Cleco 1700 Series Operation & Service Manual

Vertical grinders
Hide thumbs Also See for 1700 Series:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
1700 & 1900 Series Vertical Grinders
Series:
17
1700
19
1900
RPM:
45
60
72
Generation:
B
Second
Type:
V
Vertical
Throttle Terminations:
Quick Release
(Lock Off)
L
Lever
Self Closing Thumb
S
For additional product information visit our website at http://www.clecotools.com
NORTH AMERICA
CooperTools
P.O. Box 1410
Lexington, SC 29071
XX
XX
B
77
Operation & Service Manual
823008
V
X
- XX
Wheel Type:
07
7" Type 27 or 28 Depressed Center Wheel
09
9" Type 27
11
9" Type 28
05
5"
Cup
06
6"
Cup
SS
Sanding Shroud
EUROPE
Cooper Power Tools GmbH & Co.
Postfach 30
D-73461 Westhausen
Depressed Center Wheel
Depressed Center Wheel
Type 6 or 11
Type 6 or 11
2/01
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1700 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cleco 1700 Series

Summary of Contents for Cleco 1700 Series

  • Page 1 Vertical Throttle Terminations: Quick Release (Lock Off) Lever Self Closing Thumb For additional product information visit our website at http://www.clecotools.com NORTH AMERICA EUROPE CooperTools Cooper Power Tools GmbH & Co. P.O. Box 1410 Postfach 30 Lexington, SC 29071 D-73461 Westhausen...

  • Page 2: Safety Recommendations

    Safety Recommendations For your safety and the safety of others, read and understand the safety recommendations before operating any grinder. WARNING Always wear protective equipment and clothing. Wear respirator where necessary. WARNING Impact resistant eye protection Grinding or other applications of this tool may produce hazard- must be worn while operating ous fumes and/or dust.
  • Page 3 Safety Recommendations • Improper shipment or storage • Exposure to water, solvents, high humidity, 203011 869974 WARNING TAG WARNING TAG freezing and extreme temperatures 202408 WARNING AND • Mismatched speed ratings INSTRUCTION LABEL • Age Abrasive wheels known to have been subjected to any of the above conditions can violently disintegrate.
  • Page 4 Safety Recommendations • Avoid anything that inhibits blood circulation —Smoking Tobacco (another contributing factor) WARNING —Cold Temperatures —Certain Drugs Repetitive work motions and/or vibration Avoid Avoid Avoid Avoid can cause injury to hands and arms. Use minimum hand grip force. Keep body and hands warm and dry.
  • Page 5 Safety Recommendations WIRE BRUSHES STORAGE If a grinder is used for wire brushing applications the same In the event that it becomes necessary to store the tool for an problems of balance, roundness, and trueness as experienced extended period of time (overnight, weekend, etc.), it should with abrasive wheels prevail.
  • Page 6 GUARD DEPRESSED CENTER WHEEL GUARDS, WHEEL CAPACITY Size Type 27 Type 28 WRENCHES AND ADAPTORS 7" 867740 867740 7" Dia. x 1/4" Thick Max. (175mm x 6.4mm) 9" 867741 869067 9" Dia. x 1/4" Thick Max. (225mm x 6.4mm) GUARD CUP WHEEL CAPACITY WARNING 5"...

  • Page 7: Operating Instructions

    THROTTLE HANDLE MAINTENANCE: OPERATING INSTRUCTIONS Should the throttle valve seal, No. 869539, need replacing, un- screw the throttle valve cap, No. 867753, for removal of the throttle valve and components. READ SAFETY RECOMMENDATIONS BEFORE CONNECTING TOOL. The tool is equipped with two (2) air screens for protection of the internal motor parts from foreign material.
  • Page 8 Slip the rotor collar, chamfered side first, on the rotor spindle IMPORTANT: After the governor is completely assembled, in- and drive the bearing plate and bearing (drive on the bearing's stall it (left hand threads) on the rear of the rotor shaft and torque inner race) down on the rotor.

  • Page 9: Optional Equipment

    OPTIONAL EQUIPMENT PARTS LIST - MUFFLER ASSEMBLY MUFFLER PART NO. NAME OF PART QTY. 1700-V 867945 202112 Muffler Screw (self tapping) 1900-V 867943 202113 Muffler (incl. 867947) 1700-V 867947 202114 Muffler (incl. 867948) 1900-V 867948 867943 Baffle Plate 867945 Baffle Plate 1700-V 202113 867947 Muffler Gasket...
  • Page 10 VERTICAL GRINDERS GOVERNOR & SHUT-OFF DISC Part No. Name of Part Quantity 204187 Washer 204730 Governor Adjusting Nut COMPLETE GOVERNOR 413041 Governor Spring (Green) ASSEMBLY NO. 413042 Governor Spring (No Color) 413047 Governor Cone Pin PART NO. 413048 Governor Cone 413050 Governor Weight Pin 201788...
  • Page 11 VERTICAL GRINDERS MOTOR UNIT Qty. Part No. Name of Part 201787 Wheel Retainer Kit (incl. 204635, 204732 & 204663) 202020 Drive Screw 203011 Instruction Plate 203208 Instruction Plate 204635 Adaptor 204636 Driving Flange Available 204643 Rotor Blade (1900) Rotor Collars 204644 Rotor Blade (1700) Part No.
  • Page 12 VERTICAL GRINDERS HANDLE SUBASSEMBLIES LOCK OFF LEVER HANDLE QTY. PART NAME OF PART 867769 845228 Type Handle 845322 413056 Throttle Valve Spring 867731 413255 Lever Bushing 867758 864620 844323 415330 Self Closing Thumb Throttle 867732 867756 813041* Socket Head Cap Screw 833961 "O"-Ring 13/16"...
  • Page 13 NOTES...
  • Page 14 NOTES...
  • Page 15 NOTES...
  • Page 16 CooperTools 670 Industrial Drive Lexington, SC 29072 Phone: (803) 359-1200 Fax: (803) 359-2013 www.clecotools.com...
