Cleco 220 Series Operating Instructions Manual

Precision die grinders

Advertisement

Parts Manual
823002
05/10/2011
Tool Series
220
Tool Style
G = Grinder
Throttle Terminations
-- = Push-Pull
L = Lever
Speed Options (RPM)
600 = 60,000
Wheel Type
C = Collet
Termination Code
1 = 3/32" Collet
2 = 1/8" Collet
3M = 3mm Collet
Kit
K = Kit
For additional product information visit our website at http://www.apextoolgroup.com
220
G
X
-
Precision Die Grinders
600
C
XX
-
220 Series
X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 220 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cleco 220 Series

  • Page 1 Parts Manual 823002 05/10/2011 220 Series Precision Die Grinders Tool Series Tool Style G = Grinder Throttle Terminations -- = Push-Pull L = Lever Speed Options (RPM) 600 = 60,000 Wheel Type C = Collet Termination Code 1 = 3/32" Collet 2 = 1/8"...
  • Page 2: Safety Recommendations

    • Mismatched speed ratings • Exposure to water, solvents, high humidity, freezing, and Cleco grinders are designed to operate on 90 psig (6.2 bar) extreme temperatures max. air pressure. If the tool is properly sized and applied, higher air pressure is unnecessary.
  • Page 3: Accessory Mounting

    Do not use these tools for Type 1 wheel grinding. If your steps to prevent further occurrences. These steps might in- application calls for a Type 1 wheel, consult your Cleco repre- clude, but are not limited to, repositioning the workpiece or...
  • Page 4: Proper Lubrication

    • Use quality accessories (the primary source of vibration when using a grinder is an accessory that is out of Proper repair procedures and the use of original Cleco service balance, out of round, untrue, or possibly any combina- parts and bearings, rather than substitutes, will return the tool tion of all three;...
  • Page 5 REASSEMBLY OPERATING INSTRUCTIONS The tool is reassembled in the reverse order of disassembly. Wash all parts in a solvent and inspect for damage or wear. Check bearings for wear which can be detected by excessive READ SAFETY RECOMMENDATIONS BE- end play or roughness of the bearings which indicates a FORE CONNECTING TOOL.
  • Page 6 413594 412094 415424 .0937/.0932 415425 .0947/.0942 415426 .0957/.0952 415432 3/32 415433 415422 415430 415434 415435 844309 415429 843643 844308 415427 867622 412082 412074 412077 412078 412086 844305 412085 844305 412087 412103 412102 844787 412105 412104 844301 863398 PART NO. NAME OF PART QTY.
  • Page 7 NOTES...
  • Page 8: Sales & Service Centers

    Sales & Service Centers Note: All locations may not service all products. Please contact the nearest Sales & Service Center for the appropriate facility to handle your service requirements. Dallas, TX Detroit, MI Houston, TX Lexington, SC Apex Tool Group Apex Tool Group Apex Tool Group Apex Tool Group...
