Mini DV & HDD & DVD VIDEO RECORDER
DR-DX5SU
CABLE/DBS
TV
DVD
STANDBY/ON
TV/
VIDEO
TV/CBL/DBS
DVD
DV
HDD
DVD
TV VOL
CH
CANCEL
AUX
MEMO/MARK
LIVE
DUBBING
EDIT
PROG
TV MUTING
TOP MENU
NAVIGATION
ENTER
MENU
RETURN
PREVIOUS
NEXT
SLOW
PLAY/SELECT
SLOW
REC
STOP/
CLEAR
PAUSE
JUMP
REC MODE
DISPLAY
ON SCREEN
SET UP
REMAIN
STANDBY/ ON
VPS/PDC
SAT
S-VIDEO
VIDEO
(MONO)
L–AUDIO–R
PROGRESSIVE
AUDIO
SUBTITLE
ANGLE
SCAN
F–1
LIVE CHECK
RAM/RW
DV –
HDD –
DVD –
CH
INSTRUCTIONS
DV/HDD/DVD
SELECT
DV IN/OUT
DISPLAY
VHS
REC MODE
DV/HDD
NTSC
For Customer Use:
Enter below the Model No. and Serial
No. which are located on the rear of
cabinet. Retain this information for
future reference.
Model No.
Serial No.
EN
LPT1099-001A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR-DX5SU and is the answer not in the manual?

Questions and answers

Related Manuals for JVC DR-DX5SU

Summary of Contents for JVC DR-DX5SU

  • Page 1 Mini DV & HDD & DVD VIDEO RECORDER DR-DX5SU CABLE/DBS STANDBY/ON VIDEO TV/CBL/DBS TV VOL CANCEL MEMO/MARK LIVE DUBBING EDIT PROG TV MUTING TOP MENU NAVIGATION ENTER MENU RETURN PREVIOUS NEXT SLOW PLAY/SELECT SLOW STOP/ CLEAR PAUSE JUMP REC MODE...

  • Page 2: Safety First

    SAFETY FIRST Dear Customer, Thank you for purchasing the JVC Mini DV & HDD & DVD video recorder. Before use, please read the safety information and precautions to ensure safe use of your new unit. Cautions CAUTION RISK OF ELECTRIC SHOCK...
  • Page 3 IMPORTANT PRODUCT SAFETY INSTRUCTIONS Electrical energy can perform many useful functions. But improper use can result in potential electrical shock or fire hazards. This product has been engineered and manufactured to assure your personal safety. In order not to defeat the built-in safeguards, observe the following basic rules for its installation, use and servicing.
  • Page 4 SAFETY FIRST 1. Accessories To avoid personal injury: Do not place this product on an unstable cart, stand, tripod, bracket, or table. It may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.
  • Page 5 DISCLAIMER OF LIABILITY JVC shall not be liable for any loss relating to the unit’s failure to properly record, store or playback any content (video, audio or otherwise) for any reason whatsoever. Any applicable warranties shall only cover replacement or repair of the effected unit, and shall not apply to recovery or replacement of lost content.

  • Page 6: Table Of Contents

    CONTENTS SAFETY FIRST DISC INFORMATION About Discs ...7 INDEX INSTALLING YOUR NEW UNIT Basic Connections ...18 INITIAL SETTINGS Plug & Play Set ...19 Language ...20 Clock Set...21 Tuner Set ...22 Monitor Set...23 BASIC OPERATIONS ON DVD DECK Basic Playback...24 Playback Features ...25 Using The On-screen Bar ...29 Parental Lock ...33 Basic Recording ...34...

  • Page 7: Disc Information

    2005. Recording and playback may not be performed depending on the characteristics and condition of the disc used, leading to unsatisfactory results. Using discs manufactured by JVC is recommended since they have been tested to be compatible with this unit.

  • Page 8: Discs For Playback Only

    DISC INFORMATION Discs For Playback Only You can use discs with the following logos for playback only. DVD VIDEO Video CD/Super Video CD (example of region code indications) Audio CD CD-DA files CD-RW CD-DA/JPEG/ MP3/WMA files Playback may not be performed depending on the characteristics and condition of the disc used.

  • Page 9: Recording Medium And Format

    Recording Medium And Format DVD-RAM Recording and erasing can be performed as many times as possible on a disc. Editing can be performed after recording, such as deleting unwanted parts. While recording, it is possible not only to start playback of a program currently being recorded, but also to watch another program previously recorded.
  • Page 10 DISC INFORMATION DVD VIDEO Marks Sometimes marks are printed on a DVD disc and/or on its packaging to indicate information regarding the contents and functions of the disc. Check the marks indicating the contents and functions of the disc. Note, however, that in some cases a disc may not include a mark even for a function it supports.
  • Page 11 Care And Handling Of Discs How to handle discs When handling a disc, do not touch the surface of the disc. Since discs are made of plastic, they are easily damaged. If a disc gets dirty, dusty, scratched or warped, the images and sound will not be picked up correctly, and such a disc may cause the unit to malfunction.

  • Page 12: Index

    INDEX Front View STANDBY/ ON S-VIDEO VIDEO L–AUDIO–R (MONO) F–1 A Eject Button (M) (DV) A pg. 41 This button functions even if this unit is turned off. B Mini DV Cassette Loading Slot C DV Lamp (DV) A pg. 41 DV Recording Lamp (R) D HDD Lamp (HDD) A pg.

  • Page 13: Rear View

    Rear View A Region Number A pg. 8 B AC Power Cord A pg. 18 C Cooling Fan This prevents the temperature from rising inside the unit. Do not remove it. Install the unit so as not to block the area around the fan. The unit may become hot when it is turned off, as the cooling fan on the rear of the unit is not activated.
  • Page 14 INDEX Front Display Panel A Disc Type Indicator When a disc is loaded, the type of the disc is indicated. Disc Status Indicator When a disc is running, the disc marks rotate. VR Mode Indicator (VR) A pg. 74 Lights when a DVD-RW disc is formatted in VR mode. B Linear PCM Indicator (LPCM) Lights when AXP MODE REC AUDIOB is set to ALINEAR PCMB (A pg.
  • Page 15 (F and G) matched correctly as indicated on the battery compartment or on the lid. The remote control can operate most of your unit’s functions, as well as basic functions of TV sets of JVC and other brands. (A pg. 67) PROGRESSIVE...
  • Page 16 INDEX On-Screen Display (HDD & DVD deck) When ASUPERIMPOSEB is set to AAUTOB and ON SCREEN on the remote control is pressed, various operational indicators appear on the TV screen. To clear the operational indicators, press ON SCREEN twice. When playing back a recorded title 0:00 1:00 2:00...
  • Page 17 On-Screen Display (DV Dubbing) When capturing images from the external DV equipment 0:00 1:00 00:00:00. 00 FR360 12bit GR-DV3500 A Recording speed B HDD capacity graph C HDD time counter D Recording time scale E HDD mode F Remote control mode G Connected DV equipment mode H Connected DV equipment model information I Input channel...

  • Page 18: Installing Your New Unit

    INSTALLING YOUR NEW UNIT Basic Connections Antenna or Cable Coaxial cable AC outlet Flat feeder Matching transformer (not supplied) AC power cord Back of unit To [S-VIDEO [AUDIO/ [COMPONENT OUTPUT] VIDEO OUT (Y/P Component S-video cable Audio/Video (not supplied) video cable (not supplied) It’s essential that your unit be properly connected.

  • Page 19: Initial Settings

    Plug & Play Set Auto Clock Set/Auto Tuner Set This unit sets the clock and tuner channels automatically when AC power cord is first connected to an AC outlet. The antenna cable must be connected for the Plug & Play setting. The time and date can be set automatically by the clock setting data transmitted from one of the regular TV broadcast channels.

  • Page 20: Language

    INITIAL SETTINGS Language Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. ENTER On-screen Language Set This unit offers you the choice to view on-screen messages in 3 different languages. Press HDD or DVD so that the HDD or DVD lamp lights up on the unit.

  • Page 21: Clock Set

    Clock Set Perform clock setting only if the clock has not been set correctly by the Plug & Play setting. Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. ENTER Semiauto Clock Set You can change the host channel/D.S.T.

  • Page 22: Tuner Set

    INITIAL SETTINGS Tuner Set Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. ENTER INFORMATION The unit selects the correct mode (TV or CATV) automatically during Auto Channel Set. The selected mode (TV or CATV) will be displayed on the right side of ABANDB on the Manual Tuner Set screen.

  • Page 23: Monitor Set

    Monitor Set You can select the monitor type depending on the TV used when you play back DVD VIDEO discs recorded for wide-screen TVs. Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. ENTER Press DVD so that the DVD lamp lights up on the unit.

  • Page 24: Basic Operations On Dvd Deck

    BASIC OPERATIONS ON DVD DECK Basic Playback Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. DVD lamp ENTER ATTENTION: It takes approximately 30 seconds to read a disc depending on the type and condition of the disc since this unit is multi-disc compatible (DVD-RAM, DVD-RW, DVD-R).

  • Page 25: Playback Features

    Playback Features Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. Press DVD so that the DVD lamp lights up on the unit. TOP MENU ENTER MENU O/SLOW - JUMP - JUMP + Locating A Desired Scene Using The DVD Menu DVD VIDEO discs may have top menu and disc menu.
  • Page 26 BASIC OPERATIONS ON DVD DECK Skip Search During playback, press v. Each press initiates an approximately 30-second period of fast- motion playback. Normal playback resumes automatically. Skip search cannot be performed when a VCD/SVCD disc is being played back with the PBC function. One Touch Replay You can move back the playback position slightly.

  • Page 27: Marking Positions To Play Back Again Later

    ENTER MENU S/PREVIOUS REC MODE/REMAIN DISPLAY AUDIO SUBTITLE Marking Positions To Play Back Again Later It is possible to mark positions (up to 999 points) where you want to play back once again later, and start playback from a marked position.
  • Page 28 BASIC OPERATIONS ON DVD DECK Subtitle Selection Some DVD VIDEO discs contain more than one subtitle language, from among which you can choose the desired subtitle language. AhB appears on the TV screen at the beginning of the part where more than one subtitle language are recorded.

  • Page 29: Using The On-Screen Bar

    Using The On-screen Bar The on-screen bar allows you to control various playback functions. Some of the functions operated on Navigation Menu can be controlled on the On-screen bar. ATTENTION: The on-screen bar can also be used for the HDD deck. Be sure to clear Library Database Navigation screen by pressing NAVIGATION.
  • Page 30 BASIC OPERATIONS ON DVD DECK DVD-RAM/RW/R Repeat playback is not performed. ALL REPEAT The whole disc is played back repeatedly. TITLE REPEAT The current title is played back repeatedly. DVD VIDEO Repeat playback is not performed. TITLE REPEAT The current title is played back repeatedly. CHAPTER REPEAT The current chapter is played back repeatedly.

  • Page 31: Simulated Surround Effect

    CANCEL ENTER CLEAR Time Search You can play back a disc from the desired point by specifying the elapsed playing time from the beginning of a program (DVD-RAM, DVD-R, DVD-RW, DVD VIDEO and HDD) or a disc (Video CD/ SVCD and Audio CD). Press ON SCREEN twice to access the on-screen bar.
  • Page 32 BASIC OPERATIONS ON DVD DECK Setting The Progressive Mode You can obtain optimal picture quality by selecting whether the content on the disc is processed by field (video source) or by frame (film source). Set the unit to the progressive scan mode. (A pg. 76) Press ON SCREEN twice to access the on-screen bar.

  • Page 33: Parental Lock

    Parental Lock This function restricts playback of DVD VIDEO discs which contain violent (and other) scenes according to the level set by the user. For example, if a movie which includes violent scenes supports the parental lock feature, such scenes which you do not want to let children view can be cut or replaced by other scenes.

  • Page 34: Basic Recording

    BASIC OPERATIONS ON DVD DECK Basic Recording Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. ATTENTION: It is not possible to record programs on a DVD-R disc which has already been finalized.

  • Page 35: Recording Features

    Recording Features Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. Press DV/HDD/DVD SELECT on the unit repeatedly or DVD on the remote so that the DVD lamp lights up on the unit. DVD lamp REMAIN Instant Timer Recording (ITR)
  • Page 36 BASIC OPERATIONS ON DVD DECK Free Rate Function To record the entire program, the unit automatically sets the appropriate recording mode depending on the combination of the total time of the program to be recorded and either the remaining disc space or the specified recording time (from 60 minutes to 480 minutes).

  • Page 37: Basic Operations On Hdd Deck

    Basic Recording Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. ATTENTION: The HDD on the unit requires approximately 20 seconds to start up after the unit has been turned on, during which no operation can be made.

  • Page 38: Recording Features

    BASIC OPERATIONS ON HDD DECK Recording Features Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. Press DV/HDD/DVD SELECT on the unit repeatedly or HDD on the remote so that the HDD lamp lights up on the unit. HDD lamp REMAIN Instant Timer Recording (ITR)

  • Page 39: Basic Playback

    Basic Playback Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. ENTER DISPLAY ATTENTION: It may take a few seconds to start playback. This is not a malfunction. Forward/reverse high-speed search and other operations cannot be performed while playback is stopped.

  • Page 40: Jump Search

    BASIC OPERATIONS ON HDD DECK One Touch Replay You can move back the playback position slightly. Press w. Each press skips back for approximately 7 seconds and resumes playback. Pressing while paused skips back for approximately 7 seconds and resumes pause. 1.5x Speed Playback You can play back a title quickly.

  • Page 41: Basic Operations On Dv Deck

    Basic Playback Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. DV lamp Load a cassette. Make sure the window side is up, the rear label side is facing you and the arrow on the front of the cassette is pointed toward the unit.

  • Page 42: Playback Features

    BASIC OPERATIONS ON DV DECK Playback Features Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. Press DV/HDD/DVD SELECT on the unit repeatedly or DV on the remote so that the DV lamp lights up on the unit. DISPLAY AUDIO ATTENTION:...

  • Page 43: Live Memory Playback On Hdd/Dvd Deck

    Live Memory Playback Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. Press DV/HDD/DVD SELECT on the unit repeatedly to select the HDD or DVD deck. This unit records pictures onto the hard disk and DVD-RAM disc, instead of video tapes, then plays back the pictures recorded on the disc.
  • Page 44 LIVE MEMORY PLAYBACK ON HDD/DVD DECK Buttons To Be Used During Live Memory Playback Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. Press HDD or DVD to select the desired deck for Live Memory Playback.
  • Page 45 Temporary recording for Live Memory (HDD deck only) This unit automatically records the channel being received, within the specified range of time, to the reserved space on the hard disk. The time range can be set for 30 minutes, 1 hour, and 3 hours. (A pg.

  • Page 46: Timer Recording On Hdd/Dvd Deck

    TIMER RECORDING ON HDD/DVD DECK VCR Plus+ Timer Programming You can program this unit to timer record as many as 32 programs. With the VCR Plus+ system, timer programming is greatly simplified because each TV program has a corresponding code number which your unit is able to recognize.

  • Page 47: Weekly/Daily Recording

    Weekly/Daily Recording You can record programs with one of the following weekly/daily timer settings. For the HDD deck When you select a mode other than ONCE, the space on the hard disk drive is saved for new recordings by overwriting previous recordings.

  • Page 48: Manual Timer Programming

    TIMER RECORDING ON HDD/DVD DECK Manual Timer Programming You can program this unit to timer record as many as 32 programs. If you do not know the PlusCode number for the program you wish to record, use the following procedure to set your unit to timer record the program.
  • Page 49 CABLE/DBS PROG ENTER Selection Keys FGDE TIMER RECORDING ON HDD/DVD DECK Check Programs To check the whole list of programs Press PROG to access the program top screen. Press selection keys to select APROGRAM LISTB, then press ENTER. The details of a selected program appear on the top of the screen.

  • Page 50: Navigation On Hdd/Dvd Deck

    NAVIGATION ON HDD/DVD DECK Library Database Navigation The Library Database Navigation enables you to search and select the desired titles recorded on the HDD deck and the DVD deck very easily. You can record up to 99 titles on a disc. Each time a title is recorded, the information of the title is registered for the Library Database Navigation automatically.

  • Page 51: Edit Original Information

    Scan For Beginning Of Title Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. Press HDD or DVD to choose the corresponding deck. Load a DVD disc to scan. CANCEL ENTER You can scan the beginning of the title easily with the Library Database Navigation.
  • Page 52 NAVIGATION ON HDD/DVD DECK Modify Category Perform steps 1 – 4 of AModify IndexB (A pg. 51) before continuing. Press selection keys to select ACATEGORYB, then press ENTER. Press selection keys to select the desired category, then press ENTER. Press EDIT to return to the normal screen.

  • Page 53: Edit Play List Information

    Divide Title (HDD deck only) Press EDIT. The Editing screen appears. Press selection keys to select ADIVIDEB, then press ENTER. Press selection keys to select a title to divide, then press ENTER. Press I to start playback. Press O or N to locate a point to divide, then press W.
  • Page 54 NAVIGATION ON HDD/DVD DECK Create Play List Press EDIT. The Editing screen appears. (DVD deck only) Press selection keys to select AMODIFYB under AORIGINAL/PLAY LISTB, then press ENTER. Press selection keys to select ACREATEB, then press ENTER. Press selection keys to select a title that includes scenes to be included in a play list, then press ENTER.

  • Page 55: Navigate Library Information

    Press NAVIGATION to return to the normal screen. NOTES: It is not possible to register discs formatted on devices other than JVC’s DVD recorders. It is not possible to register discs recorded on devices other than JVC’s DVD recorders. It is not possible to register discs when ASAVE AS LIBRARYB is set to AOFFB.

  • Page 56: Playback With Mp3/Wma/Jpeg Navigation

    NAVIGATION ON HDD/DVD DECK Playback With MP3/WMA/JPEG Navigation This unit can play back discs that MP3/WMA sound files and JPEG image files taken with digital still cameras or other devices are recorded. The MP3/WMA/JPEG Navigation enables you to search and select the desired files recorded on CD-R/RW or CD-ROM discs very easily.

  • Page 57: Editing

    Dubbing Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. DUBBING ENTER NOTES: It is not possible to dub copy-protected contents. An error message will appear on the TV screen. It is not possible to dub simultaneously when timer programming is set.
  • Page 58 EDITING Dubbing From HDD To DV It is possible to perform dubbing from the HDD deck to the DV deck. Load a Mini DV cassette with the erase protection switch set to ARECB. Press DUBBING to access the Dubbing Menu screen. Press selection keys to select AHDDNDVB, then press ENTER.
  • Page 59 Dubbing From DV To HDD (Dubbing An Entire Cassette) It is possible to perform automatic dubbing of all the recorded programs of a cassette from the DV deck to the HDD deck using the AENTIREB dubbing. You cannot select the images to be dubbed;...

  • Page 60: Dv Dubbing (Hdd & Dvd Deck Only)

    EDITING DV Dubbing (HDD & DVD Deck Only) You can dub programs from a camcorder or DV equipment connected to the unit with a DV cable. The unit’s remote control allows you the limited control of the connected camcorder or DV equipment functions during dubbing.
  • Page 61 To pause dubbing, press selection keys to select then press ENTER. Both the unit and the external DV equipment pause dubbing. Pressing W on the unit also works the same way. Press selection keys to select ENTER. Then press o. The DV equipment stops. Press selection keys to select ENTER.

  • Page 62: Edit From A Camcorder

    EDITING Edit From A Camcorder You can use a camcorder as the source player and your unit as the recording deck. If your camcorder has a DV IN/OUT connector, you can use the camcorder as the recording deck and your unit (DV deck only) as the source player.

  • Page 63: Edit To Or From Another Recorder

    Edit To Or From Another Recorder You can use your unit as the source player or as the recording deck. NOTES: When using another recorder as the recording deck, refer to its instruction manual. It is not possible to dub copy-protected contents. An error message will appear on the TV screen.

  • Page 64: Digital Audio Dubbing

    EDITING Digital Audio Dubbing You can dub selected audio from a DVD or Audio CD disc to a digital audio device. However, it is not possible to dub copy-protected discs. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. Example: Dubbing to an MD Digital audio device (MD deck, etc.)

  • Page 65: Audio Dubbing (Dv Deck Only)

    Audio Dubbing (DV Deck Only) This function allows you to record new audio, without erasing the original audio, on a DV tape that was recorded with ADV AUDIO RECB set to A12BITB (A pg. 71). ATTENTION: You cannot perform Audio Dubbing on a tape that was recorded with ADV AUDIO RECB set to A16BITB (A pg.

  • Page 66: Insert Editing (Dv Deck Only)

    EDITING Insert Editing (DV Deck Only) Insert Editing replaces the pictures with new ones, while the audio soundtrack remains unchanged. For Insert Editing, use your unit as the recording deck. ATTENTION: Insert Editing is not possible with a Mini DV cassette recorded in LP mode.

  • Page 67: Remote Control

    Remote Control Functions Remote Control 1/2/3/4 Code Switching The remote control is capable of controlling four JVC video units independently. Each of the units can respond to one of the four codes (1, 2, 3 or 4). The remote control is preset to send code 3 signals because your unit is initially set to respond to code 3 signals.
  • Page 68 Your remote control can operate the basic functions of your cable box or DBS (Direct Broadcast Satellite) receiver set. In addition to JVC cable boxes or DBS receivers, other manufacturer’s cable boxes or DBS receivers can also be controlled. Slide the TV/CABLE/DBS/DVD switch to CABLE/DBS.

  • Page 69: System Connections

    Connecting To A Dolby Digital Decoder Or An Amplifier With Built-in DTS These instructions enable you to connect your unit to a Dolby Digital Decoder or an amplifier with built-in DTS. Dolby Digital Decoder or amplifier with built-in DTS Coaxial cable (not supplied) To [DIGITAL AUDIO OUT (COAXIAL)]...

  • Page 70: Subsidiary Settings

    SUBSIDIARY SETTINGS Mode Set Turn on the unit. Turn on the TV and select the AV mode. Slide the TV/CABLE/DBS/DVD switch to DVD. ENTER AUDIO Various modes of this unit are categorized into menus nested in 2 levels shown in the following table. To change the settings of these modes, find the desired mode in the menu (for details on each menu, see pages 70 through 72), then follow the procedure below.
  • Page 71 DISC PLAY SET UP RESUME OFF / / DISC RESUME When this function is set to AONB or ADISC RESUMEB, you can use the resume function. (A pg. 26) You cannot use the resume function. You can start playback from the resume point of the placed disc. DISC RESUME The unit retains a memory of the resume points of the last 30 discs played back, even though they have been ejected.
  • Page 72 SUBSIDIARY SETTINGS JUMP TIME 15 MIN / 30 MIN / 1 HR You can locate a scene ahead of or behind the currently viewed one by jumping a selected time interval during playback (or Live Memory Playback). For details, refer to AJump SearchB (A pg. 26, 40).

  • Page 73: Changing Vcr Plus+ Setting

    Changing VCR Plus+ Setting The VCR Plus+ programming system assigns a VCR Plus+ guide channel to the TV channels and the cable channels. These guide channel numbers are also called the VCR Plus+ channel codes. Most TV listings have a section, usually a chart, indicating the guide channel numbers assigned to each station.

  • Page 74: Format A Disc (Dvd Deck Only)

    SUBSIDIARY SETTINGS Format A Disc (DVD Deck Only) Some DVD-RAM/RW discs are unformatted. Format the disc when you use an unformatted disc or you want to delete all recordings and data on the disc. ATTENTION: When a disc is formatted, all recordings and data are erased. It is impossible to restore them.

  • Page 75: Finalize A Disc (Dvd Deck Only)

    Although DVD-R/RW discs finalized on this unit become playable on DVD players compatible with DVD-R/RW discs, some discs still may not play, for which JVC cannot take responsibility. Marked points marked before finalizing will be deleted, and titles will be divided automatically into AchaptersB approximately every 5 minutes.

  • Page 76: Scan Mode Set (Hdd & Dvd Deck Only)

    SUBSIDIARY SETTINGS Scan Mode Set (HDD & DVD Deck Only) If you connect the unit and TV with Component Video Connection (A pg. 18), you can select the scan mode from two modes: Interlaced scan mode which is used in the conventional TV system, and Progressive scan mode which enables reproduction of higher-quality images.

  • Page 77: Troubleshooting

    The remote control of a JVC TV will not operate the unit. The setting of the remote control code is inappropriate. ] To operate the unit using a JVC TV remote control, set the remote control code of the unit to A1B (Default: A3B). (A pg. 67)
  • Page 78 The playback picture is blurred or interrupted while TV broadcasts are clear or AUSE CLEANING CASSETTEB message appears on the screen. The video heads may be dirty. ] Use a dry cleaning cassette M-DV12CL, or consult your JVC dealer. Recording (DVD Deck) The desired program cannot be recorded.
  • Page 79 Timer Recording (HDD & DVD Deck) Timer programming cannot be made. Date and time is not correct. ] Set date and time correctly. (A pg. 21) Timer recording is in progress. ] Timer programming can’t be performed while a timer recording is in progress.
  • Page 80 TROUBLESHOOTING On-screen Message (HDD & DVD Deck Only) DISC NOT REGISTERED IN THE LIBRARY REGISTER DISC? A disc that is not registered in the library has been inserted. Register the disc as necessary. (A pg. 55) INSERT DISC XXXX Appears when a title that has been selected in the library is not contained in the loaded disc.

  • Page 81: Appendix

    Language Code List Afar Abkhazian Afrikaans Ameharic Arabic Assamese Aymara Azerbaijani Bashkir Byelorussian Bulgarian Bihari Bislama Bengali, Bangla Tibetan Breton Catalan Corsican Czech Welsh Bhutani Greek Esperanto Estonian Basque Persian Fiji Faroese Frisian Irish Scots Gaelic Galician Guarani Gujarati Hausa Hindi Croatian Hungarian...

  • Page 82: Country/Area Code List For Parental Lock

    APPENDIX Country/Area Code List for Parental Lock Andorra United Arab Emirates Afghanistan Antigua and Barbuda Anguilla Albania Armenia Netherlands Antilles Angola Antarctica Argentina American Samoa Austria Australia Aruba Azerbaijan Bosnia and Herzegovina Barbados Bangladesh Belgium Burkina Faso Bulgaria Bahrain Burundi Benin Bermuda Brunei Darussalam...
  • Page 83 Saint Lucia Liechtenstein Sri Lanka Liberia Lesotho Lithuania Luxembourg Latvia Libyan Arab Jamahiriya Morocco Monaco Moldova, Republic of Madagascar Marshall Islands Mali Myanmar Mongolia Macau Northern Mariana Islands Martinique Mauritania Montserrat Malta Mauritius Maldives Malawi Mexico Malaysia Mozambique Namibia New Caledonia Niger Norfolk Island Nigeria...

  • Page 84: Specifications

    SPECIFICATIONS GENERAL Power requirement AC 120 VH, 60 Hz Power consumption Power on: 49 W Power off: 12 W Temperature Operating: 5°C to 35°C (41°F to 95°F) Storage: –20°C to 60°C (–4°F to 140°F) Operating position Horizontal only Dimensions (WxHxD) 435 mm x 96 mm x 383 mm (17-1/10"...

  • Page 85: List Of Terms

    ... 30 A-B Repeat Playback ... 41 Accidental erasure prevention ... 31 Adjusting The Picture Quality ... 27 Angle Selection ... 28 Audio Channel Selection Audio Language/Sound Selection ... 22 Auto Channel Set ... 21 Auto Daylight Saving Time ... 24 Basic Playback ...34 Basic Recording...

  • Page 86: Warranty (Only In U.s.a.)

    WARRANTY (Only in U.S.A.)
  • Page 87 MEMO...

  • Page 88: For Servicing (Only In U.s.a.)

    FOR SERVICING (Only in U.S.A.) Printed in China © 2005 Victor Company of Japan, Limited 0905KTH-SW-BJ...

This manual is also suitable for:

Dr-dx5sekDr-dx5selDr-dx5seuDr-dx5seyDr-dx5sezDr-dx5sus

Table of Contents
