Majestic 360DVS2 Installation Instructions & Homeowner's Manual
360 dvs series direct vent fireplaces
Hide thumbs
Also See for 360DVS2:
- Homeowner's installation and operating manual (32 pages) ,
- Homeowner's installation and operating manual (44 pages) ,
- Installation instructions & homeowner's manual (39 pages)
Table of Contents
Advertisement
INSTALLER/CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING
AND USING APPLIANCE
IMPORTANT: Read all
instructions and warnings
carefully before starting
installation. Failure to follow
these instructions may result in
a possible fire hazard, and will
void the warranty.
WARNING: If the information in this
manual is not followed
exactly, a fire or explosion may
result, causing property damage,
personal injury, or loss of life.
FOR YOUR SAFETY:
• Installation and service must be
performed by a qualified
installer, service agency, or
the gas supplier.
• Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity
of this or any other appliance.
If you smell gas:
1. Open windows
2. Do not touch electrical
switches.
3. Do not try to light any
appliance.
4. Extinguish any open flame.
5. Do not use any telephone in
your building.
6. Immediately call your gas
supplier from a neighbor's
phone.
7. Follow your gas supplier's
instructions.
8. If you cannot reach your gas
supplier, call the fire
department.
INSTALLER: DO NOT DISCARD THIS MANUAL— LEAVE FOR HOMEOWNER
Multisided Top/Rear Vent
Convertible Direct Vent
Fireplaces:
Installation Instructions &
Homeowner's Manual
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
360DVS2
360DVS3
360DVSL
360DVSR
C E RT I F I E D
10006326 2/04 Rev. 0
