- Page 1 GSM/GPS Micro Tracker Model G-19B User's Manual CE No: EM/2004/80113C FCC ID: RUU-G19041000 Version: 2.6-RO Published: December 2004...
-
Page 2: Warranty
G-19B smoothly and correctly as soon as possible. Make sure to read this manual carefully before using this product. Most problems will be solved through the explanations and the troubleshooting tips. -
Page 3: Table Of Contents
Table of Contents Hardware Description ………………..………….………………………5 Getting Started ………………………..……….………………….………10 General Functions ….…………………………………..……...…….11 Setup SMS Messages …….………………………………..…...….13 4.1 Change ID. ……………………………………………………………...….…..14 4.2 Built-in Cellular Phone Setup…………………….….…………………..15 4.3 Report Interval Setup……………..……………………...……...…..…16 4.4 Remote Parking Start Setup……………..……….………….…...……..17 4.5 Reset to Factory Default………..…………………….……...…………18 4.6 Change Password………….…….…….……...………..…………….….…19 4.7 SMS Polling Command…………………………………….…………………20 4.8 Inquire IMEI code ……………………………………………………………….21 Respond SMS Messages... -
Page 4: Hardware Description
Chapter 1 Hardware Description Main Unit Package Contents Battery x2 Wall Charger (100 ~ 240V AC) x1 CD x1 (User manual & Map Tracking & PDA Tracker Cigar Charger (8 ~ 38V DC) x1 software) - Page 5 Optional Accessories For Map Tracking Cellular Phone Personal Computer (Sagem X2, Siemens C62) Vector Map Modem (Microsoft Street & Trip 2004, MapPoint2004, (Siemens TC35, MC35) GPSS, Fugawi, PaPaGo, MapKing) Necessary Accessories For PDA Track PDA Phone (For OS: Windows Mobile edition or Map For Pocket PC it above version only) VSPK CE...
- Page 6 Turn On/Off G-19B by this switch While initializing G-19B by switching it on, G-19B’s Link, Fix and Park LEDs will light for 3 seconds, and become off. G-19B will then start searching the GSM station and getting the GPS fix.
- Page 7 GPS Indicator (Blue LED) Off when GPS is not available On when G-19B fixes the current GPS position Mini-USB Connector This Reserved Com Port is for engineering purpose. Please do not try to utilize it before having proper instruction. External DC Power Connector...
- Page 8 (100V~250V) wall charger. It takes about 3 hours to fully charge the battery. Cigar Charger The picture shows the cigar charger, which you can charge the G-19B in the car. It takes about 3 hours to fully charge the battery.
- Page 9 Before that, you have to deactivate the PIN code if there is any. 3. Push the slot back into the G-19B. Don’t push too hard if you find it difficult to insert the slot. Try to pull it out and push it back gently.
- Page 10 Emergency Panic Button Press when an emergency situation occurs. Built-in buzzer will start buzzing for alert. Emergency SMS messages will also be sent to the built-in cellular phone number(s) Battery 1. If you would like to change the battery, you may open the battery case by sliding the plastic cover.
-
Page 11: Getting Started
8. For the first-time operation of G-19B, the Blue LED will light on and keep still within 90 seconds. That means the G-19B gets the GPS fixed. If you have any difficulties, please refer to the FAQ the last page 9. You may start tracking! -
Page 12: General Functions
Auto Report G-19B can report SMS message only to the designate cellular phone. It is the first cellular number predefined in G-19B. However, the default Auto Report function is off. To turn on Auto Report function, send the setup SMS message to launch. - Page 13 Low Power Alert When G-19B is in the condition of low power, it will automatically send you a SMS to inform you. In the SMS, it contains the GPRMC’s UTC time, latitude and longitude information for you to track the carrier. The...
-
Page 14: Setup Sms Messages
G-19B currently provides 7 commands to setup its functions. You can setup the G-19B by following the instructions shown in this chapter via SMS through your cellular phone. Key the specific SMS message in your cellular as the instruction, sending it to the phone number of G-19B. The setup messages are seen in the following sections. -
Page 15: Change Id
4.1 Changing ID You can change the ID of G-19B by following the format below. No space is allowed in between the characters. For example, if you send the SMS message shown in E.g.1 to the G-19B, you will change the ID from “Username”... -
Page 16: Built-In Cellular Phone Setup
Example: +491783496936 (German) Note2: If you want to setup only 1 set of phone number for G-19B to report, you need to add 4 commas ”,” straight after the phone number. G-19B needs to recognize and separate different built-in numbers. -
Page 17: Report Interval Setup
This parameter must be 2 digits. For example, 12 means that only 12 Auto Report messages will be sent in total. After that, G-19B will stop sending. If you set up this value being “00”, the G-19B will stop Auto Report. End sign. Table 4.3.1 The table 4.3.2 is showing each confirm message reply after setup. -
Page 18: Remote Parking Start Setup
Use this SMS message to remotely activate the Park function after predefining the cellular number(s). You can just send the SMS according to E.g.4 seen below to G-19B to activate the Park function. If you have changed the default ID, please use the updated one instead of “Username”. E.g.4 #Username,0000,4* The table 4.4.1 is describing the meaning of each segment in the message above. -
Page 19: Reset To Factory Default
G-19B is in Emergency Mode Username in emergency, reset not allowed. Table 4.5.2 When the reset setup is successful, all the user setting data in G-19B will be erased and reset to default. Default settings are seen below. Setting Default Value... -
Page 20: Change Password
4.6 Changing Password Use this SMS message E.g.6 seen below to change the password of G-19B E.g.6 #Username,0000,6,5725,5725* The table 4.6.1 is describing the meaning of each segment in the message above. Text Keyed In SMS Description Start sign. Username Default ID of G-19B. -
Page 21: Sms Polling Command
4.7 SMS Polling Besides dialing the number of G-19B to obtain immediate response, you also can use SMS to do the same job. This is extremely useful when you are abroad. You can just send the SMS according to E.g.7 seen below to G-19B to obtain immediate response. -
Page 22: Inquire Imei Code
4.8 Inquire IMEI code Use this SMS message E.g.8 seen below to inquire the IMEI code from GUARDIAN E.g.8 #Username,0000,imei* The table 4.8.1 is describing the meaning of each segment in the message above. Text Keyed In SMS Description Start sign. Username Default ID of GUARDIAN. -
Page 23: Respond Sms Messages
Chapter 5 Respond SMS Messages This chapter shows you how to read and understand the data/SMS sent from G-19B. According to different situations, the G-19B will send the SMS in different formats for you to distinguish them. Basically, there are 3 formats and they listed as below. -
Page 24: Polling/Auto Report
It indicates the BTS code of current GSM station used for transmission. In this case, 2906F250 is the Station ID. Respond Indicates this SMS is sent from G-19B for respond purpose. It will be shown only when Polling and Auto Report. This segment indicates GPS data validity of G-19B. -
Page 25: Parking
After you press the “Park” key, while the carrier’s position is away from its parking Towed (Still) space over 100m, G-19B will auto report “towed” message to the first predefined phone number, PH-01; otherwise it will report “still”. Move 450m NE This segment indicates the movement of G-19B. - Page 26 Interval of Parking SMS Message After G-19B detect your car is towed ( the detective conditions are adjustable, please see chapter 4.12), G-19B will send SMS messages EVERY 2 MINUTES FOR 20 TIMES, only to the first predefined phone number, PH-01 so as to remind the user that the carrier may be stolen or towed by someone.
-
Page 27: Emergency
See Chapter 6 for detail. End sign. Table 5.3.1 Note1: All the setting functions will be invalid once the Emergency is launched.Only when the power of G-19B is turned off should the Emergency status be cancelled. - Page 28 Interval of Emergency SMS Message After the emergency button is pressed, G-19B will send SMS messages to all the predefined cellular numbers (5 sets at most) to call for help. The message’s frequency and amount are every 2 minutes and 20 messages.
-
Page 29: Power Low Alert
Default ID of G-19B. A encrypted code for PDA Track Indicates the power of the battery embedded is low. Power low Before the power is exhausted, G-19B will send a SMS containing information about Last trace the last position. $GPRMC GPS NMEA information from GPS receiver, including UTC time, latitude, longitude, speed, true course, etc. -
Page 30: Nmea Gprmc Description
Chapter 6 NMEA-0183 $GPRMC Description... -
Page 31: General Specifications
Chapter 7 General Specifications GPS Micro Tracker Model G-19B Dual Band GSM Module (EGSM 900/1800 MHz), Tri-band 1900 MHz Optional Compliant with ETSI GSM Phase 2+ standard Class 4 (2W @ 900 MHz) Class 1 (1W @ 1800/1900 MHz) Equipped with 16 parallel channels GPS receiver in 0.35u CMOS technology Emergency “panic”... - Page 32 Warranty Warranty Time Period and Repair Coverage SAN JOSE NAVIGATION, INC. warrants G-19B to be free from all defects and malfunctions in materials and workmanship for a period of 12 months from the original purchase date from San Jose Navigation or authorized dealers. If the equipment functions improperly during the warranty period, San Jose Navigation will either repair or replace the unit without charge.
-
Page 33: Faq
G-19B is not working if the external power source is removed. Please switch the G-19B off and plug it with external power source. Let it charge for 2 hours and see if it is working after charging. If it is still not working after charging, you may change the battery. - Page 34 24 hours will be reached if the G-19B is in standby mode. In another word, it’s GPS status has to be in continuous tracking and always connected to the GSM network. Why G-19B does not hang up my phone when I am dialing its number? The GSM network of where G-19B is in may not be good enough.
