- Page 1 READ AND SAVE THESE INSTRUCTIONS WET LOCATION 52” Ceiling Fan Owner's Manual CF654ORB00 Part No. F40BP73360000 Model No. CF654AW00 CF654OB00 CF654WB00 CF654WW00 18.7 Net Weight: Lbs. ENERGY STAR Form No. BP7336 U.L. Model No.: CF653...
-
Page 2: Safety Instructions
6. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not know enough about electrical wiring, have your fan installed by a licensed electrician. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan. -
Page 3: Tools Needed For Assembly
Emerson Electric Co. Substitution of parts or acces- sories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. -
Page 4: How To Put Your Ceiling Fan Together
HANGER BALL DOWNROD DOWNROD Figure 4 6. The fan comes with blue, black and white leads that are 80-inches long. Before installing the fan, CLEVIS measure up approximately 6 to 9-inches above top of hanger ball/downrod assembly. Cut off excess... -
Page 5: Electrical Requirements
Consult a qualified electrician if in doubt. If your fan is to replace an existing ceiling light fixture, turn electricity off at the main fuse box at this time BLADE FLANGE and remove the existing light fixture. -
Page 6: How To Hang Your Ceiling Fan
How to Hang Your Ceiling Fan WARNING The fan must be hung with at least 7' of clearance from floor to blades (Figure 7). CEILING AT LEAST Figure 7 FLOOR WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. -
Page 7: How To Wire Your Ceiling Fan
GREEN WIRE (GROUND) FROM FAN Figure 10 NOTE: If you are using an Emerson light fixture with your fan, remove the three screws securing the switch housing cover to the switch housing and remove the cover. Remove the screw plug... -
Page 8: Using Your Ceiling Fan
7 feet above the floor and 18 inches from the walls. If ceiling height allows, install the fan 8 - 9 feet above the floor for optimal airflow. Consult your Emerson Retailer for optional mounting accessories. -
Page 9: Maintenance
Emerson Electric Co. Substitution of parts or acces- sories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. -
Page 10: How To Order Repair Parts
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: • PART NUMBER • PART DESCRIPTION • NAME OF ITEM • MODEL NUMBER The model number of your Fan will be found on a label attached to the top housing. For repair parts, phone 1-800-654-3545. - Page 11 — — — — — — — — — — — — — — — — — — BP7336 BP7336 CF654AW00 CF654ORB00 761655-21 761655-32 760169-32 760169-41 762004-4 762004-6 763116-AW 763116-ORB 763117-AW 763117-ORB 763123 763123 763122 763122-1 760360 760360-1 763118-2 763118 —...
-
Page 12: Limited Warranty
Emerson will refund the actual purchase price of your fan. We will ship the repaired product or replacement to you at no charge, but you are responsible for all costs or removal, reinstallation and shipping of the product to Emerson Electric Co.
