READ AND SAVE THESE INSTRUCTIONS
Ceiling Fan Owner's Manual
Net Weight:
Part No. F40BP74450000
LAGUNA BAY
52" Wet Location
Model Numbers
CF620AP00
CF620AW00
CF620VNB00
18.8
Lbs.
Fan Blades
Not Included
Form No. BP7445
U.L. Model No.: CF620

Advertisement

Table of Contents
loading

Summary of Contents for Emerson CF620AP00

  • Page 1 READ AND SAVE THESE INSTRUCTIONS ™ LAGUNA BAY 52” Wet Location Ceiling Fan Owner's Manual Model Numbers CF620AP00 CF620AW00 CF620VNB00 18.8 Fan Blades Net Weight: Lbs. Not Included Part No. F40BP74450000 Form No. BP7445 U.L. Model No.: CF620...
  • Page 2: Safety Instructions

    NOTE: All setscrews must be checked and re-tightened where necessary before installation. NOTE: This fan is suitable for use with solid-state speed controls. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan.
  • Page 3: Unpacking Instructions

    Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. 1. Check to see that you have received the following A.
  • Page 4: Electrical Requirements

    Electrical Requirements Your new ceiling fan will require a grounded electrical WARNING supply line of 120 volts AC, 60 Hz, 15 amp circuit. The outlet box must be securely anchored and Turning off wall switch is not sufficient. To avoid capable of withstanding a load of at least 50 pounds.
  • Page 5 How to Put Your Ceiling Fan Together (continued) 3. While pulling up on the downrod, securely tighten the two setscrews in the motor coupling (Figure 3). GROMMET NOTE: The setscrews must be properly installed as described above, or fan wobble could result. COUPLING COVER 4.
  • Page 6 How to Put Your Ceiling Fan Together (continued) 8. Remove the shipping spacers and the spacer SPACER ATTACHMENT attachment screws from the motor before SCREW installation of blade assemblies. Discard the SHIPPING spacers and spacer screws (Figure 6). SPACER 9. Mount blade flanges (supplied with fan) to fan blades (sold separately) using four #10 - 24 x 12mm washer head screws and four 16mm flat washers (supplied with fan) (Figure 7).
  • Page 7 How to Put Your Ceiling Fan Together (continued) 14. Engage the connector of the switch housing assembly with the motor connector (Figure 10). The two connectors are keyed and color-coded SWITCH HOUSING and must be mated correctly (color-to-color) ASSEMBLY before they can be engaged. Make sure the connector latch closes properly (Figure 10).
  • Page 8: How To Hang Your Ceiling Fan

    How to Hang Your Ceiling Fan CEILING WARNING The fan must be hung with at least 7' of clearance from floor to blades (Figure 12). WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. AT LEAST outlet box listed as “Acceptable for Fan Support of 22.7 kg.
  • Page 9: How To Wire Your Ceiling Fan

    OMITTED FOR CLARITY. insulation). Securely connect wires with wire connectors supplied. NOTE: If you are using an Emerson Light Fixture with your fan, see Light Fixture Owner’s Manual for wiring. 2. Securely connect the fan motor white wire to the supply white (neutral) wire using wire connector supplied (Figure 15).
  • Page 10: Fan Speed And Direction

    Emerson Electric Co. Substitution of parts or WARNING accessories not designated for use with this product by Emerson Electric Co. could result in personal The use of any other control not specifically injury or property damage. approved for this fan could result in fire, shock and personal injury.
  • Page 11: Troubleshooting

    Trouble Shooting WARNING: For your own safety, turn off power at fuse box or circuit breaker before trouble shooting your fan. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers.
  • Page 12: Repair Parts

    Repair Parts BLADES SOLD SEPARATELY U.L. Model No.: CF620...
  • Page 13: How To Order Repair Parts

    Repair Parts Listing Model Numbers Description CF620AP00 CF620AWS00 CF620VNB00 Hanger Ball Assembly, 761655-34 761655-21 761655-89 Consisting of: Hanger Bracket — — — Hanger Ball — — — Downrod (4.5”) — — — Parts Bag Containing: 764208 764208-1 764208 Pin, Clevis (1) —...
  • Page 14 Notes U.L. Model No.: CF620...
  • Page 15: Limited Warranty

    You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
  • Page 16 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Part No. F40BP74450000 Printed in China 11/11 Form No. BP7445 U.L. Model No.: CF620...
