2.6.Create Billing Plan

To create billing plan, click on packages tab, then add prepaid or add postpaid. Billing
plan is a template of the internet access configuration. Billing plan is used to generate
voucher or manually add the users. If postpaid plan is selected, you have to define the
corresponding tariff of it. Tariff is not necessary on prepaid billing.
2.7.Add User Account
User accounts is a combination of username and password used to access services
provided, distinguished in two types:
Voucher: A prepaid voucher is a random generated users and passwords. Prepaid billing
system is applied. Click Generate voucher to generate user accounts.
User: A manually set user and password. Both prepaid and postpaid can be applied to
manually added users. A postpaid account requires a postpaid billing plan. Click add user
to manually add a user account.
In addition when postpaid account is stopping the internet connection, the operator will
be closing via bill menu and afterwards click print invoice. When the invoice has been
created for the postpaid account, that account would not ever be used again.

3.Hotspot Operation

3.1.Integration with your Network

To integrate HotSpotEngine into your network, connect your existing network into the
WAN interface, and your wireless access point / switch hub into the LAN interface.
