OPERATOR'S MANUAL
®
To locate your local Shark Commercial Pressure Washer Dealer nearest you,
P O
ON
W E
PR
EN
CO
DE
CO
RR
R
O
R
UR
IE NT
AN
E
T
H E
CA
A T
CH
LE
E R
AU
NT
AD
FF
OR
E-
EA
I
U
OF
AP
AG
F
ET
AR
TE
IN
T
H E
A T
E R
O N
CO
NT
RO
T IM
LA
E R
DO
MI
R DE
—
NU
TE
TI EM
7 D
RI E
A Y
DE
PO
7 JO
DE
UR
SI ET
S
E DI
EA
S
EX
PU
TR
LL
AI GA
O U
TI RE
LA
T PI
R LE
S CL
S PO
AV
N S
IJA
TO
IN TE
S PA
SE
LE
UR
RA
T D
S HO
S VE
ES
ES
RA
RS
TA
BL
IR
IR ES
L'E
EC
ED
D' OP
XT
ER
ER
"O
IE UR
EL
N "
ER
TI EM
TI M
AT
IO
PO
UR
PO
ES
.
N
E' TA
DE
SE
BL
IR
AD
O.
10
-07
26
MODEL #
EEC-422007C
EEC-353007C
visit www.sharkpw.com
EEC
98012960-1
ORDER #
1.106-068.0
1.106-069.0
9.801-296.0
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Shark Pressure Washers EEC-422007C
Summary of Contents for Shark Pressure Washers EEC-422007C
- Page 1 IR ES L’E D’ OP “O IE UR N ” TI EM TI M E’ TA ® 98012960-1 MODEL # ORDER # EEC-422007C 1.106-068.0 EEC-353007C 1.106-069.0 To locate your local Shark Commercial Pressure Washer Dealer nearest you, visit www.sharkpw.com 9.801-296.0...
-
Page 2: Table Of Contents
CONTENTS Introduction & Important Safety Information Pre-Operation Check Component Identification Assembly Instructions Operating Instructions Detergents & General Cleaning Techniques Shut Down Procedures Storage Preventative Maintenance & Oil Change Record Maintenance Troubleshooting 13-15 Warranty Model Number ______________________________ Serial Number ______________________________ Date of Purchase ___________________________ The model and serial numbers will be found on a decal attached to the pressure washer. -
Page 3: Introduction & Important Safety Information
This product shall only be This manual covers the operation and maintenance connected to a power supply receptacle protected of the EEC-422007C and EEC-353007C washers. All by a ground fault circuit interrupter. information in this manual is based on the latest product information available at the time of printing. -
Page 4: Pre-Operation Check
IMPORTANT SAFETY INFORMATION WARNING: High pressure spray PRE-OPERATION CHECK WARNING can cause paint chips or other Heat module water level particles to become airborne Pump oil (SAE 30W non-detergent oil) and fly at high speeds. Cold water supply (6 gpm • 5/8" • 20 psi) 11. -
Page 5: Component Identification
COMPONENT IDENTIFICATION Water Fill Cabinet Spout On/Off Toggle Switch Pump Access Brass Soap Panel Nozzle Pressure Nozzles Detergent Injector Quick Coupler Collar Nozzle Quick IE NT IN T Coupler T IM — TI EM E DE 7 JO SI ET E DI TI RE T PI... -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Incoming Power Ground Terminal Terminal Block Block ¡ ¢ Small High Pressure Hose 98012960-3 98012960-4 STEP 1: Place machine in a con- STEP 2: Place the cabinet on top venient location providing ample of the heat exchanger and attach support, drainage and room for the small high pressure hose to the maintenance. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS Pressure Pressure Trigger Nozzle Nozzle Wand Wand Trigger Collar Safety Wand Latch Coupler 98012960-7 98012960-9 98012960-8 STEP 5: Attach variable pressure STEP 6: Pull the spring-loaded col- STEP 7: Release the coupler collar control wand to spray gun using tef- lar of the wand coupler collar back and push the nozzle until the collar lon tape on threads to prevent leak-... -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS Toggle Switch Discharge Nipple Garden Hose High Pressure Inlet 98012960-11 Hose Coupler 98012960-10 98012960-12 STEP 1: Connect the high pressure STEP 2: Connect water sup- STEP 3: Place toggle switch in the hose quick coupler to the discharge ply hose (garden hose) to inlet ON position and then pull the trig- nipple by sliding the quick coupler... -
Page 9: Detergents & General Cleaning Techniques
DETERGENTS & GENERAL CLEANING TECHNIQUES WARNING: Some detergents THERMAL PUMP PROTECTION WARNING may be harmful if inhaled or ingested, causing severe nau- If you run your pressure washer for 3-5 minutes without sea, fainting or poisoning. The pressing the trigger on the spray gun, circulating water harmful elements may cause in the pump can reach high temperatures. -
Page 10: Shutdown Procedures
SHUTDOWN PROCEDURES Toggle Switch 98012960-18 98012960-17 98012960-12 STEP 1: Rinse all lines (and in- STEP 2: Turn off water supply. STEP 3: Open spray gun to relieve jector) with clean water, to remove remaining pressure and remove any soap residue then turn toggle water supply hose. -
Page 11: Preventative Maintenance & Oil Change Record
PREVENTATIVE MAINTENANCE This pressure washer was produced with the best available materials and quality craftsmanship. However, you as the owner have certain responsibilities for the correct care of the equipment. Attention to regular preventative maintenance procedures will assist in preserving the performance of your equipment. Contact your Shark dealer for maintenance. -
Page 12: Maintenance
MAINTENANCE Daily: Weekly: To ensure a problem free system, simple visual checks After the first week of operation, it is recommended can be performed. Check for leaks in inlet supply, 1 quart (1 litre) of motor oil be added to the heat ex- changer tank through the 1-1/4"... -
Page 13: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION LOW OPERATING Faulty pressure gauge Install new gauge. PRESSURE Use larger garden hose; clean filter Insufficient water supply washer at water inlet. Match nozzle number to machine and/or Old, worn or incorrect spray nozzle replace with new nozzle. Check plumbing system for leaks. - Page 14 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION OIL SQUIRTS OUT OF OIL CAP Pump overfilled with oil Maintain oil level at red dot on ON PUMP sight glass at rear of pump or at top of notch on dipstick (where applicable). WATER DRIPPING FROM Piston packing worn Check and replace if necessary.
-
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION WATER ESCAPING FROM Cold water added to heat exchanger Will stop once at operating tempera- FILL PIPE ON HEAT ture. EXCHANGER Ruptured coil or leaking Check, repair or replace fittings. UNLOADER DOES NOT Spray gun or hose is leaking to Check and repair all leaks. - Page 17 WHAT THIS WARRANTY COVERS All Shark pressure washers are warranted by Shark to the original purchaser to be free from defects in materials and workmanship under normal use, for the periods specified below. This Limited Warranty, subject to the exclusions shown below, is calculated from the date of the original purchase, and applies to the original components only.
- Page 18 www.Sharkpw.com Form # 9.801-269.0 • Revised 11/12 • Printed in U.S.A. or Mexico...
