Radio Configuration / Diagnostic Utility
User Manual
Field
Single IP Address
Range of IP Addresses
Remote Port Number
Local Port Number
Delineation Method
EOL Delineator
EOL Time Gap
Packet Rate (milliseconds) This parameter sets the minimum time gap that will be interpreted as
Baud Rate
Data Bits
Parity
Page 58 of 123
Description
Enter the IP Address or URL of the radio that should receive
encapsulated serial protocol packets.
Enter up to 4 IP Address ranges for radios that should receive
encapsulated serial protocol packets.
Enter the remote UDP port number to use for encapsulated serial data
transmission.
Enter the local UDP port number to use for encapsulated serial data
transmission.
None: All data received between packet delineation events is sent to
the remote node in a single network frame.
Time Gap: The minimum time gap between characters that is to be
interpreted as a delineator for a packet. Configure this value in the
EOL Time Gap field.
Character: The particular character sequence in the stream of
characters that indicates the delineator for the packet. Configure this
value in the EOL Delineator field.
This field is available when the selected Delineation Method is
Character. Choose the type of delineator to use from the dropdown
list:
Available delineation types are:
Type Decimal Hex
Use Text
CR 13 0D
ESC 27 1B
LF 10 0A
Null 00 00
Spacebar 32 20
Tab 09 09
This field is available when the selected Delineation Method is Time
Gap; This value configures the length of time in milliseconds that must
elapse after a character is received (from the local attached device)
before that character marks the end of a packet.
NOTE: the smallest value this field can be set to will be limited by the
device and is platform dependent.
an inter-packet space. When detected the characters received up to
that point will constitute a single packet and will be sent to the remote
node. Units: microseconds. Values: 1,000 to 500,000.
Select the baud rate from the dropdown list. The baud rate on the
radio must match the baud rate on the connected serial device.
Select the number of data bits (5, 6, 7 or 8) from the dropdown list.
The data bits on the radio must match the data bits on the connected
serial device.
Select the parity (None, Even, Odd, 1 or 0) from the dropdown list. The
parity on the radio must match the parity on the connected serial
device.
RLXIB-IHA ♦ 802.11a
RadioLinx® 802.11a Industrial Hotspot
Description
Any string of characters
Carriage Return
Escape
Line Feed (New Line / nl)
Null
Space
Horizontal Tab
