Receiver Sensitivity (Typical)
Channel Selection
Security
Physical
Enclosure
Size
Vibration
Shock
Ethernet Ports
Antenna Port
Weight
Environmental
Operating Temperature
Humidity
External Power
PoE Injector
Average Power

1.1.2 Regulatory Approvals

Wireless Approvals
Visit our web site at www.prosoft-technology.com for current wireless approval information.
Hazardous Locations
UL
cULus
CSA/UL
ATEX
1.2

Package Contents

The following components are included with your RLXIB-IHA radio, and are all
required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Page 12 of 123
-92 dBm at 6 Mbps
-84 dBm at 24 Mbps
-72 dBm at 54 Mbps
36, 40, 44, 48, 149, 153, 157, 161, 165
WPA2 - 802.11i with 128 bit AES-CCM
Legacy WPA TKIP, WEP support
MAC ID filter
Admin password
Extruded aluminum with DIN and panel mount
115 x 117 x 45 mm (W x H x D)
4.5 x 4.6 x 1.75 inches
IEC 60068 2-6 (20g, 3-Axis)
IEC 60068 2-27 (5g, 10 Hz to 150 Hz)
One 10/100 Base-T connector, shielded RJ45
IEEE 802.3, 802.3u, 802.3x
(1) RP-SMA connector
1.1 lbs (499g)
-40°C to +75°C
Up to 100% RH, with no condensation
10 Vdc to 24 Vdc
802.3af PoE Powered Device
<9W
ANSI/ISA 12.12.01 Class I, Division 2, Groups A, B, C, D
C22.2 No. 213-M1987
ANSI/EN60950-1
EN60079-0/-15 Zone 2 Category 3
RLXIB-IHA ♦ 802.11a
RadioLinx® 802.11a Industrial Hotspot
ProSoft Technology, Inc.
July 25, 2013
