8
s e n s o r s

LNCS

TM ADHESIVE SENSORS
(LNCS sensors must be used in conjunction with LNC cables)
Weight Saturation Accuracy
SENSOR
Range No Motion
LNCS Adtx
> 30 kg ± 2%
LNCS Adtx-3
LNCS Pdtx
10 - 50 kg ± 2%
LNCS Pdtx-3
LNCS Inf-L
LNCS Inf 3 - 20 kg ± 2%
LNCS Inf-3
LNCS Neo-L
< 3 kg ± 3%
LNCS Neo
> 40 kg ± 2%
LNCS Neo-3
LNCS NeoPt-L
LNCS NeoPt < 1 kg ± 3%
LNCS NeoPt-3

CLEANING AND REUSE OF MASIMO SENSORS

Reusable sensors can be cleaned per the following procedure:
1. Remove the sensor from the patient.
2. Disconnect the sensor from the monitor.
3. Wipe the entire sensor clean with a 70% isopropyl alcohol pad.
4. Allow the sensor to air dry before returning it to operation.

REATTACHMENT OF SINGLE USE ADHESIVE SENSORS

■ Single use sensors may be reapplied to the same patient if the emitter and detector
windows are clear and the adhesive still adheres to the skin.
NOTE: If the sensor fails to track the pulse consistently, the sensors may be incorrectly
positioned. Reposition the sensor or choose a different monitoring site.
WARNING: TO AVOID CROSS CONTAMINATION ONLY USE MASIMO
SINGLE USE SENSORS ON THE SAME PATIENT.
CAUTIONS:
■ DO NOT ATTEMPT TO REPROCESS, RECONDITION OR RECYCLE ANY
MASIMO SENSORS AS THESE PROCESSES MAY DAMAGE THE ELECTRICAL
COMPONENTS, POTENTIALLY LEADING TO PATIENT HARM.
■ DO NOT SOAK OR IMMERSE THE SENSOR IN ANY LIQUID SOLUTION. UNLESS
OTHERWISE SPECIFIED, DO NOT STERILIZE ANY MASIMO SENSOR BY
IRRADIATION, STEAM, OR ETHYLENE OXIDE.
8-4
& p a t i e n t c a b l e s
Pulse Rate Accuracy
Low Perfusion Accuracy
Motion No Motion Motion Saturation Pulse Rate
± 3% ± 3 bpm ± 5 bpm ± 2%
± 3% ± 3 bpm ± 5 bpm ± 2%
± 3% ± 3 bpm ± 5 bpm ± 2%
± 3% ± 3 bpm ± 5 bpm ± 3%
± 3% ± 3 bpm ± 5 bpm ± 3%
± 3% ± 3 bpm ± 5 bpm ± 3%
Radical Signal Extraction Pulse Oximeter Operator's Manual
s e n s o r s
M a s i m o
Reusable patient cables of various lengths are available. Only use appropriate Masimo
oximetry patient cables for SpO
improper Radical performance.
± 3 bpm

CLEANING AND REUSE OF MASIMO SET PATIENT CABLES

± 3 bpm
Patient cables can be cleaned per the following procedure:
1. Remove the cable from the sensor.
± 3 bpm
2. Disconnect the cable from the monitor.
± 3 bpm
3. Wipe clean with a 70% isopropyl alcohol pad.
± 3 bpm
4. Allow the cable to dry before returning it to operation.
± 3 bpm
CAUTIONS:
■ CAREFULLY ROUTE PATIENT CABLES TO REDUCE THE POSSIBILITY OF
PATIENT ENTANGLEMENT OR STRANGULATION.
■ DO NOT SOAK OR IMMERSE PATIENT CABLES IN ANY LIQUID SOLUTION. DO
NOT STERILIZE PATIENT CABLES BY IRRADIATION, STEAM, OR ETHYLENE
OXIDE. SEE THE CLEANING INSTRUCTIONS IN THE DIRECTIONS FOR USE
FOR REUSABLE MASIMO PATIENT CABLES.
■ DO NOT ATTEMPT TO REPROCESS, RECONDITION OR RECYCLE ANY
MASIMO PATIENT CABLES AS THESE PROCESSES MAY DAMAGE THE
ELECTRICAL COMPONENTS, POTENTIALLY LEADING TO PATIENT HARMS.
Radical Signal Extraction Pulse Oximeter Operator's Manual
& p a t i e n t c a b l e s
S E T p a t i e n t c a b l e s
measurements. Other patient cables may cause
2
8
8-5
