- Page 1 MODEL: DE OPERATING INSTRUCTION AND PARTS MANUAL DE-2010 DE-2015 SHARK PRESSURE WASHERS 4275 N.W. Pacific Rim Blvd. Camas, WA 98607 For technical assistance or the Shark Dealer nearest you, call 1-800-771-1881.
- Page 2 MACHINE SPECIFICATIONS G G G G G G G G G G Machine Voltage: Pump Volume At Pump Head: DE-2010 120V/1PH DE-2010 2.0 GPM DE-2015 120V/1PH DE-2015 1.9 GPM G G G G G G G G G G Total Machine Amperage:...
-
Page 3: Table Of Contents
CONTENTS Introduction............. 4 Exploded View ............8 Important Safety Information ....... 4-5 Parts List, Exploded View ........9 Pre-Operation Check ..........5 Hose & Spray Gun Assembly ....... 10 Setup Procedures ........... 5 Downstream Injector Assembly ......11 Operating Instructions ..........5 Troubleshooting ............ -
Page 4: Introduction
DE SERIES PRESSURE WASHER OPERATOR’S MANUAL WARNING: Flammable liquids INTRODUCTION WARNING can create fumes which can ig- Thank you for purchasing a Shark Pressure Washer. nite causing property damage or This manual covers the operation and maintenance of severe injury. the DE-201001D and DE-201501D washers. -
Page 5: Pre-Operation Check
DE SERIES PRESSURE WASHER OPERATOR’S MANUAL 8. On 230V machines, attach appropriate plug end (not 10. The best insurance against an accident is precau- included) to power cord. tion and knowledge of the machine. 11. Shark will not be liable for any changes made to our OPERATING INSTRUCTIONS standard machines, or any components not pur- chased from Shark. -
Page 6: Component Identification
DE SERIES PRESSURE WASHER OPERATOR’S MANUAL COMPONENT IDENTIFICATION ALL MODELS Unloader Nozzle Soap Nozzle Power Supply Water Supply Plug GFCI Water Supply Hose (not included) Detergent Detergent Injector Bucket (not included) Wand Nozzle Quick Trigger Coupler High Pressure Nozzle Spray Gun Shark DE •... -
Page 7: How To Use The Detergent Injector
DE SERIES PRESSURE WASHER OPERATOR’S MANUAL HOW TO USE 5. Install the brass soap nozzle provided with the in- jector into the quick coupler of the wand. THE DETERGENT INJECTOR 6. Open spray gun. Water detergent ratio is approxi- mately 15 to 1. WARNING: Some detergents may WARNING be harmful if inhaled or ingested... -
Page 8: Exploded View
DE SERIES PRESSURE WASHER OPERATOR’S MANUAL EXPLODED VIEW ALL MODELS On/Off Switch Model 201001D Shark DE • Rev. 7/02... -
Page 9: Parts List, Exploded View
90-1006 Bolt, 5/16" x 3/4" NC GR 5 95-07200021 Handle, Assy, Grab CS ZN 4-12804015 Nozzle, SAQCMEG, 1504, 90-4001 Washer, 5/16", Flat, SAE Yellow (DE-2010) 6-01041 Cord, Electric 12/3 SJOWA 4-12803015 Nozzle, SAQCMEG, 1503, (2015) 3 Ft Yellow (DE-2015) 6-051595... -
Page 10: Hose & Spray Gun Assembly
DE SERIES PRESSURE WASHER OPERATOR’S MANUAL HOSE & SPRAY GUN ASSEMBLY ALL MODELS ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 2-2000 Coupler, 1/4" Female, Brass 2-2002 Coupler, 3/8" Female, Brass L O-Ring, Quick Coupler, L O-Ring, Quick Coupler, 2-0119 2-0121 1/4"... -
Page 11: Downstream Injector Assembly
DE SERIES PRESSURE WASHER OPERATOR’S MANUAL DOWNSTREAM INJECTOR ASSEMBLY ITEM PART NO. DESCRIPTION 3-1202 Detergent Injector, 2-3 GPM, 0.70 2-9000 Clamp, Screw, #4 4-02080000 Tube, 1/4" x 1/2", Clear Vinyl /ft. 2-1904 Strainer, 1/4", Hose Barb Shark DE • Rev. 7/02... -
Page 12: Troubleshooting
DE SERIES PRESSURE WASHER OPERATOR’S MANUAL TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION PUMP RUNNING Pump sucking air Check water supply and possibility of air seepage. NORMALLY BUT Check valves sticking Check and clean or replace if necessary. PRESSURE LOW ON Unloader valve seat faulty Check and replace if necessary. -
Page 13: Preventative Maintenance
DE SERIES PRESSURE WASHER OPERATOR’S MANUAL PREVENTATIVE MAINTENANCE This pressure washer was produced with the best available materials and quality craftsmanship. However, you as the owner have certain responsibilities for the correct care of the equipment. Attention to regular preventative mainte- nance procedures will assist in preserving the performance of your equipment. -
Page 14: Warranty
WHAT THIS WARRANTY COVERS All SHARK PRESSURE WASHERS are warranted by SHARK to the original purchaser to be free from defects in materials and workmanship under normal use, for the periods specified below. This Limited Warranty is subject to the exclusions shown below, is calculated from the date of the original purchase, and applies to the original components only. - Page 16 4275 N.W. Pacific Rim Blvd. • Camas, WA 98607 • 1-800-771-1881 Form #97-6127 • Revised 7/02 • Printed in U.S.A.
