READ AND SAVE THESE INSTRUCTIONS
DEVONSHIRE
Damp Location
52" Ceiling Fan
Owner's Manual
Net Weight:
What The Warranty Covers:
This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and materials.
You must be the original purchaser or user of the product to be covered.
What The Period Of Coverage Is:
As it applies to the motor, this warranty will last for ten years from the date you purchased your ceiling fan. All other components and accessories are
covered by this warranty for one year from the date you purchased your ceiling fan. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, MADE WITH RESPECT TO COMPONENTS AND ACCESSORIES IS ALSO LIMITED TO ONE YEAR.
What Will Emerson Electric Co. Do To Correct Problems:
Emerson Electric Co. will replace a defective Emerson Air Comfort Ceiling Fan motor, blade, component or other accessory at no charge to you. If repair of the
motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson Electric Co. will refund the actual purchase
price of your fan. We will ship the repaired product or replacement to you at no charge, but you are responsible for all costs or removal, reinstallation and
shipping of the product to Emerson Electric Co.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE CEILING FAN TO OBTAIN LIMITED WARRANTY SERVICE. KEEP YOUR RECEIPT OR OTHER PROOF
OF PURCHASE. You can return the product to our factory or to your nearest authorized service center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to Air Comfort Products, Division of Emerson
Electric Company, 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model numbers shown on the product with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort
Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
What Is Not Covered:
The glass globes and light bulbs of your ceiling fan are not covered by this warranty. This warranty also does not cover any defects, malfunctions or failures
caused by:
• Repairs by persons not authorized by Emerson Electric Co.,
• Use of parts or accessories not authorized by Emerson Electric Co.,
• Mishandling, improper installation, modifications or damage to your ceiling fan while in your possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided when:
• The original purchaser or user ceases to own the product, or
• The fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or oral warranties apply, and no employee,
agent, dealer or other person is authorized to give any warranties on behalf of Emerson Electric Co.
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS WARRANTY AND EMERSON IS NOT RESPONSIBLE
FOR DAMAGES OF ANY KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGES. Incidental damages include but are not limited to such damages
as loss of time and loss of use. Consequential damages include but are not limited to the cost of repairing or replacing other property which was damaged if
this product does not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Part No. F40BP72710003
22.8
Lbs.
LIMITED WARRANTY
Model No.
CF670BQ01
CF670ORB01
ENERGY STAR
Form No. BP7271-3
U.L. Model No.: 51-OD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEVONSHIRE CF670BQ01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Emerson DEVONSHIRE CF670BQ01

  • Page 1 What Will Emerson Electric Co. Do To Correct Problems: Emerson Electric Co. will replace a defective Emerson Air Comfort Ceiling Fan motor, blade, component or other accessory at no charge to you. If repair of the motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson Electric Co. will refund the actual purchase price of your fan.
  • Page 2: Safety Instructions

    6. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not know enough about electrical wiring, have your fan installed by a licensed electrician. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan.
  • Page 3: Unpacking Instructions

    Emerson Electric Co. Substitution of parts or accessories not designated for use with this product The upper foam pad serves as a holder for the fan by Emerson Electric Co. could result in personal during the first stages of assembly. injury or property damage.
  • Page 4 WARNING It is critical that the clevis pin in the motor coupling is properly installed and the setscrews securely tightened. Failure to verify that the pin and setscrews HANGER BALL are properly installed (as shown in Figure 2) could DOWNROD result in the fan falling.
  • Page 5: Electrical Requirements

    Electrical Requirements 9. Loosely attach one blade assembly to the motor using the two captive Phillips flange screws Your new ceiling fan will require a grounded electrical (Figure 6). Make sure the screws are NOT tight- supply line of 120 volts AC, 60 Hz, 15 amp circuit. ened.
  • Page 6: How To Wire Your Ceiling Fan

    Securely connect wires with wire connectors supplied. (Figure 12.) Hanger bracket must seat firmly against outlet box. If NOTE: If you are using an Emerson Light Fixture the outlet box is recessed, remove wall board until with your fan, see Light Fixture Owner’s Manual bracket contacts box.
  • Page 7: Maintenance

    7 feet above the floor and 18 inches from the walls. If ceiling height allows, install the fan 8 - 9 feet THREADED above the floor for optimal airflow. Consult your Emerson LOCKWASHER STUD Retailer for optional mounting accessories.
  • Page 8: Troubleshooting

    WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: Air Comfort Products • PART NUMBER • NAME OF ITEM DIVISION OF EMERSON ELECTRIC CO. • PART DESCRIPTION • MODEL NUMBER 8100 W. Florissant ¥ St. Louis, MO 63136 The model number of your Fan will be found on a label attached to the top housing.

This manual is also suitable for:

Devonshire cf670orb01
