Summary of Contents for Windsor Versamatic VSE I-3
- Page 1 VSE l-3 Optional Straight Tube 1084 Crevice Nozzle 1092 Clip 1081 Dusting Brush 1094 Upholstery Nozzle 1090 6 Wall- and Upholstery Brush 1325 Paper Bag (Pkg of 10) 2003 Cloth Bag 1079 (only use with Micro-Filter) Exhaust Filter 1534 1044 Micro-Hospital-Filter 1435...
-
Page 2: Important Safety Instructions
1. Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing. 2. Do not use outdoors or on wet surfaces. 3. Do not use near small children. Do not allow to be used as a toy. Close attention is necessary when used by or near children. -
Page 3: Grounding Instructions
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be inserted into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 4: Important Safeguards
This vacuum cleaner is designed to be safe when used to perform cleaning functions. Should damage occur to electrical or mechanical parts, cleaner should be repaired by WINDSOR or competent service station before using in order to avoid further damage to machine or physical injury to user. -
Page 5: Maintenance
Preparation To release the machine from (1) Vacuum motor housing the upright position press down (2) Dustbag housing the foot pedal. (16) (3) Suction hose (4) On -off switch Cable cleats (6) Carrying recess (7) Back cover (8) Power head Hold the vacuum section in the Power head motor stops auto- vertical position and insert into... -
Page 6: Service Instructions
Service Instructions To remove the dust bag housing (2) from the vacuum motor housing (1) take off the back cover and remove the four large screws. Keeping the power head attached, the dust bag housing can be eased off. The switch housing cover is removed by taking out the three screws then lifting off. Circuit Board (33) can be removed by loosening screw (32). -
Page 7: Parts List
Parts List... -
Page 8: Limited Warranty
WINDSOR will, at its option, repair or replace without charge, except for transportations costs, parts that fail under normal use and service when operated and maintained in accordance with the Instructions Manual.
