Summary of Contents for Uwatec X-Tek

  • Page 1 ® X-Tek...

  • Page 2: Table Of Contents

    Adjustment: FORM HARNESS SYSTEM ................27 Thread Guide: SOFT TRAVEL BACK PACK ................. 30 Thread guide: SINGLE TANK ADAPTER ................31 Attachment: SOFT BACKPLATE ON X-TEK FORM HARNESS .......... 33 ADJUSTING THE SYSTEM: ....................34 Waist and Front Closures ..................34 AFTER THE DIVE ........................

  • Page 3: Important Warnings

    This information is for your safety. Please read the entire instruction manual before using your X-TEK buoyancy compensator and equipment for the first time! IMPORTANT WARNINGS ! WARNING This manual must be read and understood entirely before using the product. It is advised that you keep this manual in your possession during the entire life of your BC.

  • Page 4: En 250: 2000 Norm Regulations And What They Mean

    ! WARNING In accordance with European standards, our BCs can only be considered certified where all components are present, as per the original SCUBAPRO configuration, including the low pressure hose supplied. Any variation of the original configuration invalidates conformity to European certification standards.

  • Page 5: General Information

    Accessory Weight Pocket System The removable Buckle Weight Pocket System (BW) (Picture 1) is designed to be used with the waist webbing of the X-Tek backplate system. Pictured below is the proper way to load and secure the weight pockets into their pouches.

  • Page 6: Tank Counter Weight Pouches

    The weights are inserted into the weight pocket (Picture2) The weight pockets are pushed into the weight pockets system (Picture 3+4) and held in proper position by securing the quick release buckle and then pulling the strap until it is snug (Picture 5) To release the weights from the pouch squeeze the tabs on the quick release buckle and pull the pocket from the pouch.

  • Page 7: Valve Set Up

    SCUBAPRO X-TEK BC´s are completed by the BPI System(Balance Power Inflator). It is possible to change the SCUBAPRO Balance Power Inflator to the X-TEK Inflator. This must be done by an authorized dealer or the company SCUBAPRO. The power inflator, when connected to the tank and regulator by a low pressure hose, makes it possible to control buoyancy in the water (inflation/ deflation of the BC) by using inflate and deflate buttons.

  • Page 8: Deflating The Bc With The Manual Dump Valve

    Over Pressure Valve (OPV). Shoulder Valves SCUBAPRO X-Tek bladders may have either an elbow or an overpressure valve on the left shoulder that can also act as dump valves. The dump valve on the left shoulder is activated either by: a) Pulling gently on the hose assembly.

  • Page 9: Bc Examination And Procedures

    ! WARNING Never breathe from the BC. Your BC may contain gas residue, liquid, or contamination that may result in injury or death if inhaled. Keep water out of the bladder of the BC. Repeated use of the oral valve or the Overpressure Valve may allow water inside the BC, reducing the amount of buoyancy provided by the BC.

  • Page 10: Low Pressure Hose / Pneumatic Inflation Valve

    Pure TEK Harness: Pure TEK System, stainless steel backplate, 50 mm high-strength strap, 3 D-Rings, belt strap, crotch, belt stopper, single tank adapter. X-TEK PURE TEK SYSTEM, Doubletank Specifically to the needs of the Pure TEK tailored jacket. Donut Wing with 27 kg* (270 Lift N for max. bottle size 2x12l) buoyancy , SCUBAPRO Power Inflator.
  • Page 11 Form TEK Harness: Form System, padded back panel with two shoulder pads, 6 x D-rings, crotch. X-TEK PRO TEK SYSTEM TWIN With this system you are prepared for any dives. Two Layer Wing, two redundant bladders, stainless steel backplate and 50 mm high-strength strap give you the security you need in any depth.

  • Page 12: Thread Guide: Pro Harness System

    Thread Guide: PRO HARNESS SYSTEM 1. Place the webbing with the hole aligned onto the center rear of the backplate. Depending of height of your tank you use the upper or lower hole at the backplate. 2. Thread the right end of the strap through the right angled slot at the top of the back plate. Repeat the procedure with the left side.
  • Page 13 4. Attach the right shoulder pad by threading the strap through the top pad loop. Make sure that the webbing is on the outside of the pad. (The exact adjustment of the shoulder pads is described on page 34). 5. Thread a three bar slide on the right side to the shoulder pad. 6.
  • Page 14 8. Thread the end of the strap through the second loop. 9. Thread the second three bar slide between the second and the third loop, as described above. 10. Thread the three bar slide- without teeth- on the webbing for the left strap. Make sure that it is at the same height as the right shoulder strap is located.
  • Page 15 11. Thread the webbing through all loops of the left shoulder pad. Make sure that the webbing is on the outside of the shoulder pad. 12. Thread the end of the strap through the lower slot of the female Quick Release Buckle. 13.
  • Page 17 15. Thread the end of the webbing through the top of the three bar slide (see 10). 16. Snap the quick release buckle together.
  • Page 18 17. Thread the end of the webbing for the bottom left strap from the inside out through the inner slot. 18. Thread a three bar slide to the webbing and thread the end of it from the outside in, through the outer slot.
  • Page 19 19. Thread a three bar slide about 4 inches (10cm) away from the front of the backplate. 20. Thread a flat D-ring up to the three bar slide and then lead the end of the webbing through the second slot of the three bar slide. 21.
  • Page 20 22. Thread the right end of the webbing in the same manner as described in step 18 on Page 16.
  • Page 21 23. Attaching the crotch strap: Place the inverted plate on a table, so that you can see the backside of the plate. Place the crotch strap in front of you, so that the D-ring with the three bar slide is facing up. Thread the upper end of the strap from back to front through the lower slot of the backplate.

  • Page 22: Thread Guide: Pure Tek Harness System

    25. Thread the other end of the crotch strap with the loop on the waistband. ! WARNING When using a weight belt with the crotch strap you must place the weight belt on top of the crotch strap so it can fall freely from your body. Failure to follow this practice will prevent the weight belt from being released and may result in serious injury or death.
  • Page 23 3 Thread the ends of the webbing through the top horizontal slits of the front through the backplate. front view rear view rear view rear view front view 4. Thread a three bar slide and a curved D-ring to the webbing on the right side. Make sure that the curve is facing up.
  • Page 24 6. Thread the left end of the webbing from the inside out through the inner slot. 7. Thread a three bar slide to the webbing and thread the end of the strap from the outside in, through the outer slot.
  • Page 25 8. Thread a three bar slide to about 4 inches (10cm) from the front of the backplate. 9. Thread a flat D-ring up to the three bar slide and then lead the end of the webbing through the second slot of it. 10.
  • Page 27 11. Thread the right side of the webbing as described in steps 6, 7 & 8 on Pages 22 & 23.

  • Page 28: Adjustment: Form Harness System

    Adjustment: FORM HARNESS SYSTEM You have the option to position the shoulder straps at the Form Harness System in different ways: 1. Thread the strap with the stainless steel buckle inward, in order to position the shoulder straps further back. Weight Pocket...
  • Page 29 2. Thread the strap with the stainless steel buckle outward, in order to position the shoulder straps on the outside.
  • Page 30 3. To widen the placement of the straps you can adjust them to the desired position. Use the same instructions as described above.

  • Page 31: Thread Guide: Soft Travel Back Pack

    Thread Guide: SOFT TRAVEL BACK PACK Super Cinch Tank Strap: 1. Set the soft backplate in front of you, so you see the loops. Unthread the D-ring and the plastic stopper. 2. Thread the Super Cinch belt without the grommets through the upper loop. 3.

  • Page 32: Thread Guide: Single Tank Adapter

    Remove the D-ring and the plastic stopper from the Super cinch strap and then thread it though the slots of the adapter. Replace the plastic stopper first and the the D-ring. Attachment of the single tank adapter to the X-TEK Form Harness, Pro Harness, Pure Tek Harness in conjunction with the stainless steel backplate:...
  • Page 33 1. Place the backplate so it is facing down and then place the bladder onto the backplate. 2. Place the single tank adapter on the bladder so that the grommets are on top of each other. Insert the screw from the bottom of the backplate and through the grommets and tighten the nut from the top.

  • Page 34: Attachment: Soft Backplate On X-Tek Form Harness

    Attachment: SOFT BACKPLATE ON X-TEK FORM HARNESS ! WARNING Check the tightness of the screws and nuts before each dive. The system must be securely fastened together to be used safely. Failure to check the security of the system may lead to the tank becoming detached before, during, or after the dive and could lead to serious injury or death 1.

  • Page 35: Adjusting The System

    ADJUSTING THE SYSTEM: ! WARNING Adjust the BC so that it does not restrict your breathing when fully inflated. Restriction of normal breathing while wearing your BC could result in injury or death. Before each use, check all bands, straps, quick-connect clips, and/or cummerbund for proper adjustment to the user.

  • Page 36: After The Dive

    AFTER THE DIVE Cleaning the BC, Check, Storage and Transport: Correct servicing and maintenance guarantees you many years reliable function of your SCUBAPRO X-TEK BC. ® Keep the following instructions for care: • Fill the bladder with fresh water and shake so that the water reaches everywhere.

  • Page 37: Transport Of The X-Tek Systems

    TRANSPORT OF THE X-TEK SYSTEMS: Handle the XTEK systems in such a way to ensure that no sharp or heavy objects (e.g. knives, bottles, lamps, lead etc.) damage the harness, bladder, or inflators. IMPORTANT! Avoid prolonged or repeated exposure to chlorinated water, such as in swimming pools.

  • Page 38: General Specifications

    28°F 104°F X-TEK WING BLADDERS Diving with a back inflation wing BC is different from a standard BC. The X-Tek system uses either a Horseshoe or Donut shaped bladder. Bladder: Each bladder is constructed of a 1680DEN Ballistic Nylon outer cover and one or more inner bladders constucted from 420 D Nylon.

  • Page 39: Appendix

    Appendix Attachment: CLAMPS FOR TWIN TANKS 1. Put the clamps onto the double tank. (The setting of the clamps for the tank bottles, as described on pages 39-40). 2. Turn the screws for the clamps from back to front, towards the backplate. 3.

  • Page 40: Adjustment Of The Bands On The Double Tanks

    Adjustment of the bands on the double tanks: For setting the bands on the double tanks, you should note the following: • Attach the bands to the tanks. • The distance between the two tank valves is set by using the connector manifold. The distance between the tank bands (see sample drawing below), has to be the same as between the valves.
  • Page 41 Procedure: Set the tanks parallel, the valves showing in one direction. Screw the connector manifold into a valve. The space between A and B, (see picture above) should be exactly the same as the measure between the clamps. (See sample drawing page 37).
  • Page 42 X-TEK Accessory Bag big 23812000 X-TEK Counter Weight Pockets 23817000 X-TEK Buoy Bag 23813000 X-TEK Inflator 23814000 X-TEK Double -Tank Clamps ss140mm 23815000 X-TEK Double -Tank Clamps ss171mm 23816000 X-TEK Double -Tank Clamps ss204mm 21200217 SCUBAPRO Quick Stop Valve 22193010...
  • Page 43 Test according to DIN EN 1809:1998-1 Buoyancy Notified body 0299 BG Bau, Arbeitsschutzzentrum Haan, Zentrum fuer Sicherheitstechnik, Zwengenberger Str. 68, 42781 Hann, Germany.
  • Page 44 SUBSIDIARIES SCUBAPRO SCUBAPRO GERMANY SCUBAPRO ASIA PACIFIC Johnson Outdoors SWITZERLAND 1208 Block A, MP Industrial Center Vertriebsgesellschaft mbH Oberwilerstrasse 16 18 Ka Yip St. Johann-Höllfritsch-Str.47 CH-8444 Henggart - Switzerland Chai Wan - Hong Kong 90530 Wendelstein - Germany SCUBAPRO SCUBAPRO SCUBAPRO AUSTRALIA ITALY...
