Table 12. AD9854 Customer Evaluation Board (AD9854 PCB > U1 = AD9854ASVZ)
Reference
Item Qty Designator
1 3 C1, C2, C45
2 21 C7, C8, C9, C10,
C11, C12, C13,
C14, C16, C17,
C18, C19, C20,
C22, C23, C24,
C26, C27, C28,
C29, C44
3 2 C4, C37
4 2 C5, C38
5 3 C6, C21, C25
6 2 C30, C39
7 2 C31, C40
8 2 C32, C41
9 2 C33, C42
10 2 C34, C43
11 9 J1, J2, J3, J4, J5,
J6, J7, J25, J26
12 1 J10
13 4 L1, L2, L3, L5
14 2 L4, L6
15 2 R1, R5
16 2 R2, R20
17 2 R3, R7
18 1 R4
19 4 R6, R11,
R12, R13
20 1 R8
21 2 R9, R10
22 4 R15, R16,
R17, R18
23 1 RP1
24 1 TB1
25 1 U1
26 1 U2
Device Package
Capacitor 0805 805
Capacitor 0603 603
Capacitor 1206 1206
Capacitor 1206 1206
Capacitor TAJC TAJC
Capacitor 1206 1206
Capacitor 1206 1206
Capacitor 1206 1206
Capacitor 1206 1206
Capacitor 1206 1206
SMB STR-PC MNT
40-pin header Header 40
Inductor coil 1008CS
Inductor coil 1008CS
RES_SM 1206
RES_SM 1206
RES_SM 1206
RES_SM 1206
RES_SM 1206
RES_SM 1206
RES_SM 1206
RES_SM 1206
Resistor SIP-10P
network
TB4 4-position
terminal
AD9854 SV-80
74HC125D 14 SOIC
Rev. E | Page 45 of 52
Min
Value Tol Manufacturer
0.01 μF, 10% Kemet Corp.
50 V, X7R
0.1 μF, 10% Murata
50 V, X7R Manufacturing
Co., Ltd.
27 pF, 5% Yageo Corporation
50 V, NPO
47 pF, 5% Yageo Corporation
50 V, NPO
10 μF, 10% AVX
16 V, TAJ
39 pF, 5% Yageo Corporation
50 V, NPO
22 pF, 5% Yageo Corporation
50 V, NPO
2.2 pF, 0.25 Yageo Corporation
50 V, NPO pF
12 pF, 5% Yageo Corporation
50 V, NPO
8.2 pF, 0.5 Yageo Corporation
50 V, NPO pF
N/A N/A Emerson/Johnson
N/A N/A Samtec, Inc.
68 nH 2% Coilcraft, Inc.
82 nH 2% Coilcraft, Inc.
49.9 Ω, 1% Panasonic-ECG
¼ W
3.92 kΩ, 1% Panasonic-ECG
¼ W
24.9 Ω, 1% Panasonic-ECG
¼ W
1.3 kΩ, 1% Panasonic-ECG
¼ W
49.9 Ω, 1% Panasonic-ECG
¼ W
2 kΩ, 1% Panasonic-ECG
¼ W
100 Ω, 1% Panasonic-ECG
¼ W
10 kΩ, 1% Panasonic-ECG
¼ W
10 kΩ 2% Bourns
N/A N/A Wieland Electric, Inc.
N/A N/A Analog Devices, Inc.
N/A N/A Texas Instruments
Incorporated
AD9854
Manufacturer Part No.
C0805C103K5RACTU
GRM188R71H104KA93D
CC1206JRNPO9BN270
CC1206JRNPO9BN470
TAJC106K016R
CC1206JRNPO9BN390
CC1206JRNPO9BN220
CC1206CRNPO9BN2R2
1206CG120J9B200
CC1206DRNPO9BN8R2
131-3701-261
TSW-120-23-L-D
1008CS-680XGLB
1008CS-820XGLB
ERJ-8ENF49R9V
ERJ-8ENF3921V
ERJ-8ENF24R9
ERJ-8ENF1301V
ERJ-8ENF49R9V
ERJ-8ENF2001V
ERJ-8ENF1000V
ERJ-8ENF1002V
4610X-101-103LF
Plug: 25.602.2453.0;
terminal strip: Z5.530.3425.0
AD9854ASVZ
SN74HC125DR
