- Page 1 nstall atI o n nstru c tI o ns ® referen ce o o k to P For use with models: SGM304, SGM365, SGM466 Part No. 65141 Rev. E...
-
Page 2: Table Of Contents
Front of unit Web site: www.Dacor.com Monday — Friday 6:00 a.m. to 5:00 p.m. Pacific Time Product Data Label All specifications are subject to change without notice. Dacor assumes no liability for changes in specifications. © 2007 Dacor, all rights reserved... -
Page 3: Important Safety Instructions
• From a neighbor’s phone, immediately call the gas • Always contact the Dacor Customer Service Team supplier. Follow the gas supplier’s instructions. about problems and conditions that you do not • If you cannot contact the gas supplier, call the fire understand. -
Page 4: General Safety Precautions
• Do not use this appliance in combination with a the cooktop. Do not allow clothing to come into surface (countertop) ventilation system. Dacor contact with the cooktop and surrounding areas strongly recommends the installation of a range during and immediately after use. -
Page 5: Installation Specifications
nstallatIon PecIfIcatIons Gas Supply Requirements WARNING Observe all governing codes and ordinances during • Be certain that the cooktop being installed is correct for planning and installation. Contact your local building the gas service being provided (natural gas or LP gas). department for further information. -
Page 6: Cabinet And Countertop Layout
nstallatIon PecIfIcatIons Cabinet and Countertop Layout • Allow a minimum ¼” (6mm) clearance between the bottom of the cooktop chassis and all combustible surfaces, including the upper edge of a drawer installed WARNING below the cooktop. • To reduce the risk of personal injury caused by reaching over a hot appliance, avoid locating cabinet storage space directly above the cooktop. -
Page 7: Product And Cutout Dimensions
nstallatIon PecIfIcatIons Product and Cutout Dimensions 4" (102mm) 21" Chassis height (533mm) 30" (762mm) 1/4" (6mm) Min. to combustibles Vertical below chassis combustible surface Rear 7 1/2" (191mm) Min. wall to combustible 3 1/8" side wall above (79mm) the cooktop 2 1/4"... -
Page 8: Installation Instructions
nstallatIon nstructIons Installing the Cooktop Connecting the Gas WARNING WARNING • To prevent damage to the gas pressure regulator, • Do not install or use the cooktop without the included install it only after the cooktop is mounted in its gas regulator installed. -
Page 9: Installing The Burner And Grill Components
nstallatIon nstructIons Installing the Burner and Components and Grates Set each porcelain burner cap on top of its WARNING corresponding burner ring. • Never attempt to operate the cooktop with any of the Put each grate onto the cooktop. Be sure that the burner parts removed. -
Page 10: Verifying Proper Operation
• Repeat the above burner ignition test. • If the appliance still does not work, do not attempt to repair the appliance yourself. Contact the Dacor Customer Service Team at (800) 793-0093. -
Page 11: Installation Checklist
• Proper installation is the responsibility of the homeowner. The importance of proper installation of your Dacor cooktop cannot be overemphasized. □ Is the electrical outlet for the cooktop grounded and located according to these instructions and in accordance with all applicable electrical codes? See pages 3 and 4. -
Page 12: Wiring Diagrams
IrIng Iagrams... - Page 13 IrIng Iagrams...
- Page 14 IrIng Iagrams...
- Page 16 Dacor ● 1440 Bridge Gate Drive, Diamond Bar, CA 91765 ● Tel: (800) 793-0093 ● FAX: (626) 403-3130 ● www.Dacor.com...
