Dacor RGC Series Planning Manual

Document # PGCI-007

Cutout Dimensions

IMPORTANT: Be careful to use the correct cutout diagram (on page 2/2) to determine the countertop dimensions. Carefully double check
all dimensions against the table below and the correct diagram before cutting the countertop.
Installation Type
RGC/SGM304
with RV30
RGC/SGM365
with RV36
SGM466 with
RV46
* Total cutout depth, accommodates both the cooktop and raised vent
** IMPORTANT: Notch depth is included in total cutout depth (D). DO NOT add notch depth to total cutout depth (D).
◊ Observe all governing codes and ordinances during
planning and installation. Contact your local building
department for further information.
◊ All appliances must be installed in accordance with the
accompanying installation instructions.
www.Dacor.com
Phone: (800) 793-0093
COMBINATION INSTALLATIONS
RGC/SGM Series Drop-In Gas Cooktop
with RV Series Raised Vent
Cutout
C (Min.)
Diagram
Figure 1 5/8"
(Square) (16 mm)
Figure 1 5/8"
(Square) (16 mm)
Figure 2 5/8"
(Notched) (16 mm)
wARNING
All tolerances +1/16" -0 (+1.6 mm, 0) unless otherwise noted

Countertop Dimensions

D
22 1/4" * 27 3/4"
(565 mm) (686 mm)
22 1/4" * 33 5/8"
(565 mm) (854 mm)
22 1/4" * 44 3/4"
(565 mm) (1137 mm)
Stiffener
Side View - RGC/SGM Series Cooktop with
Specifications are subject to change without notice.
See installation instructions for additional details.
Revised 05/07/09 Page 1/2
PLANNING
E F G
NA NA
NA NA
43 1/2" 5/8"
(1105 mm) (16 mm)
5/8" Min. (16 mm)
flat countertop overhang
required behind cutout
RGC or SGM series cooktop SGM Series Cooktop
Cabinet face
5/8" Min. (16 mm) space
behind raised vent
chassis to clear stiffener
RV series raised vent:
Check raised vent
dimensions/specifications
to determine proper fit
Floor
RV Series Raised Vent
GUIDE
H
NA
NA
2 5/8" **
(67 mm)
Countertop
