JVC DR-M10SAG Service Manual

Video
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
6
2004
YD025
DR-M10SAA, DR-M10SAG
TV
STANDBY/ON
TV
TV/
MUTING
VIDEO
TV
DVD
ABC
DEF
TV VOLUME
GHI
JKL
MNO
CH
PQRS
TUV
WXYZ
DBS
CANCEL
AUX
MEMO/MARK
G-CODE
PROG/CHECK
REC LINK
TIMER
SHOW VIEW
TOP MENU
NAVIGATION
ENTER
MENU
RETURN
PREVIOUS
NEXT
SLOW
PLAY/SELECT
SLOW
REC
STOP/
CLEAR
PAUSE
REC MODE LIVE CHECK
OPEN/
SET UP DISPLAY ON SCREEN
CLOSE
PROGRESSIVE
AUDIO SUBTITLE ANGLE
SCAN
Since the whole mechanism assembly unit is replaced, the DVD recorder
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
DVD VIDEO RECORDER
DR-M10SAX
DVD
STANDBY/ON

TABLE OF CONTENTS

COPYRIGHT © 2004 Victor Company of Japan, Limited
AG ----------- Universal Asia
AX -------------- Middle East
REC
LINK
F1
S-VIDEO
VIDEO
DR-M10SAA, DR-M10SAG, DR-M10SAX [D4R10]
REC MODE
PULL - OPEN
DV
DV IN
L(MONO)-AUDIO-R
No.YD025
2004/6

Advertisement

Table of Contents
loading

Related Manuals for JVC DR-M10SAG

Summary of Contents for JVC DR-M10SAG

  • Page 1: Table Of Contents

    SCAN S-VIDEO VIDEO L(MONO)-AUDIO-R DR-M10SAA, DR-M10SAG, DR-M10SAX [D4R10] Since the whole mechanism assembly unit is replaced, the DVD recorder mechanism of this unit need not be adjusted. TABLE OF CONTENTS PRECAUTION............... . . 1-3 SPECIFIC SERVICE INSTRUCTIONS .
  • Page 2 SPECIFICATION DR-M10SAA DR-M10SAG,DR-M10SAX GENERAL Power requirement AC 220 V - 240 V~, 50 Hz/60 Hz AC 110 V -240V~, 50/60 Hz Power consumption Power on : 33 W Power off : 17.6 W Temperature Operating : 5°C to 40°C Storage : -20°C to 60°C Operating position Horizontal only Dimensions (W ×...

  • Page 3: Precaution

    SECTION 1 PRECAUTION Safety Precautions (1) This design of this product contains special hardware and voltmeter. many circuits and components specially for safety purpos- Move the resistor connection to each exposed metal es. For continued protection, no changes should be made part, particularly any exposed metal part having a return to the original design unless authorized in writing by the path to the chassis, and measure the AC voltage across...
  • Page 4 Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.5.1 Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as DVD players.
  • Page 5 Important for laser products 5.CAUTION : If safety switches malfunction, the laser is able 1.CLASS 1 LASER PRODUCT to function. 2.DANGER : Invisible laser radiation when open and inter 6.CAUTION : Use of controls, adjustments or performance of lock failed or defeated. Avoid direct exposure to beam. procedures other than those specified here in may result in 3.CAUTION : There are no serviceable parts inside the hazardous radiation exposure.

  • Page 6: Specific Service Instructions

    SECTION 2 SPECIFIC SERVICE INSTRUCTIONS This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS. 1-6 (No.YD025)

  • Page 7: Disassembly

    SECTION 3 DISASSEMBLY Main body section 3.1.1 Remove the top cover (See figure 1) (1) Remove the four screws A attaching the top cover on both sides of the main body. (2) Remove the five screws B attaching the top cover on the TOP COVER TOP COVER TOP COVER...
  • Page 8 3.1.3 Remove the mechanism assembly (See figure 5) Mechanism assembly • Prior to performing the following procedure, remove the top Digital board cover. • There is no need to remove the front panel assembly. (1) Disconnect the socket wire from connector CN5303 on the switching regurator board.
  • Page 9 3.1.5 Remove the switching regurator board (See figure 8) CN5302 Fastener • Prior to performing the following procedure, remove the top cover. (1) Disconnect the card wire from connector CN5301 on the Switching regurator switching regurator board. board (2) Disconnect the socket wire from connector CN5302, Fastener CN5303, CN5305...

  • Page 10: Adjustment

    SECTION 4 ADJUSTMENT Timer clock adjustment If an error comes to arise for a clock, the following procedure will adjust. Signal (A1) No signal Mode Equipment Frequency counter Measuring point (D1) IC3001 pin 61 (D2) IC3001 pin 17 (D3) C3026 + and - Adjustment part C3025 (TIMER CLOCK) Specified value...

  • Page 11: Troubleshooting

    SECTION 5 TROUBLESHOOTING JIG Mode The following remote control units are required to set and cancel JIG mode. For setting : a remote control unit attached to product. For cancellation : JIG remote control unit (part number : PTU94023B) Remote control unit JIG remote control unit attached to product STANDBY/ON...
  • Page 12 5.1.1 Setting JIG mode To display SYSTEM INFO or to upgrade firmware, the main body needs to be set to JIG mode. (1) Turn the main body ON. (2) Press the buttons of the remote control unit attached to product in the following order : "SET UP" → "2" → "8" → "ENTER" (3) When a colon ":"...
  • Page 13 5.1.3 Displaying SYSTEM INFO SYSTEM INFO contains information on firmware version of the main body and the mechanism drive, and an initialize execution menu. (1) Set the main body to JIG mode. (2) Transmit "43-8B" to the main body by using JIG remote control unit. (3) SYSTEM INFO menu is displayed in the television screen.
  • Page 14 The setting method of a region code A region code should be set after a DVD recorder mechanism unit is replaced. While a DVD recorder mechanism unit is in a warehouse as a stock, a region code of the drive unit is not determined. Only replacement of a DVD recorder mechanism unit may cause abnormal playback of Disc.
  • Page 15 (No.YD025)1-15...
  • Page 16 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY DIGITAL VIDEO STORAGE CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan (No.YD025) Printed in Japan...

  • Page 17: Mechanism Of This Unit Need Not Be Adjusted

    PROGRESSIVE AUDIO SUBTITLE ANGLE SCAN S-VIDEO VIDEO L(MONO)-AUDIO-R DR-M10SAA, DR-M10SAG, DR-M10SAX [D4R10] Since the whole mechanism assembly unit is replaced, the DVD recorder mechanism of this unit need not be adjusted. No.YD025SCH COPYRIGHT 2004 Victor Company of Japan, Limited 2004/06...
  • Page 19 CHARTS AND DIAGRAMS CIRCUIT BOARD NOTES 1. Foil and Component sides NOTES OF SCHEMATIC DIAGRAM 4. Voltage measurement 1) Foil side (B side) : Parts on the foil side seen from foil face (pattern face) 1) Regulator (DC/DC CONV) circuits Safety precautions are indicated.

  • Page 20: Wiring Diagram

    Wiring diagram S/RCA OUT BB[AL5V] AUDIO_IN AUDIO_IN MOD_SDA CH_SW MOD_B[AL5V] MOD_B[SW5V] MOD_SCL CONV.CTL[H] VIDEO_IN VIDEO_IN RF_AGC [RF_AGC] MB[SW5V] MB[SW5V] LOCK[L] TU[30V] TU[30V] AUDIO_OUT AUDIO_OUT CN1901 CN6901 SIF_OUT VIDEO_OUT VIDEO_OUT NC[OPEN] CN5102 CN3002 CN7101 CN1402 JLIP_RX JLIP_TX D3.3V p10596001a_rev0...

  • Page 21: Block Diagrams

    Block diagrams DIGITAL 0 2 J4112 IEEE1394 TPA+ TPA- TPB+ TPB- IEEE1394 controller terminal PHY_RESET[L] CIN VYIN SYNCDET CROUT CBOUT IC1801 PHY_LREQ PHY_CLK YVOUT COUT RYOUT RCOUT Video PHY_CNA PHY_CTL[0],[1] TO CN4101 PHY_DATA[0-7] PHY_LPS controller PHY_LINK_ON SHEET 10 IC1001 IEEE1394 section (SHEET 2) AO_FSYNC AO_D[0] DAC_RST[L] AO_SCLK A_DAC_CS AO_MCLKO AP A0 to A9...
  • Page 22 MAIN 0 3 Audio signal control section (SHEET 8) J7308 J7307 L-1 SCART Terminal TO SHEET 11 S-VIDEO AUDIO OUT AUDIO_OUT1[L/R] J7301 Muting A_MUTE2[H] RAPID_SW BIAS/RGB_CTL Q7310 to Q8201,Q8202 DEC_OUT[L/R] Q7312 LINE_OUT[L/R] IC8301 IC8202 4_3[H] P50_I/O AV_YC_IN[H] TV[H] IC8302 TO SHEET 11 DAC_SDA AOUTL DAC_SCL...
  • Page 23 SW.REG 0 1 OPERATE 2 7 D2.5V 2.5V REG. IC5305 TO CN5102 AC-DC SHEET 10 AC IN Operation switch S12 to S15 KEY1,KEY2 D1.8V D5001 TO CN3002 S7132,S7134,S7135 1.8V REG. P.SAVE[L] S7113 to S7115 IC5302 TO CN5101 J7001 Switching 3.3V REG. V3.3V Power SHEET 10...
  • Page 24 Standard schematic diagrams Power supply section CN5301 B5501 DC3.9[+] D5201 CP5301 R5310 DC3.9[-] 10ERB20 1.5A /125 Q5310 ERA18-02 2SD2144S/UV/ -29V C5201 2SC3576 AL-12V /6.3 FAN_CTL DANGEROUS VOLTAGE AL12V R5314 D5207 P.CTL[H] AU01Z 1/4W ERA18-02 SW12V F5001 T5001 1SR153-400 C5206 R5327 R5328 R5317 CN5001...
  • Page 25 IEEE1394 section D3.3V B1802 B1801 OPEN C1806 L1802 L1801 C1804 C1803 /6.3 /6.3 OPEN C1814 C1813 OPEN OPEN C1805 R1820 C1810 OPEN K1801 X1801 NAX0551-001X SHORT NAX0666-001X IC1801 TSB41AB2PAP D3.3V PHY_RESET[L] PHY_LREQ LREQ AGND R1801 0‘ PHY_CLK SYSCLK R1802 0‘ PHY_CNA TO SHEET 4 PHY_CTL[0]...
  • Page 26 DDR SDRAM section SDRAM_DQ[0] SDRAM_DQ[0] DDR_DQ[0] RA1601 SDRAM_DQ[1] SDRAM_DQ[1] RA1609 DDR_DQ[1] SDRAM_DQ[2] SDRAM_DQ[2] DDR_DQ[2] SDRAM_DQ[3] SDRAM_DQ[3] DDR_DQ[3] SDRAM_DQ[4] SDRAM_DQ[4] DDR_DQ[4] RA1602 SDRAM_DQ[5] SDRAM_DQ[5] RA1610 DDR_DQ[5] SDRAM_DQ[6] SDRAM_DQ[6] DDR_DQ[6] C1637 OPEN SDRAM_DQ[7] SDRAM_DQ[7] DDR_DQ[7] SDRAM_DQ[8] SDRAM_DQ[8] DDR_DQ[8] RA1603 SDRAM_DQ[9] SDRAM_DQ[9] RA1611 DDR_DQ[9] C1638 SDRAM_DQ[10]...
  • Page 27 Media processor section AO_D[0] SDRAM_A[14-17] SDRAM_A[14-17] AO_SCLK SDRAM_VREF SDRAM_CLK_L[1] AO_FSYNC SDRAM_CLK_L[1] TO SHEET 5 SDRAM_CLK[1] AO_IEC958 SDRAM_CLK[1] SDRAM_CLK_L[0] AO_MCLKO SDRAM_CLK_L[0] SDRAM_CLK[0] AI_D[0] SDRAM_CLK[0] SDRAM_WE_L VIDEO_MUTE[H] SDRAM_WE_L SDRAM_CKE TO SHEET 2 TO SHEET 3 PHY_CNA SDRAM_CKE SDRAM_RAS_L 480I[H] SDRAM_RAS_E SDRAM_CAS_L SDRAM_CAS_L SDRAM_DQM[0-3] TO SHEET 5 SDRAM_DQM[0-3]...
  • Page 28 Video signal controller section VDDI1.8 DIGI3.3V IC1002 D2.5V HY57V161610DTC8 K4S161622D-TC80 D1.8V C1042 K_BUS_OUT DQ15 TO SHEET 4 DQ15 K_BUS_IN DQ14 DQ14 RA1003 RA1005 P_CTL[H] VSSQ VSSQ R1036 SYS_RESET[L] DQ13 DQ13 AI_D[0] DQ12 R1035 C1043 DQ12 C1047 K_BUS_REQ Q1002 VDDQ VDDQ C1088 A_MUTE2[H] DQ11...
  • Page 29 ATAPI Interface section ATA_DAT[7] RA2201 FE_DAT[7] OPEN ATA_DAT[8] FE_DAT[8] ATA_DAT[6] FE_DAT[6] ATA_DAT[9] FE_DAT[9] ATA_DAT[5] RA2202 FE_DAT[5] OPEN ATA_DAT[10] FE_DAT[10] ATA_DAT[4] FE_DAT[4] ATA_DAT[11] FE_DAT[11] ATA_DAT[3] RA2203 FE_DAT[3] OPEN ATA_DAT[12] FE_DAT[12] ATA_DAT[2] FE_DAT[2] ATA_DAT[13] FE_DAT[13] ATA_DAT[1] RA2204 FE_DAT[1] OPEN ATA_DAT[14] FE_DAT[14] ATA_DAT[0] FE_DAT[0] ATA_DAT[15] FE_DAT[15]...
  • Page 30 FLASH-ROM section C1207 IC1203 SN74LVC373APW-X LH_AR[14] LH_AR[21] MADD[14] MADD[21] IC1201 MBPL65LM90TN MADD[15] MADD[20] K1201 SHORT LH_AR[16] LH_AR[17] LH_AR[15] LH_AR[20] LH_AR[15] LH_AR[16] LH_AR[19] VCCQ LH_AR[14] MADD[16] MADD[19] LH_AR[13] MADD[21] MADD[17] MADD[18] C1203 DQ15 LH_AR[12] MADD[13] LH_AR[17] LH_AR[18] LH_AR[11] MADD[20] DQ14 LH_AR[22] LH_AR[10] MADD[12] C1204...
  • Page 31 Audio signal control section AV1_L AV2_H D8202 I2C_CLK2 TO SHEET 12 1SS133 I2C_DATA2 A_MUTE1[H] D8201 OPEN R8220 ADC_RST[L] 4.7k _0.5% Q8202 R8218 C8208 R8222 DTA144WKA _0.5% 470p 4.3k R8223 Q8201 _0.5% DTC144WKA C8206 4700p R8221 C8005 R8046 C8210 R8017 R8217 C8207 C8209 R8250...
  • Page 32 Audio/Video signal input control section C4318 C4319 470p C/R1 R4319 C4310 470p C/R2 R4311 D4301 L4301 1SS133 R4317 R4318 IC4301 LA7357M C4306 R4306 0.01 1.2k R4312 Q4301 0‘ IC4304 R4307 R4304 74HC4538D C4308 C4302 C4307 0.01 0.01 FSC_IN C4301 C4304 Q4302 Q4303 R4320...
  • Page 33 OPEN C4084 AL5.3V CTODIGI TO SHEET 9 YTODIGI CBOUT 480I[H] COUT QNS0089-001 CROUT J4109 RCOUT TO SHEET 11 YVOUT RYOUT 2SC3576-JVC 2SD2144S Q4101 RF5V R4104 R4105 OPEN C4110 C4109 SW5V TO SHEET 9 CN4104 B4121 SHORT CN5102 AL-12V TO SHEET 11...
  • Page 34 Input/Output terminal section J7309 J7309 Pr_OUT Pb_OUT Y_OUT 4_3[L] TV[L] R7302 4.7k R7339 R7340 SHEET 12 Q7310 Q7302 1/4W SHEET 12 R7378 Q7312 R7341 UN221E-X DTC144WKA-X 1/4W P50_I/O R7301 4.7k R7305 RT1N44HC-X Q7301 Q7311 SCR_ID R7309 BIAS/RGB_CTL 100k R7304 R7342 D7304 1SS133 AV1_YC_IN[H]...
  • Page 35 System controller section TO SHEET 9 443[H] TO SHEET 11 SCR_ID SEPA_IN[H] TO SHEET 9 SECAM_DET[H] 4_3[L] TV[L] RGB_TH[H] AV1_YC_IN[H] BIAS/RGB_CTL AV1_L AV1_L SHEET 11 AV2_H AV2_H P.MUTE[H] ADC_RST[L] RAPID_SW A_MUTE1[H] SHEET 8 V_MUTE[L] I2C_DATA2 I2C_CLK2 I2C_DATA_A/V TO SHEET 9 I2C_CLK_A/V SVss DVD_REC_LED...
  • Page 36 C6720 DVSUP K6705 R6721 5.6k R6710 IC6701 MSP3417G MSP3417GQGB8V3 MSP3417D C6753 /6.3 SC1_IN_L *Refer to the "EU/EK" in a table C6722 OPEN for DR-M10SAA,DR-M10SAG, SC1_IN_R R6709 DR-M10SAX C6723 VREFTOP K6704 C6724 C6711 OPEN MONO_IN I2C_DA C6710 OPEN R6080 AVSS I2C_CL...
  • Page 37 FL Display and operation switch section CN7102 R7152 R7151 FRONT C IN C7150 0.01 FRONT Y IN J7001 TO CN4001 J7002 R7153 FRONT VIDEO SHEET 9 F_AUDIO[R] C7151 C7152 F_AUDIO[L] 100p OPEN S7001 R7156 R7154 OPERATION 1SS133 1SS270A C7153 C7154 100p OPEN IC7002...
  • Page 38 Printed circuit boards Main board <03> LPB10239-001C K6703 X6701 C6701 K6704 R4041 C6709 TU6001 R6719 C6711 C6708 C6710 C6707 C6006 CN4102 R4147 K6705 B4101 C4078 K6701 R6710 IC6701 R6033 CN4101 C6713 C6032 D6002 C6724 L6002 C6753 R6711 K6707 C6037 D6701 C6752 R6712 C6715...
  • Page 39 COMPONENT PARTS LOCATION GUIDE <MAIN> LPB10239-001C Switch display board <28> LPB10239-001C REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION CAPACITOR C4304 B C 17E C8014 L4201 A D 13F R3094 R7007 B C 10C R8242 B C 14J C3007...
  • Page 40 Switching regurator board <01> LPB10235-001C CN5305 C5004 R5303 D5103 R5310 B5501 R5317 CN5302 D5105 CN5301 R5301 R5102 R5318 Q5310 D5306 R5105 Q5301 B5302 D5201 R5324 R5323 D5307 D5302 CN5303 R5328 D5207 C5315 R5314 R5108 R5327 D5209 CN5304 IC5303 C5330 C5103 C5314 DANGEROUS VOLTAGE D5210...
  • Page 41 Digital board <02> LPB10236-001D Forward side Reverse side ZP162 ZP161 ZP160 ZP159 ZP158 TL1020 TL1018 TL1014 TL1011 TL1009 TL1005 TL1003 TL1002 ZP94 ZP90 ZP86 ZP82 ZP152 ZP151 ZP78 ZP72 ZP70 C1449 ZP67 ZP65 ZP63 ZP61 ZP59 ZP57 ZP55 ZP53 ZP51 ZP49 ZP47 ZP45...
  • Page 42 COMPONENT PARTS LOCATION GUIDE <DIGITAL> LPB10236-001D VOLTAGE CHARTS REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION <POWER SUPPLY> <MAIN> CAPACITOR C1421 A C 2C CN1403 R1069 R1614 A C 5D RA1617 A C 5D TL1412 MODE MODE...
  • Page 44 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY DIGITAL VIDEO STORAGE CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan Printed in Japan No.YD025SCH...
  • Page 45 PARTS LIST [DR-M10SAA, DR-M10SAG,DR-M10SAX ] * All printed circuit boards and its assemblies are not available as service parts. * (x_) in a description column shows the number of the used part. Area Suffix AA ------------------ Australia AG ----------- Universal Asia...
  • Page 46 Exploded view of general assembly and parts list Block No.M1MM DRAWING FROM DIRECTION GASKET is attached so that MAIN BOARD ASSY the solder of PCB may be made to contact and may be touched Soldering side at the perimeter of PCB. DRAWING FROM DIRECTION FIG.5 FIG.1...
  • Page 47 Block No.M1MM DVD UNIT REAR SIDE. SPACER is stuck on DVD UNIT. NEUTRAL (WHITE LINE) CN5001 CN5305 Match the position. MAIN BOARD ASSY REGULATOR BOARD ASSY SHILED PLATE is fixed by WIRE currently attached to SHILED PLATE. so that TAPE may be put. TAPE DIGITAL BOARD ASSY...
  • Page 48 General assembly Block No. [M][1][M][M]  Symbol No. Part No. Part Name Description Local  1 LP10533-016A FRONT PANEL ASSY LP21252-001A DOOR PU60109 CATCHER LP31382-001A STOPPER (x2) QYTDSF2608ZA TAP SCREW M2.6 x 8mm(x2) LP31372-002A FITTING(DVD) AY QYTDSF2608ZA TAP SCREW M2.6 x 8mm FRONT BOARD(x6) QYSBSG3006NA TAP SCREW M3 x 6mm TOP SIDE(x4)

  • Page 49: Electrical Parts List

    MTZJ12A-T2 Z DIODE Q5304 or RT1N141C-X DIGI TRANSISTOR D5303 or RD12ES/B1/-T2 Z DIODE Q5305 2SD2144S/UV/-T TRANSISTOR D5304 MTZJ5.6C-T2 Z DIODE Q5305 or 2SC3576-JVC-T TRANSISTOR D5304 or RD5.6ES/B3/-T2 Z DIODE Q5308 2SD1858/QR/-T TRANSISTOR D5305 RL2Z-LFB2 Q5310 2SD2144S/UV/-T TRANSISTOR D5306 1SS133-T2 DIODE...

  • Page 50: Digital Board

     Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C5302 QFLC1HJ-333Z M CAPACITOR 0.033uF 50V J  LF5002 QQR1031-001 LINE FILTER M10SAA C5303 NCF31AZ-105X C CAPACITOR 1uF 10V Z  LF5002 QQR0908-001 LINE FILTER M10SAG,M10SAX...
  • Page 51  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local D1403 or MA111-X SI DIODE C1421 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1422 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1001 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M C1423 NCB31CK-104X C CAPACITOR...
  • Page 52  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C1803 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M R1223 NRSA63J-472X MG RESISTOR 4.7kΩ1/16W J C1804 NCB31CK-104X C CAPACITOR 0.1uF 16V K R1224 NRSA63J-472X MG RESISTOR 4.7kΩ1/16W J...
  • Page 53  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R1604 NRSA63J-100X MG RESISTOR 10Ω1/16W J RA1006 NRZ0034-103W NET RESISTOR 10kΩ1/32W J R1605 NRSA63J-470X MG RESISTOR 47Ω1/16W J RA1201 NRZ0034-103W NET RESISTOR 10kΩ1/32W J R1606 NRSA63J-470X MG RESISTOR...
  • Page 54 K2210 NQR0129-002X FERRITE BEADS Q4006 or 2SC3928A/QRS/-X TRANSISTOR K2211 NQR0129-002X FERRITE BEADS Q4101 2SD2144S/UV/-T TRANSISTOR K2212 NQR0129-002X FERRITE BEADS Q4101 or 2SC3576-JVC-T TRANSISTOR K2213 NQR0129-002X FERRITE BEADS Q6030 2SA1037AK/QR/-X TRANSISTOR K2214 NQR0129-002X FERRITE BEADS Q6030 or 2SB709A/QR/-X TRANSISTOR K2215 NQR0129-002X...
  • Page 55  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local Q7317 or 2SA1530A/QR/-X SI TRANSISTOR C4013 NCF31AZ-105X C CAPACITOR 1uF 10V Z Q8201 UN221E-X TRANSTSTOR C4015 NCB31EK-103X C CAPACITOR 0.01uF 25V K Q8201 or DTC144WKA-X DIGI TRANSISTOR...
  • Page 56  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C7311 NCB31CK-104X C CAPACITOR 0.1uF 16V K C8321 QETN1CM-227Z E CAPACITOR 220uF 16V M C7312 NCB31EK-103X C CAPACITOR 0.01uF 25V K C8322 NCB31CK-104X C CAPACITOR 0.1uF 16V K...
  • Page 57  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R3252 NRSA63J-0R0X MG RESISTOR 0Ω1/16W J R7341 NRSA63J-102X MG RESISTOR 1kΩ1/16W J R3256 NRSA63J-103X MG RESISTOR 10kΩ1/16W J R7342 NRSA63J-102X MG RESISTOR 1kΩ1/16W J R3257 NRSA63J-103X...
  • Page 58  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R8249 NRSA63J-273X MG RESISTOR 27kΩ1/16W J K6704 NRSA02J-0R0X MG RESISTOR 0Ω1/10W J R8250 NRSA63J-471X MG RESISTOR 470Ω1/16W J K6705 NQR0200-003X FERRITE BEADS R8252 NRSA63J-682X MG RESISTOR...
  • Page 59 Operation board  Symbol No. Part No. Part Name Description Local Block No. [2][7] C7007 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z  Symbol No. Part No. Part Name Description Local C7008 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M C7010 QCFB1HZ-473Y C CAPACITOR 0.047uF 50V Z C7011 QCFB1HZ-473Y...
  • Page 60 Packing materials and accessories parts list Block No.M2MM ADHESIVE TAPE FINAL ASSY<M1> SPEC OF BARCODE 3-16(No.YD025)
  • Page 61 Packing and accessories Block No. [M][2][M][M]  Symbol No. Part No. Part Name Description Local LP31384-021A PACKING CASE M10SAA LP31384-023A PACKING CASE M10SAG LP31384-027A PACKING CASE M10SAX LP31387-001B CUSHION ASSY PQM30021-93 POLY BAG QAM0525-002 RF CABLE QAM0522-001 A/V CABLE ------------ BATTERY R6TYPE(x2) QPC02202230P...

This manual is also suitable for:

Dr-m10saaDr-m10sax
