SAVE AND READ THESE INSTRUCTIONS
TESTED IN ACCORDANCE WITH THE LATEST EDITION OF ANSI/UL 858-2001 AND CAN/CSA-C22.2 NO. 64
STANDARD FOR HOUSEHOLD ELECTRIC COOKING AND LIQUID HEATING APPLIANCES.
CONVENTIONS USED IN THESE INSTRUCTIONS
WARNINGS:
Must be followed carefully to avoid personal injury or damage.
NOTES:
Contain helpful hints and tips to facilitate the installation.
IMPORTANT
1.
Before beginning installation, please thoroughly read and become familiar with these instructions.
2.
Installation and service must be completed by a qualified installer or service agency.
3.
Installer: Please leave these Installation Instructions with the owner.
4.
Owner: Please keep these instructions for local electrical inspector's use and for future reference.
5.
Read the accompanying Use & Care Manual prior to operating this appliance.

TABLE OF CONTENTS

Part No. 65141 Rev. D
Installation Instructions
SGM Cooktops
Page 2
Page 2
Page 2-3
Page 3-4
Page 4
Page 4
Page 5
Page 5
Page 5-6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGM304 and is the answer not in the manual?

Questions and answers

Related Manuals for Dacor SGM304

Summary of Contents for Dacor SGM304

  • Page 1: Table Of Contents

    Installation Instructions SGM Cooktops SAVE AND READ THESE INSTRUCTIONS TESTED IN ACCORDANCE WITH THE LATEST EDITION OF ANSI/UL 858-2001 AND CAN/CSA-C22.2 NO. 64 STANDARD FOR HOUSEHOLD ELECTRIC COOKING AND LIQUID HEATING APPLIANCES. CONVENTIONS USED IN THESE INSTRUCTIONS WARNINGS: Must be followed carefully to avoid personal injury or damage. NOTES: Contain helpful hints and tips to facilitate the installation.

  • Page 2: Important Safety Instructions

    Contact the additional information, consult nearest DACOR Authorized a qualified installer, service Servicer at (800) 772-7778, agency, manufacturer (dealer), or at www.dacor.com for or the gas supplier. examination, repair or For your safety: adjustment. • Do not obstruct the flow of...

  • Page 3: Verifying Package Contents

    Model Minimum Maximum placed for convenient access, but away from a drawer installed below the SGM304 30” (762mm) 36” (914mm) drafts that may be caused by open doors and cooktop. windows or by HVAC duct outlets. Make certain...

  • Page 4: Gas And Electrical Supply Requirements

    21" Chassis height The only downdraft approved (533mm) 30" for use with the SGM464GG (762mm) is the Dacor ERV/PRV. Dacor recommends a 54 inch wide 1/4" (6mm) Min. hood with a minimum 1100 to combustibles Vertical below chassis CFM blower.

  • Page 5: Installing The Cooktop

    In the absence of local required load pressure codes, this appliance should be installed in SGM304 Natural 4” Water Column 5” Water Column accordance with the National Fuel Gas Code ANSI Z223.1/NFPA 54. Be certain that the...

  • Page 6: Installing The Burner And Grill Components

    a soap and water solution. SGM Burner Components Plug the three-prong plug from the appliance Remove the brass burner rings, porcelain burner into the properly grounded and polarized wall Do not use a flame to check caps, and porcelain grates from their shipping receptacle.
  • Page 7 turn off the knob, wait for at least two minutes to allow any gas to dissipate, then repeat this ignition test.) The control knob can then be rotated counterclockwise from “HIGH” to “LOW” to adjust the flame height progressively. Repeat the ignition test for all burners.
  • Page 8 Web Site: www.dacor.com For a Dealer/Service: (800) 772-7778 Corporate Phone: (800) 793-0093...
