- Page 1 OPERATOR’S MAN U AL MODEL ORDER # DE-201007D 1.106-061.0 DE-201507D 1.106-062.0 DE-301007D 1.106-063.0 DE-352007A 1.106-064.0 To locate your local Shark Commercial Pressure Washer Dealer nearest you, visit www.shark-pw.com 8.919-015.0...
-
Page 2: Table Of Contents
CONTENTS Important Safety Information ..............3-4 Component Identifi cation ................. 5 Assembly Instructions ................6 Operating Instructions................7 Applying Detergents & General Cleaning Techniques ......8 Shut Down and Clean-Up ................ 9 Storage ....................9 Troubleshooting ..................10 Preventative Maintenance ..............11 Oil Change Record ................ -
Page 3: Important Safety Information
INTRODUCTION & IMPORTANT SAFETY INFORMATION Thank you for purchasing this Pressure Washer. DANGER: Improper connection of the equip- ment-grounding conductor can result in a risk We reserve the right to make changes at any time of electrocution. Check with a qualifi ed electri- without incurring any obligation. -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION 14. Inlet water must be clean fresh water and no hotter WARNING: Grip cleaning wand WARNING then 90°F. securely with both hands before starting. Failure to do this could 15. Manufacturer will not be liable for any changes result in injury from a whipping made to our standard machines or any components wand. -
Page 5: Component Identifi Cation
COMPONENT IDENTIFICATION Detergent Injector Pump Protector Water Supply Pressure (not included) Nozzle Unloader Soap Nozzle Quick On/Off Coupler Switch Wand Hanger Pump Detergent Safety Bucket (not Latch included) Garden Hose (not included) High Pressure GFCI Hose Spray Gun and Wand Pump —... -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Carriage Bolts Hose/Gun Handle Bolt Storage Bracket Alignment Holes Frame Assy. Studs STEP 1: Attach handle to the frame STEP 2: Insert the carriage bolt STEP 3: Attach the spray gun/hose of the pressure washer. Note: It through the holes from the outside storage handle, and bracket to may be necessary to move the of the unit and attach a nut from... -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Cold Water Source Garden Hose STEP 1: Connect garden hose STEP 2: Trigger the spray gun to STEP 3: Connect to appropriate to the cold water source and turn eliminate trapped air then wait for power supply. Push reset button water on completely. -
Page 8: Applying Detergents & General Cleaning Techniques
DETERGENTS & GENERAL CLEANING TECHNIQUES WARNING: Some detergents THERMAL PUMP PROTECTION WARNING may be harmful if inhaled or If you run the motor on your pressure washer for 3-5 ingested, causing severe nau- minutes without pressing the trigger on the spray gun, sea, fainting or poisoning. -
Page 9: Shut Down And Clean-Up
SHUTTING DOWN AND CLEAN-UP On/Off Switch STEP 1: Remove deter- STEP 2: Turn off machine STEP 3: Turn off water STEP 4: Press trigger to gent suction tube from by turning switch to “OFF” supply. release water pressure. container and insert into switch. -
Page 10: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION PUMP RUNNING Pump sucking air Check water supply and possibility of air. NORMALLY BUT Check valves sticking Check and clean or replace if necessary. PRESSURE LOW ON Unloader valve seat faulty Check and replace if necessary. INSTALLATION Nozzle incorrectly sized Check and replace if necessary. -
Page 11: Preventative Maintenance
PREVENTATIVE MAINTENANCE PREVENTATIVE MAINTENANCE This pressure washer was produced with the best available materials and quality craftsmanship. However, you as the owner have certain responsibilities for the correct care of the equipment. Attention to regular preventative maintenance procedures will assist in preserving the performance of your equipment. Contact your dealer for maintenance. -
Page 12: Exploded View
EXPLODED VIEW 15 16 17 6, 7 DEPO SITIV H TO O DE REPO SICIO 18, 19 14, 28 Models Models 253.0, 14, 28 251.0, 252.0, 064.0 062.0, 063.0 TIVO H TO Models 250.0, 061.0 9.800-085.0 • 8.919-015.0 • Rev. 01/11... -
Page 13: Exploded View Parts List
EXPLODED VIEW PARTS LIST ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 9.104-016.0 NOZZLE KIT 3.25 (23326) 9.802-478.0 Lid, Plastic, Carlon E9801 Box 1 (251.0, 252.0, 253.0, 062.0, 9.804-624.0 Nozzle, 1504, Yellow 063.0, 064.0 ) (250.0, 061.0) 9.802-477.0 Box, Plastic, Carlon E9801, 9.804-625.0 Nozzle, 2504, Green w/o Lid (251.0, 252.0, 253.0,... - Page 14 EXPLODED VIEW PARTS LIST ITEM PART NO. DESCRIPTION 9.802-706.0 Bolt, Carriage, 1/4"-20 x 1-3/4" 6 9.802-802.0 Washer, 1/4" Flat 9.802-776.0 Nut, 5/16" ESNA, NC 9.803-119.0 Handle, Lower Grab, Chrome 9.803-114.0 Retainer Bracket, Handle, Black 9.802-728.0 Bolt, 3/8" x 2" 9.802-730.0 Bolt, 3/8"...
-
Page 15: Hose And Spray Gun Assembly
HOSE AND SPRAY GUN ASSEMBLY HOSE AND SPRAY GUN ASSEMBLY PARTS LIST ITEM PART NO. DESCRIPTION 9.802-166.0 Coupler, 3/8" Female 9.802-100.0 Quick Coupler O-Ring 8.739-125.0 Hose, 3/8" x 50', 1 Wire, Tuff-Flex 9.802-223.0 Spray Gun, Shut-Off 9.802-220.0 Wand, Straight 9.802-164.0 Coupler, 1/4"... -
Page 16: Unloader Exploded View And Parts List
UU1 UNLOADER EXPLODED VIEW 9.175-018.0 UU1 3500PSI, UNIVERSAL UNLOADER (SPARE) UU1 UNLOADER EXPLODED VIEW PARTS LIST ITEM PART # DESCRIPTION KIT QTY ITEM PART # DESCRIPTION KIT QTY 8.749-792.0 Piston housing 9.149-006.0 Sliding connector guide Piston O-ring backup 6X 1.45X 1.68 Piston O-ring back up Conical seal 8.749-796.0 Main block... -
Page 17: Pump Exploded View And Parts List
KE.1 SERIES PUMP EXPLODED VIEW 9.803-814.0 KE 2020F 9.803-815.0 KE 2020S 9.803-816.0 KE 2825F 9.803-817.0 KE 2825S 9.803-818.0 KE 3525F TORQUE SPECS Item # Ft.-lbs KE.1 SERIES PUMP EXPLODED VIEW PARTS LIST ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 9.803-951.0 Brass Plug G1/4 9.803-938.0... - Page 18 KE.1 SERIES PUMP EXPLODED VIEW PARTS LIST ITEM PART NO. DESCRIPTION 9.804-584.0 Flange Screw 9.804-585.0 Crankshaft Seal 38* See Kit Below Plunger Nut 39* See Kit Below Copper Spacer 40* See Kit Below Plunger 15mm (2020F, 2825F, 3525F) 3 See Kit Below Plunger 18mm (2020S, 2825S) 41* See Kit Below...
-
Page 19: Specifi Cations
SPECIFICATIONS HD Models Machine Pessure Nozzle Pump Pump Unloader Motor Motor Model (PSI) Size Hose p/n Part # Model Part # Part # 1.575-250.0 1000 3.75 9.802-233.0 9.803-814.0 KE2020F 9.175-018.0 1-1/2 9.802-338.0 1.575-251.0 1500 9.802-233.0 9.803-814.0 KE2020F 9.175-018.0 9.802-339.0 1.575-252.0 1000 9.802-233.0 9.803-816.0... -
Page 20: Warranty
Dealer or other sales or service outlet to another purchaser. Shark products that are sold by any distributor or retailer that is not an official authorized dealer or retailer of Shark products. Defects caused by acts of nature and disaster including, but not limited to, floods, fires, wind, freezing, earthquakes, tor- nadoes, hurricanes and lightning strikes. - Page 21 Form # 8.919-015.0 • Revised 01/11 • Printed in U.S.A. or México...
