MC13xx
High Speed CMOS Camera
MC13xx Users Manual Rev. 1.19
Camera-Firmware:
V1.51-F2.53
Kamera ID Nr.:
MC1302 .. MC1319
Copyright © 2006 Mikrotron GmbH
Mikrotron GmbH
Landshuter Str. 20-22
D-85716 Unterschleißheim
Germany
Tel.: +49 89 726342 00
Fax: +49 89 726342 99
info@mikrotron.de
www.mikrotron.de
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mikrotron MC13xx
Summary of Contents for Mikrotron MC13xx
- Page 1 MC13xx High Speed CMOS Camera MC13xx Users Manual Rev. 1.19 Camera-Firmware: V1.51-F2.53 Kamera ID Nr.: MC1302 .. MC1319 Copyright © 2006 Mikrotron GmbH Tel.: +49 89 726342 00 Mikrotron GmbH Landshuter Str. 20-22 Fax: +49 89 726342 99 D-85716 Unterschleißheim info@mikrotron.de...
-
Page 2: Table Of Contents
General MC13xx Users Manual Rev. 1.19 Table of contents General..........................4 For customers in the U.S.A............................. 4 For customers in Canada ............................4 Pour utilisateurs au Canada ............................. 4 Life Support Applications ............................4 Declaration of conformity ............................5 Warranty Note................................. 6 Remarks, Warnings .............................. - Page 3 8.1.2 Dimensioned drawing, side view of MC13x6 – MC13x9 ................34 8.1.3 Dimensioned drawing, front view of MC1302/03/10/11.................. 35 8.1.4 Dimensioned drawing, rear view of MC13xx ....................35 Lens adjustment ..............................36 8.2.1 Lens adaption ..............................36 8.2.2 Adjustable lens adapter, only for camera models with C-mount flange ............36 8.2.3...
-
Page 4: General
These products are not designed for use in life support appliances, devices, or systems where malfunc- tion of these products can reasonably be expected to result in personal injury. Mikrotron customers us- ing or selling these products for use in such applications do so at their own risk and agree to fully in-... -
Page 5: Declaration Of Conformity
General MC13xx Users Manual Rev. 1.19 1.5 Declaration of conformity Manufacturer: Mikrotron GmbH Landshuter Str. 20-22 Address: 85716 Unterschleissheim Deutschland Product: camera MC1302, MC1303, MC1304, MC1305 camera MC1306, MC1307, MC1308, MC1309 camera MC1310, MC1311, MC1314, MC1315 camera MC1316, MC1317, MC1318, MC1319 The dedicated products conform to the requirements of the Council Directives 2004/108/EG for the approximation of the laws of the Member States relating to electromagnetic consistency. -
Page 6: Warranty Note
General MC13xx Users Manual Rev. 1.19 1.6 Warranty Note Do not open the body of the camera. The warranty becomes void if the body is opened. 1.7 Remarks, Warnings This document contains important remarks and warnings. See the corresponding symbols:... -
Page 7: Introduction
MC13xx Users Manual Rev. 1.19 2 Introduction The CMOS high speed camera MC13xx is a high resolution camera with 1280•1024 pixel. Benefits of CMOS technology are high speed, random access to pixels with free programmability and low power. The camera uses industry-standard C-Mount lenses. The sensor diagonal is 1,25“ with square pixels measuring 12µm. -
Page 8: Differences Between The Camera Types
Introduction MC13xx Users Manual Rev. 1.19 2.3 Differences between the camera types The CMOS cameras are available in different versions depending on the supported features mono- chrome/color or Base/Full Camera Link ® interface, lens connection to C-mount or changeable lens adapter C-mount/F-mount. -
Page 9: Hardware
If doing so, the warranty will expire immediately. 3.3 Status LED A dual colour LED on the camera backplane shows the operating condition of the MC13xx. LED orange... The MC13xx is configuring the internal FPGA. No other activity is possible. -
Page 10: Getting Started
Getting started MC13xx Users Manual Rev. 1.19 4 Getting started Before starting to operate the camera, make sure that the following equipment is available: • Camera MC13xx • C-Mount Lens • Mikrotron Support CD • Image processing system, e.g.: PC, frame grabber and Software The frame grabber must have a Base- or Full Camera Link®... -
Page 11: Initial Setup
Initial setup MC13xx Users Manual Rev. 1.19 5 Initial setup The MC13xx is delivered with initial parameters and therefore does not need to be configured via the serial link. 5.1 Serial number and firmware revision Serial number and firmware revision is provided in MC13xx non volatile memory. Use :v command (Read serial number and firmware revision) to read serial number and firmware revision. -
Page 12: Configuration
MC13xx Users Manual Rev. 1.19 6 Configuration The MC13xx has 15 FPGA registers, r1..rf , each 10 bit wide, eight D/A registers, a1..a8, 8-bit wide, and one clock select register, 4 bit wide. The contents of all the above registers is called a profile. There is space in non volatile memory for 17 profiles: one PowerUpProfile, 8 user profiles and 8 factory pro- files. -
Page 13: Table Of Commands
Configuration MC13xx Users Manual Rev. 1.19 6.1.1 Table of commands Syntax Range Answer Description :a<n><xx> <n> = 1...8 Set one of eight analog voltages for the sensor <xx> = 0...ff :A<n> <n> = En- or disable a command acknowledge or not „y“,“Y“,“n“,“N“... - Page 14 Configuration MC13xx Users Manual Rev. 1.19 Example for ":W" (output as ASCII string, 91 Bytes total, 88 databytes, 1x CR preceding the databytes, 1x CR after 32 ASCII-characters and 1x CR after 64 ASCII- characters): ↓6d6448c66500650061008541898c0000↓ 03f f03f f0000007f 0030000000000000↓...
-
Page 15: Profile Processing
Configuration MC13xx Users Manual Rev. 1.19 6.3 Profile processing All camera settings are loaded or stored as complete data blocks (= Profiles). There are 17 profiles, the Camera profile, the PowerUpProfile, eight factory profiles and eight user profiles. Power- factory... -
Page 16: Load User Profile
6.4 Video data width, Base/ Full Camera Link® MC13xx can output video data with 2 x 8-Bit or 2 x 10-Bit via the „Base Camera Link®“ interface, or 8 x 8-Bit or 10 x 8-Bit data via the „Full Camera Link®“ interface. Use register 7 Bits 7/5 to select.. -
Page 17: Gain
Configuration MC13xx Users Manual Rev. 1.19 6.5.2 Gain This is the threshold for the A/D converters. Its standard value is 66h for app. 1V. One step is app. 10mV. To increase the gain the value of a2 must be lowered. -
Page 18: Address Of The First Pixel Of A Line
. For more than one window MC13xx offers a separate function, which allows to select more fields of iew with different shapes. It can be adjusted by a selection mask consisting of 16.384 read tiles. Each tile has a size of 10(H) x 8(V). - Page 19 :r8200 and :r8000 will enable and disable the function. The programmed settings of the 2048 bytes are volatile and must be programmed new after each power up. The file may be written with the camera tool MC13xx using the function “Write” “File to camera”.
-
Page 20: Clock Selection
• image frequency) and the data rate on the output. Example: The MC13xx is connected to a frame grabber with a maximum data rate of 66MBytes/s via the„Base Camera Link®“ interface using 2 x 8 bit video data.. A pixel clock of 33 MHz has to be selected. -
Page 21: Image Format/Speed Change
Exposure time table 6-1 6.8.1 Type of exposure The MC13xx can expose the images synchronous or asynchronous. An external signal on CC1 can be used to synchronize MC13xx cameras to each other or to an external event. 6.8.1.1 Synchronous exposure Synchronous exposure means that the next image is exposed, while the current image is output. -
Page 22: Frame Rate With Synchronous Exposure
EXP (CC1) signal. The time between two consecutive EXP (CC1) edges can be indefinite. Frame rate = 1/(exposure time + image output time). Image output time equals the selected free running frame rate. Use MC13xx camera configuration tool for selection. The following registers select exposure type: Register Bits :r6[7..4] :r7[8]... -
Page 23: Synchronous Operation Without Shutter
6.8.5 External synchronisation with synchronous exposure MC13xx cameras can be synchronized to an external signal that is input on the EXP (CC1) signal. The strobe output signal of a MC13xx “master camera” can be used for that purpose. The attached frame grabber must provide the connection of an external input to the CC1 signal to the camera. -
Page 24: Frame Rate With Asynchronous Exposure
Make sure that a sync signal is present on EXP/CC1 before this command is issued or the “trigger on CC1” button is pressed on the MC13xx camera configuration tool. The polarity of the sync signal can be selected with the _Polarity_of_EXP-signal 6.8.6 Frame rate with asynchronous exposure... -
Page 25: Firmware
6.9 Firmware 6.9.1 Update Firmware MC13xx’s logic is integrated into a FPGA (Field Programmable Gate Array), which’s configuration is stored in an EEPROM. Upon power up or a command the FPGA is loaded with this configuration. Con- figuration data can be downloaded via the serial interface of Camera Link®. Mikrotron may provide configuration files (*.ibf) on request. -
Page 26: Digital Shading Correction
For the best possible image quality even at the sensors clock limit, and non uniform lighting, the MC13xx can store gray levels along one line and subtract these from all lines of an image. To setup shading correction set: :r6[1] = 0. -
Page 27: Test Image
MC13xx has a 16-Bit image counter whose count can replace the first two pixel of every image. The image counter is cleared with every low to high transition of r7[1], the camera enable bit. It is incre- mented by every new image. -
Page 28: Imageblitz® Processing
1. Wait for an active edge on the EXP input. 2. The MC13xx exposes a line, that was chosen with :rC[9..0] and is called trigger line, for an exposure time defined by :r2[9..0]. It compares the intensity of a group of 10 pixel along the selected trigger line against an adjustable threshold (:rA [7..0], Range: 255..0). - Page 29 Configuration MC13xx Users Manual Rev. 1.19 6.18.2.3 Rightmost pixel of the trigger line The end of the trigger line is determined by the value of register r9. Command: :r9<x > > ... range 000h ...7fh <x Response: none Calculation of r9: Value of r9 = pixel number / 10 6.18.2.4 Threshold level, mark trigger line...
-
Page 30: Imageblitz® Registers
Configuration MC13xx Users Manual Rev. 1.19 6.18.2.6 Release Inhibit The Release Inhibit function is defined with :rD . It tells ImageBLITZ how often sequentially the “re- lease condition” must not be met, before an image is output. This feature allows to trigger an object only once on the dark- to bright edge of the scene. This avoids retriggering, once the trigger condition was met and the object is still visible within the triggerline after the image has been output. -
Page 31: Imageblitz® Setup
Configuration MC13xx Users Manual Rev. 1.19 6.18.4 ImageBLITZ® setup The MC131x is configured for asynchronous operation with timer , registers r8, r9 and rC are loaded for the desired position of the trigger line. Register rB is loaded with 0, register rA... -
Page 32: Mc13Xx Configuration Tool
This software provides an almost self explaining user interface to modify any camera parameter. The description of the parameters follows the marked chapters in this user manual. To use this tool with the camera MC13xx the serial interface is integrated in the Camera Link® inter- face. You do not need any other additional cable. -
Page 33: Imageblitz® Configuration
MC13xx configuration tool MC13xx Users Manual Rev. 1.19 .2 ImageBLITZ® Configuration 1 Col, Num Of Col., Row ( Position of TriggerLine ): r8, r9 and rC Threshold: ease Condition: ease Inhibit: e Visible: Bit 8 ImageBL ITZ Active: Bit 0... -
Page 34: Mechanical Dimensions
Mechanical dimensions MC13xx Users Manual Rev. 1.19 8 Mechanical dimensions 8.1 Camera body MC13xx The camera body has (without lens) has very compact. To fasten the camera there are two mounting holes M4x7mm and one tripod connection on each side available. -
Page 35: Dimensioned Drawing, Front View Of Mc1302/03/10/11
Mechanical dimensions MC13xx Users Manual Rev. 1.19 8.1.3 Dimensioned drawing, front view of MC1302/03/10/11 8.1.4 Dimensioned drawing, rear view of MC13xx Cameralink® base conf., Cameralink® full conf., MDR26-connector MDR26-connector... -
Page 36: Lens Adjustment
Mechanical dimensions MC13xx Users Manual Rev. 1.19 8.2 Lens adjustment 8.2.1 Lens adaption In dependence of the camera model the MC13xx camera are prepared for either C-mount or F-mount connection (see table overview of cameras). Camera types with F-mount adaption may be converted to C-mount adaption by exchanging the lens mount flange of the camera, which is attached with 4 screws. -
Page 37: Technical Data
Technical Data MC13xx Users Manual Rev. 1.19 9 Technical Data MC1302 – MC1319 Monochrome Bayer Filter Number of pixel 1280 x 1024 Pixel size 12 x 12 µm Active area 15,36 (H) x 12,29 (V) mm Fill factor Sensitivity at 550 nm @ Vref... -
Page 38: Spectral Response
Technical Data MC13xx Users Manual Rev. 1.19 9.1 Spectral response... -
Page 39: Sensitive Area Of A Pixel
Technical Data MC13xx Users Manual Rev. 1.19 Sensitive area of a pixel Pixel size: 12 x 12 µm Fill factor: 40 % Sensitive area: 10,5 x 6,5 µm 10.5 µm Sensitive Area µm 12 µm 12 µm... -
Page 40: Connector Pinning
Technical Data MC13xx Users Manual Rev. 1.19 9.3 Connector pinning 9.3.1 Camera Link® Connector, MDR-26 „Base Camera Link® “ Pinning: signal signal XCLK- XCLK+ SERTC+ SERTC- SERTFG- SERTFG+ CC1- CC1+ CC2+ CC2- CC3- CC3+ CC4+ CC4- Table 9.3-1 „Full Camera Link® “ Pinning:... -
Page 41: Circular Power Connector, 6-Pin
Technical Data MC13xx Users Manual Rev. 1.19 9.3.2 Circular power connector, 6-pin signal signal DGND* STRB Table 9.3-3 *DGND ... digital GND for signal STRB Manufacturer: Hirose Order no.: HR10A-7P-6S Before applying power to the camera we strongly recommend to verify the used pins of the power connector, the polarity (+/-) of the leads and the supply voltage. -
Page 42: Camera Link® Bit Assignments
Technical Data MC13xx Users Manual Rev. 1.19 9.4 Camera Link® Bit Assignments 9.4.1 Base Camera Link® 2*8/10 - Bit Assignment The following table shows the bit assignment of two adjacent pixel, eight or ten bits each. All unused bits are set to logical LOW level, the SPARE outputs are set to logical HIGH level. -
Page 43: Full Camera Link® 8*8-Bit Assignment
Technical Data MC13xx Users Manual Rev. 1.19 9.4.2 Full Camera Link® 8*8-Bit Assignment The following table shows the bit assignment of eight adjacent pixel. All unused bits are set to logical LOW level, the SPARE outputs are set to logical HIGH level. -
Page 44: 10*8-Bit Assignment
Technical Data MC13xx Users Manual Rev. 1.19 9.4.3 10*8-Bit Assignment The below table shows the the assignment of 10 adjacent pixel, 8-Bit each. This assignment is compati- ble to Baslers A504 camera. Plug 1, Camera Link® X Plug 2, Camera Link® Y Plug 2, Camera Link®... -
Page 45: Frequency Selection
Technical Data MC13xx Users Manual Rev. 1.19 9.5 Frequency selection Depending on the selected line length and the datarate on the “Camera Link®” interface the frequency selection table can provide an optimal ratio of sensor /pixel clock. The pixel clock is only dependent on the selected step and not on the linelength. - Page 46 Technical Data MC13xx Users Manual Rev. 1.19 9.5.1.2 Linelength <= 240 Pixel Frequencies Pixelclock Sensorclock Framerate (fps) for (MHz) (MHz) for resolution: 240 x linelength <= 240 Pixel Step 240 Pixel 20,0 217,5 20,0 291,1 20,0 11,9 364,6 20,0 14,3...
- Page 47 Technical Data MC13xx Users Manual Rev. 1.19 9.5.1.4 Linelength <= 1280 Pixel Frequencies Pixelclock Sensorclock Framerate (fps) for (MHz) (MHz) for resolution: 1280 x linelength <= 1024 Pixel Step 1280 Pixel 20,0 10,8 20,0 14,3 20,0 17,9 20,0 21,5 20,0...
- Page 48 Technical Data MC13xx Users Manual Rev. 1.19 9.5.1.5 Respective codes for the clock synthesizer Each frequency pair corresponds to two hexadecimal codes that are used to program the synthesizer. These are also obtained on a read Camera Profile ( ) command.
-
Page 49: Frequencies For Video Data Width 8*8 - Bit, Full Camera Link
Technical Data MC13xx Users Manual Rev. 1.19 9.5.2 Frequencies for video data width 8*8 - Bit, Full Camera Link® clock pixel clock Pixelclock sensor clock Sensorclock Frame rate fps step in MHz program code in MHz program code 20,0 :S612505... -
Page 50: Programming Sequence, Factory Profile F3
Technical Data MC13xx Users Manual Rev. 1.19 9.6 Programming sequence, factory profile f3 Example: resolution: 1.280 x 1.024 pixel frame rate: 48 fps pixel clock: 35,3 MHz sensor clock: 6,65 MHz shutter: full frame , exposure time: 21 ms Strings:... -
Page 51: Timing
Technical Data MC13xx Users Manual Rev. 1.19 9.7 Timing 9.7.1 Pixel clock Tclk, 12..~200ns Pixel clock FVAL LVAL Data tdh = 4.5 ±1 ns The above illustration shows hold time of video data, LVAL and FVAL signal to rising edge of pixel clock. -
Page 52: Frame Valid (Fval)
Technical Data MC13xx Users Manual Rev. 1.19 9.7.3 Frame Valid (FVAL) FVAL tfdvl tfdvh tfdv The rising edge of FVAL marks that line, that is programmed in Register r1. Tfdvh is equal to the value programmed in Register r3 multiplied with time/line. Tfdvl in... -
Page 53: Synchronous Exposure With External Synchronisation Via Cc1
9.7.5 Synchronous exposure with external synchronisation via CC1 LVAL FVAL Image Image (n-1) STROBE exp(n) exp(n+1) sync : Exposure time selectable with register : The synchronisation frequency must be smaller than the framerate to which the MC13xx is set and sync greater 30Hz.
