SECTION 6
[SW-A UNIT] ([F11] AND [F12] ONLY)
REF ORDER
NO. NO.
Q1 1590003020 S.TRANSISTOR XP4216-(TX)
R1 7210003060 VARIABLE
R2 7030003380 S.RESISTOR
R3 7030003410 S.RESISTOR
F1 5210000710 S.FUSE
DS1 5040002070 S.LED
S1 2250000450 ENCODER
EP1 0910054463 PCB
[SW-B UNIT] ([F11BR], [F11S] AND [F12S] ONLY)
REF ORDER
NO. NO.
Q1 1590003020 S.TRANSISTOR XP4216-(TX)
R1 7210003060 VARIABLE
R2 7030003380 S.RESISTOR
R3 7030003410 S.RESISTOR
F1 5210000710 S.FUSE
DS1 5040002070 S.LED
W1 7120000470 JUMPER
W2 7120000470 JUMPER
EP1 0910054473 PCB

[MAIN UNIT]

REF ORDER
NO. NO.
IC1 1140005990 S.IC
IC2 1110002750 S.IC
IC3 1110003490 S.IC
IC4 1110001810 S.IC
IC5 1110005320 S.IC
IC6 1130008090 S.IC
IC7 1140009850 S.IC
IC8 1130009110 S.IC
IC9 1190000350 S.IC
IC10 1110005350 S.IC
IC11 1130010490 S.IC
IC12 1110005330 S.IC
IC13 1130007020 S.IC
IC15 1130007570 S.IC
IC16 1110005330 S.IC
A: [F12] and [F12S]
C: [F11]and [F12]

PARTS LIST

DESCRIPTION
TP76N00N-15F-10KA-2251
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 561 V (560 Ω)
KAB 2402 322 NA29
LNJ107W5PRW
TP70QF4161-16F-2458A
B 5603C
DESCRIPTION
TP76N00N-15F-10KA-2251
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 561 V (560 Ω)
KAB 2402 322 NA29
LNJ107W5PRW
ERDS2T0
ERDS2T0
B 5604C
DESCRIPTION
MB15A02PFV1-G-BND-ER
TA75S01F (TE85R)
TA31136FN (D,EL)
TA7368F (TP1)
NJM13403V-TE1
BU4066BCFV-E1
HD6433664A24FP
S-80942ANMP-DD6-T2
M62363FP-650C
NJM2870F05-TE1
BR24C16FV-E2
NJM12904V-TE1
TC7S66FU (TE85R)
BU4094BCFV-E2
NJM12904V-TE1
B: [F11], [F11BR] and [F11S]
D: [F11BR], [F11S] and [F12S]
[MAIN UNIT]
REF ORDER
NO. NO.
Q1 1560001050 S.FET
Q2 1560001020 S.FET
Q4 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q5 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q6 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q7 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q8 1590000430 S.TRANSISTOR DTC144EUA T106
Q10 1530003230 S.TRANSISTOR 2SC5085-Y (TE85R)
Q11 1530003230 S.TRANSISTOR 2SC5085-Y (TE85R)
Q12 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q13 1560000540 S.FET
Q14 1590000720 S.TRANSISTOR DTA144EUA T106
Q15 1580000750 S.FET
Q16 1580000660 S.FET
Q17 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q18 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q19 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q20 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q21 1590000430 S.TRANSISTOR DTC144EUA T106
Q22 1590002530 S.TRANSISTOR UN911H (TX)
Q23 1590000720 S.TRANSISTOR DTA144EUA T106
Q24 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q25 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q26 1510000920 S.TRANSISTOR 2SA1577 T107 Q
Q27 1510000920 S.TRANSISTOR 2SA1577 T107 Q
Q28 1590000430 S.TRANSISTOR DTC144EUA T106
Q29 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q30 1590001770 S.TRANSISTOR XP1213 (TX)
Q31 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q32 1590000660 S.TRANSISTOR DTC144TU T107
Q33 1560000840 S.FET
Q35 1590000430 S.TRANSISTOR DTC144EUA T106
Q36 1560000840 S.FET
D1 1750000580 S.DIODE
D2 1790001670 S.DIODE
D3 1790000620 S.DIODE
D4 1790000620 S.DIODE
D5 1720000780 S.VARICAP
D6 1790001260 S.DIODE
D7 1720000780 S.VARICAP
D9 1750000580 S.DIODE
D10 1790000620 S.DIODE
D12 1720000780 S.VARICAP
D13 1720000780 S.VARICAP
D14 1720000780 S.VARICAP
D15 1720000780 S.VARICAP
D16 1790000620 S.DIODE
D17 1790001670 S.DIODE
D18 1790001250 S.DIODE
D19 1750000830 S.VARICAP
D20 1790001250 S.DIODE
D21 1790001250 S.DIODE
D22 1790000620 S.DIODE
D23 1790001250 S.DIODE
D24 1720000360 S.DIODE
D25 1790001250 S.DIODE
FI1 2030000130 S.XTAL
FI2 2020001840 CERAMIC
X1 6050011070 S.XTAL
X2 6070000210 S.DISCRIMINATOR CDBCA450CX24
X3 6050011180 S.XTAL
L1 6200008580 S.COIL
L2 6200009800 S.COIL
L3 6200002860 S.COIL
L4 6200008280 S.COIL
L5 6200008230 S.COIL
L6 6200003590 S.COIL
6 - 1
DESCRIPTION
2SK2974
2SK2973 (MTS101P)
2SK880-Y (TE85R)
3SK294 (TE85L)
3SK272-(TX)
A
2SK1829 (TE85R) only
2SK1829 (TE85R)
1SV307 (TPH3)
RB706F-40T106
MA77 (TX)
MA77 (TX)
HVU350B TRF
MA2S077-(TX)
HVU350B TRF
1SV307 (TPH3)
MA77 (TX)
HVU350B TRF
HVU350B TRF
HVU350B TRF
HVU350B TRF
MA77 (TX)
RB706F-40T106
A
MA2S111-(TX) only
HVC362TRF
MA2S111-(TX)
MA2S111-(TX)
MA77 (TX)
MA2S111-(TX)
HSU88TRF
MA2S111-(TX)
FL-333 (31.05 MHz)
ALFYM450F=K
CR-664A (15.300 MHz)
CR-702 (14.7456 MHz)
0.30-1.4-6TL 32N
0.26-1.1-7TR 30N
NL 252018T-4R7J
0.30-1.7-7TL 50N
0.30-1.3-5TL 22N
EXCCL3225U1
S.=Surface mount
