Amana AOES2430 Series Owner's Manual

Amana AOES2430 Series Owner's Manual

Self-cleaning built-in wall oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Self-Cleaning
Built-in Wall Oven
Owner's Manual
AOES2430*
* Additional alphanumeric characters
representing other models in series may
follow each model number.
Please Read Manual Before Operating Oven
Installer
Leave this manual for consumer's and local electrical
inspector's use.
Customer
Keep these instructions for future reference. If appliance
changes ownership, be sure this manual accompanies
range.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AOES2430 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Amana AOES2430 Series

Summary of Contents for Amana AOES2430 Series

  • Page 1 ® Self-Cleaning Built-in Wall Oven Owner's Manual AOES2430* * Additional alphanumeric characters representing other models in series may follow each model number. Please Read Manual Before Operating Oven Installer Leave this manual for consumer’s and local electrical inspector’s use. Customer Keep these instructions for future reference.

  • Page 2: Table Of Contents

    Asure™ Extended Service Plan Adjusting Oven Temperature ........17 Cleaning Wall Oven Parts ........17 Amana offers long-term service protection for this new Before You Call for Service ......... 19 oven. Asure™ Extended Service Plan is specially Warranty ..............21 designed to supplement Amana’s strong warranty.

  • Page 3: Important Safety Information

    Important Safety Information Do not use water on grease fires Recognize this symbol as a safety Smother fire or flame, or use dry chemical or foam-type precaution extinguisher. Use only dry potholders Moist or damp potholders on hot surfaces may result in WARNING burns from steam.

  • Page 4: Self-Cleaning

    Important Safety Information Installation Self-Cleaning Packaging Material Do not clean door gasket Remove protective packing materials from oven. Tape The door gasket is essential for a good seal. Care should residue can be cleaned with a soft cloth and rubbing be taken not to rub, move, or damage the gasket.

  • Page 5: Side By Side Installation

    Side by Side Installation Electrical Requirements When installing 2 ovens next to each other, leave a This oven requires 3 wires, 120/208 or 120/240 Volts, 60 minimum of 12 inches between the cutouts. Hertz A.C. This appliance must be supplied with the proper voltage and frequency, and connected to an individual, properly grounded branch circuit, protected by a circuit breaker or fuse.

  • Page 6: Grounding Instructions

    When connecting to a 4-wire electrical system, Grounding Instructions when installing in a mobile home, or when local This appliance is manufactured with neutral (white), codes DO NOT permit connecting the cabinet- power supply wire, and a cabinet-connected green (or grounding conductor to the neutral (white) junction bare copper) grounding wire.

  • Page 7: Adjusting Oven Height

    Adjusting Oven Height Cabinet Installation Oven height can be adjusted when needed to fit into an existing cabinet cutout opening. To adjust oven height: CAUTION 1. Lay the oven on its back. 2. Remove the 6 screws fastening the side of each Do not lift the oven by the door handle.

  • Page 8: Control Pad Features

    Control Pad Features Pads Description PREHEAT Used to select the preheat mode. BAKE (MODE) Used to reach the normal baking mode temperature. CLEAN Used to select the self-cleaning cycle. BROIL Used to select the broil function. BAKE (TIMING) Used to enter the length of the baking time. STOP Used with the BAKE (MODE) , BAKE (TIMING) and CLEAN pads to program a delayed automatic baking or cleaning cycle stop time.
  • Page 9 Special Modes Temperature Conversion Mode The electronic oven control is set to operate in °F (Fahrenheit) mode when (Fahrenheit to Celsius) shipped from the factory. This mode changes the temperature to °C (Celsius) or from °C to °F. Sales Mode The electronic oven control is set to USE mode when shipped from the factory.

  • Page 10: Programming

    Programming Before Setting Oven Controls Set Clock (12 hour clock) Oven Vent Location When power is connected, or when power supply to The oven is vented at the top of the control panel. When range has been interrupted, display flashes. the oven is on, warm air is released through the vent.

  • Page 11: Preheat

    Preheat Timed Bake Use the preheat function for regular baking as recommended BAKE (TIMING) pad controls the Timed Bake operation. in the recipe. The preheat function reduces preheating time. Set oven to bake for a desired amount of time. Oven Three consecutive beeps sound when preheating is automatically stops heating after baking time elapses.

  • Page 12: Delayed Bake

    Delayed Bake Broil BAKE (TIMING) and STOP pads control Timed Bake Broiling system generates immediate, intense heat using operation. Set oven to begin and end baking at later top oven element. times. Oven control automatically calculates starting time. CAUTION If an oven fire occurs, close the oven door and press WARNING OVEN CANCEL pad.

  • Page 13: Prepare Oven For Self-Cleaning

    4. Place the grid on the broiler pan, then place the food on Prepare Oven for Self-Cleaning the grid. A self-cleaning oven cleans itself with high temperatures • The broiler pan and its grid allow dripping grease to (well above cooking temperatures) which eliminate soil drain and be kept away from the high heat of the completely or reduce it to a fine powdered ash you can wipe broiler.

  • Page 14: Self-Clean

    2. Remove the broiler pan and insert, all utensils and any Self-Clean aluminum foil. These items cannot withstand high clean- Use a 2 hour self-clean cycle for light soils, a 3 hour ing temperatures. cycle for average soils, and a 4 hour cycle for heavy soils 3.

  • Page 15: Delayed Self-Clean

    To Stop or Interrupt a Self-Cleaning Cycle Delayed Self-Clean If it becomes necessary to stop or interrupt a self-cleaning Use a 2 hour self-clean cycle for light soils, a 3 hour cycle due to excessive smoke or fire: cycle for average soils, and a 4 hour cycle for heavy soils 1.

  • Page 16: Care And Cleaning

    Care and Cleaning 3. Gently lower the door so that the bottom of the hinge Removing Oven Door arm rests on the bottom of the opening. 4. Open the door to the fully opened position. 5. Replace the retaining brackets and screw(s) on each CAUTION side of the oven door.

  • Page 17: Changing Oven Light

    Changing Oven Light Adjusting Oven Temperature The oven light automatically turns on when the door is The temperature in the oven has been calibrated at the opened. To turn the oven light on and off when the door is factory. When first using the oven, be sure to follow recipe closed, use the OVEN LIGHT switch located in the control times and temperatures.
  • Page 18 Surfaces How to Clean Aluminum (Trim Pieces) Use hot, soapy water and a cloth. Dry with a clean cloth. DO NOT scour or use all- purpose cleaners, ammonia, powdered cleansers or commercial oven cleaner. They can scratch and discolor aluminum. For general cleaning , use hot soapy water and a cloth.

  • Page 19: Before You Call For Service

    Before You Call for Service Before you call for service, review this list. It may save you time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this appliance. This oven is equipped with an electronic oven controller. Among its many features is a full time oven circuit diagnostics system.
  • Page 20 Oven smokes excessively Oven door is closed. Door should be open about 3" during broiling. during broiling. Meat too close to the broil burner. Reposition the rack to provide more clearance between the meat and the broiler. Meat not properly prepared. Remove excess fat from meat. Slash remaining fatty edges at right angles to prevent curling, but do not cut into the lean.

  • Page 21: Warranty

    ? @ e @ @ e @ ? f ? @ @ @ @ L f ? @ e @ @ e @ ? Amana Appliances will repair or replace, including related labor and travel, any part (f.o.b. Amana, Iowa) which proves to be ? @ e @ @ e 3 L f J @ @ @ @ ) X ? e J 5 e @ @ e @ ? ? @ e @ @ e V / X ? ? W &...

  • Page 24: Quick Reference Instructions

    2. Once the oven has cooled for approximately 1 HOUR and the word “LOCKED” shown in the display has gone out, then the oven door can be opened. © 10/98 Amana Appliances Part No.36-31876401-0 Ref. P/N 318200910 (9808) Rev. A Amana, Iowa 52204...
