Page 1
- Vintage Steel 24.9 Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 • Español - página 25 • Français - page 49 www.emersonfans.com Part No.
3. Do not put anything into the fan blades while they are WARNING: To avoid fire, shock or injury, do not use an turning. Emerson or any other brand of control not specifically 4. Do not operate reversing switch until fan blades have approved for this fan.
Hanger Bracket Emerson Electric Co. Substitution of parts or accessories not designated for use with this product Hanger Ball/4.5” Downrod Assembly by Emerson Electric Co. could result in personal injury Fan Blade Flanges or property damage. Fan Blades NOTE: If you are uncertain of part description, refer Check to see that you have received the following parts: to exploded view illustration below.
Turning off wall switch is not sufficient. To avoid possible electrical shock, be sure electricity is turned Please call Emerson technical support off at the main fuse box before wiring. All wiring must 1-800-654-3545 if you have any questions about be in accordance with National and Local codes and installation and operation of this ceiling fan.
3. Ceiling Fan Assembly WARNING Turning off wall switch is not sufficient. To avoid Disconnect electrical power to the branch circuit at the possible electrical shock, be sure electricity is turned circuit breaker or fuse box before attempting to install off at the main fuse box before wiring.
Page 6
3. Ceiling Fan Assembly (Continued) #10-32 x 5/16" WASHER HEAD SCREW (3) Mount the blade flange to the fan blade using three #10-32 x 5/16” washer head screws (supplied) FAN BLADE (Figure 3). Repeat this procedure for other four fan blades and blade flanges.
Page 7
Retain the screws for future use in Step 3.10. Spare #8-32 x 5/16” flat head screw is provided in parts NOTE: If you are using an Emerson light fixture bag if needed. with your fan. Remove the screw plug from the...
Page 8
3. Ceiling Fan Assembly (Continued) 3.10 REINSTALL SWITCH HOUSING #8-32 x 5/16" FLAT HEAD SCREW (3) Position the switch housing assembly on the switch SWITCH HOUSING housing adapter and align the holes in the switch ASSEMBLY housing assembly with the holes in the adapter. Secure the switch housing assembly by reinstalling the three #8-32 x 5/16”...
Page 9
3. Ceiling Fan Assembly (Continued) 3.12 THREE 80" MOTOR LEADS (UNTWISTED) Separate, untwist and unkink the three 80” motor leads. Route the 80” black, blue and white motor leads through the downrod (Figure 11). 4.5" DOWNROD Figure 11 3.13 Loosen the two setscrews in the motor coupling. Place the 4.5”...
Page 10
3. Ceiling Fan Assembly (Continued) 3.14 While pulling up on the 4.5” downrod, retighten the two setscrews (previously loosened) in the motor coupling NOTE: The setscrews must be properly installed as to secure the downrod into place (Figure 13). 4.5" DOWNROD described above, or fan wobble could result.
Page 11
3. Ceiling Fan Assembly (Continued) 3.17 4.5" DOWNROD Route the three 80” motor leads through the hanger HANGER BALL ball. Reinstall the hanger ball (Figure 16) on the downrod as follows: Position the hanger ball pin through the two holes in the downrod and align the ball so the pin is captured in the SETSCREW groove in the top of the hanger ball.
4. How to Hang Your Ceiling Fan WARNING CEILING The fan must be hung with at least 7' of clearance from floor to blades (Figure 18). AT LEAST FLOOR Figure 18 WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs.
Page 13
4. How to Hang Your Ceiling Fan (Continued) NOTE: SUPPLY WIRES AND FAN WIRES OMITTED FOR CLARITY. Carefully lift the fan and seat the hanger ball/ downrod assembly on the hanger bracket that was just attached to the outlet box (Figure 20). OUTLET Be sure the groove in the ball is engaged with the anti- rotation tab on the hanger bracket (Figure 20).
Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. Securely connect the fan motor white wire to the supply...
Page 15
5. How to Wire Your Ceiling Fan (Continued) Securely connect the fan motor black wire and blue wires to the supply black (hot) wire using wire connector (supplied) (Figure 23). FAN MOTOR BLACK WIRE SUPPLY BLACK (HOT) LISTED WIRE CONNECTOR FAN MOTOR BLUE WIRE Figure 23...
Page 16
5. How to Wire Your Ceiling Fan (Continued) Screw the two threaded studs (supplied) into the tapped holes in the hanger bracket (Figure 25). THREADED STUDS (2) Figure 25 Lift the ceiling cover up to the threaded studs and turn until studs protrude through the holes in the ceiling cover (Figure 26).
6. Using Your Ceiling Fan Restore electrical power to the outlet box by turning the electricity on at the main fuse box. All fans are shipped from the factory with the reversing switch positioned to the “left” circulate air downward. If airflow is desired in opposite direction, turn your fan OFF and wait for the blades to stop turning, then slide the reversing switch to the “right”...
WARNING Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury The use of any other control not specifically approved or property damage. for this fan could result in fire, shock and personal injury.
9. Trouble Shooting WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Reversing switch in neutral position. 1. Make sure reversing switch position is all the way to one side.
What We Will Do To Correct Problems: If during the one (1) year warranty period the motor or any component or accessory of your Emerson Ceiling Fan is defective in materials or workmanship, or if during the expected lifetime of the Emerson Ceiling Fan (when used in accordance with the User Manual or other instructions) the motor is defective in materials or workmanship, you must contact Emerson during the applicable warranty period.
Page 24
Air Comfort Products DIVISION OF EmErSON ElEctrIc cO. 8100 W. Florissant • St. louis, mO 63136 Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 www.emersonfans.com Retain this manual for future use.
