Introduction - Masimo Radical Signal Extraction Operator's Manual

1
Masimo SET Parallel Engines
(Conventional
Pulse Oximetry)
R/IR
Digitized,
Filtered &
Normalized
Proprietary
Algorithm 4
Proprietary
Algorithm 5
Masimo SET DST
1-6
o v e r v i e w
MEAS
R/IR
CONF
Processor
MEAS
Adaptive
Filter with
CONF
DST TM
Saturation
MEAS
Confidence
Based
TM
SST
CONF
Arbitrator
MEAS
CONF
MEAS
CONF
Radical Signal Extraction Pulse Oximeter Operator's Manual
s y s t e m
I n t r o d u c t i o n
Radical provides the functionality of three pulse oximeters in one:
■
The Radical is a fully featured Handheld pulse oximeter
■
The Radical is a fully featured standalone pulse oximeter
Post
■
The Radical interfaces to the SpO
to upgrade conventional pulse oximetry technology to Masimo SET technology.
CAUTIONS:
■
THE WAVEFORM DISPLAYED ON THE MULTIPARAMETER PATIENT MONITOR
IS A SIMULATED SIGNAL (NON-NORMALIZED). REFER TO THE RADICAL
DISPLAY FOR PATIENT WAVEFORM.
■
IF DISPLAYING THE SIMULATED WAVEFORM IS NOT DESIRABLE, IT IS
RECOMMENDED TO TURN OFF THE PLETH WAVEFORM DISPLAY ON THE
MULTIPARAMETER MONITOR
■
ONLY USE A SATSHARE CABLE THAT HAS A FERRITE BEAD INSTALLED.
Refer to Section 3, SatShare Setup and Section 4, SatShare Operation for additional
details.
*Contact Masimo for the latest list of SatShare validated multiparameter monitors.
Radical Signal Extraction Pulse Oximeter Operator's Manual
d e s c r i p t i o n
input module of multiparameter patient monitors*
2
The Handheld portion of the Radical contains the
majority of the pulse oximeter features. All pulse
oximetry measurement information, as well as device
status data is displayed on the Handheld LCD screen.
All user input is handled through the control buttons on
the front panel. The sensor cable connector is located
on the Radical Handheld oximeter.
The Handheld oximeter snaps into the Radical Docking
Station to provide a fully featured standalone pulse
oximeter. The Docking Station connects to AC power
for standalone operation or charging of the Handheld.
An optional Docking Station battery is available. The
standalone Radical features nurse call, analog output
and interfaces to serial printers.
Utilizing a SatShare TM cable, the standalone
Radical also interfaces with the SpO
of a validated multiparameter patient
monitor*, instantly upgrading
conventional pulse oximetry to Masimo SET
pulse oximetry. The SatShare cable
attaches to the back of the Radical Docking
Station, and SatShare cables are available
to interface with most multiparameter patient
monitors*.
2
input
2
the
2-1
