DOOR LOCKS Press U to unlock all doors and L to lock all doors. POWER SIDE VIEW MIRRORS (IF EQUIPPED) To adjust your mirrors: 1. Select to adjust the left mirror or to adjust the right mirror. 2.
  • Page 52 Controls and features CENTER CONSOLE Your vehicle may be equipped with a variety of console features. These include: dual cupholders auxiliary power point coin holder slots (if equipped) foglamp control (if equipped) convertible top control (if equipped) Use only soft cups in the cupholder. Hard objects can injure you in a collision.
  • Page 53 Controls and features Convertible (If equipped) Do not store articles behind rear seat. Articles stored in the convertible top stowage compartment may break the rear glass window when the top is lowered. Lowering the convertible top The convertible top can be lowered with the side windows either up or down.
  • Page 54 Controls and features 6. Push the convertible top switch on the console in front of the armrest and hold until the top is completely stored. 7. Disengage the parking brake. Installation of the boot 1. Insert boot tongue into groove located on rear seat.
  • Page 55 Controls and features 4. Tuck side attachments under molding. Repeat on other side of vehicle. 5. Push and pull front of boot to ensure tongue is engaged into groove. 6. Removal Raising the convertible top The convertible top will not operate unless the parking brake is engaged.
  • Page 56 Controls and features 5. Open both top clamps before the top meets the windshield header 6. Continue to use the top motor to raise the top until it has reached the fully closed position flush to the header. 7. The two pins under the forward edge of the top should seat themselves in the matching holes in the header.
  • Page 57 Controls and features Locking the doors Press this control to lock all doors. To confirm all doors are closed and locked, press the control a second time within three seconds. The doors will lock again, the horn will chirp and the lamps will flash. If any of the doors are ajar, the horn will make two quick chirps and the chime may sound, reminding you to properly close all doors.
  • Page 58 Controls and features Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Illuminated entry The interior lamps illuminate when the remote entry system is used to unlock the door(s) or sound the personal alarm.
  • Page 59 After doors lock/unlock, press any control on all transmitters (up to four). With each control press of the transmitters, the door should cycle (lock/unlock) to confirm programming. When completed, turn the ignition to OFF. The door locks should cycle (lock/unlock) one last time to confirm completion of programming.
  • Page 60 Controls and features SECURILOCK PASSIVE ANTI-THEFT SYSTEM The SecuriLock an advanced level of vehicle theft protection. Your vehicle’s engine can only be started with the two special SecuriLock provided with your vehicle. Each time you start your vehicle, the SecuriLock SecuriLock passive anti-theft system.
  • Page 61 Theft indicator The theft indicator on the instrument cluster will operate as follows: When the ignition is OFF, the theft indicator will flash briefly every 2 seconds to indicate the SecuriLock system is protecting your vehicle. When the ignition is turned to RUN or START, the theft indicator will light for 3 seconds and then go out.
  • Page 62 Controls and features 1. Insert the first previously programmed SecuriLock key into the ignition and turn the ignition from OFF to RUN (maintain ignition in RUN for at least one second). 2. Turn ignition to OFF and remove the first SecuriLock key from the ignition.

  • Page 63: Seating And Safety Restraints

    Seating and safety restraints SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
  • Page 64 Seating and safety restraints Lift handle to move seat forward or backward. Pull lever up to adjust seatback. Adjusting the front power seat (if equipped) Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop.
  • Page 65 Seating and safety restraints Press to raise or lower the front portion of the seat cushion. Press to raise or lower the rear portion of the seat cushion. Press the control to move the seat forward, backward, up or down. Rear seat entry/exit Use the seatback release to fold the back of the front seat forward for rear seat passenger entry or...
  • Page 66 Seating and safety restraints Using the manual lumbar support (if equipped) The lumbar control is located on the inboard side of the driver’s seatback. Move the control up to increase firmness and down to decrease firmness. 2nd seat/Split-folding rear seat (if equipped) One or both rear seatbacks can be folded down to provide additional cargo space.
  • Page 67 Seating and safety restraints To prevent the risk of injury, make sure children sit where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision.
  • Page 68 Seating and safety restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
  • Page 69 Seating and safety restraints When to use the automatic locking mode When a tight lap/shoulder fit is desired. Anytime a child safety seat is installed in a passenger front or outboard rear seating position (if equipped). Refer to Safety Restraints for Children or Safety Seats for Children later in this chapter.
  • Page 70 Seating and safety restraints Safety belt extension assembly If the safety belt assembly is too short, even when fully extended, 20 cm (8 inches) can be added to the safety belt assembly by adding a safety belt extension assembly (part number 611C22). Safety belt extension assemblies can be obtained from your dealer at no cost.
  • Page 71 (if equipped), child safety seat tether bracket assemblies (if equipped), and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However,...
  • Page 72 Seating and safety restraints Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly or gently and the risk of injury from a deploying air bag is greatest close to the trim...
  • Page 73 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer. Children and air bags For additional...
  • Page 74 Seating and safety restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains sufficient longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation.
  • Page 75 Seating and safety restraints there is the risk of death or serious injuries such as fractures, facial and eye injuries or internal injuries, particularly to occupants who are not properly restrained or are otherwise out of position at the time of air bag deployment. Thus, it is extremely important that occupants be properly restrained as far away from the air bag module as possible while maintaining vehicle control.
  • Page 76 Seating and safety restraints A difficulty with the system is indicated by one or more of the following: The readiness light will either flash or stay lit. The readiness light will not illuminate immediately after ignition is turned on. A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and light are repaired.
  • Page 77 Do not leave children, unreliable adults, or pets unattended in your vehicle. To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all Federal motor...
  • Page 78 Seating and safety restraints seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child. A belt-positioning booster should be used if the shoulder belt rests in front of the child’s face or neck, or if the lap belt does not fit snugly on both thighs, or if the thighs are too short to let the child sit all the way back on the seat cushion when the...
  • Page 79 Refer to Automatic locking mode (passenger side front and outboard rear seating positions)(if equipped). Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage.
  • Page 80 Seating and safety restraints Installing child safety seats in combination lap and shoulder belt seating positions 1. Position the child safety seat in a seat with a combination lap and shoulder belt. An air bag can kill or injure a child in a child seat.
  • Page 81 Seating and safety restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
  • Page 82 Tether anchorage hardware kits (part number 613D74) including instructions, may be obtained at no charge from any Ford or Lincoln-Mercury dealer. All vehicles built for sale in Canada include a tether anchor hardware kit.

  • Page 83: Starting

    PREPARING TO START YOUR VEHICLE Engine starting is controlled by the ignition system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting. Only use the accelerator when you have difficulty starting the engine.
  • Page 84 Starting Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs faster to warm the engine. If the engine idle speed does not slow down automatically, have the vehicle checked. Do not allow the vehicle to idle for more than ten minutes at high engine RPM.
  • Page 85 3. Turn the key to 4 (ON) without turning the key to 5 (START). FUEL DOOR THEFT Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced. If the driver’s safety belt is fastened, the may not illuminate.
  • Page 86 Starting STARTING THE ENGINE 1. Turn the key to 5 (START) without pressing the accelerator pedal and release as soon as the engine starts. The key will return to 4 (ON). 2. If the temperature is above –12°C (10°F) and the engine does not start within five seconds on the first try, turn the key to OFF, wait ten seconds and try again.
  • Page 87 Guarding against exhaust fumes Although odorless and colorless, carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. If you ever smell exhaust fumes of any kind inside your vehicle, have your dealer inspect and fix your vehicle immediately. Do not drive if you smell exhaust fumes.

  • Page 88: Driving

    Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
  • Page 89 The ABS operates by detecting the onset of wheel lockup during brake applications and compensating for this tendency. The wheels are prevented from locking even when the brakes are firmly applied. The accompanying illustration depicts the advantage of an ABS equipped vehicle (on bottom) to a non-ABS equipped vehicle (on top) during hard braking with loss of front braking traction.
  • Page 90 Driving stopping distance. Always leave enough room between your vehicle and the vehicle in front of you to stop. We recommend that you familiarize yourself with this braking technique. However, avoid taking any unnecessary risks. Hydraulic brake booster system (Hydroboost) The Hydroboost system receives fluid pressure from the power steering pump to provide power assist during braking.
  • Page 91 The parking brake is not recommended to stop a moving vehicle. However, if the normal brakes fail, the parking brake can be used to stop your vehicle in an emergency. Since the parking brake applies only the rear brakes, the vehicle’s stopping distance will increase greatly and the handling of your vehicle will be adversely affected.
  • Page 92 Driving the fully electronic spark and fuel injection systems. This process is very sensitive to driving conditions and very fast acting. The rear wheels “search” for optimum traction several times a second and adjustments are made accordingly. The Traction Control vehicle to make better use of available traction on slippery surfaces.
  • Page 93 If the power steering system breaks down (or if the engine is turned off), you can steer the vehicle manually, but it takes more effort. If the steering wanders or pulls, the condition could be caused by any of the following: underinflated tire(s) on any wheel(s) high crown in center of road high crosswinds...
  • Page 94 Driving Press lightly on the accelerator in each gear. Do not rock the vehicle for more than a few minutes. The transmission and tires may be damaged or the engine may overheat. Always set the parking brake fully and make sure the gearshift is latched in P (Park).
  • Page 95 P (Park) Always come to a complete stop before shifting into P (Park). Make sure the gearshift is securely latched in P (Park). This position locks the transmission and prevents the rear wheels from turning. Always set the parking brake fully and make sure the gearshift is securely latched in P (Park).
  • Page 96 Driving N (Neutral) With the gearshift in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this gear. (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears one through four.
  • Page 97 gears one through three. engine braking than when: driving with a heavy load towing a trailer up or down steep hills additional engine braking is desired. If towing a trailer, refer to Driving while you tow in the Trailer Towing chapter. To return to (Overdrive) mode, press the transmission control switch.
  • Page 98 Driving MANUAL TRANSMISSION OPERATION (IF EQUIPPED) Using the clutch Vehicles equipped with a manual transmission have a starter interlock that prevents cranking the engine unless the clutch pedal is fully depressed. When starting a vehicle with a manual transmission, you must: 1.
  • Page 99 Recommended shift speeds Do not downshift into 1 (first) when your vehicle is moving faster then 24 km/h (15 mph). This will damage the clutch. Upshift and downshift according to the following chart: Upshifts when accelerating (recommended for best fuel economy) 1 - 2 2 - 3 3 - 4...
  • Page 100 Driving 4. Turn the ignition key to position 3 (OFF). Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Reverse You can shift into R (Reverse) only by moving the gearshift to the right of 5 (Fifth) gear before you shift into R (Reverse).
  • Page 101 gearshift back into Neutral. Then, release the clutch pedal for a moment and repeat steps 2 through 4. Removing key from ignition Turn the ignition key to position 3 (OFF). Push the release lever forward and rotate the key towards you and remove.
  • Page 102 Driving Payload: Combined maximum allowable weight of cargo, passengers and optional equipment. The payload equals the gross vehicle weight rating minus base curb weight. GVW (Gross Vehicle Weight): Base curb weight plus payload weight. The GVW is not a limit or a specification.
  • Page 103 Trailer Weight Range: Specified weight range that the trailer must fall within that ranges from zero to the maximum trailer weight rating. Remember to figure in the tongue load of your loaded trailer when figuring the total weight. Do not exceed the GVWR or the GAWR specified on the Safety Compliance Certification Label.
  • Page 104 Driving limitation could result in serious damage to the vehicle and/or personal injury. TRAILER TOWING Your vehicle is capable of towing a trailer up to 454 kg (1 000 lbs.) gross trailer weight with a maximum tongue load of 45 kg (100 lbs.). Do not tow a trailer until your vehicle has been driven at least 800 km (500 miles).
  • Page 105 Trailer brakes Electric brakes and manual, automatic or surge-type brakes are safe if installed properly and adjusted to the manufacturer’s specifications. The trailer brakes must meet local and Federal regulations. Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system.
  • Page 106 Driving Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your Scheduled Maintenance guide for more information. Trailer towing tips Practice turning, stopping and backing up in an area before starting on a trip to get the feel of the vehicle trailer combination.
  • Page 107 Driving Once through the water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes. Drying can be improved by moving your vehicle slowly while applying light pressure on the brake pedal. Driving through deep water where the transmission is submerged may allow water into the transmission and cause internal transmission damage.

  • Page 108: Roadside Emergencies

    Roadside emergencies HAZARD FLASHER Use only in an emergency to warn traffic of vehicle breakdown, approaching danger, etc. The hazard flashers can be operated when the ignition is off. The hazard lights control is located on top of the steering column.
  • Page 109 The fuel pump shut-off switch is located on the left side of the trunk behind the trunk liner. FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components.
  • Page 110 Roadside emergencies Standard fuse amperage rating and color Fuse Mini Rating Fuses Grey Violet Pink 7.5A Brown Blue Yellow Natural Natural Green — — — — — Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal.
  • Page 111 OWNERS The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating Roadside emergencies MANUAL FUSE INFO Description Cigar Lighter Engine Controls — Not Used RH Low Beam Headlamp Instrument Cluster, Traction Control Switch Starter Motor Relay GEM, Interior Lamps Engine Controls —...
  • Page 112 Roadside emergencies Fuse/Relay Fuse Amp Location Rating Description Power Lumbar — Not Used Speed Control Servo, Shift Lock Actuator Electronic Flasher Power Mirror Switch, GEM, Anti-Theft Relay, Power Door Locks, Door Ajar Switches Convertible Top Switch Instrument Cluster and Engine Control Memory —...

  • Page 113: Power Distribution Box

    Fuse/Relay Fuse Amp Location Rating 20A CB Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
  • Page 114 Roadside emergencies Always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. GUIDE CONSULTER The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating Relay 1 Relay 2 Relay 3 Relay 4 Relay 5 50A** (4.6L), 30A...
  • Page 115 Fuse/Relay Fuse Amp Location Rating 30A** 50A** 20A** 30A** 30A** 40A** 30A** 20A** 25A CB * Mini Fuses ** Maxi Fuses CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed.
  • Page 116 Roadside emergencies Temporary spare tire information Your vehicle may have a temporary spare tire. The temporary spare tire for your vehicle is labeled as such. It is smaller than a regular tire and is designed for emergency use only. Replace this tire with a full-size tire as soon as possible.
  • Page 117 Roadside emergencies 1. Park on a level surface, activate hazard flashers and set parking brake. 2. Place gearshift lever in P (Park) or R (manual transmission), turn engine OFF, and block the diagonally opposite wheel. 3. Remove the spare tire, jack and lug wrench.
  • Page 118 Roadside emergencies Never use the rear differential as a jacking point. To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack.
  • Page 119 (not the dealer) to get a replacement key. If the lug wrench/lug nut key assembly is lost, see your nearest Ford or Lincoln/Mercury dealer who has access to the master set of keys. Do not use an impact wrench with the anti-theft key.
  • Page 120 Roadside emergencies JUMP STARTING YOUR VEHICLE The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Do not push start your vehicle. You could damage the catalytic converter. Batteries contain sulfuric acid which can burn skin, eyes, and clothing, if contacted.
  • Page 121 Roadside emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
  • Page 122 Roadside emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor. The preferred locations of an exposed metal part (to ground the circuit) are the alternator mounting brackets or an engine lifting eye.
  • Page 123 Roadside emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3.
  • Page 124 Roadside emergencies 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
  • Page 125 T-hooks can also be used. Do not tow Cobra or Convertible models with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure for these vehicles. If your vehicle is to be towed from the rear using...

  • Page 126: Maintenance And Care

    Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a Scheduled Maintenance Guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide necessary parts and service.
  • Page 127 Working with the engine off Automatic transmission: 1. Set the parking brake and ensure the gearshift is securely latched in P (Park). 2. Turn off the engine and remove the key. 3. Block the wheels to prevent the vehicle from moving unexpectedly.
  • Page 128 Maintenance and care OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. HOOD 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.
  • Page 129 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.8L OHV V6 engine 1. Engine oil filler cap 2. Engine oil dipstick 3. Brake fluid reservoir 4. Power distribution box 5. Windshield washer fluid reservoir 6. Battery 7. Power steering fluid reservoir 8.
  • Page 130 Maintenance and care 4.6L SOHC V8 engine 1. Engine oil dipstick 2. Brake fluid reservoir 3. Power distribution box 4. Windshield washer fluid reservoir 5. Battery 6. Engine coolant reservoir 7. Power steering fluid reservoir 8. Engine oil filler cap 9.
  • Page 131 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan. 3. Set the parking brake and ensure the gearshift is securely latched in P (Park) (automatic transmissions) or 1 (First) (manual transmissions). 4.
  • Page 132 Maintenance and care If the oil level is below the MIN mark, add enough oil to raise the level within the MIN—MAX range. Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician.

  • Page 133: Brake Fluid

    Ford material and design specifications, startup engine noises or knock may be experienced. It is recommended you use the appropriate Motorcraft oil filter (or another brand meeting Ford specifications) for your engine application. BRAKE FLUID Checking and adding brake fluid Brake fluid should be checked and refilled as needed.
  • Page 134 MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter. Brake fluid is toxic.

  • Page 135: Clutch Adjustment

    If you use a brake fluid that is not DOT 3, you will cause permanent damage to your brakes. Do not let the reservoir for the master cylinder run dry. This may cause the brakes to fail. CLUTCH ADJUSTMENT (IF EQUIPPED) Check the clutch adjustment.
  • Page 136 Maintenance and care WINDSHIELD WASHER FLUID Checking and adding washer fluid Check the washer fluid whenever you stop for fuel. The reservoir is highlighted with a symbol. If the level is low, add enough fluid to fill the reservoir. In very cold weather, do not fill the reservoir all the way.
  • Page 137 ENGINE COOLANT 3.8L OHV V6 engine 4.6L V8 engine Check the level of the engine coolant in the reservoir. Refer to the Scheduled Maintenance Guide for service interval schedules. Be sure to read and understand Precautions when servicing your vehicle in this chapter. If the engine coolant has not been checked at the recommended interval, the engine coolant reservoir may become empty.
  • Page 138 Maintenance and care Adding engine coolant Do not put engine coolant in the container for the windshield washer fluid. Do not mix conventional green coolant, orange coolant or recycled coolants together in your vehicle. Use only the type of coolant that your vehicle was originally equipped with.
  • Page 139 Maintenance Guide. Before adding engine coolant, check the color of the coolant in your vehicle. For vehicles with green coolant, use Ford Premium Cooling System Fluid E2FZ-19549–AA (in Canada, Motorcraft CXC-8–B) or an equivalent premium engine coolant that meets Ford specification ESE-M97B44–A.
  • Page 140 Maintenance and care For vehicles with orange coolant, no recycling process has been approved at this time and use of such coolant may harm engine and cooling system components. Always dispose of used automotive fluids in a responsible manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids.
  • Page 141 Maintenance and care If your vehicle is equipped with the 3.8L V6 engine, check the power steering fluid level with the engine at normal operating temperature. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near...
  • Page 142 Maintenance and care If your vehicle is equipped with a 4.6L V8 engine, check the power steering fluid level with the engine at ambient temperature. Allow at least one-half hour after driving for the power steering fluid to cool. 1. Start the engine and allow the engine to idle.
  • Page 143 Maintenance and care been operated for an extended period at high speeds, in city traffic during hot weather or pulling a trailer, the vehicle should be turned off for about 30 minutes to allow fluid to cool before checking. 1. Drive the vehicle 30 km (20 miles) or until it reaches normal operating temperature.
  • Page 144 Maintenance and care could result when the vehicle reaches normal operating temperature. The transmission fluid should be in this range if at normal operating temperature (66°C-77°C [150°F-170°F]). The transmission fluid should be in this range if at ambient temperature (10°C-35°C [50°F-95°F]). High fluid level Fluid levels above the safe range may result...
  • Page 145 4. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter.
  • Page 146 Maintenance and care BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the Scheduled Maintenance Guide for the service interval schedules.
  • Page 147 Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation. When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting...
  • Page 148 Maintenance and care 4. The relearning process will automatically complete as you drive the vehicle. The vehicle may need to be driven 16 km (10 miles) or more to relearn the idle and fuel trim strategy. If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
  • Page 149 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information...
  • Page 150 Maintenance and care about tire grades exactly as the government has written it. Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
  • Page 151 Motor Vehicle Safety Standard No. 109. Grades B and A represent higher levels of performance on the laboratory test wheel than the minimum required by law. The temperature grade for this tire is established for a tire that is properly inflated and not overloaded.
  • Page 152 Maintenance and care 15 or 16 inch four tire rotation 17 inch four tire rotation Replacing the tires Replace the tires when the wear band is visible through the tire treads. Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier for the driver to lose control and roll over.
  • Page 153 Tires that are larger or smaller than your vehicle’s original tires may also affect the accuracy of your speedometer. SNOW TIRES AND CHAINS Driving too fast for conditions creates the possibility of loss of vehicle control. Driving at very high speeds for extended periods of time may result in damage to vehicle components.
  • Page 154 Maintenance and care The suspension insulation and bumpers will help prevent vehicle damage. Do not remove these components from your vehicle when using snow tires and chains. WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire.
  • Page 155 Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury. If fuel is swallowed, call a physician immediately, even if no symptoms are immediately apparent. The toxic effects of fuel may not be visible for hours.
  • Page 156 If you must replace the fuel filler cap, replace it with a genuine Ford or Motorcraft part. The customer warranty may be void for any damage to the fuel tank or fuel system if a genuine Ford or Motorcraft fuel filler cap is not used.
  • Page 157 Maintenance and care Emissions Control Information label) are designed to operate on California cleaner-burning, low-sulfur gasolines. If you have a California-certified vehicle and California cleaner-burning gasoline is not available when you refuel, your engine should perform adequately. However, the performance of the emission control devices and systems may be adversely affected.
  • Page 158 Cleaner air Ford approves the use of gasolines to improve air quality, including reformulated gasolines that contain oxygenates up to 10% ethanol or 15% MTBE. Running out of fuel...
  • Page 159 Maintenance and care If you replace the fuel filter, replace it with an authorized Motorcraft part. The customer warranty may be void for any damage to the fuel system if an authorized Motorcraft fuel filter is not used. ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver.
  • Page 160 Maintenance and care Filling the tank For consistent results: Use the same filling rate setting (low — medium — high) each time the tank is filled. Allow three automatic click-offs when filling. Always use the recommended octane rating of a known quality gasoline, preferably a national brand.
  • Page 161 Driving style — good driving and fuel economy habits Give consideration to the lists that follow and you may be able to change a number of variables and improve your fuel economy. Habits Smooth, moderate operation can yield up to 10% savings in fuel.
  • Page 162 Maintenance and care Combine errands and minimize stop-and-go driving. Maintenance Keep tires properly inflated and use only recommended size. Operating a vehicle with the wheels out of alignment will reduce fuel economy. Use recommended engine oil. Refer to Lubricant Specifications. Perform all regularly scheduled maintenance items.
  • Page 163 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability. Maintenance and care...
  • Page 164 Maintenance and care Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the charging system warning light, “Service Engine Soon”...
  • Page 165 If the vehicle’s powertrain system or its battery has just been serviced, the OBD-II system is reset to a “not ready for I/M test” condition. To ready the OBD-II system for I/M testing, a minimum of 30 minutes of city and highway driving is necessary as described below: First, at least 10 minutes of driving on an expressway or highway.
  • Page 166 Maintenance and care Replacing headlamp bulbs Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.
  • Page 167 Maintenance and care To install the new bulb: 1. With the flat side of the new bulb’s plastic base facing upward, insert the glass end of the bulb into the lamp assembly. You may need to turn the bulb left or right to align the grooves in the plastic base with the tabs in the lamp assembly.
  • Page 168 Maintenance and care 5. Rotate the bulb socket counterclockwise about ⁄ turn and remove from lamp assembly. 6. Carefully pull the bulb straight out from the socket and push in the new bulb. 7. To complete installation, follow the removal procedure in reverse order.
  • Page 169 1. Rotate the foglamp bulb counterclockwise and remove from foglamp (the rear side of the foglamp is shown). 2. Disconnect the electrical connector from the foglamp bulb. 3. Connect the electrical connector to the new foglamp bulb. 4. Install the foglamp bulb in foglamp by rotating clockwise.
  • Page 170 Maintenance and care Map lamps For bulb replacement, see a qualified service technician or your dealer. Using the right bulbs Function Tail lamp, brakelamp, turn lamp Park lamp, turn lamp, side marker (front) Backup lamp License plate lamp High-mount brakelamp Headlamps Luggage compartment lamp Dome lamp...
  • Page 171 6. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS NON-ADJUSTABLE. 7. Close the hood and turn off the lamps. CLEANING AND CARING FOR YOUR VEHICLE Refer to the “Customer Assistance Guide” for a list of Ford-approved cleaners, polishes and waxes.
  • Page 172 Maintenance and care Washing your vehicle Wash your vehicle regularly with cold or lukewarm water. Never use strong detergents or soap. If your vehicle is particularly dirty, use a quality car wash detergent. Always use a clean sponge, washing glove or similar device and plenty of water for best results.
  • Page 173 Repairing paint chips Minor scratches or paint damage from road debris may be repaired with touch-up paint, repair foil or aerosol paint spray from the Ford accessory line. Observe the application instructions on the products. Remove particles such as bird droppings, tree sap, insect remains, tar spots, road salt and industrial fallout immediately.
  • Page 174 Maintenance and care Cover the highlighted areas to prevent water damage when cleaning the engine. Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning plastic exterior parts Use vinyl cleaner for routine cleaning. Clean with a tar remover if necessary.
  • Page 175 Dry with a soft cloth. For tougher soiling concerns, Ford recommends using the leather cleaning kit F8AJ-19G253–AA, which is available from your Ford Dealer. This mild cleaner and special pad, cleans the leather and maintains its natural beauty. Follow the instructions on the cleaner label.
  • Page 176 Convertible top and padded molding care To avoid damage to the vinyl top and moldings, use only an approved Ford cleaner, or equivalent. Do not use stiff bristle brushes or abrasive materials or cleaners. Hot waxes applied by commercial car washes can affect the cleanability of vinyl material.

  • Page 177: Capacities And Specifications

    Capacities and specifications MOTORCRAFT PART NUMBERS Component Air filter Fuel filter Battery Oil filter PCV valve Spark plugs* * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. **If a spark plug is removed for inspection, it must be reinstalled in the same cylinder.

  • Page 178: Refill Capacities

    Capacities and specifications REFILL CAPACITIES Fluid Ford Part Name Brake fluid High Per- formance DOT 3 Motor Vehicle Brake Fluid Engine oil Motorcraft (includes 5W30 filter Super change) Premium Motor Oil Engine coolant footnote Power Motorcraft steering MER- fluid CON V...
  • Page 179 Windshield fluid Washer Concentrate If your engine coolant is green in color, use Ford Premium Cooling System Fluid. If your coolant is orange in color, use Ford Extended Life Engine Coolant. Refer to Adding engine coolant, in the Maintenance and Care chapter.
  • Page 180 Capacities and specifications LUBRICANT SPECIFICATIONS Item Ford part name Brake fluid High Per- formance DOT 3 Motor Vehicle Brake Fluid Door Silicone weather- Lubricant strips Door latch, Multi- hood latch, Purpose auxiliary Grease hood latch, door hinges, striker plates, seat...
  • Page 181 Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546–A, Ford specification EST-M2C118–A for complete refill of Traction-Lok axles. Ford design rear axles contain a synthetic lubricant that does not require changing unless the axle has been submerged in water.
  • Page 182 Capacities and specifications ENGINE DATA Engine Cubic inches Horsepower Torque Recommended fuel Firing order Spark plug gap Ignition system Compression ratio VEHICLE DIMENSIONS Vehicle dimensions (1) Overall length (2) Overall width (3) Overall height (4) Wheelbase (5) Track - Front 1 534.2 (60.4) (5) Track - Rear 1 539.2 (60.6) 1 358.9 mm (53.5 in) for Mustang GT 1 361.4 mm (53.6 in) for Mustang GT...
  • Page 183 Capacities and specifications...

  • Page 184: Vehicle Identification Number

    The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if equipped). MFD. BY FORD MOTOR CO. IN U.S.A. DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG FGAWR: XXXXXX/XXXXXXX...

  • Page 185: Reporting Safety Defects

    National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 186: Index

    Index Air bag supplemental restraint system ... 71 and child safety seats ... 73 description ... 72 disposal ... 76 indicator light ... 75 passenger air bag ... 74 Automatic transmission driving an automatic overdrive .. 94,95,96,97 Axle refill capacities ... 178 Battery voltage gauge ...
  • Page 187 Fuel choosing the right fuel ... 156 comparisons with EPA fuel economy estimates ... 163 detergent in fuel ... 158 filling your vehicle with fuel ... 154,155 gauge ... 12 quality ... 157 running out of fuel ... 158 safety information relating to automotive fuels ...
  • Page 188 Index Mirrors side view mirrors (power) ... 51 Motorcraft parts ... 158 Octane rating ... 157 Odometer ... 14 Panic alarm feature, remote entry system 57 Parking brake ... 90 Power distribution box (see Fuses) ... 113 Power door locks ... 51 Power steering ...
  • Page 189 fluid, checking and adding (manual) ... 145 manual operation ... 98 Trip odometer ... 15 Trunk ... 57 Vehicle dimensions . 182 Vehicle Identification Number (VIN) ... 184 Vehicle loading ... 101 104,105,106 Ventilating your vehicle ... 87 Warning chimes ... 6 Washer fluid ...

  • Page 191: Filling Station Information

    Unleaded fuel only - 87 octane 58.7L (15.5 gallons) 4.7L (5.0 quarts). Use Motorcraft 5W30 Super Premium Motor Oil, Ford specification WSS-M2C153-G See label on inside of glove box door. Pull handle under the left side of the instrument panel.
  • Page 192 Filling station information If your engine coolant is green in color, use Ford Premium Cooling System Fluid. If your engine coolant is orange in color, use Ford Extended Life Engine Coolant. Refer to Adding engine coolant, in the Maintenance and Care chapter.

This manual is also suitable for:

Mustang gt 1998

Table of Contents

Save PDF
