READ AND SAVE THESE INSTRUCTIONS
52" Ceiling Fan Owner's Manual
CF654AW01 -
CF654ORB01 -
CF654WW01 -
Questions, problems, missing parts: Before returning to the store call
Part No. F40BP73360001
Revision: 131002
SEA BREEZE
WET LOCATION
Model Numbers
Summer White
Appliance White
18.70
Net Weight:
Emerson Electric Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-800-654-3545
www.emersonfans.com
Oil Rubbed Bronze
Lbs.
Form No. BP7336-1
U.L. Model No.: CF654

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF654AW01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emerson CF654AW01

Summary of Contents for Emerson CF654AW01

  • Page 1 Oil Rubbed Bronze CF654WW01 - Appliance White 18.70 Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-800-654-3545 www.emersonfans.com Part No. F40BP73360001 Form No. BP7336-1 Revision: 131002...

  • Page 2: Safety Instructions

    Emerson fan without blades. Electric Co. Substitution of parts or accessories not des- ignated for use with this product by Emerson could result 2. All wiring must be in accordance with the National in personal injury or property damage.

  • Page 3: Unpacking Instructions

    NOTE: Place the parts from the loose parts bag in designated specifically for use with this product by Emerson Electric Co. Substitution of parts or acces- a small container to keep them from being lost. sories not designated for use with this product by Emerson Electric Co.

  • Page 4: How To Put Your Ceiling Fan Together

    How to Put Your Ceiling Fan Together 1. Remove the hanger ball by loosening the setscrew 3. Tighten the two upper setscrews (Figure 2) in the hanger ball until the ball falls freely down the securely while pulling up on the downrod. downrod (Figure 1).

  • Page 5: Electrical Requirements

    6. Turn fan assembly upside down in preparation for Electrical Requirements mounting fan blade assemblies. Your new ceiling fan will require a grounded electrical IMPORTANT: THE SIDE OF THE FAN BLADE supply line of 120 volts AC, 60 Hz, 15 amp circuit. HAVING THE RIB LINE MUST BE FACING UPWARDS AS SHOWN IN FIGURE 5.

  • Page 6: How To Hang Your Ceiling Fan

    How to Hang Your Ceiling Fan WARNING WARNING Hanger bracket must seat firmly against outlet box. If The fan must be hung with at least 7' of clearance the outlet box is recessed, remove wall board until from floor to blades (Figure 7). bracket contacts box.

  • Page 7: How To Wire Your Ceiling Fan

    KNURLED KNOB (HOT) Figure 11 Figure 10 NOTE: If you are using an Emerson light fixture WARNING with your fan, remove the three screws securing the switch housing cover to the switch housing To avoid possible fire or shock, make sure that the electrical wires are completely inside the outlet box and remove the cover.

  • Page 8: Using Your Ceiling Fan

    8 - 9 feet above the floor for optimal 3. All fans are shipped from the factory with the airflow. Consult your Emerson Retailer for optional reversing switch positioned “down” to circulate air mounting accessories.

  • Page 9: Maintenance

    Emerson Electric Co. Substitution of parts or acces- sories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage.

  • Page 10: Repair Parts

    Repair Parts Before discarding packaging material, be certain all parts have been removed. HOW TO ORDER REPAIR PARTS WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: • PART NUMBER • PART DESCRIPTION • NAME OF ITEM • MODEL NUMBER The model number of your Fan will be found on a label attached to the top housing.
  • Page 11 Repair Parts Listing Service Part No. Description CF654WW01 CF654AW01 CF654ORB01 Hanger Assembly 761655 761655-21 761655-32 Ceiling Cover 761620 761620-29 761620-33 Blade Set (5) 762004 762004-4 762004-6 Flange Set (5) 763116-WW 763116-AW 763116-ORB Switch Housing Cover 763117-WW 763117-AW 763117-ORB Capacitor 763123...
  • Page 12 Customer Service, prior to your call please be prepared to provide all model numbers shown on your Emerson Ceiling Fan. Once we have processed your return autho- rization request, we will provide you with a postage paid return label which should be affixed to the Emerson Ceiling Fan package you ship to the address listed at the end of this limited warranty.
