Cleco 1200 Series Operating Instructions And Parts Manual

Vertical grinders

Advertisement

Quick Links

Parts Manual
823119
05/10/2011
Tool Series
12 = 1200
Speed Options
60 = 6,000
77 = 7,700
Tool Style
Generation
Throttle
Wheel Type
07 = 7" Type 27 or 28 Depressed Center Wheel
04 = 4" Cup Type 6 or 11
SS = Sanding Shroud
For additional product information visit our website at http://www.apextoolgroup.com
12
V = Vertical
D = Fourth
L = Locking Lever
XX
V
D
1200 Series
Vertical Grinders
L
-
XX

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cleco 1200 Series

  • Page 1 Parts Manual 823119 05/10/2011 1200 Series Vertical Grinders Tool Series 12 = 1200 Speed Options 60 = 6,000 77 = 7,700 Tool Style V = Vertical Generation D = Fourth Throttle L = Locking Lever Wheel Type 07 = 7" Type 27 or 28 Depressed Center Wheel 04 = 4"...
  • Page 2: Safety Recommendations

    ANSI Z87.1 states that separate eyewear shall be used. For additional information on eye protection, refer to Federal OSHA Cleco grinders are designed to operate on 90 psig (6.2 bar) max. Regulations, 29 CFR, Section 1910.133, Eye and Face Protec- air pressure.
  • Page 3 Safety Recommendations The guard must be securely attached to the grinder with all bolts, Causes of abrasive wheel failures have been traced to such nuts and lockwashers in place and torqued to 30 - 40 in. lbs.. factors as: • Dropping, bumping, or abuse (careless handling 869974 of the grinder or wheel) WARNING TAG...
  • Page 4 Safety Recommendations Avoid Avoid Avoid Avoid WARNING Repetitive work motions and/or vibration Neutral Neutral Ulnar Deviation Extension Flexion Radial Deviation can cause injury to hands and arms. Use minimum hand grip force. Keep body and hands warm and dry. • Tasks should be performed in such a manner that the Avoid anything that inhibits blood curculation.
  • Page 5 3/8" (9.5mm) at either end. governor mechanism is clean, in good operating condition, and functioning properly. The 1200 Series grinders are equipped with the CLECO SHUT-OFF disc which is designed to shut the tool down in the event of excessive overspeed. Replace if 3/8"...
  • Page 7 (2) governor weight pins, No. 833862. Do not disassemble OPERATING INSTRUCTIONS the governor body any further. Inspect the governor weights and weight pins for wear and replace if necessary. Note: During reassembly, be sure the two (2) groove pins The 1200VDL Series Grinders are designed to operate on are in place and retain the two (2) weight pins in the body.
  • Page 8 the finger spring washer. Assemble the rest of the motor complete. Tighten the governor body to 15/20 ft. lbs. (20.3/ SELECT OR SAND 27.1Nm). ROTOR COLLAR TO THIS MEASUREMENT PLUS .002" (.051mm) The spring washer, No. 869817, should be assembled in the motor housing with its large diameter against the motor FRONT BEARING...
  • Page 9 NOTES...
  • Page 10 867758 867732 202356 202355 1200D VERTICAL GRINDER 202365 813041 844912 844787 202376 202361 202353 202371 844320 202354 202710 869712 843615 203338 202843 203335 202387 202362 863887 202389 202352 202388 202364 834228 Rotor Collar (See Chart on Parts List) 203011 202367 202357 869818 869817...
  • Page 11 Part No. Name of Part Qty. 201073* Shut-off Disc Assembly 201396* 6,000 RPM Governor Body Assembly (See Note Below) 201397* 7,700 RPM Governor Body Assembly (See Note Below) 202020 Drive Screw 202352 Rotor Blade 202353 Air Screen 202354 Bushing 202355 Throttle Valve Spring 202356 Spacer...
  • Page 12: Sales & Service Centers

    Sales & Service Centers Note: All locations may not service all products. Please contact the nearest Sales & Service Center for the appropriate facility to handle your service requirements. Dallas, TX Detroit, MI Houston, TX Lexington, SC Apex Tool Group Apex Tool Group Apex Tool Group Apex Tool Group...
