Summary of Contents for Sanav GC-101
- Page 1 GC-101 GPS/GSM Micro Tracker May 25 2009 Version: 2.04F 11F, No.2, Sec. 4, Jhongyang Rd., Tucheng City, Taipei County 236, Taiwan Taipei County 220, Taiwan (R.O.C.). Tel: + 886-2-2269-4456 Fax: +886-2-2269-4451 E-Mail: sanav@sanav.com Web: www.sanav.com All Right Reserved...
-
Page 2: Table Of Contents
Table of Contents 1. Hardware Description................3 2. Specifications..................3 3. Function Overview .................. 4 3.1 General ......................... 4 4. Easy Start ..................6 5. Setup....................8 5.1 Change Username..................... 9 5.2 Change Password ....................10 5.3 Set up the GPRS APN (Access Point Name) ........... 11 5.4 Set up Host Name (URL) to Transmit Data............. - Page 3 1. Hardware Description 1.1 Front Face GSM Status Indicator GPS Status Indicator Flashing: Searching GSM Flashing: Firmware running signals Light off: Searching GPS signals Light on: GSM fixed Light on: GPS fixed 1.2 Side Face Power Switch SOS Button Press when in an emergency...
- Page 4 Below is the indication of LED light status of GC-101 When you operate the GC-101, there are 4 different color lights to indicate different status of GC-101. Please refer to below chart for the detail information.
-
Page 5: Bottom Face
1.3 Bottom Face Power Input Use the chargers provided by SANAV to charge the battery. Cigar Charger Wall Charger Voltage: 8 ~ 35V Operating Temperature: 0 to 40°C Storage Temperature: -20 to 85°C... - Page 6 1.4 Charging When power is ON When power is OFF When GC-101 is When GC-101 is charged with power charged with power switched on and switched off, you GPS is fixed, you shall see a clear shall see a faint green light here.
- Page 7 1.5 Rear Face (Battery Cap) Use your thumb to press the Open the cap and move put away the Put in the SIM card in the correct orientation. battery cap and then slide battery. downward to open it.
-
Page 8: Hardware Description
2. Specifications SPECIFICATIONS Electrics Data Tri Band 8501800/1900MHz or /900/1800/1900MHz Frequency 1575.42 MHz Reacquisition < 2sec. Cold < 60sec. TTFF (Time To First Fix) Acquisition time Warm < 35 sec. TTFF GPS Receiver Hot < 10sec. TTFF TTFF Accuracy Position 10 meters RMS without SA Velocity 0,1m/s without SA Power Battery Power... -
Page 9: Function Overview
3. Function Overview 3.1 General GC-101 is using the GPRS service to upload the RMC sentences containing latitude, longitude, speed and time to an assigned web server. It is specially designed for the intensive tracking applications, such as fleet management and life security. - Page 10 3.2 Features Panic ● The diagram bellow shows the action after Panic button is pressed under HTTP/SMS mode. Please note panic report interval is 60 seconds a time and total are 60 times. Interval is unable to be set. Press Panic Upload messages to URL via GPRS.
-
Page 11: Easy Start
3. Set up the phone book. When either APN or URL is incorrect or GPRS/URL is not available, the GC-101 will not be able to upload the data to the website. In any case mentioned above, the GC-101 will send a SMS instead containing GPS position to the 1 predefined number. - Page 12 5. If you do not have the SMS containing the position, please surf to following website and key in your imei code as the 4.1 shown to check out the GPS data. http://www.sanav.com/eric-gga/gprs_read.aspx 6. Click on OK and you shall read the RMC data. If you have the message of “invalid imei code”, please kindly contact us.
-
Page 13: Setup
SMS from a cellular phone. Key the specific SMS message in your cellular phone as the instruction and send it to the SIM number of GC-101. The setup messages are showed in the following sections. -
Page 14: Change Username
You can change the ID of GC-101 by following the format below. No space is allowed between the characters. For example, if you send the SMS message shown in the example below to the GC-101, you will change the ID from “username” to “ason”... -
Page 15: Change Password
5.2 Change Password Use this SMS message example seen below to change the password of GC-101. For example, by following the example below, you will change the default password, “0000” to a new password, “1111”. Setup format：#「username」,「Password」,「Function Code」,「new Password」,「new Password」* Example：#username,0000,2,1111,1111*... -
Page 16: Set Up The Gprs Apn (Access Point Name)
Table 5.3.1 The table 5.3.2 shows each confirmation message reply after setup. Situation Message Reply Setup Succeeds [username] + GC-101 GPRS APN is updated. Setup Fail [username] + GC-101 GPRS APN setup Fail! Incorrect password [username] + Password setup Fail! -
Page 17: Set Up Host Name (Url) To Transmit Data
GC-101, the URL “http://www.sanav.com/eric-gga/gprs.aspx “ will be assigned to receive the data sent from the GC-101. Please note that the question mark “?” or any symbol is not allowed to be keyed in behind the URL. The GC-101 will add the necessary symbol(s) on automatically. -
Page 18: Set Up Phone Number List
The table 5.5.2 shows each confirmation message reply after setup. Situation Message Reply Setup Succeeds [username] + GC-101 phone book is updated. Setup Fail [username] + GC-101 phone book setup Fail! Non-numeric data is input for numbers [username] + Parameter error... -
Page 19: Set Up Auto Report
Use this command to set up the frequency of Auto Report. If you send the SMS according to the example shown below to GC-101, you will have an Auto Report Message every 300 seconds for 99 messages. Once the loop is done, you can send a SMS message to update/renew, or switching off it in order to renew it. -
Page 20: All Parameters Reset To Default
5.7 All Parameters Reset to Default Use this SMS message to reset GC-101 to factory default. You can just send the SMS according to the example seen below. It will overwrite all the current parameters to default. Setup format：#「username」,「Password」,「Function Code」* Example：#username,0000,9*... -
Page 21: Acquire Report Of Current Position
Note that the message reply shown in Table 5.8.2 will only be sent back to cell phone that sent the SMS to do configuration. The caller’s ID of cellular phone must be activated in order to let the GC-101 recognize the caller ID and... -
Page 22: Set Up Router For Transmitting Data By Url/Ip
The table 5.9.2 describes the meaning of each segment in the message above. Description Text Keyed In SMS Start sign. username Default ID of GC-101. If you have changed the Username, please use the updated one. 0000 Default password. - Page 23 [username] + in emergency, switching to HTTP mode is not allowed. [username] + in emergency, switching to SMS mode is not allowed. GC-101 is in Emergency Mode [username] + in emergency, switching to Map Center mode is not allowed. [username] + in emergency, switching to TCP/SMS mode is not allowed.
-
Page 24: Request Imei Code
Imei stands for international mobile equipment identification. We offer you a command to acquire the Imei number from GC-101 via SMS. Actually, every GC-101 budget has a different default Imei code. You can send the SMS according to the example shown below to check its imei number so as to register to the web server for tracking. -
Page 25: Deactivate Panic Mode
Default password. If you have changed the password, please use the updated one. offpanic Mode offpanic is to deactivate the panic status of GC-101 End sign. Table 5.11.1 The table 5.11.2 shows each confirmation message reply after setup. Situation... - Page 26 [username] + Panic report setting Setup Fail! Incorrect password [username] + Password setup Fail! Incorrect username or command format [username] + command error GC-101 is in Emergency Mode [username] + in emergency, Auto Report setting is not allowed. Table 5.11.4...
-
Page 27: Activate/Deactivate Park Function
Mode 7 is to activate/deactivate the park mode. Speed Limit Setup: This command is to define the speed limit for Park function. When GC-101 exceeds the speed limit in Park mode, it will trigger the event and start sending report according to the setting. - Page 28 Setup format：#「username」,「Password」,「Function Code」,「Time Interval」,「Total Report」* Command: #username,0000,16,60,12* Description Text Keyed In SMS Start sign. username Default ID of GC-101. If you have changed the Username, please use the updated one. 0000 Default password. If you have changed the password, please use the updated one.
-
Page 29: Setup Geofence Coordinate
Command: #username,0000,gf,2458.9741,N,12125.6460,E,500,1~3* Format for canceling geofence : Command: #username,0000,gf,0* Text Keyed In SMS Description Start sign. username Default ID of GC-101. If you have changed the Username, please use the updated one. 0000 Default password. If you have changed the password, please use the updated one. -
Page 30: Geofence Alarm Report
Setup format：#「username」,「Password」,「Function Code」,「Time Interval」,「Total Report」* Command: #username,0000,17,60,12* Description Text Keyed In SMS Start sign. username Default ID of GC-101. If you have changed the Username, please use the updated one. 0000 Default password. If you have changed the password, please use the updated one. -
Page 31: Set Up Voice Monitoring Mode
0: GC-101 will automatically get in the voice monitoring 1: GC-101 will get in voice monitoring function after waiting for “do” sounds for 10 seconds 2: Voice polling then GC-101 will send a GPS data via assigned router to terminal. -
Page 32: Activate The Buzzer
5.15 Activate the Buzzer GC-101 offers a buzzer to alert the user when he is in Emergency situation. The beep sound could be either turned off or turned on. When the SOS key is pressed, the buzzer will start to beep continuously for 20 seconds. This command allows users to enable/disable the buzzer. -
Page 33: Input Tcp/Ip Address
Setup Succeeds [username] +", setup ok. Device TCP/IP is updated." Setup Fail [username] +", TCP/IP setup fail!" GC-101 is in Emergency Mode [username] + "in emergency, TCP/IP is not allowed." Incorrect username or password [username] + Username or Password error... -
Page 34: Sos Phone Setting
5.17 SOS Phone Setting While Panic function is triggered, GC-101 will automatically call the SOS phone to the user if SOS phone is set. The command format will be like following: Setup format：#「username」,「Password」,「Sosphone」,「Phone Number」* Example：#username,0000,sosphone,+886933123456* The table 5.17.1 describes the meaning of each segment in the message above. -
Page 35: Operate Log Function
5.18 Operate Log Function User can use this command to define the log mode of GC-101. There are two log modes can be defined. For the detail, please refer to following explanation and also the diagram of log function logic at the page of 36 and 37. -
Page 36: Define Log Interval
The table 5.19.1 describes the meaning of each segment in the message above. Description Text Keyed In SMS Start sign. username Default ID of GC-101. If you have changed the Username, please use the updated one. 0000 Default password. - Page 37 Operation logic of log mode is set “1”; #username,0000,21,1*...
- Page 38 Operation logic of log mode is set “2”; #username,0000,21,2* Log data interval is set “X”; #username,0000,20,X*...
-
Page 39: Erase The Logged Data
The table 5.20.1 describes the meaning of each segment in the message above. Description Text Keyed In SMS Start sign. username Default ID of GC-101 If you have changed the Username, please use the updated one. 0000 Default password. -
Page 40: Respond Messages
GPRS/SMS mode it will upload the data to the assigned URL first. However, if GPRS service is not available, it will send the SMS to the predefined phone number instead. In the case of GPRS-only mode, GC-101 will only send the data by GPRS no matter there is GPRS service or not. -
Page 41: Auto Report
6.1 Auto Report 6.1.1. Uploading Auto data to URL when GPS is fixed When execute the Auto Report according to the settings with a GPS fixed, GC-101 will upload the data to your URL. The data format will be like the following. -
Page 42: Emergency Response
6.2 Emergency Response When there is GPRS, GC-101 will upload the data to the URL. If the GPRS is not available, it will send the SMS instead. Please read Chapter 3.1 for how Panic works. 6.2.1. Uploading Emergency data to URL when GPS is fixed... -
Page 43: Polling Response
6.3 Polling Response 6.3.1. Uploading Poll data to URL when GPS is fixed When send an SMS to poll a report with a GPS fixed, GC-101 will upload a data to your URL. The data format will be like the following. -
Page 44: Move Report
6.4.1. Uploading park alarm data to URL when GPS is fixed When execute the Auto Report according to the settings with a GPS fixed, GC-101 will upload the data to your URL. The data format will be like the following. -
Page 45: Park Activated/ Deactivated Report
GPRMC,095838.000,V,2458.9733,N,12125.6583,E,0.41,79.21,220905,,*30,PARK/UNPA Field Descriptions imei The username of GC-101 that is a unique number. GPRMC It is a full sentence of GPRMC including the current Lat/Long, UTC and others. PARK/UNPK This is the event triggers the response. !! Note: 1. When in GPRS mode and there is no GPRS service, the report will be sent to the 1st predefined number. In the mean while, the “IMEI”... -
Page 46: Nmea 0183 Gprmc Sentence
6.6 NMEA 0183 GPRMC Sentence... -
Page 47: Warranty
Warranty Time Period and Repair Coverage SAN JOSE TECHNOLOGY, INC. warrants GC-101 to be free from all defects and malfunctions in materials and workmanship for a period of 12 months from the original purchase date from San Jose Technology or authorized dealers.
