Juniper Allegro CE Quick Start Manual

Complete all of the steps in this guide before using your Allegro CE
Step 1
Insert the battery pack into the Allegro
1. Push up on the release latches on the sides of
the Allegro to open the battery compartment
door.
2. Place the NiMH battery pack in the left side of
the battery compartment, push down, and
slide it all the way to the right.
Step 4
Plug the charger into the Allegro
1. Remove the rubber protector from the Allegro's
external power input jack.
2. Plug the power connector end of the charger
into the Allegro.
Allegro CE Field PC Quick Start Guide
TM
Step 2
Close and latch the battery door
1. Push the battery door closed until each release
latch clicks into place.
2. Slide the release latches downward until they
cannot slide any further to securely latch the
battery door closed.
Do not turn on the Allegro yet.
Step 5
Turn the Allegro on
1. Push the On/Off button on the Allegro.
As Windows CE loads, a progress bar is
shown that does not require any action until it
gets to the Set Main Battery Parameters screen.
Step 3
Plug the charger into the wall
1. Plug the AC wall charger that came with the
Allegro into the wall socket.
The small green light on the wall adapter
turns on when it is plugged into the wall.
Step 6
Fill out the Set Main Battery Parameters
screen and charge the battery pack
1. Set the charge to 10% and tap on OK.
2. Charge the installed battery pack for 3 to 4
hours. This is to ensure the batteries are
charged to full capacity.
