NComputing N400 User Manual page 24

N-series Firmware Tag 174
Use this tag in conjunction with 172 to store the
firmware server's password (if username and
password are required).
To the right is an example of a completed
entry (in this case, the VMC 171 tag).
3. You can now verify that the tag you created has been saved by clicking on the Option Name
drop down (see image below) and searching for the tag(s) in question.
4. Once again from the Predefined Options and Values window, select each tag and fill in the Value
field with the string values specified earlier in step 2.
a. Example: For Tag 171, the string value
would be the IP address or Fully
Qualified Domain Name of your
vSpace Management Center server.
b. Note: For tags that accept IP
addresses, you can enter multiple IP
addresses so long as each IP is
separated by a semi-colon (;).
5. Once your entries are complete, click "OK".
Your DHCP Tags are now configured. You may
now exit Server Management.
Page 24 of 25
NComputing N-series User Manual rev11.09.12
Name N-series Firmware Password
Data Type String
Code 174
Description Address of firmware update
server.
STRING VALUE (The FTP, HTTP, or HTTPS
address of your firmware
server.)
Notes This tag is only required if the
server you are storing N-series
firmware on requires a
password.
