Juniper AMXU GPS EXPANSION POD Manual

Juniper AMXU GPS EXPANSION POD Manual

Ultra rugged field pc
Hide thumbs

Advertisement

Quick Links

Download this manual
AMXU GPS EXPANSION POD

Advertisement

loading
Need help?

Need help?

Do you have a question about the AMXU GPS EXPANSION POD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Juniper AMXU GPS EXPANSION POD

Summary of Contents for Juniper AMXU GPS EXPANSION POD

  • Page 1 AMXU GPS EXPANSION POD...
  • Page 2 AMXU GPS Expansion Pod Overview The Field PC AMXU GPS Expansion Pod integrates a SBAS-capable GPS receiver with the Field PC. The Field PC communicates with the receiver. The GPS receiver is a uBlox high-performance, low power, micro GPS receiver that supports NMEA protocols with an accuracy of 2 to 5 meters.

  • Page 3: Getting Started

    GPS program (refer to the Field PC Owner’s Manual for instructions), you should be ready to start using the Field PC AMXU GPS Expansion Pod. Note: If your Field PC has Wi-Fi, for maximum battery performance we recommend that you turn Wi-Fi off if it is not needed.
  • Page 4 Tips for Using the Field PC AMXU GPS Expansion Pod Keep the following tips in mind while using the Field PC with the AMXU GPS Expansion Pod: For best performance seek locations with the clearest „ view of the sky as possible. Obstructions such as buildings, trees, power lines, mountains, and your body can keep signals from reaching the receiver.

  • Page 5: Reference Information

    (see the following page for details). Check or uncheck options to enable or disable them. Setting changes are preserved through suspend, resume and complete power off. To exit the program, select “OK.” Field PC AMXU GPS Expansion Pod...
  • Page 6 To help you avoid potential start up delays, select “GPS always on.” When selected, the GPS receiver remains powered when the Field PC is suspended. The receiver is Field PC AMXU GPS Expansion Pod...
  • Page 7 Menu on the Field PC then to Settings > System > External GPS and click on the icon. The GPS control panel opens. Note: Before you change GPS configuration settings, exit all GPS application software. Field PC AMXU GPS Expansion Pod...
  • Page 8 If your GPS program has a checkbox or setting to enable the DTR function, enable it for proper operation of the GPS Expansion pod. Juniper Systems LandMark Mobile GPS Utility has a DTR function option which must be checked. Field PC AMXU GPS Expansion Pod...
  • Page 9 GPS pod Installs the AMXU GPS Pod Setup utility „ Installs a background task to reconfigure the GPS „ when the unit is turned on Provides registry settings to configure the GPS „ Expansion Pod Field PC AMXU GPS Expansion Pod...

  • Page 10: Gps Receiver Specifications

    Autonomous: <2.5 m Position SBAS: <2.0 m Accuracy Navigation 1 Hz (1 second) Update Rate Velocity 0.1 m/s Accuracy Heading 0.1 m/s Accuracy Dynamics < 4 g Operational Velocity: 515 m/s (1000 knots) Limits Field PC AMXU GPS Expansion Pod...
  • Page 11 You can also refer to the Field PC Owner’s Manual for more information. CAUTION: Do not attempt to repair the AMXU GPS Expansion Pod or Field PC yourself. This action voids the warranties. Field PC AMXU GPS Expansion Pod...
  • Page 12 P/N 23020-01 © Copyright 02-2011 Juniper Systems, Inc. Information is subject to change without notice. Juniper Systems, AMXU GPS Expansion Pod, and LandMark Mobile GPS Utility are trademarks of Juniper Systems, Inc. in the U.S. Field PC AMXU GPS Expansion Pod...
